Epson S5U13506P00C100 User manual

S1D13506 LCD/CRT/TV Controller
S5U13506P00C100 PCI Evaluation
Board User Manual
Document Number: X25B-G-014-02
Status: Revision 2.0
Issue Date: 2009/03/02
© SEIKO EPSON CORPORATION 2006 - 2009. All Rights Reserved.
Information in this document is subject to change without notice. You may download and use this document, but only for your own use in
evaluating Seiko Epson/EPSON products. You may not modify the document. Epson Research and Development, Inc. disclaims any
representation that the contents of this document are accurate or current. The Programs/Technologies described in this document may contain
material protected under U.S. and/or International Patent laws.
EPSON is a registered trademark of Seiko Epson Corporation. All other Trademarks are the property of their respective owners.

Page 2 Epson Research and Development
Vancouver Design Center
S1D13506 S5U13506P00C100 PCI Evaluation Board User Manual
X25B-G-014-02 Issue Date: 2009/03/02
THIS PAGE LEFT BLANK

Epson Research and Development Page 3
Vancouver Design Center
S5U13506P00C100 PCI Evaluation Board User Manual S1D13506
Issue Date: 2009/03/02 X25B-G-014-02
Table of Contents
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3 Installation and Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.1 Configuration DIP Switches . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.2 Configuration Jumpers . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
4 Technical Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.1 PCI Bus Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.2 Non-PCI Host Interface Support . . . . . . . . . . . . . . . . . . . . . . . 14
4.2.1 CPU Interface Pin Mapping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
4.2.2 CPU Bus Connector Pin Mapping . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.3 LCD Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
4.3.1 LCD Interface Pin Mapping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
4.3.2 Buffered LCD Connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
4.4 CRT/TV Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
4.4.1 CRT/TV Interface Pin Mapping . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
4.4.2 CRT Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
4.4.3 TV Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
4.5 Current consumption measurement . . . . . . . . . . . . . . . . . . . . . . 21
5 References . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
5.1 Documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
5.2 Document Sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
6 Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
7 Schematic Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
8 Board Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
9 Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
9.1 EPSON LCD/CRT Controllers (S1D13506) . . . . . . . . . . . . . . . . . . 31

Page 4 Epson Research and Development
Vancouver Design Center
S1D13506 S5U13506P00C100 PCI Evaluation Board User Manual
X25B-G-014-02 Issue Date: 2009/03/02
THIS PAGE LEFT BLANK

Epson Research and Development Page 5
Vancouver Design Center
S5U13506P00C100 PCI Evaluation Board User Manual S1D13506
Issue Date: 2009/03/02 X25B-G-014-02
1 Introduction
This manual describes the setup and operation of the S5U13505P00C100 PCI Evaluation
Board. The S5U13506P00C100 is designed as an evaluation platform for the S1D13506
Color LCD/CRT/TV Controller chip.
This document is updated as appropriate. Please check the Epson Research and Devel-
opment website at http://www.erd.epson.com for the latest revision of this document before
beginning any development.
We appreciate your comments on our documentation. Please contact us via email at
documentati[email protected].

Page 6 Epson Research and Development
Vancouver Design Center
S1D13506 S5U13506P00C100 PCI Evaluation Board User Manual
X25B-G-014-02 Issue Date: 2009/03/02
2 Features
The S5U13506P00C100 features the following:
• S1D13506 Color LCD/CRT/TV controller chip
• PCI bus operation using on-board PCI bridge
• Headers for connecting to a 3.3V host bus interface (5V host bus interface also possible
with modifications to the board)
• 1Mx16 EDO DRAM
• Configuration options
• Headers for S1D13506 current consumption measurements
• 4/8-bit 3.3V or 5V monochrome passive LCD panel support
• 4/8/16-bit 3.3V or 5V color passive LCD panel support
• 9/12/18-bit 3.3V or 5V TFT/D-TFD LCD panel support
• Embedded RAMDAC for CRT and TV support
• Software initiated Power Save Mode

Epson Research and Development Page 7
Vancouver Design Center
S5U13506P00C100 PCI Evaluation Board User Manual S1D13506
Issue Date: 2009/03/02 X25B-G-014-02
3 Installation and Configuration
The S5U13506P00C100 is designed to support as many platforms as possible. The board
incorporates a DIP switch and several jumpers which allow both evaluation board and
S1D13506 LCD controller settings to be configured for a specified evaluation platform.
3.1 Configuration DIP Switches
The S1D13506 LCD controller has 16 configuration inputs (MD[15:0]) which are read on
the rising edge of RESET#. Where appropriate, the S5U13506P00C100 hard-wires some
of these configuration inputs, but in order to configure the S1D13505 for multiple host bus
interfaces an eight-position DIP switch is required. The following figure shows the location
of DIP switch S1 on the S5U13506P00C100 board.
Figure 3-1: Configuration DIP Switch (S1) Location
DIP Switch - S1

Page 8 Epson Research and Development
Vancouver Design Center
S1D13506 S5U13506P00C100 PCI Evaluation Board User Manual
X25B-G-014-02 Issue Date: 2009/03/02
The following DIP switch settings configure the S1D13506.
The following table shows the Host Bus Interface options available. The host bus interface
is selected according to the evaluation platform to be used.
Table 3-1: Configuration DIP Switch Settings
Switch Signal Value of this pin at rising edge of RESET# is used to configure:
Closed/On=1 Open/Off=0
S1-1 MD15 WAIT# is always driven. WAIT# is tristated when S1D13506 is not selected
S1-2 MD1
See Table 3-2:, “Host Bus Interface Selection” on page 8S1-3 MD2
S1-4 MD3
S1-5 MD4 Little Endian Big Endian
S1-6 MD5 WAIT# is active high WAIT# is active low
S1-7 MD11 See Table 3-2:, “Host Bus Interface Selection” on page 8
S1-8 MD12 BUSCLK input divided by 2 BUSCLK input not divided
= Required configuration when used in a PCI environment
Table 3-2: Host Bus Interface Selection
MD11 MD3 MD2 MD1 Host Bus Interface
0000 SH-4/SH-3
0 0 0 1 MC68K Bus 1
0 0 1 0 MC68K Bus 2
0 0 1 1 Generic
0100 Reserved
0101 MIPS/ISA
0110 PowerPC
0111 PCCard
1 1 1 1 Philips PR31500/PR31700 / Toshiba TX3912
= Required configuration when used in a PCI environment

Epson Research and Development Page 9
Vancouver Design Center
S5U13506P00C100 PCI Evaluation Board User Manual S1D13506
Issue Date: 2009/03/02 X25B-G-014-02
3.2 Configuration Jumpers
The S5U13505B00C has seven jumper blocks which configure various board settings. The
jumper positions for each function are shown below.
JP1 - BUSCLK Selection
JP1 selects the source for BUSCLK.
When the jumper is at position 1-2, the BUSCLK source is provided by the oscillator at U2
(default setting).
When the jumper is at position 2-3, the BUSCLK source is provided by the non-PCI host
system.
Note
When used in a PCI environment, JP1 must be set to the 1-2 position.
Figure 3-2: Configuration Jumper (JP1) Location
Table 3-3: Jumper Settings
Jumper Function Position 1-2 Position 2-3 Jumper Off
JP1 BUSCLK Selection BUSCLK from U2 oscillator BUSCLK from H2 header n/a
JP2 CLKI Selection CLKI from U3 oscillator CLKI is the same as BUSCLK n/a
JP3 VDD current Normal operation n/a Current measurement for
VDD
JP4 DACVDD current Normal operation n/a Current measurement for
DACVDD
JP5 LCD Panel Voltage +5V LCDVCC +3.3V LCDVCC n/a
JP6 Panel Enable Polarity LCDPWR active high LCDPWR active low n/a
JP7 PCI FPGA enable Disable FPGA for non-PCI
host n/a Enable FPGA for PCI host
JP8 IREF for CRT/TV DAC 4.6mA for CRT 9.2mA for TV n/a
= Default configuration
JP1
BUSCLK
BUSCLK from
Oscillator (U2) from H2

Page 10 Epson Research and Development
Vancouver Design Center
S1D13506 S5U13506P00C100 PCI Evaluation Board User Manual
X25B-G-014-02 Issue Date: 2009/03/02
JP2 - CLKI Selection
JP2 selects the source for CLKI.
When the jumper is at position 1-2, the CLKI source is provided by the oscillator at U3
(default setting).
When the jumper is at position 2-3, the CLKI source is the same as BUSCLK (provided by
the non-PCI host system).
Figure 3-3: Configuration Jumper (JP2) Location
JP3 - VDD current
JP3 allows the measurement of S1D13505 VDD current consumption.
When the jumper is at position 1-2, the evaluation board is operating normally (default
setting).
When no jumper is installed, VDD current consumption can be measured by connecting an
ammeter to JP3.
Figure 3-4: Configuration Jumper (JP3) Location
JP2
CLKI from
Oscillator (U3)
CLKI same
as BUSCLK
JP3
CoreVDDNormal
Operation Measurement

Epson Research and Development Page 11
Vancouver Design Center
S5U13506P00C100 PCI Evaluation Board User Manual S1D13506
Issue Date: 2009/03/02 X25B-G-014-02
JP4 - DACVDD current
JP4 allows the measurement of S1D13505 DACVDD current consumption.
When the jumper is at position 1-2, the evaluation board is operating normally (default
setting).
When no jumper is installed, DACVDD current consumption can be measured by
connecting an ammeter to JP4.
Figure 3-5: Configuration Jumper (JP4) Location
JP5 - LCD panel voltage
JP5 selects the voltage level to the LCD panel.
When the jumper is at position 1-2, the LCD panel voltage level is configured for 5.0V.
When the jumper is at position 2-3, the LCD panel voltage level is configured for 3.3V
(default setting).
Figure 3-6: Configuration Jumper (JP5) Location
JP4
CoreVDDNormal
Operation Measurement
JP5
+3.3 LCDVCC+5V LCDVCC

Page 12 Epson Research and Development
Vancouver Design Center
S1D13506 S5U13506P00C100 PCI Evaluation Board User Manual
X25B-G-014-02 Issue Date: 2009/03/02
JP6 - Panel Enable Polarity
JP6 selects the polarity of the LCDPWR panel enable signal.
When the jumper is at position 1-2, the LCDPWR signal is active high (default setting).
When the jumper is at position 2-3, the LCDPWR signal is active low.
Figure 3-7: Configuration Jumper (JP6) Location
JP7 - PCI FPGA Enable
JP7 controls the PCI FPGA.
When no jumper is installed, the PCI FPGA is enabled and the evaluation board may be
used in a PCI environment (default setting).
When the jumper is in position 1-2, the PCI FPGA is disabled and the evaluation board may
be used with a non-PCI host system.
Note
Non-PCI host system must be connected to headers H1 and H2.
Figure 3-8: Configuration Jumper (JP7) Location
JP6
LCDPWR
Active High
LCDPWR
Active Low
JP7
non-PCI
(FPGA Disabled)
PCI
(FPGA Enabled)

Epson Research and Development Page 13
Vancouver Design Center
S5U13506P00C100 PCI Evaluation Board User Manual S1D13506
Issue Date: 2009/03/02 X25B-G-014-02
JP8 - IREF for CRT/TV DAC
JP8 selects the magnitude of the IREF current used by the embedded RAMDAC.
When the jumper is at position 1-2, the IREF current is 4.6mA. This setting is used for CRT
display.
When the jumper is at position 2-3, the IREF current is 9.2mA. This setting is used for TV
display, but it may be used by CRT display as well.
Figure 3-9: Configuration Jumper (JP8) Location
JP8
IREF = 9.2mAIREF = 4.6mA

Page 14 Epson Research and Development
Vancouver Design Center
S1D13506 S5U13506P00C100 PCI Evaluation Board User Manual
X25B-G-014-02 Issue Date: 2009/03/02
4 Technical Description
The S5U13506P00C100 operates with both PCI and non-PCI evaluation platforms. It
supports passive LCD panels (4/6/16-bit), TFT/D-TFD panels (9/12/18-bit), CRT displays
(analog RGB output) and TV (NTSC and PAL).
4.1 PCI Bus Support
The S5U13506P00C100 does not have on-chip PCI bus interface support. The
S5U13506P00C100 uses the PCI FPGA to support the PCI bus.
4.2 Non-PCI Host Interface Support
The S5U13506P00C100 is specifically designed to support a standard PCI bus
environment (using the PCI Bridge Adapter FPGA). However, the S5U13506P00C100 can
directly support many other Host Bus Interfaces. When the FPGA is disabled (using jumper
JP7), headers H1 and H2 provide the necessary IO pins to interface to the Host Bus Inter-
faces listed in Table 4-4:, “CPU Interface Pin Mapping”.
Note
The S5U13506P00C100 is designed to work only with 3.3V systems. To use it with a
5V system, some modifications must be done to the board as follows:
1. Replace the 3.3V DRAM (U6) on the board with a 5V DRAM.
2. Cut the trace between JP9-2 and JP9-3 on the solder side of the board.
3. Connect JP9-1 and JP9-2. This will set IOVDD to 5V.

Epson Research and Development Page 15
Vancouver Design Center
S5U13506P00C100 PCI Evaluation Board User Manual S1D13506
Issue Date: 2009/03/02 X25B-G-014-02
4.2.1 CPU Interface Pin Mapping
The functions of the S1D13506 host interface pins are mapped to each host bus interface
according to the following table.
Note
1A0 for these busses is not used internally by the S1D13506.
Table 4-4: CPU Interface Pin Mapping
S1D13505
Pin
Names
Generic Hitachi
SH-4/SH-3 MIPS/ISA
Motorola
MC68K
Bus 1
Motorola
MC68K
Bus 2
Motorola
PowerPC PC Card
Philips
PR31500
/PR31700
Toshiba
TX3912
AB20 A20 A20 LatchA20 A20 A20 A11 A20 ALE ALE
AB19 A19 A19 SA19 A19 A19 A12 A19 /CARDREG CARDREG*
AB18 A18 A18 SA18 A18 A18 A13 A18 /CARDIORD CARDIORD*
AB17 A17 A17 SA17 A17 A17 A14 A17 /CARDIOWR CARDIOWR*
AB[16:13] A[16:13] A[16:13] SA[16:13] A[16:13] A[16:13] A[15:18] A[16:13] Connected to VDD
AB[12:1] A[12:1] A[12:1] SA[12:1] A[12:1] A[12:1] A[19:30] A[12:1] A[12:1] A[12:1]
AB0 A01A01SA0 LDS# A0 A31 A01A0 A0
DB[15:8] D[15:0] D[15:8] SD[15:0] D[15:8] D[31:24] D[0:7] D[15:0] D[23:16] D[23:16]
DB[7:0] D[7:0] D[7:0] SD[7:0] D[7:0] D[23:16] D[8:15] D[7:0] D[31:24] D[31:24]
WE1# WE1# WE1# SBHE# UDS# DS# BI -CE2 /CARDxCSH CARDxCSH*
M/R# External Decode Connected to VDD
CS# External Decode Connected to VDD
BUSCLK BCLK CKIO CLK CLK CLK CLKOUT CLK DCLKOUT DCLKOUT
BS# Connected
to VDD BS# Connected to VDD AS# AS# TS Connected to VDD Connected to VDD
RD/WR# RD1# RD/WR# Connected to
VDD R/W# R/W# RD/WR -CE1 /CARDxCSL CARDxCSL*
RD# RD0# RD# MEMR# Connected
to VDD SIZ1 TSIZ0 -OE /RD RD*
WE0# WE0# WE0# MEMW# Connected
to VDD SIZ0 TSIZ1 -WE /WE WE*
WAIT# WAIT# RDY#
/WAIT# IOCHRDY DTACK# DSACK1# TA -WAIT /CARDxWAIT CARDxWAIT*
RESET# RESET# RESET# inverted
RESET RESET# RESET# RESET# inverted
RESET RESET# PON*

Page 16 Epson Research and Development
Vancouver Design Center
S1D13506 S5U13506P00C100 PCI Evaluation Board User Manual
X25B-G-014-02 Issue Date: 2009/03/02
4.2.2 CPU Bus Connector Pin Mapping
The pinouts for Connector H1 are listed in the following table.
Table 4-5: CPU/BUS Connector (H1) Pinout
Pin No. Function
1 Connected to DB0 of the S1D13506
2 Connected to DB1 of the S1D13506
3 Connected to DB2 of the S1D13506
4 Connected to DB3 of the S1D13506
5 Ground
6 Ground
7 Connected to DB4 of the S1D13506
8 Connected to DB5 of the S1D13506
9 Connected to DB6 of the S1D13506
10 Connected to DB7 of the S1D13506
11 Ground
12 Ground
13 Connected to DB8 of the S1D13506
14 Connected to DB9 of the S1D13506
15 Connected to DB10 of the S1D13506
16 Connected to DB11 of the S1D13506
17 Ground
18 Ground
19 Connected to DB12 of the S1D13506
20 Connected to DB13 of the S1D13506
21 Connected to DB14 of the S1D13506
22 Connected to DB15 of the S1D13506
23 Connected to RESET# of the S1D13506
24 Ground
25 Ground
26 Ground
27 +12 volt supply, required in non-PCI applications
28 +12 volt supply, required in non-PCI applications
29 Connected to WE0# of the S1D13506
30 Connected to WAIT# of the S1D13506
31 Connected to CS# of the S1D13506
32 Connected to MR# of the S1D13506
33 Connected to WE1# of the S1D135065
34 S1D13506 supply, provided by the S5U13506P00C100

Epson Research and Development Page 17
Vancouver Design Center
S5U13506P00C100 PCI Evaluation Board User Manual S1D13506
Issue Date: 2009/03/02 X25B-G-014-02
The pinouts for Connector H2 are listed in the following table.
Table 4-6: CPU/BUS Connector (H2) Pinout
Pin No. Function
1 Connected to AB0 of the S1D13506
2 Connected to AB1 of the S1D13506
3 Connected to AB2 of the S1D13506
4 Connected to AB3 of the S1D13506
5 Connected to AB4 of the S1D13506
6 Connected to AB5 of the S1D13506
7 Connected to AB6 of the S1D13506
8 Connected to AB7 of the S1D13506
9Ground
10 Ground
11 Connected to AB8 of the S1D13506
12 Connected to AB9 of the S1D13506
13 Connected to AB10 of the S1D13506
14 Connected to AB11 of the S1D13506
15 Connected to AB12 of the S1D13506
16 Connected to AB13 of the S1D13506
17 Ground
18 Ground
19 Connected to AB14 of the S1D13506
20 Connected to AB15 of the S1D13506
21 Connected to AB16 of the S1D13506
22 Connected to AB17 of the S1D13506
23 Connected to AB18 of the S1D13506
24 Connected to AB19 of the S1D13506
25 Ground
26 Ground
27 +5 volt supply, required in non-PCI applications
28 +5 volt supply, required in non-PCI applications
29 Connected to RD/WR# of the S1D13506
30 Connected to BS# of the S1D13506
31 Connected to S1D13506 BUSCLK if JP1 is in position 2-3
32 Connected to RD# of the S1D13506
33 Connected to AB20 of the S1D13506
34 Not connected

Page 18 Epson Research and Development
Vancouver Design Center
S1D13506 S5U13506P00C100 PCI Evaluation Board User Manual
X25B-G-014-02 Issue Date: 2009/03/02
4.3 LCD Support
The S1D13506 supports 4/8-bit dual and single passive monochrome panels, 4/8/16-bit
dual and single passive color panels, and 9/12/18-bit active matrix color TFT/D-TFD
panels. All necessary signals are provided on the 40-pin LCD connector (J1). The interface
signals are alternated with grounds on the cable to reduce cross-talk and noise. When
supporting an 18-bit TFT/D-TFD panel, the S1D13505 can display 64K of a possible 256K
colors because only 16 of the18 bits of LCD data are available from the S1D13505. For
details, refer to the S1D13506 Hardware Functional Specification, document number
X25B-A-001-xx.
For S1D13506 FPDAT[15:0] pin mapping for various types of panel see Table 4-7:, “LCD
Signal Connector (J4)” on page 19.

Epson Research and Development Page 19
Vancouver Design Center
S5U13506P00C100 PCI Evaluation Board User Manual S1D13506
Issue Date: 2009/03/02 X25B-G-014-02
4.3.1 LCD Interface Pin Mapping
Note
1For FPDATxx to LCD interface hardware connections refer to the Display Interface
AC Timing section of the S1D13506 Hardware Functional Specification, document
number X25B-A-001-xx.
2The S5U13506B00C was designed using S1D13506 pin 75 (LCDPWR) to control the
LCD bias power. This design is no longer supported. Applications should use one of
the available GPIO pins to control the LCD bias power allowing for software control
of power sequencing delays. For further information on LCD power sequencing, see
the S1D13506 Programming Notes and Examples, document number X25B-G-003-
xx.
Table 4-7: LCD Signal Connector (J4)
S1D13505
Pin Names
Connector
Pin No.
Monochrome Passive
Panels Color Passive Panels Color TFT/D-TFD
Panels
Single Dual Single Single
Format 1
Single
Format 2 Single Dual
4-bit 8-bit 8-bit 4-bit 8-bit 8-bit 16-Bit 8-bit 16-bit 9-bit 12-bit 18-bit
FPDAT0 1 and 6 D0 LD0 D0 D0 D0 LD0 LD0 R2 R3 R5
FPDAT1 3 D1 LD1 D1 D1 D1 LD1 LD1 R1 R2 R4
FPDAT2 5 D2 LD2 D2 D2 D2 LD2 LD2 R0 R1 R3
FPDAT3 7 D3 LD3 D3 D3 D3 LD3 LD3 G2 G3 G5
FPDAT4 9 D0 D4 UD0 D0 D4 D4 D8 UD0 UD0 G1 G2 G4
FPDAT5 11 D1 D5 UD1 D1 D5 D5 D9 UD1 UD1 G0 G1 G3
FPDAT6 13 and 4 D2 D6 UD2 D2 D6 D6 D10 UD2 UD2 B2 B3 B5
FPDAT7 15 D3 D7 UD3 D3 D7 D7 D11 UD3 UD3 B1 B2 B4
FPDAT8 17 D4 LD4B0B1B3
FPDAT9 19 D5 LD5 R0 R2
FPDAT10 21 D6 LD6 R1
FPDAT11 23 D7 LD7 G0 G2
FPDAT12 25 D12 UD4 G1
FPDAT13 27 D13 UD5 G0
FPDAT14 29 D14 UD6 B0 B2
FPDAT15 31 D15 UD7 B1
FPSHIFT 33 FPSHIFT
DRDY 35 and 38 MOD FPSHIFT2 MOD DRDY
FPLINE 37 FPLINE
FPFRAME 39 FPFRAME
GND 2 and 8-26
(Even Pins) GND
N/C 28 N/C
N/C 30 N/C
LCDVCC 32 +5V or +3.3V according to JP5
+12V 34 +12V
N/C 36 N/C
NC (pin 75)240 Panel Enable, active low (LCDPWR)2
= Driven low

Page 20 Epson Research and Development
Vancouver Design Center
S1D13506 S5U13506P00C100 PCI Evaluation Board User Manual
X25B-G-014-02 Issue Date: 2009/03/02
4.3.2 Buffered LCD Connector
J4 provides the same LCD panel signals as those directly from S1D13505, but with voltage-
adapting buffers which can be set to 3.3V or 5V. Pin 32 on this connector provides power
for the LCD panel logic at the same voltage as the buffer power supply.
