Epson ProofPlus TM-H6000III User manual

User’s Manual / Petunjuk Penggunaan
Di Impor oleh:
PT. Epson Indonesia
Wisma Kyoei Prince Lt.16
Jalan Jenderal Sudirman Kav.3
Jakarta Pusat 10220, Indonesia
No. Reg: 03/DJPDN/MG/III/2001
Tgl. 13 Maret 2001
M00031300

ii
A
B

iii
C
D
➀
➁

iv
E
F

v
G
H
I
(A)
(B)

vi
DIP Switch Tables
Serial
SW Function ON OFF
1-1 Data receive error Ignored Prints “?”
1-2 Receive buffer
capacity
45 bytes 4 KB
1-3 Handshaking XON/XOFF DTR/DSR
1-4 Data word length 7 bits 8 bits
1-5 Parity check Enabled Disabled
1-6 Parity selection Even Odd
1-7
1-8
Transmission speed (See table below.)
2-1 Handshaking
(BUSY condition)
Receive
buffer full
Offline or
Receive buffer
full
2-2 Customer display
connection
Connected Not connected
2-3
2-4
Print density See Table A.
2-5
2-6
Internal use. Fixed to Off.
2-7 I/F pin 6 reset Enabled Disabled
2-8 I/F pin 25 reset Enabled Disabled
Transmission speed (bps)-bits per second
SW 4800 9600 19200 38400
1-7 ON OFF ON OFF
1-8 ON ON OFF OFF
USB/Parallel
SW Function ON OFF
1-1 Auto line feed Always
enabled
Always disabled
1-2 Receive buffer
capacity
45 bytes 4 KB
1-3~
1-8
Reserved. Fixed to Off.
2-1 Handshaking
(BUSY condition)
Receive
buffer full
Offline or Receive
buffer full
2-2 USB: Customer
display
connection
Connected Not connected
Parallel: Internal use. Do not change setting. Fixed
to Off.
2-3
2-4
Print density See Table A.
2-5
2-6
Internal use. Fixed to Off.
2-7 Reserved (for serial interface) Fixed to Off.
2-8 USB: Fixed to Off.
Parallel: I/F pin 31 reset signal. Do not change set-
ting. Fixed to On.
Table A
Print density/low power SW 2-3 SW 2-4
1 Print density (Light) ON ON
2OFF OFF
3ON OFF
4 Print density (Dark) OFF ON

TM-H6000III User’s Manual 1
English
English
User’s Manual
Illustrations
All of the illustrations are at the beginning of this manual. They may be different from your printer in
appearance, depending on your printer model. They are identified by letters (A, B, C . . .). In the text the
illustrations are referred to by these letters. (“See illustration A,” for example.)
DIP Switch Tables
The DIP switch tables are at the beginning of this manual.
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or
transmitted in any form or by any means, electronic, mechanical, photocopying, recording, or otherwise,
without the prior written permission of Seiko Epson Corporation. No patent liability is assumed with
respect to the use of the information contained herein. While every precaution has been taken in the
preparation of this book, Seiko Epson Corporation assumes no responsibility for errors or omissions.
Neither is any liability assumed for damages resulting from the use of the information contained herein.
Neither Seiko Epson Corporation nor its affiliates shall be liable to the purchaser of this product or third
parties for damages, losses, costs, or expenses incurred by purchaser or third parties as a result of:
accident, misuse, or abuse of this product or unauthorized modifications, repairs, or alterations to this
product, or (excluding the U.S.) failure to strictly comply with Seiko Epson Corporation’s operating and
maintenance instructions.
Seiko Epson Corporation shall not be liable against any damages or problems arising from the use of any
options or any consumable products other than those designated as Original Epson Products or Epson
Approved Products by Seiko Epson Corporation.
EPSON is a registered trademark of Seiko Epson Corporation in Japan and other countries/regions.
NOTICE: The contents of this manual are subject to change without notice.
Copyright © 2011 by Seiko Epson Corporation

2 TM-H6000III User’s Manual
English
Important Safety Information
This section presents important information intended to ensure safe and effective
use of this product. Read this section carefully and store it in an accessible location.
Key to Symbols
The symbols in this manual are identified by their level of importance, as defined
below. Read the following carefully before handling the product.
WARNING:
Warnings must be followed carefully to avoid serious bodily injury.
CAUTION:
Cautions must be observed to avoid minor injury to yourself or damage to your
equipment.
Safety Precautions
WARNING:
Shut down your equipment immediately if it produces smoke, a strange odor, or
unusual noise. Continued use may lead to fire. Immediately unplug the
equipment, and contact your dealer or a Seiko Epson service center for
advice.
Never attempt to repair this product yourself. Improper repair work can be
dangerous.
Never disassemble or modify this product. Tampering with this product may
result in injury or fire.
Be sure to use the specified power source. Connection to an improper power
source may cause fire.
Do not allow foreign matter to fall into the equipment. Penetration by foreign
objects may lead to fire.
If water or other liquid spills into this equipment, unplug the power cord
immediately, and then contact your dealer or a Seiko Epson service center for
advice. Continued usage may lead to fire.
Do not use aerosol sprayers containing flammable gas inside or around this
product. Doing so may cause fire.
CAUTION:
Do not connect cables in ways other than those mentioned in this manual.
Different connections may cause equipment damage and burning.
Be sure to set this equipment on a firm, stable, horizontal surface. Product may
break or cause injury if it falls.
Do not use in locations subject to high humidity or dust levels. Excessive humidity
and dust may cause equipment damage or fire.
Do not place heavy objects on top of this product. Never stand or lean on this
product. Equipment may fall or collapse, causing breakage and possible injury.
Take care not to injure your fingers on the manual cutter
•Whenyouremoveprintedpaper
• When you perform other operations such as loading/replacing roll paper
To ensure safety, unplug this product before leaving it unused for an extended
period.

TM-H6000III User’s Manual 3
English
Do not touch the thermal head or paper feed motor. Wait for the head and the
motor to be cool. The head and the motor can be very hot after printing for a
long time. Touching them may cause burns.
Safety Labels
The caution labels on the product indicate the following precautions.
WARNING:
Do not connect a telephone line to the drawer kick-out connector or the
display module connector; otherwise, the printer and the telephone line may
be damaged.
CAUTION:
The thermal head and paper feed motor for the thermal section are hot.
CAUTION:
Caution label for autocutter blade.
Important Installation Notes
❏For a serial interface, use a null modem cable.
❏For a parallel interface, use an IEEE 1284 cable.
❏For a USB interface, install the driver before connecting the printer.
Restriction of Use
When this product is used for applications requiring high reliability/safety, such
as transportation devices related to aviation, rail, marine, automotive, etc.;
disaster prevention devices; various safety devices, etc.; or functional/precision
devices, etc.; you should use this product only after giving consideration to
including fail-safes and redundancies into your design to maintain safety and
total system reliability. Because this product was not intended for use in
applications requiring extremely high reliability/safety, such as aerospace
equipment, main communication equipment, nuclear power control equipment,
or medical equipment related to direct medical care, etc., please make your own
judgment on this product’s suitability after a full evaluation.
Purpose of This Manual
This manual applies to the standard model and the image scanner (gray scale)
model of the TM-H6000III, and provides information describing basic operations
to operators of the TM-H6000III to enable safe and correct use of the printer.
Unpacking
*1: Only for models with endorsement printers
❏Printer ❏Roll paper
❏Ribbon cassette ❏Endorsement ribbon cassette*1
❏Power switch cover ❏User’s Manual (This manual)

4 TM-H6000III User’s Manual
English
Downloading Drivers, Utilities, and Manuals
Drivers, utilities, and manuals can be downloaded from the following URL.
http://www.epson-pos.com/
Part Names
Control Panel (LEDs and Buttons)
POWER LED
Lights when the power is on and is off when the power is off.
ERROR LED
Off when the printer is online, lights when the printer is offline, and flashes when
an error occurs.
PAPER OUT LED
Lights when roll paper is out or nearly out.
SLIP LED
Lights when a slip is being printed or scanned. Flashes while waiting for a slip to
be inserted or removed.
FEED button
Feeds the roll paper.
RELEASE button
Releases a slip.
Power Switch Cover
See illustration A.
You can use the enclosed power switch cover to make sure that the power switch
is not accidentally pressed. Just press the cover into place to install it.
WARNING:
If an accident occurs when the power switch cover is attached, immediately
unplug the power supply cable to avoid fire.
unit cover
roll paper cover
front cover
power switch
control panel

TM-H6000III User’s Manual 5
English
Installing the Roll Paper
See illustration B.
Note:
Do not use paper rolls that have the paper glued or taped to the core because they might
cause a paper jam.
To prevent paper jams, make sure that nothing obstructs paper coming out of the paper
exit, and do not pull the paper out of the printer.
Installing the Ribbon
See illustration C.
Use genuine Epson ERC-32 ribbon cassettes.
1. Turn on the printer. Turn the knob on the ribbon cassette. Open the front
cover of the printer, and insert the new ribbon.
2. Turn the knob 2 or 3 times, and check the ribbon position.
Inserting Slip Paper
See illustration D.
Note:
Be sure that the slips are flat, without curls, folds, or wrinkles.
MICR Reading/Image Scanning/Printing
(Factory installed options)
With the scanning function, when a check is inserted into the printer, the check
image is digitized and stored, which saves check processing time and cost. Epson
recommends the following sequence for single-pass processing. The single pass
eliminates the need to turn the check paper over.
1. MICR reading
2. Pre-scanning
3. Endorsement printing (printing on back)
4. Printing on front
5. VOID printing
6. Scanning
Notes on Using the Slip Image Scanner
❏Be sure to include the pre-scanning step because it can minimize as much as
possible problems of decreasing image data quality caused by environmental
temperature, wear of scanner parts, great variation in color shading of the
background of a check, and input voltage fluctuation.
❏The quality of image scanning on the front of a check may be reduced by a
large variation in density of an ink ribbon cassette.

6 TM-H6000III User’s Manual
English
❏Be sure to consider these other conditions that may reduce image quality:
• Extremely low density of handwriting on the front of a check.
• Extremely high density of the background of a check.
• An extremely large variation in the density and color tone of the
background of a check.
• Many folds or wrinkles in a check.
• Exposure of the image scanning part of the printer to strong sunlight.
• Any foreign object, such as sand, entering the printer and scratching the
glass surface of the scanner.
CAUTION:
Do not insert checks with staples in them. This may cause paper jams, MICR
reading errors, and damage to the MICR head.
Be sure the checks are flat, without curls, folds, or wrinkles.
Follow the steps below to use the slip image scanner. (See illustration E.)
1. Wait until the SLIP LED flashes. Then insert the check face up with the right
side of the check against the right side of the paper guide as far as it will go.
Be sure that the MICR characters are on the right. See the arrow in the
illustration for the proper location of the MICR characters.
2. The printer will detect the check and start drawing it in. When the printer
starts drawing it in, let go of the check immediately. When the printer ejects
the check and the SLIP LED starts flashing again, remove the check by pulling
it straight out; do not pull it at an angle.
Notes on Using the MICR reader
Do not install the printer near any magnetic fields. Be especially careful where you
install your display device, and be sure to check the recognition rate of the MICR
reader with the display device in place.
Make sure that the printer is not subjected to any impact or vibration when it is
performing a MICR reading.
Endorsement Printing
See illustration F.
If your printer has the optional endorsement printing mechanism, install the
endorsement ribbon following the steps below.
Use genuine Epson ERC-41 ribbon cassettes.
Note:
Be sure to turn on the power before installing a ribbon cassette.
1. Turn the ribbon cassette knob. Then open the unit cover.
2. Inside the printer, push the levers backward to open the unit.
Note:
Do not open the unit during printing.
3. Insert the ribbon and turn the knob again to seat the ribbon; then close the
printer.

TM-H6000III User’s Manual 7
English
Cleaning
Cleaning the Printer Case
Be sure to turn off the printer, and wipe the dirt off the printer case with a dry
cloth or a damp cloth.
CAUTION:
Never clean the product with alcohol, benzine, thinner, or other such solvents.
Doing so may damage or break the parts made of plastic and rubber.
Cleaning the Thermal Head
CAUTION:
After printing, the thermal head can be very hot. Be careful not to touch it. Also
let it cool before you clean it.
Do not damage the thermal head by touching it with your fingers or any hard
object.
To keep good print quality, remove paper dust from the thermal head as follows.
(See illustration G.)
Be sure that the printer is turned off. Open the roll paper cover and clean the
thermal element (the part indicated by the arrow in the illustration) of the thermal
head with a cotton swab moistened with an alcohol solvent (ethanol or IPA).
Clean the thermal head periodically (generally every 3 months) to maintain
receipt print quality.
Cleaning the MICR Mechanism
Foreign matter in the mechanism can cause MICR reading errors. Clean the MICR
head with a moistened cleaning sheet approximately every 12 months.
Use the following or an equivalent commercially available cleaning sheet:
KIC Products "Waffletechnology®MICR cleaning card"
Note:
Be sure not to use an adhesive cleaning sheet.
Follow the steps below:
1. Load roll paper in the printer, turn off the power, then open the roll paper
cover and turn the power back on while holding down the RELEASE button.
2. Press the RELEASE button 7 times, then
close the roll paper cover. The printer
prints the following message on receipt
paper, and the SLIP LED flashes.
3. Insert the cleaning sheet like a standard check.
CAUTION:
Be sure that the sheet is inserted with the correct side up and that it is
inserted in the correct direction.
Use a cleaning sheet only one time; then discard it.
4. When the sheet is ejected, press the RELEASE button, and remove the sheet
from the printer.

8 TM-H6000III User’s Manual
English
Cleaning the Slip Image Scanner
See illustration H.
The glass part of the scanner (indicated by the arrows in the illustration) may
become dirty due to ink or paper dust, which can decrease the image quality. To
avoid this, clean the glass part every 12 months.
1. Open the unit cover.
2. Inside the printer, push the levers backward to open the unit.
3. Wipe the glass gently with a soft, dry cloth.
Note:
When cleaning the scanner glass, do not use any liquid, such as detergent, benzine, or
water.
Liquids can reach the back of the scanner glass and cause it to become dirty. If the scanner
glass has foreign matter that is hard to remove, such as oil or grease, you can wet a cloth a
little with alcohol and wipe the scanner glass, but never put any liquid directly on the
scanner glass.
Troubleshooting
ERROR LED is on or flashing.
❏The print head temperature may be extremely high. Wait until the print head
cools and the printer resumes printing automatically.
❏Make sure that the roll paper and unit cover are properly closed.
❏Turn off the printer, and check for a paper jam.
❏The autocutter may be jammed. See the description below.
❏Turn off the power, wait several seconds, and then turn it on again. If the
error remains, contact your qualified service person.
The autocutter is jammed or the roll paper cover will not open.
1. Turn off the printer, and open the unit cover.
2. Then turn the knob (A) until you see a pin (B) in the opening. See
illustration I.

TM-H6000III User’s Manual 9
English
Specifications
TM-H6000III
*1: Be sure to use a safety-standards-applied power source that meets the following specifications.
Rated output: 24 V/2.0 A or more, Maximum output: 240 VA or less
Image Scanner
Print method Receipt: Thermal line
Slip: 9-pin serial impact dot matrix
Endorsement: 8-pin shuttle impact dot matrix
Print font Receipt: 9 × 17 / 12 × 24
Slip: 5 × 9 / 7 × 9
Endorsement: 5 × 7
Columns Receipt: 56/42
Slip: 60/45
Endorsement: 40
Character size
(W × H)
Receipt: 0.99 × 2.40 mm {0.04 × 0.09"}
1.41 × 3.39 mm {0.06 × 0.13"}
Slip: 1.56 × 3.1 mm {0.06 × 0.12"}
1.24 × 3.1 mm {0.05 × 0.12"}
Endorsement: 1.1 × 2.42 mm {0.04 × 0.10"}
Character sets 95 alphanumeric, 37 international characters
128 × 11 (slip: 12) pages extended graphic characters
Print speed Receipt: 63, Slip: 5.14, Endorsement: 1.9 (lines per second)
Paper dimensions Receipt: Thermal roll paper 79.5 ± 0.5 × 83 mm {3.1 ± 0.02 × 3.3"}
Slip/endorsement: 70 ~148 × 150 ~ 210 mm {2.8 ~ 5.8 × 5.9 ~ 8.3"} (W × L)
Paper thickness Slip (single-ply): 0.09 ~ 0.2 mm {0.0035 ~ 0.0079"}
Endorsement: 0.09 ~ 0.2 mm {0.0035 ~ 0.0079"}
Copy capability Receipt/Endorsement: Single-ply
Slip: 1 original + 3 copies
Inked ribbon Slip: ERC-32
Endorsement: ERC-41
Interface (compatible) RS-232/Bi-directional parallel/RS-485/USB (dealer option)
Data buffer 45 bytes/4 KB
D.K.D. function 2 drives
Power supply*1 +24 VDC ± 10%
Current consumption Slip: Approximately 1.7 A (mean)
Receipt: Approximately 1.8 A (mean)
Temperature Operating: 5 to 45°C {41 to 113°F}
Storage: -10 to 50°C {14 to 122°F}
Humidity 10 to 90% without condensation
Overall dimensions 185 × 186 × 298 mm {7.28 × 7.32 × 11.73"} (H × W × D)
Mass Approximately 5.4 kg {11.9 lb}
Image scanner type CIS (Contact Image Sensor)
Resolution 200 dpi × 200 dpi (W × H)
(dpi: dots per inch [number of dots per 25.4 mm {1"}])
Image scanning mode Black and white / Gray scale
Image scanning area Width: 100 mm (typ.)
Image scanning speed 120 mm/s
Data compression Black and white: CCITT Group 4
Gray scale: JPEG
Data transmission format Black and white:
TIFF (If data is not compressed, the format is raw data or BMP.)
Gray scale:
JFIF (If data is not compressed, the format is raw data, BMP, or TIFF.)

10 TM-H6000III User’s Manual
English

TM-H6000III Petunjuk Penggunaan 11
English
Bahasa Indonesia
Petunjuk Penggunaan
Ilustrasi
Semua ilustrasi terdapat di bagian awal manual ini. Ilustrasi tersebut mungkin kelihatan berbeda dengan
printer Anda, bergantung pada model printer Anda. Ilustrasi tersebut diidentifikasi dengan huruf (A, B,
C. . .). Dalam teks, ilustrasi tersebut dirujuk dengan huruf-huruf ini. (“Lihat ilustrasi A,” sebagai contoh.)
Tabel Sakelar DIP
Tabel sakelar DIP terdapat di bagian awal manual ini.
Semua hak dilindungi. Bagian publikasi ini tidak boleh diproduksi ulang, disimpan di sistem
pengambilan, atau dikirimkan dalam bentuk atau cara apa pun, elektronik, mekanis, memfotokopi,
merekam, atau lainnya, tanpa izin tertulis Seiko Epson Corporation sebelumnya. Tidak ada pertanggung
jawaban paten yang diasumsikan berkenaan dengan penggunaan informasi yang terdapat di dalamnya.
Karena setiap perhatian telah diambil dalam persiapan buku ini, Seiko Epson Corporation
mengasumsikan tidak ada tanggung jawab untuk kesalahan atau penghilangan. Tidak ada pertanggung
jawaban apa pun yang diasumsikan untuk kerusakan yang dihasilkan penggunaan informasi yang
terdapat di dalamnya.
Baik Seiko Epson Corporation maupun afiliasinya tidak akan bertanggung jawab pada pembeli produk
ini atau pihak ketiga atas kerusakan, kerugian, biaya, atau pengeluaran yang dikenakan oleh pembeli
atau pihak ketiga sebagai akibat dari: kecelakaan, kesalahan penggunaan atau penyalahgunaan produk
ini atau modifikasi, perbaikan, perubahan yang tidak resmi pada produk ini, atau (tidak termasuk A.S.)
kegagalan dalam mematuhi instruksi pengoperasian dan perawatan Seiko Epson Corporation.
Seiko Epson Corporation tidak akan bertanggung jawab terhadap kerusakan atau masalah yang timbul
dari penggunaan opsi apa pun atau produk habis pakai apa pun selain yang ditunjuk sebagai Produk
Epson Asli atau Produk yang Disetujui Epson oleh Seiko Epson Corporation.
EPSON adalah merek dagang terdaftar dari Seiko Epson Corporation di Jepang dan negara/wilayah
lainnya.
PEMBERITAHUAN: Isi manual ini dapat berubah tanpa pemberitahuan.
Hak cipta © 2011 oleh Seiko Epson Corporation

12 TM-H6000III Petunjuk Penggunaan
English
Informasi Keselamatan Penting
Bagian ini menyajikan informasi penting yang dimaksudkan untuk memastikan
penggunaan produk ini dengan aman dan efektif. Baca bagian ini dengan saksama
dan simpanlah di lokasi yang mudah diakses.
Kunci untuk Simbol
Simbol dalam manual ini diidentifikasi menurut tingkat kepentingannya, seperti
didefinisikan di bawah. Baca peringatan berikut dengan saksama sebelum
menangani produk.
PERINGATAN:
Peringatan harus dipatuhi dengan saksama untuk menghindari cedera parah.
PERHATIAN:
Perhatian harus dipatuhi untuk menghindari cedera ringan pada diri Anda
atau kerusakan pada peralatan.
Perhatian Keselamatan
PERINGATAN:
Matikan peralatan Anda segera jika mengeluarkan asap, bau aneh, atau
kebisingan tidak biasa. Penggunaan yang berkelanjutan bisa mengakibatkan
kebakaran. Cabut peralatan dengan segera, dan hubungi dealer Anda atau
pusat layanan Seiko Epson untuk mendapatkan nasihat.
Jangan pernah berusaha untuk memperbaiki produk ini sendiri. Pekerjaan
perbaikan yang tidak tepat bisa berbahaya.
Jangan pernah membongkar atau memodifikasi produk ini. Merusakkan
produk ini bisa mengakibatkan luka atau terbakar.
Pastikan menggunakan sumber daya khusus. Koneksi ke sumber daya yang
tidak tepat bisa mengakibatkan kebakaran.
Jangan biarkan bahan asing masuk ke dalam peralatan. Penetrasi oleh benda
asing bisa mengakibatkan kebakaran.
Jika air atau cairan lainnya tumpah ke dalam peralatan ini, segera cabut
kabel daya, lalu hubungi dealer Anda atau pusat layanan Seiko Epson untuk
mendapatkan nasihat. Penggunaan yang berkelanjutan bisa mengakibatkan
kebakaran.
Jangan gunakan penyemprot aerosol yang berisi gas yang mudah terbakar di
dalam atau di sekitar produk ini. Jika dilakukan bisa berakibat kebakaran.
PERHATIAN:
Jangan menyambung kabel dengan cara selain yang disebutkan dalam
manual ini. Sambungan yang berbeda bisa mengakibatkan kerusakan atau
kebakaran peralatan.
Pastikan untuk menyetel peralatan ini pada permukaan datar yang kokoh dan
stabil. Produk bisa pecah atau mengakibatkan cedera jika jatuh.
Jangan gunakan produk ini di lokasi dengan tingkat kelembaban dan debu
tinggi. Kelembaban dan debu yang berlebihan bisa mengakibatkan peralatan
rusak atau terbakar.
Jangan letakkan benda berat di atas produk ini. Jangan pernah berdiri atau
bersandar pada produk ini. Peralatan bisa jatuh atau roboh, yang
mengakibatkan pecah atau kemungkinan luka.

TM-H6000III Petunjuk Penggunaan 13
English
Berhati-hatilah agar jari Anda tidak terluka di pemotong manual
• Saat Anda melepas kertas yang sudah dicetak
• Saat Anda melakukan operasi lainnya seperti memasang/mengganti
kertas kasir
Untuk memastikan keselamatan, cabut produk ini sebelum meninggalkannya
dalam keadaan tidak terpakai untuk periode yang lama.
Jangan sentuh kepala termal atau motor umpan kertas. Tunggu kepala cetak
dan motor menjadi dingin. Kepala cetak dan motor dapat menjadi sangat
panas setelah pencetakan dalam waktu lama. Menyentuhnya bisa
menyebabkan luka bakar.
Label Keselamatan
Label perhatian pada produk mengindikasikan perhatian berikutnya.
PERINGATAN:
Jangan sambungkan kabel telepon ke laci konektor keluar atau konektor
modul tampilan; jika tidak, printer dan kabel telepon bisa rusak.
PERHATIAN:
Kepala termal dan motor umpan kertas untuk komponen termal panas.
PERHATIAN:
Label perhatian untuk pisau pemotong otomatis.
Catatan Penting Pemasangan
❏Untuk antarmuka seri, gunakan kabel modem nol.
❏Untuk antarmuka paralel, gunakan kabel IEEE 1284.
❏Untuk antarmuka USB, pasang driver sebelum menyambungkan printer.
Batasan Penggunaan
Saat produk ini digunakan untuk aplikasi yang memerlukan keandalan/
keselamatan tinggi seperti alat transportasi yang terkait dengan penerbangan,
kereta api, laut, atau otomotif dll.; alat penanggulangan bencana; beragam alat
keselamatan dll.; atau alat fungsional/presisi dll., Anda harus menggunakan
produk ini hanya setelah mempertimbangkan penyertaan keselamatan-kegagalan
dan cadangan ke dalam rancangan Anda untuk menjaga keselamatan dan
keandalan sistem keseluruhan. Karena produk ini tidak dimaksudkan untuk
penggunaan pada aplikasi yang memerlukan keandalan/keselamatan yang
sangat tingi seperti peralatan ruang angkasa, peralatan komunikasi utama,
peralatan pengontrol tenaga nuklir, atau peralatan medis terkait dengan
perawatan medis dll., buat pertimbangan sendiri atas kesesuaian produk ini
setelah evaluasi penuh.
Tujuan Manual Ini
Manual ini berlaku untuk model standar dan model pemindai gambar (skala abu-
abu) dari TM-H6000III dan memberikan informasi yang menguraikan operasi
dasar kepada operator TM-H6000III untuk memungkinkan penggunaan printer
dengan aman dan benar.

14 TM-H6000III Petunjuk Penggunaan
English
Membuka kemasan
*1: Hanya untuk model dengan printer endosemen
Mendownload Driver, Utilitas, dan Manual
Driver, utilitas, dan manual dapat didownload dari URL berikut.
http://www.epson-pos.com/
Nama Komponen
Panel Kontrol (LED dan Tombol)
LED POWER (Daya)
Menyala apabila daya hidup dan mati apabila daya mati.
LED ERROR (Kesalahan)
Mati saat printer online, menyala saat printer offline, dan berkedip saat terjadi
kesalahan.
LED PAPER OUT (Kertas keluar)
Menyala apabila kertas kasir keluar atau hampir keluar.
LED SLIP (Struk)
Menyala saat struk dicetak atau dipindai Berkedip saat menunggu struk
dimasukkan atau dikeluarkan.
Tombol FEED (Umpan)
Mengumpan kertas kasir.
Tombol RELEASE (Lepaskan)
Melepaskan struk.
❏Printer ❏Kertas kasir
❏Kaset pita ❏Kaset pita endosemen*1
❏Penutup sakelar daya ❏Petunjuk Penggunaan (Manual
ini)
penutup unit
penutup
kertas kasir
tutup depan
sakelar daya
panel kontrol
