Designed with your installation needs in mind, the Epson PowerLite
Pro G5150NL and G5350NL each offer the perfect solution for any
auditorium, classroom or boardroom. With 4000/5000 lumens and
XGA resolution, these powerful, network-ready performers ensure
amazing presentations. Engineered to interface and integrate more
easily with sophisticated programming and controller applications
— both IP and RS-232 — these products work with modules and
drivers for industry-leading systems that can include touch-panel
screens and multiple content devices. And, they’re ready for future
technology, including systems with built-in HDMI, digital and
wireless capabilities.
Engineered to integrate seamlessly with existing systems, the
G5150NL and G5350NL include a full feature set that ensures easy
installation with greater flexibility. Their unique networking capabilities
allow you to send presentations over the network both wirelessly or
through the wired LAN. And, Epson Easy Management™ gives your
system administrators the power to remotely monitor and control
your projectors.
Add to that the easy maintenance features and you’ve got everything
you need for brilliant presentations and a better bottom line. With
one-touch filter removal and easy side lamp access, these projectors
offer a low cost of ownership and added peace of mind. They
even include a closed captioning decoder, so there are no added
costs to accommodate the hearing impaired. The Epson PowerLite
Pro G5150NL and G5350NL are ideal choices for both executive
boardrooms and educational institutions, with the value, power and
performance for all your presentation needs.
Features/Benefits
• Amazingpresentationsinanyclassroomorboardroom—5000
lumens(G5350NL)/4000lumens(G5150NL),XGAresolution
• Industry-leadingsystemsupport—advancedconnectivity:two
computerRGBinputs,threecomponentconnections(5BNCand
HD15)andanHDMIdigitalportwithHDCP
• Greaterpositioningflexibility—centeredlensdesign,vertical/
horizontallensshiftmechanismandstandardlenswith1.8xwider
zoom(lenssoldseparately)
• Closedcaptioningcapabilitieswithoutanyaddedcosts—
built-indecoder
• DirectOnandDirectOff—powerinstalledprojectorsoffandon
withtheflipofanoutletswitch
• Superiorcoloranddetail—1000:1contrastratio
• Greaterinstallationflexibilitywithoptionalbayonetlenses—five
easilyexchangeableEpsonlensesavailable;standardlensfor
ceiling-mountedapplications(lenssoldseparately)
• Convenientmaintenancefeatures—fast,easyfiltercleaningand
replacement,easysideaccesstothelamp
• Wirelesspeer-to-peerconnections—optionalwirelesscardfor
evengreaterflexibility(cardnotrequiredifnetworkcontainsa
reachableaccesspoint)
• Easyimagesetup—convenientQuickCorner®function
• Easymonitoringandcontrol—RJ-45withEpsonmonitoring
softwareincluded
• Singleoff-axisinstallation—30-degreetiltoperation
G5150NL and G5350NL Top
G5150NL and G5350NL Front
G5150NL and G5350NL Remote
USB Type B
Speaker
SD Card Slot
RCA Audio
LAN
Audio
Composite Video 2
HDMI
S-Video
Audio
Computer 2/Component 2
Computer 1/Component 1
BNC Composite Video
Remote
Audio Out
Monitor Out
Control Panel
Power RS-232c
Component 5BNC
USB Type A
PowerLite®Pro
G5150NL and G5350NL
Precision control and a low cost of ownership.
G5150NL and G5350NL Back
Lens not included

Projection System
High-aperture Epson 3-chip 3LCD technology
Projection Method
Front/rear/ceiling mount
LCD
Driving Method
Epson Poly-silicon TFT Active Matrix
Pixel Number
786,432 pixel x 3 LCDs (1024 x 768)
Native Resolution
XGA
Aspect Ratio
Supports 4:3, 16:9, 16:10
Pixel Arrangement
Cross stripe
Projection Lens
Type
Manual focus/zoom
F-number
1.64 – 2.5 (standard lens), lens not included
Focal Length
21.27 mm – 37.93 mm (standard lens)
Zoom Ratio
Optical zoom 1.0 – 1.8
Lamp
Type
G5150NL: 210 W UHE
G5350NL: 275 W UHE
Lamp Life*
2000 hours (High Brightness Mode)
3000 hours (Low Brightness Mode)
Screen
Throw Ratio Range
1.64" – 2.5"
Size (projected distance)
30" – 300"
Lens Shift
Vertical: ±50 degrees
Horizontal: ±10 degrees
Keystone Correction
Vertical: -40 degrees to +40 degrees
Horizontal: -20 degrees to +20 degrees
Brightness (High Brightness Mode)
G5150:
Light output — white: up to 4000 lumens (ISO 21118)
Light output — color: up to 4000 lumens
G5350:
Light output — white: up to 5000 lumens (ISO 21118)
Light output — color: up to 5000 lumens
Contrast Ratio (High Brightness, Game Mode)
Up to 1000:1
Brightness Uniformity (typical)
86% G5150NL, 88% G5350NL
Color Reproduction
16.7 million colors
Dimensions (W x D x H)
Including Feet (with standard lens)
18.5" x 13.26" x 5.94"
Excluding Feet, Lens
18.5" x 12.27" x 5.31"
Weight
G5150NL: 14.8 lb
G5350NL: 15.0 lb
Effective Scanning Frequency Range
Pixel Clock
13.5 MHz – 162 MHz (up to UXGA 60 Hz)
Horizontal
15 KHz – 99 KHz
Vertical
50 Hz – 120 Hz
Remote Control
Features
Source search selection, power, aspect resize, color
mode, volume, e-zoom, A/V mute, freeze, menu,
page up and down, help, auto, mouse functions, ID
Operating Angle
Right/left ± 60 degrees
Upper/lower ± 20 degrees
Rear ± 30 degrees
Operating Distance
40 ft (6 m)
Display Performance
Native
1024 x 768
Resize
640 x 480
800 x 600
1280 x 1024
1400 x 1050
1600 x 1200
Video I/O
Display Performance
NTSC: 560 line
PAL: 560 line
(depends on observation of the multi-burst pattern)
Input Signal
NTSC/NTSC4.43/PAL/M-PAL/N-PAL/PAL60/
SECAM
SDTV: 480i, 480p; HDTV: 720p, 1080i
Pixel works: video chip
3D Y/C separation, noise reduction motion
compensated
Interlace-Progressive conversion (2 – 2,
3 – 2 film detection)
Interfaces
Computer/component video: mini D-sub HD 15 pin x 2
5BNC component x1
HDMI x1
Hardwire remote jack x1
S-video: mini DIN x 1
Composite video RCA x 1, composite x 1 BNC
Audio in (RCA (L & R) x 1, mini stereo x 1)
Variable audio out: mini stereo x 1
LAN networking: RJ-45 x 1, 10/100MB
Serial: RS-232c x 1
USB A x 1, USB B x 1
Monitor out: mini D-sub 15 pin x 1
SD card slot
Other Features
Audio Output
7 W monaural
Audio Signal
500 m Vrms/47K ohm
Operating Temperature
32 ˚ to 104 ˚F (0 ˚ to 40 ˚C)
Power Supply Voltage
100 – 240 V ±10%, 50/60 Hz AC
Power Consumption
G5150NL: 343 W
G5350NL: 423 W
0.6 W standby (network off)
Fan Noise
G5150NL:
35 dB (High Brightness Mode)
29 dB (Low Brightness Mode)
G5350NL:
38 dB (High Brightness Mode)
31 dB (Low Brightness Mode)
Security
Kensington®-style lock provision, anchor (metal) bar
for security lock or cable
Support — Epson ConnectionSM
Pre-sales support
U.S. and Canada 800-463-7766
Internet website www.epson.com
Projector resources available at presentersonline.com
Service Programs
Three-year limited warranty, 90-day lamp warranty,
Epson Road Service Program and Epson PrivateLine®
dedicated toll-free support (U.S. and Canada only)
Contents
Power cable, computer cable, projector remote control,
batteries, cable cover, user manual CD, NS connection
monitor, Quick Setup Sheet, PrivateLine support card,
password protection sticker
Accessory Part Numbers
Standard zoom lens <1.64 – 2.5> V12H004S03
Long throw zoom lens <1.84 – 2.32> V12H004L06
Middle throw zoom lens 1 <1.83 – 2.45> V12H004M04
Middle throw zoom lens 2 <1.83 – 2.53> V12H004M05
Rear projection wide lens <2.03> V12H004R03
802.11 wireless g/b/a module V12H306P11
Wireless mouse receiver for
Remote control (ELPST16) V12H007T16
Air filter V13H134A17
Hardware remote control cable set V12H005C28
Replacement remote control 1485872
Advanced projector ceiling mount
with precision gear ELPMBPRG
High security projector ceiling mount ELPMBATA
Adjustable suspended ceiling channel kit ELPMBP01
False ceiling plate kit ELPMBP02
Structural round ceiling plate ELPMBP03
Adjustable extension column (pipe) 6” – 9” ELPMBC01
Kensington security lock ELPSL01
50-inch portable screen (4:3 aspect ratio) ELPSC06
60-inch portable pop-up screen
(4:3 aspect ratio) ELPSC07
80-inch portable pop-up screen
(4:3 aspect ratio) ELPSC08
Duet™ portable projector screen
(4:3/16:9 combination) ELPSC80
Component to VGA video cable ELPKC19
S-video cable ELPSV01
Distribution amplifier ELPDA01
Image presentation camera (ELPDC05) V12H162020
Replacement Lamp for
G5150NL (ELPLP47) V13H010L47
Replacement Lamp for
G5350NL (ELPLP46) V13H010L46
Projector Part Numbers
PowerLite Pro G5150NL V11H273920
PowerLite Pro G5350NL V11H286920
Epson PowerLite Pro G5150NL and G5350NL Specifications
Packaging Specifications
PowerLite Pro G5150NL and G5350NL
Dimensions 19.9" x 25.3" x 12.2" (W x D x H)
Weight 23.3 lb
Replacement Lamp
Dimensions 6.3" x 5.6" x 5.6" (W x D x H)
Weight 0.97 lb
Master Carton
Dimensions 28.4" x 13.1" x 6.8" (W x D x H)
Weight 11.7 lb
Units Per Master Carton 10
Replacement Air Filter
Dimensions 11.14" x 3.59" x 1.73" (W x D x H)
Weight 0.21 lb
Master Carton
Dimensions 19.17" x 11.78" x 4.84" (W x D x H)
Weight 3.09 lb
Units Per Master Carton 10
Specifications and terms are subject to change without notice. Epson and Quick Corner are registered trademarks, Epson Exceed Your Vision is a registered logomark and Easy Management is a trademark of
Seiko Epson Corporation. PowerLite and PrivateLine are registered trademarks, Duet is a trademark and Epson Connection and Epson PresentersOnline are service marks of Epson America, Inc. All other product
and brand names are trademarks and/or registered trademarks of their respective companies. Epson disclaims any and all rights in these marks. Copyright 2008 Epson America, Inc. CPD-24957 5/08 PDF
Epson America, Inc.
3840 Kilroy Airport Way, Long Beach, CA 90806
Epson Canada, Ltd.
3771 Victoria Park Avenue, Toronto, Ontario M1W 3Z5
www.epson.com
www.epson.ca
* Lamp life results will vary depending upon mode selected, environmental conditions and usage. Lamp brightness decreases over time.
