USER MANUAL
Roll to roll system
for EPSON C6500P
this product is certified:

The Roll to Roll system specically designed for Epson C6500P color label printer can handle
rolls up to 220mm (8.66”) media wide and having an outside diameter up to 250mm (10”). Both
Unwinder and Rewinder are equipped with a xed 3” core holder. An external power supply
100/240VAC - 2.5A at 24V allows an electronic circuit to provide, through the tension arm, the
speed and sense of rotation auto adjustment.
LABEL UNWINDER INSTALLATION
STEP 1
Place carefully the printer into the lock guides.
STEP 2
On the back side, place and screw the
unwinder to the printer plate.
Do not tighten the knobs until the unwinder will
be properly aligned to the printer.
STEP 3
Remove the additional support and the outer
disk.
Now Load both roll of media and outer disk
onto the core holder.
If you do not have the printer
plate (JPL-6500P), place and
align the unwinder behind the
printer and than follow the
instructions from STEP 3.

STEP 5
Keeping the media underneath the tension
arm, turn on the unwinder and feed the media
into the printer.
Please look at printer’s user manual and
follow the detailed procedure on how to
load the media into the printer.
STEP 6
Once the media is loaded into the printer, slide
left and right the unwinder to nd the correct
alignment between the two units and tighten
the knobs.
Complete the roll to roll system with the Label Rewinder Installation
STEP 7
Behind the unwinder (A), place and screw
the additional plate “B” (equipped with the
rewinder).
Than screw the rewinder (C) to this plate
extension.
Do not tighten the knobs until the rewinder will
be properly aligned to the printer.
B CA
STEP 4
Tighten the core through the knob and install
the additional support.

STEP 10
Keeping the printed media underneath the
tension arm, stick the end on the cardboard
core.
Tighten the knob.
STEP 9
Remove the additional support and the outer
disk. Load the empty cardboard core onto the
core holder.
Slide in the outer disk onto the core holder and
keep it close to the media edge.
STEP 11
Install the additional support.
STEP 8
Pull the printed media underneath both printer
and label unwinder.
STEP 12
Once the media is loaded on the rewinder,
slide left and right the rewinder to nd the
correct alignment between the two units and
tighten the knobs.

LABEL REWINDER ONLY INSTALLATION
STEP 1
Place carefully the printer into the lock guides.
ATTENTION.
The unit is equipped with an
extension plate as default, for this
conguration it is not required to be
used.
STEP 3
Remove the additional support and the outer
disk.
Load the empty cardboard core onto the core
holder.
Slide in the outer disk onto the core holder and
keep it close to the media edge.
If you do not have the printer plate (JPL-6500P), place and align the rewinder behind the
printer and than follow the instructions from STEP 3.
STEP 3
On the back side, place and screw the
rewinder to the printer plate.
Do not tighten the knobs until the rewinder will
be properly aligned to the printer.

STEP 4
Pull the printed media underneath the printer
and under the tension arm.
STEP 6
Tighten the core through the knob.
STEP 5
Stick the end on the cardboard core.
Tighten the knob and install the additional
support.
STEP 7
Once the media is loaded into the printer, slide
left and right the unwinder to nd the correct
alignment between the two units and tighten
the knobs.

Label unwinder
ON-OFF
Push this button to turn On or O󰀨 the unit.
INCREASE SPEED
Push this button to increase the rotation speed.
DECREASE SPEED
Push this button to decrease the rotation speed.
FUNCTIONING
ON-OFF
Push this button to turn On or O󰀨 the unit.
INCREASE SPEED
Push this button to increase the rotation speed.
DECREASE SPEED
Push this button to decrease the rotation speed.
LABEL FACE-OUT
Turn the unit o󰀨. Keep pushed “FACE OUT” button and
push “ON-OFF” until it beeps and the unit starts to rotate.
LABEL FACE-IN
Turn the unit o󰀨. Keep pushed “FACE IN” button and push
“ON-OFF” until it beeps and the unit starts to rotate.
LABEL REWINDER MODE
Turn the unit o󰀨. Keep “ON-OFF” button pushed until both
LEDs will be blinking, than push “Label Rewinder” button.
Once the programming procedure will be completed, turn
ON the unit and it is ready to work.
BACKING PAPER REWINDER
Turn the unit o󰀨. Keep “ON-OFF” button pushed until both
LEDs will be blinking, than push “Backing Paper Rewinder”
button. Once the programming procedure will be completed,
turn ON the unit and it is ready to work.
Backing paper can be rewinded face out only.
Label rewinder
