Epson S5U13L03P00C100 User manual

Revision 1.0
S1D13L03 Simple LCDC
S5U13L03P00C100 Evaluation Board
User Manual

Page 2 Epson Research and Development
Vancouver Design Center
S1D13L03 S5U13L03P00C100 Evaluation Board User Manual
XB1AG001 Issue Date: 2014/05/15
Revision 1.0
NOTICE
No part of this material may be reproduced or duplicated in any form or by any means without the written permission of Seiko
Epson. Seiko Epson reserves the right to make changes to this material without notice. Seiko Epson does not assume any lia-
bility of any kind arising out of any inaccuracies contained in this material or due to its application or use in any product or cir-
cuit and, further, there is no representation that this material is applicable to products requiring high level reliability, such as,
medical products. Moreover, no license to any intellectual property rights is granted by implication or otherwise, and there is
no representation or warranty that anything made in accordance with this material will be free from any patent or copyright
infringement of a third party. When exporting the products or technology described in this material, you should comply with
the applicable export control laws and regulations and follow the procedures required by such laws and regulations. You are
requested not to use, to resell, to export and/or to otherwise dispose of the products (and any technical information furnished,
if any) for the development and/or manufacture of weapon of mass destruction or for other military purposes.
All brands or product names mentioned herein are trademarks and/or registered trademarks of their respective companies.
©SEIKO EPSON CORPORATION 2014, All rights reserved.
Evaluation Board/Kit and Development Tool Important Notice
1. This evaluation board/kit or development tool is designed for use for engineering evaluation, demonstration, or develop-
ment purposes only. Do not use it for other purposes. It is not intended to meet the requirements of design for finished
products.
2. This evaluation board/kit or development tool is intended for use by an electronics engineer and is not a consumer product.
The user should use it properly and in a safe manner. Seiko Epson does not assume any responsibility or liability of any
kind of damage and/or fire caused by the use of it. The user should cease to use it when any abnormal issue occurs even
during proper and safe use.
3. The part used for this evaluation board/kit or development tool may be changed without any notice.

Epson Research and Development Page 3
Vancouver Design Center
S5U13L03P00C100 Evaluation Board User Manual S1D13L03
Issue Date: 2014/05/15 XB1AG001
Revision 1.0
Table of Contents
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
2 Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3 Installation and Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
3.1 Configuration DIP Switch . . . . . . . . . . . . . . . . . . . . . . . . . . .7
3.2 Configuration Jumpers . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
4 Technical Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.1 Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.1.1 Power Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.1.2 Voltage Regulators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.1.3 S1D13L03 Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
4.2 Clocks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.3 Reset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.4 Power Save . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
4.5 Host Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.5.1 Direct Host Bus Interface Support . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4.5.2 Connecting to the Epson S5U13U00P00C100 USB Adapter Board . . . . . . . . . 15
4.6 LCD Panel Interface . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
4.7 GPIO Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
5 Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
6 Schematic Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
7 Board Layout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
8 References . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
8.1 Documents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
8.2 Document Sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26

Page 4 Epson Research and Development
Vancouver Design Center
S1D13L03 S5U13L03P00C100 Evaluation Board User Manual
XB1AG001 Issue Date: 2014/05/15
Revision 1.0

Epson Research and Development Page 5
Vancouver Design Center
S5U13L03P00C100 Evaluation Board User Manual S1D13L03
Issue Date: 2014/05/15 XB1AG001
Revision 1.0
1 Introduction
This manual describes the setup and operation of the S5U13L03P00C100 Evaluation
Board. The evaluation board is designed as an evaluation platform for the S1D13L03
Simple LCD Controller.
The S5U13L03P00C100 Evaluation Board can also connect to the S5U13U00P00C100
USB Adapter board so that it can be used with a laptop or desktop computer, via USB 2.0.
However, if you do not use the S5U13U00C100 USB Adapter board, there is no headers
mounted for the other host interface. (only allocated space) Please use the allocated space
mount the headers for the host interface.
This user manual is updated as appropriate. Please check the Epson Electronics America
Website at www.vdc.epson.com for the latest revision of this document before beginning
any development.
We appreciate your comments on our documentation. Please contact us via email at
documentati[email protected]pson.com.

Page 6 Epson Research and Development
Vancouver Design Center
S1D13L03 S5U13L03P00C100 Evaluation Board User Manual
XB1AG001 Issue Date: 2014/05/15
Revision 1.0
2 Features
The S5U13L03P00C100 Evaluation Board includes the following features:
• 176-pin QFP S1D13L03 Simple LCD Controller
• Headers for connection to the S5U13U00P00C100 USB Adapter board
• Header with all S1D13L03 Host Bus Interface signals (optional)
Note
These headers are not mounted. There are allocated areas for mounting.
• Headers for connecting to LCD panels
• Header for S1D13L03 GPIO pins (optional)
Note
These headers are not mounted. There are allocated areas for mounting
• On-board 4MHz oscillator
• 3.3V input power
• On-board voltage regulator with 1.5V output
• On-board voltage regulator with adjustable 38V/60mA max, to provide power for LED
back-light of LCD panel.

Epson Research and Development Page 7
Vancouver Design Center
S5U13L03P00C100 Evaluation Board User Manual S1D13L03
Issue Date: 2014/05/15 XB1AG001
Revision 1.0
3 Installation and Configuration
The S5U13L03P00C100 Evaluation Board incorporates a DIP switch, jumpers, and 0 ohm
resistors which allow it to be used with a variety of different configurations.
3.1 Configuration DIP Switch
The S1D13L03 has 3 configuration inputs (CNF[2:0]). A DIP switch (SW1) is used to
configure CNF[2:0] as described below.
The following figure shows the location of DIP switch SW1 on the S5U13L03P00C100
board.
Figure 3-1: Configuration DIP Switch (SW1) Location
Table 3-1: Summary of Power-On/Reset Options
S5U13L03P00C100
SW1-[4:1] Config S1D13L03 CNF[2:0] Config Power-On/Reset State
1 (ON) 0 (OFF)
SW1-[1] CNF0 Host Data lines are normal Host data lines are swapped
SW1-[2] CNF1 Host Data is 16-bit Host data is 8-bit
SW1-[3] CNF2 PIOVDD output current = 6.5mA PIOVDD output current = 2.5mA
SW1-[4] - not used
= Required settings when using S5U13U00P00C100 USB Adapter board

Page 8 Epson Research and Development
Vancouver Design Center
S1D13L03 S5U13L03P00C100 Evaluation Board User Manual
XB1AG001 Issue Date: 2014/05/15
Revision 1.0
3.2 Configuration Jumpers
The S5U13L03P00C100 Evaluation Board has 6 jumpers which configure various board
settings. And this board has 8-pin jumper for setting back-light of the LDC panel. The
jumper positions for each function are shown below.
Table 3-2: Configuration Jumper Setting
Table 3-3: 8-PinJumper Setting
Jumper Function Position 1-2 Position 2-3 No Jumper
JP1 COREVDD Normal — COREVDD current
measurement
JP2 PLLVDD Normal — PLLVDD current
measurement
JP3 IOVDD Normal — IOVDD current
measurement
JP4 IOVDD Source H1 connector, pin 32 3.3VDD —
JP5 PIOVDD Normal — PIOVDD current
measurement
JP6 PIOVDD Source H4 connector, pin 8 3.3VDD —
= Required settings when using S5U13U00P00C100 USB Adapter board
Jumper Position Function
JP7
Position 1-2 No Jumper In connect case, TPS61161A is Enable
Position 3-4 No Jumper In connect case, Vout = 20mA
Position 5-6 No Jumper In connect case, Vout = 40mA (add connect Position 3-4)
Position 7-8 No Jumper In connect case, Vout = 60mA (add connect Position3-4 and
Position5-6)
= suggested settings

Epson Research and Development Page 9
Vancouver Design Center
S5U13L03P00C100 Evaluation Board User Manual S1D13L03
Issue Date: 2014/05/15 XB1AG001
Revision 1.0
JP1, JP2, JP3, JP5 - Power Supplies for the S1D13L03
JP1, JP2, JP3, JP5 can be used to measure the current consumption of each S1D13L03
power supply.
When the jumper is at position 1-2, normal operation is selected.
When no jumper is installed, the current consumption for each power supply can be
measured by connecting an ammeter to pin 1 and 2 of the jumper.
The jumper associated with each power supply is as follows:
JP1 for COREVDD
JP2 for PLLVDD
JP3 for IOVDD
JP5 for PIOVDD
Figure 3-2: Configuration Jumper Locations (JP1, JP2, JP3, JP5)

Page 10 Epson Research and Development
Vancouver Design Center
S1D13L03 S5U13L03P00C100 Evaluation Board User Manual
XB1AG001 Issue Date: 2014/05/15
Revision 1.0
JP4 - IOVDD Source
JP4 is used to select the source for the IOVDD supply voltage.
When the jumper is at position 1-2, the IOVDD voltage must be provided to the H1
connector, pin 32.
When the jumper is at position 2-3, the IOVDD voltage is provided by the 3.3V power
supply of the board.
Note
H1 connector is not mounted. There is an allocated area for mounting.
JP6 - SIOVDD Source
JP6 is used to select the source for the PIOVDD supply voltage.
When the jumper is at position 1-2, the PIOVDD voltage must be provided to the H4
connector, pin 8.
When the jumper is at position 2-3, the PIOVDD voltage is provided by the 3.3V power
supply of the board.
Note
H4 connector is not mounted. There is an allocated area for mounting.
JP7 - Backlight Power Supply for LCD Panel
The S5U13L03P00C100 Evaluation Board is designed to generate backlight power supply
for LCD panels from 3.3V via the S5U13U00P00C100 USB Adapter Board or connector
H1. The 3.3V must be supplied from the S5U13U00P00C100 or H1. The
S5U13L03P00C100 has incorporated a White LED Driver Controller(TPS61161A)for the
panel backlighat. The White LED Driver Controller drives the panel at a constant current.
The S5U13L03P00C100 is capable of changing the output current (20mA, 40mA,
60mA/Max 38V). The current is adjusted by connection of JP7 “See Table 3.3: 8-Pin
Jumper Setting”
Note
H1 connector is not mounted. There is an allocated area for mounting

Epson Research and Development Page 11
Vancouver Design Center
S5U13L03P00C100 Evaluation Board User Manual S1D13L03
Issue Date: 2014/05/15 XB1AG001
Revision 1.0
Figure 3-3: Configuration Jumper Location (JP4, JP6, JP7)

Page 12 Epson Research and Development
Vancouver Design Center
S1D13L03 S5U13L03P00C100 Evaluation Board User Manual
XB1AG001 Issue Date: 2014/05/15
Revision 1.0
4 Technical Description
4.1 Power
4.1.1 Power Requirements
The S5U13L03P00C100 Evaluation Board requires an external regulated power supply
(3.3V / 0.5A). The power is supplied to the evaluation board through pin 34 of the H1
header, or pin 5 of the P2 header.
The green LED ‘3.3V Power’ is turned on when 3.3V power is applied to the board.
Note
H1 connector is not mounted. There is an allocated area for mounting.
4.1.2 Voltage Regulators
The S5U13L03P00C100 Evaluation Board has an on-board linear regulator to provide the
1.5V power required by the S1D13L03 Simple LCD Controller. It also has a step-up
switching voltage regulator togenerate adjustable 12~38V, whichcan be used to power the
LED backlight on some LCD panels.
4.1.3 S1D13L03 Power
The S1D13L03 Simple LCD Controler requires 1.5V and 1.65~3.6V power supplies.
1.5V power for COREVDD and PLLVDD is provided by an on-board linear voltage
regulator.
IOVDD range of S1D13L03 isin the range of 1.65~3.6V. However, IOVDD of the
S5U13L03 P00C100 Evaluation Board can range from 3.0V to 3.6V. When JP4 is set tothe
2-3 position, IOVDD is connected to 3.3V. If a different voltage is required for IOVDD,
set JP4 to the 1-2 position and connect the external powersupply to pin 32 ofconnector H1.
Note
HI connector is not mounted. It is only land.
PIOVDD of S1D13L03 is the power used by the LCD interface and can be in the range of
1.65~3.6V. However, PIOVDD of the S5U13L03P00C100 Evaluation Board can range
from 3.0V to 3.6V. When JP6 is set to the 2-3 position, PIOVDD is connected to 3.3V. If
a different voltage is needed for PIOVDD because of the LCD panel requirements, set JP6
to the 1-2 position and connect the external power supply to pin 8 of connector H4.
Note
H4 connector is not mounted. There is an allocated area for mounting.

Epson Research and Development Page 13
Vancouver Design Center
S5U13L03P00C100 Evaluation Board User Manual S1D13L03
Issue Date: 2014/05/15 XB1AG001
Revision 1.0
4.2 Clocks
The clock for the S1D13L03 Simple LCD Controller is provided by a 4MHz oscillator.
Note
The on-board 4MHz oscillator is not specified to work below a 3.0V supply voltage.
The S1D13L03 can output the input clock on the CLKOUT pin depending on the state of
the CLKOUTEN input. Both these signals are available on the H4 connector: CLKOUT on
pin 1 and CLKOUTEN on pin 4. On the board the CLKOUTEN pin is pulled down which
disables the CLKOUT signal.
Note
H4 connector is not mounted. There is an allocated area for mounting.
4.3 Reset
The S1D13L03 Simple LCD Controller on the S5U13L03P00C100 Evaluation Board can
be reset using a push-button (SW2), or via an active low reset signal from the host devel-
opment platform (pin 33 on the H1 connector).
Note
H1 connector is not mounted. There is an allocated area for mounting..
4.4 Power Save
The S1D13L03 chip has an input called PWRSVE that will enable (when high) or disable
(when low) the power save mode. This signal is available on pin 5 of the H4 connector. On
the board the PWRSVE pin is pulled down which means power save mode is controlled
only by the S1D13L03 register setting.
Note
H4 connector is not mounted. There is an allocated area for mounting.

Page 14 Epson Research and Development
Vancouver Design Center
S1D13L03 S5U13L03P00C100 Evaluation Board User Manual
XB1AG001 Issue Date: 2014/05/15
Revision 1.0
4.5 Host Interface
4.5.1 Direct Host Bus Interface Support
All S1D13L03 host interface pins are available on connector H1 which allows the
S5U13L03P00C100 Evaluation Board to be connected to a variety of development
platforms. For detailed S1D13L03 pin mapping, refer to the S1D13L03 Hardware
Functional Specification, document number xxxxxxxxxx.
The following figure shows the location of host bus connector H1. H1 is not mounted. H1
connector is optional. Therefore H1 connector is an allocated area formounting. To use this
mounting area, it is recommended to attach the 0.1 inch x 0.1 inch, 34-pin header (17x2).
Figure 4-1: Host Bus Connector Location (H1)
For the pinout of connector H1, see “Schematic Diagrams” on page 21.

Epson Research and Development Page 15
Vancouver Design Center
S5U13L03P00C100 Evaluation Board User Manual S1D13L03
Issue Date: 2014/05/15 XB1AG001
Revision 1.0
4.5.2 Connecting to the Epson S5U13U00P00C100 USB Adapter Board
The S5U13L03P00C100 Evaluation Board is designed to connect to a S5U13U00P00C100
USB Adapter Board.The USB adapter boardprovides asimple connection to anycomputer
via a USB 2.0 connection. The S5U13L03P00C100 directly connects to the USB adapter
board through connectors P1 and P2.
The USB adapter board also supplies the 3.3V power required by the S5U13L03P00C100.
IOVDD should be selected for 3.3V and JP4 should be set to the 2-3 position.
When the S5U13L03P00C100 is connected to the S5U13U00P00C100 USB Adapter
board, there are 2 LEDs on S5U13L03P00C100 which provide a quick visual status of the
USB adapter. HB (D300) blinks to indicate that the USB adapter board is active. ENUM
(D301)turns on to indicate that the USB has been enumerated by the PC.
The following diagram shows the location of connectors P1 and P2. P1 and P2 are 2mm x
2mm, 40-pin headers (20x2).
Figure 4-2: USB Adapter Connector Locations (P1 and P2)

Page 16 Epson Research and Development
Vancouver Design Center
S1D13L03 S5U13L03P00C100 Evaluation Board User Manual
XB1AG001 Issue Date: 2014/05/15
Revision 1.0
For the pinout of connectors P1 and P2, see “Schematic Diagrams” on page 21.
Note
A windows driver must be installed on the PC when the S5U13L03P00C100 is used
with the S5U13U00P00C100 USB Adapter Board. The S1D13xxxUSB driver is avail-
able at vdc.epson.com.

Epson Research and Development Page 17
Vancouver Design Center
S5U13L03P00C100 Evaluation Board User Manual S1D13L03
Issue Date: 2014/05/15 XB1AG001
Revision 1.0
4.6 LCD Panel Interface
The LCD interface signals are available on connectors H3 and H5. For S1D13L03 LCD
interface pin mapping, refer to the S1D13L03Hardware Functional Specification,
document number xxxxxxxxxx.
ConnectorH3 is 0.1x0.1” 40-pin header (20x2), Connector H5 is 0.5mm pitch FPC
connector. For the pinout of connectorsH3 and H5, see “Schematic Diagrams” on page 21.
Note
Connector H3 is no mounted. Connector H3 is optional. Therefore Connector H3 is only
allocated are for mounting. To use this area for mounting H3, it is recommended to use
the header of the size mentioned above.
The following diagram shows the location of the LCD panel connectors H3 and H5.
Figure 4-3: LCD Panel Connectors Location (H3, H5)
For the pinout of connectorsH3 and H5, see “Schematic Diagrams” on page 21.

Page 18 Epson Research and Development
Vancouver Design Center
S1D13L03 S5U13L03P00C100 Evaluation Board User Manual
XB1AG001 Issue Date: 2014/05/15
Revision 1.0
4.7 GPIO Connections
The S1D13L03 Simple LCD Controller has 8 GPIO pins. All the GPIO pins are routed to
the H4 connector. Note that connector H4 is not populated on the S5U13L03P00C100
Evaluation Board.
The following figure shows the location of the GPIO connector, H4. Connector H4 is 0.1
inch x 0.1 inch” 16-pin header (8x2).
Note
Connector H4 is not mounted. Connector H4 is optional. Therefore Connector H4 is
only allocated area for mounting. Toto use this allocated are for mounting H4, it is rec-
ommended to use the header of the size mentioned above.
Figure 4-4: GPIO Connector Location (H4)
For the pinout of connector H4, see “Schematic Diagrams” on page 21.

Epson Research and Development Page 19
Vancouver Design Center
S5U13L03P00C100 Evaluation Board User Manual S1D13L03
Issue Date: 2014/05/15 XB1AG001
Revision 1.0
5 Parts List
Table 5-1: Parts List
Item Qty Reference Part Description Mfg / Mfg PN / Notes
116
C1, C2, C3, C4, C9, C12,
C13, C14, C18, C19, C20,
C21, C26, C27, C30, C35 0.1uF C0402 Yageo America
04022F104Z7B20D
213
C5, C6, C7, C8, C15, C16,
C17, C22, C23, C24, C25,
C31, C33 0.01uF C0402 Yageo America
0402ZRY5V7BB103
3 1 C10 1nF C0402 Yageo America
04022R102K9B20D
4 1 C11 10uF C0805 Panasonic - ECG
ECJ-CV50J106M
5 1 C34 0.22uF/25V
6 1 C36 1uF/50V
7 1 C29 4.7uF 10V T C3528 Kemet T491B475K010AS
8 3 D1, D2, D3 LED LED0603 ROHM SML-310VTT86
9 1 D4 CRS04 Schottky Barrier Rectifier TOSHIBA CRS04
10 0 H1 HEADER_17X2 Not mounted AMP 1-87215-7
11 0 H3 LCD Connector Not mounted Samtec TST-120-01-G-D
12 0 H4 HEADER 8X2 Not mounted Samtec TSW-108-07-G-D
13 1 H5 WM3436CT-ND FPC Connector Molex
14 4 JP1, JP2, JP3, JP5 SIP2 CONN HEADER VERT 2POS .100 TIN or
GENERIC
15 2 JP4, JP6 SIP3 CONN HEADER VERT 3POS .100 TIN or
GENERIC
16 1 JP7 67997-108HLF Pin Header 2.54mm 4x2 FCI
17 2 L1, L2 Ferrite R0603
Steward
HZ0603B751R-10
FERRITE 200MA 938
OHMS 0603 SMD
18 1 L3 10uH IND_ELL6
Panasonic - ECG
ELL-6SH100M
COIL 10UH 1300MA
CHOKE SMD
19 2 P1, P2 HEADER_20X2 HDR2X20/2MM 3M 151240-8422-RB
20 3 R1, R2, R3, R23 10k R0402
21 6 R4, R6, R7, R8, R9,
R11,R19 0 R0603
22 1 R5 150k 1% R0402
23 1 R10 33 1% R0402
24 0 R12, R13 NP R0402

Page 20 Epson Research and Development
Vancouver Design Center
S1D13L03 S5U13L03P00C100 Evaluation Board User Manual
XB1AG001 Issue Date: 2014/05/15
Revision 1.0
25 3 R14, R15, R16 270 1% R0402
26 2 R17, R18 47koro R0402
27 3 R20, R21, R22 10 RC0603
28 6 SH1, SH2, SH3, SH4, SH5, SH6, SH7, SH8,
SH9, SH10 .100 in. Jumper Shunt Not Applicable
Sullins Electronics Corp.
STC02SYAN
JUMPER SHORTING TIN
29 1 SW1 CHS-04A DIPSW4 COPAL
30 1 SW2 SW TACT-SPST SW_EVQQW
ITT Industries
KSC241GLFS
SWITCH TACT SILVER
PLT GULLWING
31 2 TPGND1, TP3.3VDD1 TP_SMT TP_1206
Keystone 5015
PC TEST POINT
MINIATURE SMT
31 4 TP1, TP2, TP3, TP4 T POINT F SIP1
33 1 U1 S1D13L03 Ultralow Power Low
Dropout Linear Regulator EPSON
34 1 U2 TPS76915DBVT SOT23-5
Texas Instruments
TPS76915DBVT
IC 1.5V 100MA LDO REG
SOT-23-5
35 1 U3 TPS61161A White LED Driver with Digital and PWM
Brightness Control TI TPS61161ADRVT
38 1 Y1 4M OSC OSC 4.0000MHz 3.3V
50ppm SMD EPSON SG-636
Table 5-1: Parts List
Item Qty Reference Part Description Mfg / Mfg PN / Notes
