Epson S5U13705B00C User manual

Rev. 3.1
S1D13705 Embedded Memory LCD Controller
S5U13705B00C Rev. 1.0 ISA Bus
Evaluation Board User Manual
Document Number: X27A-G-005-03.1

NOTICE
No part of this material may be reproduced or duplicated in any form or by any means without the written permission
of Seiko Epson. Seiko Epson reserves the right to make changes to this material without notice. Seiko Epson does
not assume any liability of any kind arising out of any inaccuracies contained in this material or due to its application
or use in any product or circuit and, further, there is no representation that this material is applicable to products
requiring high level reliability, such as, medical products. Moreover, no license to any intellectual property rights
is granted by implication or otherwise, and there is no representation or warranty that anything made in accordance
with this material will be free from any patent or copyright infringement of a third party. When exporting the
products or technology described in this material, you should comply with the applicable export control laws and
regulations and follow the procedures required by such laws and regulations. You are requested not to use, to resell,
to export and/or to otherwise dispose of the products (and any technical information furnished, if any) for the devel-
opment and/or manufacture of weapon of mass destruction or for other military purposes.
All brands or product names mentioned herein are trademarks and/or registered trademarks of their respective
companies.
©SEIKO EPSON CORPORATION 1999-2018. All rights reserved.
Evaluation Board/Kit and Development Tool Important Notice
1. This evaluation board/kit or development tool is designed for use for engineering evaluation, demonstration, or develop-
ment purposes only. Do not use it for other purposes. It is not intended to meet the requirements of design for finished
products.
2. This evaluation board/kit or development tool is intended for use by an electronics engineer and is not a consumer product.
The user should use it properly and in a safe manner. Seiko Epson does not assume any responsibility or liability of any
kind of damage and/or fire caused by the use of it. The user should cease to use it when any abnormal issue occurs even
during proper and safe use.
3. The part used for this evaluation board/kit or development tool may be changed without any notice.
2Seiko Epson Corporation S5U13705B00C Rev 1.0 Evaluation Board
Rev. 3.1

S5U13705B00C Rev 1.0 Evaluation Board Seiko Epson Corporation 3
Rev. 3.1
Table of Contents
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
1.1 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2 Installation and Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3 LCD Interface Pin Mapping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
4 CPU/Bus Interface Connector Pinouts . . . . . . . . . . . . . . . . . . . . . . . . . 9
5 Host Bus Interface Pin Mapping . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
6 Technical Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
6.1 Embedded Memory Support . . . . . . . . . . . . . . . . . . . . . . . . . 12
6.2 ISA Bus Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
6.2.1 Display Adapter Card Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
6.2.2 Expanded Memory Manager Support . . . . . . . . . . . . . . . . . . . . . . . . . 13
6.3 Non-ISA Bus Support . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
6.4 Decoding Logic . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
6.5 Clock Input Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
6.6 LCD Panel Voltage Setting . . . . . . . . . . . . . . . . . . . . . . . . . 15
6.7 Monochrome LCD Panel Support . . . . . . . . . . . . . . . . . . . . . . . 15
6.8 Color Passive LCD Panel Support . . . . . . . . . . . . . . . . . . . . . . 15
6.9 Color TFT/D-TFD LCD Panel Support . . . . . . . . . . . . . . . . . . . . 15
6.10 Power Save Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
6.11 Adjustable LCD Panel Negative Power Supply . . . . . . . . . . . . . . . . . 16
6.12 Adjustable LCD Panel Positive Power Supply . . . . . . . . . . . . . . . . . . 16
6.13 CPU/Bus Interface Header Strips . . . . . . . . . . . . . . . . . . . . . . . 16
7 Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
8 Schematic Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
9 Change Record . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
10 Sales and Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

4Seiko Epson Corporation S5U13705B00C Rev 1.0 Evaluation Board
Rev. 3.1
THIS PAGE LEFT BLANK

Introduction
S5U13705B00C Rev 1.0 Evaluation Board Seiko Epson Corporation 5
Rev. 3.1
1 Introduction
This manual describes the setup and operation of the S5U13705B00C Rev. 1.0 Evaluation
Board. Implemented using the S1D13705 Embedded Memory Color LCD Controller, the
S5U13705B00C board is designed for the 16-bit ISA bus environment. To accommodate
other bus architectures, the S5U13705B00C board also provides CPU/Bus interface
connectors.
For more information regarding the S1D13705, refer to the S1D13705 Hardware
Functional Specification, document number X27A-A-001-xx.
This document is updated as appropriate. Please check for the latest revision of this
document before beginning any development. The latest revision can be downloaded at
vdc.epson.com.
We appreciate your comments on our documentation. Please contact us via email at
vdc-document[email protected]pson.com.
1.1 Features
• 80-pin QFP14 package.
• SMT technology for all appropriate devices.
• 4/8-bit monochrome and color passive LCD panel support.
• 9/12-bit LCD TFT/D-TFD panel support.
• Selectable 3.3V or 5V LCD panel support.
• Oscillator support for CLKI (up to 50MHz with internal clock divider or 25MHz with
no internal clock divider).
• Embedded 80K byte SRAM display buffer for 1/2/4 bit-per-pixel (bpp), 2/4/16-level
gray shade display and 1/2/4/8 bpp, 2/4/16/256 level color display.
• Support for software and hardware power save modes.
• On-board adjustable LCD bias positive power supply (+23V to +40V).
• On-board adjustable LCD bias negative power supply (-23V to -14V).
• 16-bit ISA bus support.
• CPU/Bus interface header strips for non-ISA bus support.

Installation and Configuration
6Seiko Epson Corporation S5U13705B00C Rev 1.0 Evaluation Board
Rev. 3.1
2 Installation and Configuration
The S1D13705 has four configuration inputs, CNF[3:0], which are read on the rising edge
of RESET# and are fully configurable on this evaluation board. One six-position DIP
switch is provided on the board to configure the four configuration inputs, select the
S5U13705B00C memory/register start address, and enable/disable hardware power save
mode.
The following settings are recommended when using the S5U13705B00C with the ISA
bus.
Table 2-1: Configuration DIP Switch Settings
Switch Signal Closed (0 or low) Open (1 or high)
S1-1 CNF0
See “Host Bus Selection” table below See “Host Bus Selection” table belowS1-2 CNF1
S1-3 CNF2
S1-4 CNF3 Little Endian Big Endian
S1-5 ADDR Memory/Register Start Address = C0000h Memory/Register Start Address = F00000h
S1-6 GPIO0 Hardware Suspend Disable Hardware Suspend Enable
= recommended settings (configured for ISA bus support)
Table 2-2: Host Bus Selection
S1-3 S1-2 S1-1 BS# Host Bus Interface
0 0 0 X SH-4 bus interface
0 0 1 X SH-3 bus interface
010Xreserved
0 1 1 X MC68K bus interface #1, 16-bit
100Xreserved
1 0 1 X MC68K bus interface #2, 16-bit
1100reserved
1101reserved
1 1 1 0 Generic #1, 16-bit
1 1 1 1 Generic #2, 16-bit
= recommended settings (configured for ISA bus support)

Installation and Configuration
S5U13705B00C Rev 1.0 Evaluation Board Seiko Epson Corporation 7
Rev. 3.1
Table 2-3: Jumper Settings
Description 1-2 2-3
JP1 IOVDD Selection 5.0V IOVDD 3.3V IOVDD
JP2 RD/WR# Signal Selection Pulled up to IOVDD No Connection
JP3 BS# Signal Selection Pulled up to IOVDD No Connection
JP4 LCD Panel Voltage Selection 5V LCD Panel 3.3V LCD Panel
JP6 LCDPWR polarity Active low (‘LCDPWR#’) Active high (‘LCDPWR’)
= recommended settings (JP1 through JP3 configured for ISA bus support)

LCD Interface Pin Mapping
8Seiko Epson Corporation S5U13705B00C Rev 1.0 Evaluation Board
Rev. 3.1
3 LCD Interface Pin Mapping
Note
1. Un-used GPIO pins must be connected to IO VDD.
2. Inverse Video is enabled on FPDAT11 by REG[02h] bit 1.
Table 3-1: LCD Signal Connector (J5) Pinout
Connector Single Passive Panel Dual Passive Panel Color TFT/D-TFD
Pin Name Pin #
Color Mono Color Mono
4-bit 8-bit
8-bit
Alternate
Format
4-bit 8-bit 8-bit 8-bit 9-bit 12-bit
BFPDAT0 1 driven 0 D0 LD0 driven 0 D0 D0 LD0 R2 R3
BFPDAT1 3 driven 0 D1 LD1 driven 0 D1 D1 LD1 R1 R2
BFPDAT2 5 driven 0 D2 LD2 driven 0 D2 D2 LD2 R0 R1
BFPDAT3 7 driven 0 D3 LD3 driven 0 D3 D3 LD3 G2 G3
BFPDAT4 9 D0 D4 UD0 D0 D4 D4 UD0 G1 G2
BFPDAT5 11 D1 D5 UD1 D1 D5 D5 UD1 G0 G1
BFPDAT6 13 D2 D6 UD2 D2 D6 D6 UD2 B2 B3
BFPDAT7 15 D3 D7 UD3 D3 D7 D7 UD3 B1 B2
BFPDAT8 17 GPIO1 GPIO1 GPIO1 GPIO1 GPIO1 GPIO1 GPIO1 B0 B1
BFPDAT9 19 GPIO2 GPIO2 GPIO2 GPIO2 GPIO2 GPIO2 GPIO2 GPIO2 R0
BFPDAT10 21 GPIO3 GPIO3 GPIO3 GPIO3 GPIO3 GPIO3 GPIO3 GPIO3 G0
BFPDAT11 23
GPIO4/
Inverse
Video
GPIO4/
Inverse
Video
GPIO4/
Inverse
Video
GPIO4/
Inverse
Video
GPIO4/
Inverse
Video
GPIO4/
Inverse
Video
GPIO4/
Inverse
Video
GPIO4 B0
BFPSHIFT 33 FPSHIFT FPSHIFT FPSHIFT FPSHIFT FPSHIFT FPSHIFT FPSHIFT FPSHIFT FPSHIFT
BFPSHIFT2 35 FPSHIFT2
BFPLINE 37 FPLINE FPLINE FPLINE FPLINE FPLINE FPLINE FPLINE FPLINE FPLINE
BFPFRAME 39 FPFRAME FPFRAME FPFRAME FPFRAME FPFRAME FPFRAME FPFRAME FPFRAME FPFRAME
GND
2-26
(Even
Pins)
GND GND GND GND GND GND GND GND GND
N / C 28
VLCD 30 LCD panel negative bias voltage (-24V to -14V)
LCDVCC 32 +3.3V or +5V (selectable with JP4)
+12V 34 +12V +12V +12V +12V +12V +12V +12V +12V +12V
VDDH 36 LCD panel positive bias voltage (+23V to +40V)
BDRDY 38 MOD MOD MOD MOD MOD MOD DRDY DRDY
BLCDPWR 40 LCDPWR LCDPWR LCDPWR LCDPWR LCDPWR LCDPWR LCDPWR LCDPWR LCDPWR

CPU/Bus Interface Connector Pinouts
S5U13705B00C Rev 1.0 Evaluation Board Seiko Epson Corporation 9
Rev. 3.1
4 CPU/Bus Interface Connector Pinouts
Table 4-1: CPU/BUS Connector (H1) Pinout
Connector
Pin No.
CPU/BUS
Pin Name Comments
1 SD0 Connected to DB0 of the S1D13705
2 SD1 Connected to DB1 of the S1D13705
3 SD2 Connected to DB2 of the S1D13705
4 SD3 Connected to DB3 of the S1D13705
5 GND Ground
6 GND Ground
7 SD4 Connected to DB4 of the S1D13705
8 SD5 Connected to DB5 of the S1D13705
9 SD6 Connected to DB6 of the S1D13705
10 SD7 Connected to DB7 of the S1D13705
11 GND Ground
12 GND Ground
13 SD8 Connected to DB8 of the S1D13705
14 SD9 Connected to DB9 of the S1D13705
15 SD10 Connected to DB10 of the S1D13705
16 SD11 Connected to DB11 of the S1D13705
17 GND Ground
18 GND Ground
19 SD12 Connected to DB12 of the S1D13705
20 SD13 Connected to DB13 of the S1D13705
21 SD14 Connected to DB14 of the S1D13705
22 SD15 Connected to DB15 of the S1D13705
23 RESET# Connected to the RESET# signal of the S1D13705
24 GND Ground
25 GND Ground
26 GND Ground
27 +12V 12 volt supply
28 +12V 12 volt supply
29 WE0# Connected to the WE0# signal of the S1D13705
30 WAIT# Connected to the WAIT# signal of the S1D13705
31 CS# Connected to the CS# signal of the S1D13705
32 NC Not connected
33 WE1# Connected to the WE1# signal of the S1D13705
34 IOVDD Connected to the IOVDD supply of the S1D13705

CPU/Bus Interface Connector Pinouts
10 Seiko Epson Corporation S5U13705B00C Rev 1.0 Evaluation Board
Rev. 3.1
Table 4-2: CPU/BUS Connector (H2) Pinout
Connector
Pin No.
CPU/BUS
Pin Name Comments
1 SA0 Connected to AB0 of the S1D13705
2 SA1 Connected to AB1 of the S1D13705
3 SA2 Connected to AB2 of the S1D13705
4 SA3 Connected to AB3 of the S1D13705
5 SA4 Connected to AB4 of the S1D13705
6 SA5 Connected to AB5 of the S1D13705
7 SA6 Connected to AB6 of the S1D13705
8 SA7 Connected to AB7 of the S1D13705
9 GND Ground
10 GND Ground
11 SA8 Connected to AB8 of the S1D13705
12 SA9 Connected to AB9 of the S1D13705
13 SA10 Connected to AB10 of the S1D13705
14 SA11 Connected to AB11 of the S1D13705
15 SA12 Connected to AB12 of the S1D13705
16 SA13 Connected to AB13 of the S1D13705
17 GND Ground
18 GND Ground
19 SA14 Connected to AB14 of the S1D13705
20 SA15 Connected to AB14 of the S1D13705
21 SA16 Connected to AB16 of the S1D13705
22 SA17 Connected to SA17 of the ISA bus connector
23 SA18 Connected to SA18 of the ISA bus connector
24 SA19 Connected to SA19 of the ISA bus connector
25 GND Ground
26 GND Ground
27 VCC 5 volt supply
28 VCC 5 volt supply
29 RD/WR# Connected to the R/W# signal of the S1D13705
30 BS# Connected to the BS# signal of the S1D13705
31 BUSCLK Connected to the BCLK signal of the S1D13705
32 RD# Connected to the RD# signal of the S1D13705
33 NC Not connected
34 CLKI Connected to the CLKI signal of the S1D13705

Host Bus Interface Pin Mapping
S5U13705B00C Rev 1.0 Evaluation Board Seiko Epson Corporation 11
Rev. 3.1
5 Host Bus Interface Pin Mapping
Table 5-1: Host Bus Interface Pin Mapping
S1D13705
Pin Names SH-3 SH-4 MC68K #1 MC68K #2 Generic Bus #1 Generic Bus #2
AB[16:1] A[16:1] A[16:1] A[16:1] A[16:1] A[16:1] A[16:1]
AB0 A0 A0LDS#A0 A0 A0
DB[15:0] D[15:0] D[15:0] D[15:0] D[15:0] D[15:0] D[15:0]
WE1# WE1# WE1# UDS# DS# WE1# BHE#
CS# CSn# CSn# External Decode External Decode External Decode External Decode
BCLK CKIO CKIO BCLK BCLK BCLK BCLK
BS# BS# BS# AS# AS# Connect to VSS Connect to IO VDD
RD/WR# RD/WR# RD/WR# R/W# R/W# RD1# Connect to IO VDD
RD# RD# RD# Connect to IO VDD SIZ1 RD0# RD#
WE0# WE0# WE0# Connect to IO VDD SIZ0 WE0# WE#
WAIT# WAIT# RDY# DTACK# DSACK1# WAIT# WAIT#
RESET# RESET# RESET# RESET# RESET# RESET# RESET#

Technical Description
12 Seiko Epson Corporation S5U13705B00C Rev 1.0 Evaluation Board
Rev. 3.1
6 Technical Description
6.1 Embedded Memory Support
The S1D13705 contains 80K bytes of embedded, 16-bit, SRAM used for the display buffer
and a 32 byte internal register set.
Since the S1D13705 does not distinguish between memory and register accesses, both the
80K byte display buffer and the 32 byte register set must be memory mapped into the host’s
memory space.
When using the S5U13705B00C board on an ISA bus system, the board can be configured
to map the S1D13705 to one of two memory blocks.
The SRAM start address is determined by a DIP switch setting. See Table 2-1: “Configu-
ration DIP Switch Settings,” on page 6.
1. When switch S1-5 is in the closed position, the S1D13705 is mapped into segments
0C0000h and 0D0000h.
This memory space is in the first 1M byte of ISA bus memory and should be used if
these segments are not taken up by other devices such as network adapters, SCSI
cards, or other peripherals.
Note
Since VGA and VGA compatible video adapters use address 0C8000, these cards can-
not be used while using the S5U13705B00C board at this memory address. A mono-
chrome display adapter, a terminal, or a non-VGA compatible display adapter must be
used.
2. When switch S1-5 is in the open position, the S1D13705 is mapped into the upper
megabyte of ISA bus memory, starting address of F00000h. To use this memory on an
ISA bus system, the system BIOS has to be configured to set a memory ‘hole’ starting
at this address. Some systems allow the user to configure the size of this hole and the
starting address of where it begins while others just allow a 1M byte hole at the top of
the 16M byte memory space. This memory hole is configured by entering the system
CMOS Setup Utility. This memory space should be used if segments 0Dh and 0Eh are
being used by other devices or if a VGA display adapter is needed.
Starting at the SRAM start address, the board design decodes a 128K byte segment accom-
modating both the 80K byte display buffer and the S1D13705 internal register set. The
S1D13705 registers are mapped into the upper 32 bytes of the 128K byte segment (1FFE0h
to 1FFFFh).
When using the S5U13705B00C board on a non-ISA bus system, system or external
decode logic must map the S1D13705 into an appropriate memory space.

Technical Description
S5U13705B00C Rev 1.0 Evaluation Board Seiko Epson Corporation 13
Rev. 3.1
6.2 ISA Bus Support
The S5U13705B00C board has been designed to directly support the 16-bit ISA bus
environment and can be used in conjunction with either a VGA or a monochrome display
adapter card.
There are 4 configuration inputs associated with the Host Interface (CNF[2:0] and BS#).
Refer to Table 2-3: “Jumper Settings,” on page 7 and Table 5-1: “Host Bus Interface Pin
Mapping,” on page 11 for complete details.
6.2.1 Display Adapter Card Support
When using the S5U13705B00C in conjunction with another primary Display Adapter
(VGA or Monochrome) the following applies:
VGA Display Adapter
All VGA display adapters can be used with the S5U13705B00C board if the S1D13705 is
mapped to the upper 1M Byte of ISA bus memory, address F00000-F1FFFF. If the
S1D13705 is mapped to the address range 0C0000-0D0000, then no VGA or VGA
compatible display adapters can be used with the S5U13705B00C board. See Embedded
Memory Support on page 12.
Monochrome Display Adapter
The S5U13705B00C board can be used with monochrome display adapters at both memory
addresses.
6.2.2 Expanded Memory Manager Support
If a memory manager is being used for system memory, the address range selected for the
SRAM start address must be excluded from use or memory conflicts will arise.
6.3 Non-ISA Bus Support
The S5U13705B00C board is specifically designed to support the standard 16-bit ISA bus.
However, the S1D13705 directly supports many other host bus interfaces. Header strips H1
and H2 are provided and contain all the necessary IO pins to interface to these host buses.
See CPU/Bus Interface Connector Pinouts on page 9; Table 2-1: “Configuration DIP
Switch Settings,” on page 6; and Table 2-3: “Jumper Settings,” on page 7 for details.

Technical Description
14 Seiko Epson Corporation S5U13705B00C Rev 1.0 Evaluation Board
Rev. 3.1
When using the header strips to provide the bus interface observe the following:
• All signals on the ISA bus card edge must be isolated from the ISA bus (do not plug the
card into a computer). Power must be provided through the headers.
• U7, a PLD of type 22V10-15, is used to provide the S1D13705 CS# (pin 74) and other
decoding logic signals for ISA bus mode. For non-ISA applications, this functionality
must be provided externally. Remove the PAL from its socket to eliminate conflicts
driving S1D13705 control signals. Refer to Table 5-1: “Host Bus Interface Pin
Mapping” for connection details.
Note
When using a 3.3V host bus interface, IO VDD must be set to 3.3V by setting jumper
(JP1) to the 2-3 position. Refer to Table 2-3: “Jumper Settings,” on page 7.
6.4 Decoding Logic
All the required decode logic is provided through a PLD of type 22V10-15 (U7, socketed).
This PAL contains the following equations.
!CS = (Address >= ^hC0000) & (Address <= ^hDFFFF) & !ADDR & REFRESH & ENAB
# (Address1 >= ^hF00000) & (Address1 <= ^hF1FFFF) & ADDR & REFRESH & ENAB;
!MEMCS16 = (Address1 >= ^h0C0000) & (Address1 <= ^h0DFFFF) & !ADDR & !CS
# (Address1 >= ^hF00000) & (Address1 <= ^hF1FFFF) & ADDR & !CS;
!WE0 = (!CS & !ADDR & !SMEMW) # (!CS & ADDR & !MEMW);
!RD = (!CS & !ADDR & !SMEMR) # (!CS & ADDR & !MEMR);
Note
ADDR = Switch S1-5 (see Table 2-1:, “Configuration DIP Switch Settings,” on page 6).
6.5 Clock Input Support
The input clock (CLKI) frequency can be up to 50MHz for the S1D13705 if the internal
clock divide-by-2 mode is set. If the clock divider is not used, the maximum CLKI
frequency is 25MHz. There is no minimum input clock frequency.
A 25.0MHz oscillator (U2, socketed) is provided as the input clock source. However,
depending on the LCD resolution , desired frame rate, and power consumtion budget, a
lower frequency clock may be required.

Technical Description
S5U13705B00C Rev 1.0 Evaluation Board Seiko Epson Corporation 15
Rev. 3.1
6.6 LCD Panel Voltage Setting
The S5U13705B00C board supports both 3.3V and 5V LCD panels through the LCD
connector J5. The voltage level is selected by setting jumper J4 to the appropriate position.
Refer to Table 2-3: “Jumper Settings,” on page 7 for setting this jumper.
Although not necessary for signal buffering, buffers have been implemented in the board
design to provide flexibility in handling 3 and 5 volt panels.
6.7 Monochrome LCD Panel Support
The S1D13705 directly supports 4 and 8-bit, dual and single, monochrome passive LCD
panels. All necessary signals are provided on the 40-pin ribbon cable header J5. The
interface signals on the cable are alternated with grounds to reduce crosstalk and noise.
Refer to Table 3-1: “LCD Signal Connector (J5) Pinout,” on page 8 for specific connection
information.
6.8 Color Passive LCD Panel Support
The S1D13705 directly supports 4 and 8-bit, dual and single, color passive LCD panels. All
the necessary signals are provided on the 40-pin ribbon cable header J5. The interface
signals on the cable are alternated with grounds to reduce crosstalk and noise.
Refer to Table 3-1: “LCD Signal Connector (J5) Pinout,” on page 8 for specific connection
information.
6.9 Color TFT/D-TFD LCD Panel Support
The S1D13705 directly supports 9 and 12-bit active matrix color TFT/D-TFD panels. All
the necessary signals can also be found on the 40-pin LCD connector J5. The interface
signals on the cable are alternated with grounds to reduce crosstalk and noise.
Refer to Table 3-1: “LCD Signal Connector (J5) Pinout,” on page 8 for connection infor-
mation.
6.10 Power Save Modes
The S1D13705 supports hardware and software power save modes. These modes are
controlled by the utility 13705PWR. The hardware power save mode needs to be enabled
by 13705PWR and then activated by DIP switch S1-6. See Table 2-1: “Configuration DIP
Switch Settings,” on page 6 for details on setting this switch.

Technical Description
16 Seiko Epson Corporation S5U13705B00C Rev 1.0 Evaluation Board
Rev. 3.1
6.11 Adjustable LCD Panel Negative Power Supply
For those LCD panels requiring a negative power supply to provide between -23V and -
14V (Iout=25mA) a power supply has been provided as an integral part of this design. The
VLCD power supply can be adjusted by R21 to give an output voltage from -23V to -14V,
and is enabled and disabled by the active high S1D13705 control signal LCDPWR, inverted
externally.
Determine the panel’s specific power requirements and set the potentiometer accordingly
before connecting the panel.
6.12 Adjustable LCD Panel Positive Power Supply
For those LCD panels requiring a positive power supply to provide between +23V and
+40V (Iout=45mA) a power supply has been provided as an integral part of this design. The
VDDH power supply can be adjusted by R15 to provide an output voltage from +23V to
+40V and is enabled and disabled by the active high S1D13705 control signal LCDPWR,
inverted externally.
Determine the panel’s specific power requirements and set the potentiometer accordingly
before connecting the panel.
6.13 CPU/Bus Interface Header Strips
All of the CPU/Bus interface pins of the S1D13705 are connected to the header strips H1
and H2 for easy interface to a CPU/Bus other than ISA.
Refer to Table 4-1: “CPU/BUS Connector (H1) Pinout,” on page 9 and Table 4-2:
“CPU/BUS Connector (H2) Pinout,” on page 10 for specific settings.
Note
These headers only provide the CPU/bus interface signals from the S1D13705. When
another host bus interface is selected by CNF[3:0] and BS#, appropriate external decod-
ing logic MUST be used to access the S1D13705. Refer to Table 5-1: “Host Bus Inter-
face Pin Mapping,” on page 11 for connection details.

Parts List
S5U13705B00C Rev 1.0 Evaluation Board Seiko Epson Corporation 17
Rev. 3.1
7 Parts List
Item # Qty/board Designation Part Value Description
1 15 C1-C11, C15-17,C24 0.1uF, 20%, 50V 0805 ceramic capacitor
2 3 C12-14 10uF, 10%, 25V Tantalum capacitor size D
3 2 C18, C22 47uF, 10%, 16V Tantalum capacitor size D
4 3 C19-C21 4.7uF, 10%, 50V Tantalum capacitor size D
5 1 C23 56uF, 20%, 63V Electrolytic, radial, low ESR
6 2 H1,H2 CON34A Header 0.1” 17x2 header, PTH
7 5 JP1-JP4, JP6 HEADER 3 0.1” 1x3 header, PTH
8 1 J1 AT CON-A ISA Bus gold fingers
9 1 J2 AT CON-B ISA Bus gold fingers
10 1 J3 AT CON-C ISA Bus gold fingers
11 1 J4 AT CON-D ISA Bus gold fingers
12 1 J5 CON40A Shrouded header 2x20, PTH, center key
13 1 L1 1µH MCI-1812 inductor
14 2 L3, L4 Ferrite bead Philips BDS3/3/8.9-4S2
15 1 Q1 2N3906 PNP signal transistor, SOT23
16 1 Q2 2N3904 NPN signal transistor, SOT23
17 6 R1-R6 15K, 5% 0805 resistor
18 9 R7-R13, R17, R18 10K, 5% 0805 resistor
19 1 R14 475K, 1% 0805 resistor
20 1 R15 200K Pot. 200K Trim POT Spectrol 63S204T607 (or equivalent)
21 1 R16 14K, 1% 0805 resistor
22 3 R19, R20, R22 100K, 5% 0805 resistor
23 1 R21 100K Pot. 100K Trim POT Spectrol 63S104T607 (or equivalent)
24 1 S1 SW DIP-6 6 position DIP switch
25 1 U1 S1D13705F00A QFP14-80, 80 pin, SMT
26 1 U2 25.0 MHz oscillator FOX 25MHz oscillator or equiv., 14 pin DIP socketed
27 3 U3-U5 74AHC244 SO-22, TI74AHC244
28 1 U6 LT1117CM-3.3 Linear Technology 5V to 3.3V regulator, 800mA
29 1 U7 PLD22V10-15 PLD type 22V10-15, 20 Pin DIP, socketed
30 1 U8 74ALS125 SO-14, 74ALS125
31 1 U9 74HCT04 SO-14, 74HCT04
32 1 U10 RD-0412 Xentek RD-0412, positive PS
33 1 U11 EPN001 Xentek EPN001 negative PS

Schematic Diagrams
18 Seiko Epson Corporation S5U13705B00C Rev 1.0 Evaluation Board
Rev. 3.1
8 Schematic Diagrams
Figure 8-1: S1D13705B00C Schematic Diagram (1 of 4)
1 1
2 2
3 3
4 4
5 5
6 6
7 7
8 8
A A B B C C D D
By-pass Capacitors (1 per power pin)
1 2 5.0V IOVDD 2 3 3.3V IOVDD 1.0
Epson Research & Development, Inc. S5U13705B00C ISA-Bus Rev. 1.0 Evaluation Board : 13705F00A Chip
B
14Monday, January 04, 1999
Size Document Number Rev Date: Sheet of
FPDAT2
SD2
FPDAT4SD11
SD4 SA3 SD13 SD5 FPDAT[0..7] SD6 SA15 SD8 SA7
FPDAT0
SD10 SD7 SD1
SA[0..19] SD[0..15]
SD12 SD3 SA2 SA5 SD14 SA13 SA1
FPDAT3
SA4 SA0 SD15 SA10 SA9 SA8
FPDAT1
SD9 SD0 SA14 SA12 SA11 SA6
FPDAT5 FPDAT6 FPDAT7
CNF2
CNF1 CNF2
CNF0 CNF3
CNF3
CNF[0..3]
CNF1
CNF0
SA16
3.3V
IOVDD
3.3V
IOVDD
IOVDD IOVDD
IOVDD
VCC
C1 0.1uF
C6 0.1uF
C7 0.1uF
C5 0.1uF
JP3 HEADER 3
1 2 3
JP2 HEADER 3
1 2 3
R4 15K
R3 15K
R2 15K
R1 15K
R5 15K
C2 0.1uF
C4 0.1uF
C3 0.1uF
JP1 HEADER 3
1 2 3
R6 15K
S1 SW DIP-6
1 2 3 4 5 6
12 11 10 9 8 7
U1 S1D13705F00A
AB0
70
AB1
69
AB2
68
AB3
67
AB4
66
AB5
65
AB6
64
AB7
63
AB8
62
AB9
59
AB10
58
AB11
57
AB12
56
AB13
55
AB14
54
AB15
53
FPDAT0 37 FPDAT1 36 FPDAT2 35 FPDAT3 34 FPDAT5 32 FPDAT6 31 FPDAT7 30
CS#
74
LCDPWR 43
COREVDD
61
VSS
20
VSS
40
VSS
72 VSS 60 VSS 50
VSS
27
VSS
80
DB0
19
DB1
18
DB2
17
DB3
16
DB4
15
DB5
14
DB6
13
DB7
12
DB8
11
DB9
9
DB10
8
DB11
7
DB12
6
DB13
5
DB14
4
DB15
3
FPDAT4 33
CNF0 49 CNF1 48 CNF2 47 CNF3 46
AB16
45
RD/WR#
79
WE1#
78
WE0#
77
RD#
76
BS#
75
RESET#
73
CLKI
51
BCLK
71
WAIT#
2
TESTEN
44
COREVDD
1
COREVDD
21
IOVDD
10
COREVDD
41
IOVDD
52 IOVDD 29
FPDAT8/GPIO1 26
FPDAT9GPIO2 25
FPDAT10/GPIO3 24 FPDAT11/GPIO4 23
FPFRAME 39
FPLINE 38
FPSHIFT 28
DRDY 42 GPIO0 22
SD[0..15]
LCDPWR DRDY FPFRAME FPLINE FPSHIFT FPDAT[0..7]
RD/WR#
WE1# WE0#
CS#
BUSCLK
CLKI
RESET#
RD#
WAIT#
BS#
SA[0..19]
FPDAT8
FPDAT9 FPDAT10 FPDAT11 CNF[0..3] SUSPEND
BS# RD/WR#
CNF[0..3]
SUSPEND ADDR

Schematic Diagrams
S5U13705B00C Rev 1.0 Evaluation Board Seiko Epson Corporation 19
Rev. 3.1
Figure 8-2: S1D13705B00C Schematic Diagram (2 of 4)
1 1
2 2
3 3
4 4
5 5
6 6
7 7
8 8
A A B B C C D D
MEMCS16
1.0
Epson Research & Development, Inc. S5U13705B00C ISA-Bus Rev. 1.0 Evaluation Board : ISA-Bus and PAL Decode
B
24Monday, January 04, 1999
Size Document Number Rev Date: Sheet of
SD7 SD6 SD5 SD4 SD3 SD2 SD1 SD0
SD8 SD9 SD10 SD11 SD12 SD13 SD14 SD15
SD[0..15]
SA[0..19]
SA9 SA10 LA21 SA14 SA17 SA8 SA15 SA0 SA4 SA13 LA23
LA[17..23]
SA19 LA19 LA18 SA7 SA3 LA20 SA16 SA6 SA2 SA11 SA12 LA22 LA17 SA1 SA18 SA5
LA[17..23] SA[0..19]
LA23 LA22 LA21 LA20 LA19 LA18 LA17 SA19 SA18 SA17 SA16
IOVDD
VCC
IOVDD
VCC
+12V
IOVDDIOVDD
VCC
VCC
VCC
IOVDD
VCC
J1 AT CON-A /IOCHCK
1
SD7
2
SD6
3
SD5
4
SD4
5
SD3
6
SD2
7
SD1
8
SD0
9
IOCHRDY
10
AEN
11
SA19
12
SA18
13
SA17
14
SA16
15
SA15
16
SA14
17
SA13
18
SA12
19
SA11
20
SA10
21
SA9
22
SA8
23
SA7
24
SA6
25
SA5
26
SA4
27
SA3
28
SA2
29
SA1
30
SA0
31
J2 AT CON-B
GND 1
RESET 2
+5V 3
IRQ9 4
-5V 5
DRQ2 6 -12V 7
OWS 8
+12V 9
GND 10
/SMEMW 11 /SMEMR 12
/IOW 13 /IOR 14
/DACK3 15
DRQ3 16
/DACK1 17
DRQ1 18
/REFRESH 19
CLK 20
IRQ7 21 IRQ6 22 IRQ5 23 IRQ4 24 IRQ3 25
/DACK2 26
T/C 27
BALE 28
+5V 29 OSC 30 GND 31
J4 AT CON-D
/MEMCS16 1
/IOCS16 2
IRQ10 3 IRQ11 4 IRQ12 5 IRQ15 6 IRQ14 7
/DACK0 8
DRQ0 9
/DACK5 10
DRQ5 11
/DACK6 12
DRQ6 13
/DACK7 14
DRQ7 15
+5V 16
MASTER 17
GND 18
+C14
10uF/25V
R7 10K
+C13
10uF/25V
J3 AT CON-C
/SBHE
1
LA23
2
LA22
3
LA21
4
LA20
5
LA19
6
LA18
7
LA17
8
/MEMR
9
/MEMW
10
SD8
11
SD9
12
SD10
13
SD11
14
SD12
15
SD13
16
SD14
17
SD15
18
R9 10K
R10 10K R12
10K
U8A 74LS125
2 3
14
1
7
C16 0.1uF
R8 10K
U7 TIBPAL22V10
CLK/IN
1
IN
2
IN
3
IN
4
IN
5
IN
6
IN
7
IN
8
IN
9
IN
10
IN
11
GND
12
I/O 23 I/O 22 I/O 21 I/O 20 I/O 19 I/O 18 I/O 17 I/O 16 I/O 15 I/O 14
IN 13
VCC 24
C15 0.1uF
R11 10K
R13 10K
C17 0.1uF
U9A 74HCT04
1 2
14
7
R22 100K
REFRESH# RESET
MEMCS16#
WE1#
SD[0..15] SA[0..19] LA[17..23]
WAIT#
BUSCLK SMEMW# SMEMR#
CS#
RESET#
RESET
REFRESH#
MEMCS16#
MEMW#
MEMR#
LA[17..23] SA[0..19]
ADDR MEMR# MEMW# SMEMR# SMEMW# RD# WE0#

Schematic Diagrams
20 Seiko Epson Corporation S5U13705B00C Rev 1.0 Evaluation Board
Rev. 3.1
Figure 8-3: S1D13705B00C Schematic Diagram (3 of 4)
1 1
2 2
3 3
4 4
5 5
6 6
7 7
8 8
A A B B C C D D
SELECTABLE 3.3V / 5.0V COLOR/MONO LCD CONNECTOR
1 2 5.0V LCD Panels 2 3 3.3V LCD Panels
1.0
Epson Research & Development, Inc. S5U13705B00C ISA-Bus Rev. 1.0 Evaluation Card : LCD Connector & Headers
B
34Monday, January 04, 1999
Size Document Number Rev Date: Sheet of
FPDAT[0..7]
BFPDAT0 BFPDAT1 BFPDAT2 BFPDAT3 BFPDAT4 BFPDAT5 BFPDAT6 BFPDAT7 BFPDAT8 BFPDAT9 BFPDAT10 BFPDAT11
FPDAT0 FPDAT1 FPDAT2 FPDAT3 FPDAT4 FPDAT5 FPDAT6 FPDAT7 FPDAT8 FPDAT9 FPDAT10 FPDAT11
SA[0..19]
SA1 SA3 SA9 SA11 SA13 SA15 SA17 SA19
SA0 SA2 SA4 SA6 SA8 SA10 SA12 SA14 SA16 SA18
SA5 SA7
SD14
SD9 SD13SD12 SD7 SD11SD10
SD8
SD5 SD3
SD6 SD4
SD1
SD[0..15]
SD2 SD0
SD15
FPSHIFT
LCDVCC
LCDVCC
FPFRAME
BLCDPWR
DRDY
BDRDY
FPLINE
BFPFRAME BFPSHIFT BFPLINE
LCDP
+12V VDDH VLCD
VCC
VCC
VCCVCC+12V+12V
3.3V
VCC
IOVDD
J5 CON40A 1 3 5 7 9 11 13 15 17 19 21 23 25 27 29 31 33 35 37 39
2 4 6 8
10 12 14 16 18 20 22 24 26 28 30 32 34 36 38 40
U3 74AHC244
1A1
21Y1 18
1A2
41Y2 16
1A3
61Y3 14
1A4
81Y4 12
2A1
11 2Y1 9
2A2
13 2Y2 7
2A3
15 2Y3 5
2A4
17 2Y4 3
1G
1
2G
19 VCC 20
GND 10
U4 74AHC244
1A1
21Y1 18
1A2
41Y2 16
1A3
61Y3 14
1A4
81Y4 12
2A1
11 2Y1 9
2A2
13 2Y2 7
2A3
15 2Y3 5
2A4
17 2Y4 3
1G
1
2G
19 VCC 20
GND 10
C8 0.1uF
C9 0.1uF
JP4 HEADER 3
1
2
3
+C12
10uF/25V
U6 LT1117CM-3.3
VIN
3
ADJ
1
VOUT 2
C11 0.1uF
H1 HEADER 17X2
1 2 3 4 5 6 7 8 910 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34
H2 HEADER 17X2
1 2 3 4 5 6 7 8 910 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34
C10 0.1uF
U5 74AHC244
1A1
21Y1 18
1A2
41Y2 16
1A3
61Y3 14
1A4
81Y4 12
2A1
11 2Y1 9
2A2
13 2Y2 7
2A3
15 2Y3 5
2A4
17 2Y4 3
1G
1
2G
19 VCC 20
GND 10
U2 25.0Mhz NC
1
OUT
8GND 7
VCC 14
C24 0.1uF
JP6 HEADER 3
1
2
3
FPSHIFT
DRDY
FPLINE
FPFRAME
FPDAT[0..7]
FPDAT8 FPDAT9 FPDAT10 FPDAT11
BS# RD#
WAIT#WE0#
CS#
RESET#
WE1#
SA[0..19]
SD[0..15]
RD/WR# BUSCLK
CLKI
CLKI
LCDPWR LCDPWR#
