ergoline Passion-S Series Technical manual

Planning Manual Stereo sound Ergoline Passion-S, Ergoline Flair and Beauty Angel C 28
Stereo sound Ergoline Passion-S, Ergoline Flair and Beauty Angel C 28 – 1
Stereo sound Passion-S, Flair...
The devices of the Ergoline Passion-S and Flair series and the
Beauty Angel C 28 can be equipped with optional stereo sound
Plus (see stereo sound Plus Ergoline Passion-S, Ergoline Flair
and Beauty Angel C 28) or stereo sound. Stereo sound
includes:
• 2 loudspeakers
• Connectivity features for external music
for Ergoline Passion-S and
Ergoline Flair series
and Beauty Angel C 28
Contents
Stereo sound description . . . . . . . . . . . . . . . . . . . . . 2
Sound package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Input for an external music source without
channel selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Stereo sound Ergoline Passion-S, Ergoline Flair and Beauty Angel C 28 Planning Manual
2 – Stereo sound Ergoline Passion-S, Ergoline Flair and Beauty Angel C 28
Stereo sound Passion-S, Flair...
1. Loudspeakers
2. Board with plug to connect an external audio system
Stereo sound description
1
2
40504 / 0
Sound package
Package Art. / Part No. Notes
Stereo sound 100002315 –
Technical data
Power supply: via the unit
Max. ambient temperature: 0 to 40 °C
Max. relative humidity: 70 %
Max. storage temperature: 0 to 50 °C
External connections: connectivity features for external music without channel selection
Weight: 4.75 kg

Planning Manual Stereo sound Ergoline Passion-S, Ergoline Flair and Beauty Angel C 28
Stereo sound Ergoline Passion-S, Ergoline Flair and Beauty Angel C 28 – 3
Stereo sound Passion-S, Flair...
The connected music source can be switched on or off.
1. External music source
2. Socket for connecting the cables to the audio system
(supplied)
Left left music channel +
GNDL left music channel –
GNDR right music channel –
Right right music channel +
Permissible input signal levels
Pre-amplifier: 600 mV to 3 V
or
Power amplifier: 5 V to 30 V
Input for an external music source without channel selection
1
2
40500 / 0
