Epygi Quadro Series User manual

Epygi Technologies
How to Configure Fermax IP DP device
on the Quadro IP PBX
Revision Revised By Date
Initial draft Harutyun Gerasimenko 20-May-11
valid for Quadro IP
PBX SW-version: 5.2.x and higher
tested with
SW version: 5.2.21
Filename: ConfiguringFermaxIPDPdevice.doc
Version: 1.0
Last saved: 27/07/2011 14:43:52
Revision: 1.0
Abstract: This document describes how to configure Quadro
IP PBX with the Fermax Audio and Video Door Entry IP DP
1CP201 device (cityline series), hereafter referred as Fermax
IP DP device.
Please Note: This document contains confidential and proprietary information owned by Epygi Technologies Ltd. Any copying, use or disclosure of
the document or the information contained herein without the written permission of Epygi Technologies Ltd. is strictly prohibited.

Epygi Technologies Configuring Quadro with Fermax IP DP device
Document Revision History
Revision Date Description Valid for SW Valid for models
1.0 27-Jul-11 Initial release 5.2.x Quadro IP PBXs
PAGE 2 27-Jul-11

Epygi Technologies Configuring Quadro with Fermax IP DP device
Table of Contents:
1Introduction........................................................................4
2Requirements and Preparations..........................................4
3Configuration ......................................................................4
3.1 Configuring the Quadro IP PBX................................................ 5
3.2 Fermax IP DP Device Configuration as IP Line of Quadro IP PBX... 7
4IP Video Phone configuration notice .................................11
5References ........................................................................11
PAGE 3 27-Jul-11

Epygi Technologies Configuring Quadro with Fermax IP DP device
1Introduction
Quadro IP PBXs provide the option of using SIP phones/devices along with standard analogue
phones. SIP phones/devices are connected to any network interface of Quadro via Ethernet and
serve as additional extensions similar to onboard FXS extensions. The Quadro can be configured to
serve IP phones connected to either LAN or WAN interfaces (see Figure 1, 2). Some products like
Quadro6L and QuadroM32x are configured to have IP phones/devices connected to WAN interface
by default.
To allow SIP phones/devices to function as Quadro extensions, both the SIP phones/devices and
the Quadro should be appropriately configured.
Figure 1: IP Phone connected to the Quadro LAN Figure 2: IP Phone connected to the Quadro WAN
This document describes how to configure Fermax IP DP device connected to the Quadro LAN or WAN.
2Requirements and Preparations
•The Quadro IP PBX is connected to the network and all network settings are correctly
configured.
•Fermax IP DP device is located in the network, available through the interface which is
selected as “Network Interface” on IP Line Settings page and powered up.
•SW version 5.2.x or higher running on the Quadro IP PBX.
•Valid for Fermax IP DP device VoIP version: 1.53, UDV version: 3.5 and higher.
3Configuration
In general there are two ways to configure Quadro with Fermax IP DP device:
1. Register device as IP Line of Quadro IP PBX. This kind of configuration is described in
Section 3.1 and Section 3.2.
2. Configure Fermax IP DP device as standalone device, and configure routing rules on
Quadro IP PBX to forward calls to the device. This kind of configuration is not described in
current manual.
PAGE 4 27-Jul-11

Epygi Technologies Configuring Quadro with Fermax IP DP device
3.1 Configuring the Quadro IP PBX
To configure the Quadro, login to the Quadro Web Management from your PC and configure the IP
Line that will be used for the Fermax IP DP device to register to the Quadro:
1. Log into the Quadro as an administrator and access Telephony->Line Settings->IP Line
Settings page.
2. From the Attached Extension column, choose an extension to be assigned to the SIP
device and click on the corresponding IP line link (see Figure 3).
Figure 3
3. Configure the IP line as follows:
•Select the SIP Phone radio button (see Figure 4).
•Select Other from the Phone Model drop down list.
•Specify the number for simultaneous calls – the total number of active and held
calls, in the Line Appearances text box. Set this field to 2, thus only 2 active call
will be possible to have on the phone. Making or accepting a third call will not be
allowed by Quadro (please note that having bigger number of simultaneous calls to
camera can overload it).
•Specify Username and Password fields.
Please Note: The same Username and Password should be specified when configuring
GXV 36xx device.
•Click Save to submit the changes.
PAGE 5 27-Jul-11

Epygi Technologies Configuring Quadro with Fermax IP DP device
Figure 4
Please Note: IP lines table lists only the extensions attached to the IP lines. If the extension is
not listed on this page, go to Users ->Extensions Settings page and attach an IP line to the
extension by editing the corresponding extension settings (see Figure 5).
Figure 5
PAGE 6 27-Jul-11

Epygi Technologies Configuring Quadro with Fermax IP DP device
To enable video, user should go to “Go To Codec Settings” link and enable H263 codec from that
page.
3.2 Fermax IP DP Device Configuration as IP Line of Quadro IP
PBX
To configure Fermax IP DP device as IP Line of Quadro IP PBX, one should change position of “DIP
Switch” number 2 (located at the back of the device).
DIP switch are shown at number 14 on the picture below:
DIP switch N 2 should be switched down to “SIP Server”:
PAGE 7 27-Jul-11

Epygi Technologies Configuring Quadro with Fermax IP DP device
•Log in to Fermax IP DP device using default 192.168.1.250 IP address (default user name
“admin”, default password “1234”).
•Click on “Network Settings” link and change IP address to the IP address in Quadro’s WAN or
LAN subnet (depending on the way of IP phones configured on the Quadro, either on LAN or on
WAN, please see Quadro’s configuration). Or set up DHCP based IP address, if you are sure that
DHCP provided address will be in the same subnet as Quadro’s WAN or LAN. Change default
gateway as deemed necessary. You can use Quadro’s IP address as default gateway and as DNS
also. Press “save and restart” – device will be rebooted and you will need to log in again to
device with new IP address.
Figure 6
•Next step will be to click on “SIP parameters” link (see Figure 7).
PAGE 8 27-Jul-11

Epygi Technologies Configuring Quadro with Fermax IP DP device
Figure 7
•Set up “SIP proxy server” -> “Address” to the IP address of Quadro’s interface used for
phones configuration.
•Set up “SIP proxy server” -> “Port” to the SIP UDP port of Quadro IP PBX (specified in
the UDP Port field of Quadro IP PBX in the Telephony->SIP Settings page).
•Set the same settings for “SIP registrar server” Address and Port.
•Set “Account Module” Name and Auth ID fields to the Username entered in “IP Line
Settings” page of Quadro IP PBX.
•Set up “Account Module” Password to the Password entered in “IP Line Settings” page
of Quadro IP PBX.
•Press “save changes” button. After a while you should see “Registration successful” status
as on the picture above.
Making video call to the extension attached to the Fermax IP line will result in automatic off hook of
the device and user can see and talk (if user has video phone) to the person at Fermax IP DP
device.
•The next step is to configure the Fermax IP DP device for making calls to Quadro IP PBX, by
using 2 pushbuttons locate on device (number 4 in the Figure 8):
PAGE 9 27-Jul-11

Epygi Technologies Configuring Quadro with Fermax IP DP device

Figure 8

•Press “memory number” link on the left part of WEB GUI of the phone (see Figure 9):

Figure 9
On Button 1, Button 2 user can set up any extension number or any routing rule number and
press “save changes” button. Pressing pushbutton will result in call to corresponding numbers,
and upon answered video call will be established.
PAGE 10 27-Jul-11

Epygi Technologies Configuring Quadro with Fermax IP DP device
4IP Video Phone configuration notice
Video phone making call to Fermax IP DP device, should support H263 video codec. If that video
IP phone is extension of Quadro IP PBX, H263 video codec should be enabled on that video
phone’s codecs list (see Figure 10).
Figure 10
Below is the list of Video IP phones that are tested to use for Video Conferencing:
•Polycom VVX1500
•Grandstream GXV3140
•Grandstream GXV 3175
•Yealink VP2009
5References
The following documents can be helpful for further configuration of the Quadro IP PBX. They can be
downloaded from Epygi’s WEB portal at www.epygi.com
•Quadro Manual II - Administrators Guide
PAGE 11 27-Jul-11
