Ergoswiss SLA 13 Series User manual

Operating instruction
Spindle lifting system SLA/SLG 13xx
with SCT4 iSMPS 24V and Exchangeable battery
Document no.: B-00421
Edition 2024 02
Operating instruction EN
Copyright by Ergoswiss AG
Page 1of 32
Operating instruction – Spindle lifting system SLA/SLG 13xx
with SCT iSMPS 24V and Exchangeable battery
It is essential to read this operating instruction thoroughly before commissioning the system.
The manual must be kept in close proximity to the system for future reference.

Linear unit of Type SLA or SLG
Control box SCT iSMPS 24V
Hand switch Memory
Exchangeable battery 24V
Errors and technical changes reserved.
Ergoswiss AG does not assume any liability for operating errors or
using the products outside of the intended purpose use.
At the time of delivery Ergoswiss AG will replace or repair defect
products within accordance with the warranty provisions.
In addition, Ergoswiss assumes no other liability.
For your questions and special custom demand Ergoswiss AG will
be at your disposal.
Ergoswiss AG
Nöllenstrasse 15
CH-9443 Widnau
Tel.: [phone]
Fax: [phone]
[e-mail]
www.ergoswiss.com
2
3
4
1
2
3

Operating instruction
Spindle lifting system SLA/SLG 13xx
with SCT4 iSMPS 24V and Exchangeable battery
Document no.: B-00421
Edition 2024 02
Operating instruction EN
Copyright by Ergoswiss AG
Page 2of 32
This operating instruction applies to:
Lifting systems SLA 13xx and SLG 13xx
with control box SCT iSMPS 24V and exchangeable battery
Example: Lifting system SLA.3 4330 EU/CH 12 Battery (Article number: 903.42536)
Example: Lifting system SLG.3 4330 EU/CH 12 Battery (Article number: 904.42536)
Description
Standard variations
SLA.3
Type of lifting element
SLA.3, SLG.3
4330
Number of lifting elements
1, 2, 3, 4
4330
Spindle pitch in mm
3 mm
4330
Stroke length in cm
30 cm, 40 cm
EU/CH
Country specific power cable
EU/CH, US
12
11 = Hand switch Up-Down ; 12 = Hand switch Memory
12
Battery
With exchangeable battery 10A
Battery
Other versions
Description
M12
With M12 thread connection
s01-s99
Special version: different position of threads, color, etc.
Notes over the operating instruction:
Lifting systems from Ergoswiss AG are intended for installation in an overall system (e.g. assembly table)
and classified under the category of incomplete machines in accordance with the Machinery Directive
2006/42/EC.
This operating instruction contain information on the commissioning, handling and safety of the lifting sys-
tem and are aimed at the further- user and manufacturer of the entire system. The further-user of this lifting
system is obliged to create an operating manual with all usage information and hazard warnings for the en-
tire system.
The declaration of incorporation is only valid for the Ergoswiss lifting system and not for the overall system
created by the further-user.

Operating instruction
Spindle lifting system SLA/SLG 13xx
with SCT4 iSMPS 24V and Exchangeable battery
Document no.: B-00421
Edition 2024 02
Operating instruction EN
Copyright by Ergoswiss AG
Page 3of 32
Table of content
1Safety requirements ................................................................................................................ 4
1.1 Explanations of the symbols and notes ..................................................................................... 4
2System description .................................................................................................................. 5
2.1 General .................................................................................................................................. 5
2.2 Intended purpose use ............................................................................................................. 5
2.2.1 General safety instructions................................................................................................... 6
2.3 Target group and prior knowledge ........................................................................................... 6
2.4 Handling the Lithium-Ion Battery Pack...................................................................................... 7
2.5 Performance characteristics ..................................................................................................... 8
2.5.1 Linear unit SLA.3/SLG.3 13xx............................................................................................... 8
2.5.2 Control box SCT4 iSMPS 24V ............................................................................................... 9
2.5.3 Hand switch Up/Down and Memory...................................................................................... 9
2.5.4 Exchangeable battery package........................................................................................... 10
2.5.5 System data ..................................................................................................................... 11
3Mounting instructions............................................................................................................ 12
3.1 Mounting instructions Linear unit ........................................................................................... 12
3.2 Mounting instructions Battery set ........................................................................................... 14
3.3 Mounting instructions Control box .......................................................................................... 16
3.4 Mounting instructions Hand switch ......................................................................................... 18
3.4.1 Hand switch Memory......................................................................................................... 18
3.4.2 Hand switch Up-Down ....................................................................................................... 18
4Initial operation..................................................................................................................... 19
4.1 Plug detection....................................................................................................................... 19
4.2 Duty cycle monitoring............................................................................................................ 19
5Operation with Hand switch Type Memory ........................................................................... 20
5.1 Drive Up / Down ................................................................................................................... 20
5.2 Saving and approaching a memory position ............................................................................ 20
5.3 Limit the stroke length (Container-Stop/Shelf-Stop)................................................................. 21
5.3.1 Limit upper end position - Shelf-Stop «S 04» ...................................................................... 21
5.3.2 Limit lower end position – Container-Stop «S 05» ............................................................... 21
5.4 Setting the shown height on the display «S 06»...................................................................... 22
5.5 Changing the displayed unit of measurement (cm/inch) «S 07» ............................................... 22
5.6 Deactivating / activating the tilt sensor «S 08» ....................................................................... 23
5.7 Locking the movement (child protection) ................................................................................ 24
5.8 Reference drive – Referencing the end positions ..................................................................... 25
5.9 Restore to factory settings – Factory reset «S 00» .................................................................. 26
6Operation with Hand switch Type Up-Down ......................................................................... 27
6.1 Up / Down............................................................................................................................ 27
6.2 Reference drive – Referencing the end positions ..................................................................... 27
7Safety strip – Squeezing protection ...................................................................................... 28
7.1 Commissioning...................................................................................................................... 28
8Maintenance and disposal ..................................................................................................... 29
8.1 Maintenance and cleaning ..................................................................................................... 29
8.2 Repairs and spare parts......................................................................................................... 29
8.3 Disassembly and disposal ...................................................................................................... 29
8.4 Electrical and Electronic Equipment Act .................................................................................. 29
9Error codes and trouble shooting .......................................................................................... 30
9.1 Error codes on the display ..................................................................................................... 30
9.2 Trouble shooting................................................................................................................... 31
10 Declaration of Incorporation ................................................................................................. 32

Operating instruction
Spindle lifting system SLA/SLG 13xx
with SCT4 iSMPS 24V and Exchangeable battery
Document no.: B-00421
Edition 2024 02
Operating instruction EN
Copyright by Ergoswiss AG
Page 4of 32
1Safety requirements
The safety instructions must be paid attention to! If the system is operated improperly or not in accordance
with the intended use, there may be a risk to persons and property!
Before installing and operating the lifting system, this operating instruction must be read and understood.
The manual must be kept in the close proximity to the system for future reference.
1.1 Explanations of the symbols and notes
The following explanations of symbols and notes must be observed. These are classified according to ISO
3864-2 (ANSI Z535.4).
DANGER
Indicates an imminent danger.
Failure to follow the information will result in death or severe physical injury (disability).
WARNING
Indicates a potentially dangerous situation.
Failure to follow the information will result in death or severe physical injury (disability).
ATTENTION
Indicates a potentially dangerous situation.
Failure to follow the information will result in damage to property and minor or medium
physical injuries will result.
NOTE
Indicates general information, useful user tips and work recommendations, which have no im-
pact on the health and safety of staff.

Operating instruction
Spindle lifting system SLA/SLG 13xx
with SCT4 iSMPS 24V and Exchangeable battery
Document no.: B-00421
Edition 2024 02
Operating instruction EN
Copyright by Ergoswiss AG
Page 5of 32
2System description
2.1 General
The basic functionality of a spindle lifting system SLA/SLG by Ergoswiss AG is the lifting and lowering of
work surfaces, machine parts, profile systems, etc.
An operative spindle lifting System SLA/SLG consists of a minimum of following components:
→Linear unit SLA/SLG
→Control box SCT iSMPS 24V
→Hand switch Memory
→Exchangeable battery packet (Exchangeable battery 10A, holder, charging station)
The linear unit SLA/SLG consists of a colorless anodized aluminium profile and a standpipe made of stainless
steel, which is guided in a plastic guide (SLA) or in a bronze bushing (SLG). The standpipe is moved by an
inline spindle drive. Up to 4 spindle lifting elements can be connected to one control box SCT4 iSMPS and be
operated synchronously.
The high-performance control box SCT4 iSMPS 24V is equipped with four motor channels, which are ad-
justed synchronously by an encoder converter. Due to the optimised driving comfort, the end positions are
gently approached as low-speed zones up to the standstill. An integrated tilt sensor reacts to the system tip-
ping and can prevent potentially dangerous situations. Additional functions, such as the synchronisation of
two control boxes or the connection of safety strips (squeezing protection) can be used.
The control box is powered by the Exchangeable battery 10A. The maximum possible number of lifting cy-
cles depends on the status of the battery-lifespan and the system load. If the exchangeable battery 10A is
discharged, it must be removed from the holder and charged in the charging station.
The state of charge is indicated by four LEDs;
(1st LED = 25 % | 2nd LED = 50 % | 3rd LED = 75 % | 4th LED = 100 %).
With the hand switch Memory the lifting system can be operated comfortably, the work surface will be ad-
justed steplessly in its height.
The current height of the work surface is shown continuously on the display (in cm or inches). In addition,
up to three different memory positions can be saved and approached individually. Errors that occur are also
shown on the display.
2.2 Intended purpose use
Scope of application
NOT scope of application
→
Height adjustment of worktops
→
Height adjustment of machine parts
→
Height adjustment of profile systems
→
… the list is not exhaustive
→Clamping tool
→
Press (or counterhold for press)
→
Passenger transport
→
Security component
→
… the list is not exhaustive

Operating instruction
Spindle lifting system SLA/SLG 13xx
with SCT4 iSMPS 24V and Exchangeable battery
Document no.: B-00421
Edition 2024 02
Operating instruction EN
Copyright by Ergoswiss AG
Page 6of 32
2.2.1 General safety instructions
ATTENTION
The safety instructions must be paid attention to! If the system is operated improperly or not
in accordance with the intended use, there may be a risk to persons and property!
The lifting system may be used if:
→it is located in closed rooms, in a dry and non-explosive environment.
→the ambient temperature is between +10 °C and +40 °C.
→the relative humidity range is between 30% and 70% (non-condensing).
→there are no strong electromagnetic fields nearby.
→This device can be used by children aged 8 and over and by persons with reduced physical, sensory or
mental abilities or lack of experience and knowledge if they are supervised or have been instructed in
the safe use of the device and the resulting dangers to understand.
The lifting system must not be:
→operated outside of the performance data (max. tensile, compressive, bending moment loads).
→subjected to impulse, impact and impact forces (e.g. setting down loads).
→operated with an incorrect mains voltage! Adhere to the type plate of the control box!
→designed for continuous operation (below the duty cycle ratio of 1/9).
→operated on unstable or sloping ground.
→operated with impermissible or non-designated components.
(e.g. different types of lifting elements; replacement of the control (control software))
→operated with damaged components.
→opened, reworked or rebuilt.
→operated if the power cable is not freely accessible. Disconnect the power cord in the event of a fault.
→Children must not play with the device. Cleaning and user maintenance shall not be made by children
without supervision.
When installing and operating the lifting system, the intended use of the entire system must be adhered to.
Commissioning is prohibited until the entire system complies with the provisions of the EC Directives
2006/42/EC (Machinery Directive). For this purpose, it is essential to perform a risk analysis, so that possible
residual hazards can be reacted to (e.g. through constructive measures or through instructions in the oper-
ating instructions and/or through safety indication on the system). In the event of improper use, the liability
of Ergoswiss AG and the general operating permit for the lifting system will expire.
2.3 Target group and prior knowledge
Before installing and operating the lifting system, this operating instruction must be read and understood.
The manual must be kept in close proximity to the system for future reference.
This operating instruction addresses the following groups of people:
The manufacturer of the overall system who integrates this lifting system into an overall system and
integrates these operating instructions into the operating instructions for the overall system.
The commissioning personnel who install the lifting system in a workplace, a machine, etc. and put it
into operation. For commissioning basic mechanical and electrical knowledge are required.

Operating instruction
Spindle lifting system SLA/SLG 13xx
with SCT4 iSMPS 24V and Exchangeable battery
Document no.: B-00421
Edition 2024 02
Operating instruction EN
Copyright by Ergoswiss AG
Page 7of 32
2.4 Handling the Lithium-Ion Battery Pack
The exchangeable battery belongs to the class of portable batteries. As a rule, it works smoothly and
maintenance-free. At the end of its lifetime, the power becomes smaller and the exchangeable battery
should then be replaced.
Since the actual battery cells are surrounded by a plastic housing that also contains the charging electronics,
no changes to them can be detected from the outside. The housing also provides additional protection
against potentially leaked battery cells.
Disused exchangeable batteries, as well as old batteries made of power tools, garden tools and household
appliances (e.g. vacuum cleaner robots) are taken back by municipal collection points.
ATTENTION
Do not open the housing to remove the battery cells before disposal!
Don't try to replace used battery cells with new ones!
If the housing of the exchangeable battery is damaged in such a way, that damage to the contained battery
cells cannot be ruled out, it should be disposed of immediately. Preferably at the recycling centre and as a
precaution in such a way, that it can be received by employees. Talk to the specialist staff and point out the
damage.
Storage
Under no circumstances should you store the exchangeable battery in the refrigerator or water and not ex-
pose it to moisture. The storage temperature should be between 0 – 40 °C
(32 – 104 °F) , whereby lower
temperatures are preferable. Due to self-discharge, recharging is required every 3 months.
Transport / Shipping
Lithium-ion batteries are classified as "dangerous goods" in international transport law. Thus, the regulations
for the transport of dangerous goods are relevant for them.
The following rules apply to the modes of transport:
•Road: ADR
Accord européen relatif au transport international des marchandises Dangereuses par Route.
(European Agreement on the International Carriage of Dangerous Goods by Road)
•Rail: RID
Règlement concernant le transport internaional ferr viare de marchandises Dangereuses
(Regulation on the international carriage of dangerous goods by rail)
•Sea freight: IMDG Code
International Maritime Code for Dangerous Goods
•Air freight: IATA DGR
International Air Transport Association Dangerous Goods Regulations

Operating instruction
Spindle lifting system SLA/SLG 13xx
with SCT4 iSMPS 24V and Exchangeable battery
Document no.: B-00421
Edition 2024 02
Operating instruction EN
Copyright by Ergoswiss AG
Page 8of 32
2.5 Performance characteristics
2.5.1 Linear unit SLA.3/SLG.3 13xx
Linear unit SLA.3 13xx
Linear unit SLG.3 13xx
Cross-section
35 x 35 mm (1.38” x 1.38”)
45 x 45 mm (1.77” x 1.77”)
Standard stroke length
300, 400 mm (12”, 16”)
Installation length
Stroke length + 299 mm (11.8”)
Lower block position = stroke length + 296 mm (11.7”)
Weight
SLA.3 1330 = 2.35 kg (5.2 lbs)
SLA.3 1340 = 2.75 kg (6.1 lbs)
SLG.3 1330 = 3.37 kg (7.4 lbs)
SLG.3 1340 = 3.91 kg (8.6 lbs)
Max. allowed pressure
load
1’500 N (337 lbf)
Max. allowed tensile load
1’500 N (337 lbf)
Power consumption
5 A per linear unit (at maximum load)
Voltage
24 V
Lifting speed
6 – 7.5 mm/s (0.24 – 0.3 ’’/s)
(load dependent)
Noise level
< 60 dBA
Protection class
(DIN EN 60529)
IP 20
Electrical connection Molex MiniFit plug 8 Pin
Cable length 2’000 m (79”)
End switch
No (reading Encoder)
Tested product life
5’000 cycles with 400 mm (16’’) stroke length
1’500 N (337 lbf) pressure load, duty cycle 1/9 
dyn. = during the lifting movement
Duty Cycle 1/9; operating max. 1 min, pause 9 min

Operating instruction
Spindle lifting system SLA/SLG 13xx
with SCT4 iSMPS 24V and Exchangeable battery
Document no.: B-00421
Edition 2024 02
Operating instruction EN
Copyright by Ergoswiss AG
Page 9of 32
Max. allowed bending moment
Linear unit SLA
Max. allowed bending moment
Linear unit SLG
Mby stat. 
150 Nm (111 lbf⋅ft)
Mbx dyn. 
50 Nm (37 lbf⋅ft)
Mb stat. 
200 Nm (148 lbf⋅ft)
Mb dyn. 
80 Nm (59 lbf⋅ft)
Mb = force x stroke
Mb = force x stroke
stat. = during standstill; dyn. = during stroke movement
2.5.2 Control box SCT4 iSMPS 24V
Dimension (L x B x H)
309 x 120 x 55 mm (12.2” x 4.7” x 2.2”)
Weight
SCT4: 0.63 kg (1.4 lbs)
Supply voltage
16.8 – 29 V DC (nominal 25.2 V)
10 A max. (nominal 3.0 A)
Primary standby power
< 0.6 W
Power
250 W ; 10 A @ 25 V DC
(Depending on power source)
Protection class (DIN EN 60529)
IP 20
Performance Level (DIN EN 13849-1)
PL b
2.5.3 Hand switch Up/Down and Memory
Electrical connection
RJ-12 plug 6 Pin
Cable length 2 m (79”)
Protection class (DIN EN 60529) IP 30


F
orce
[N]
F
orce
[N]


Mb
stroke
force
Mb
stroke
force

Operating instruction
Spindle lifting system SLA/SLG 13xx
with SCT4 iSMPS 24V and Exchangeable battery
Document no.: B-00421
Edition 2024 02
Operating instruction EN
Copyright by Ergoswiss AG
Page 10 of 32
2.5.4 Exchangeable battery package
Supply voltage
29 – 31 V DC
Supply current
250 mA; +/- 100 mA
Output power
250 W
Output voltage
16.8 – 29 V DC
nominal 25.2 V
Output
10 A (for ED 1/9

)
Short-term 20 A (only to absorb inrush currents)
Overcurrent shutdown 14 – 20 A
Capacity
6’000 mAh
Temperature (operating)
0 – 40 °C (32 – 104 °F)
Temperature (storage)
0 – 55 °C (32 – 131 °F)
Temperature (transport)
0 – 55 °C (32 – 131 °F)
Relative humidity
(operation, transport and storage)
< 85%; non-condensing
Load
During charging, the LEDs (power indicator) flash
(1. LED = 25 % | 2. LED = 50 % | 3. LED = 75 % | 4. LED = 100 %).
Reload
The battery is self-discharging, therefore recharging is required every
3 months.
A full charge takes a maximum of 6h.
Overload
Charging is automatically terminated when:
- Voltage of the internal battery block is greater than 29 V +/- 3 V, or
- the voltage of a single cell is greater than 4.3 V.
The battery is fully charged when all 4 LEDs are green
Charge low
The battery warns with an acoustic signal if the voltage of the internal
battery block is less than 21 – 22 V.
The battery should then be charged.
Discharge
The battery will automatically shut down if:
- Voltage of internal battery blocks is less than 16.8 V +/-0.5 V, or
- Voltage of individual cells is less than 2.5 V
This state is called "battery discharged".
Further discharge is prevented.
This state is neither audible nor visually displayed and can only be ter-
minated by charging.
Overcurrent shutdown
When the output current reaches values between 14 A and 20 A, the
battery switches off immediately. When the output current is back in
the nominal range, the battery can be used again.
If necessary, this must be cooled and charged.
Short-circuit fuse
If a short circuit occurs at the output, the battery switches off immedi-
ately. When the short circuit has been eliminated, the battery can be
used again.
If necessary, the battery must be loaded
Duty Cycle 1/9; operating max. 1 min, pause 9 min

Operating instruction
Spindle lifting system SLA/SLG 13xx
with SCT4 iSMPS 24V and Exchangeable battery
Document no.: B-00421
Edition 2024 02
Operating instruction EN
Copyright by Ergoswiss AG
Page 11 of 32
2.5.5 System data
# Lifting
elements
Max.
System
load
Stroke
length
Lifting
element
Control
type
# of cycles per load-
percentage at full
Battery charge

Lifting
speed

Duty
Cycle
[kg] (lbs)
[mm] (in)
Type
24 V
100%
50%
0%
[On/Off]
1
125
(275)
300 (12")
1330
Battery (V1891)
100
200
400
6 - 8.5 mm/s
(0.24
- 0.33 "/s)
Load dependent
1/9 min
400 (16")
1340
Battery (V1890)
80
160
320
2
250
(550)
300 (12")
1330
Battery (V1891)
65
130
260
400 (16")
1340
Battery (V1890)
50
100
200
3
300
(660)
300 (12")
1330
Battery (V1891)
40
80
160
400 (16")
1340
Battery (V1890)
30
60
120
4
300
(660)
300 (12")
1330
Battery (V1891)
30
60
120
400 (16")
1340
Battery (V1890)
25
50
100
Linear unit SLA.3 or SLG.3
The maximum number of cycles depends on the status of the battery-lifespan
Duty cycle 1/9; operating max. 1 min, pause 9 min
NOTE
The lifting system can be subjected to uneven loads as long …
→
the max. load on the single lifting element is not exceeded,
→
the max. bending torque of the lifting element is not exceeded,
→
the entire system is located on sufficient safe ground
… and the entire plant has been constructed in accordance with the provisions of the mechan-
ical equilibrium. Conducting a risk analysis
ATTENTION
High pulse / impact forces due to the discontinuation of loads are not allowed.
(e.g. discontinuation of loads in feed with crane or forklift)

Operating instruction
Spindle lifting system SLA/SLG 13xx
with SCT4 iSMPS 24V and Exchangeable battery
Document no.: B-00421
Edition 2024 02
Operating instruction EN
Copyright by Ergoswiss AG
Page 12 of 32
3Mounting instructions
3.1 Mounting instructions Linear unit
NOTE
The lifting system must be mounted in such a way, that driving to the lower position is possi-
ble at any time.
Otherwise, no initial operating and reset of the system can be carried out.
SLA
□35 mm
(1.38”)
6x thread M5 x 5.5
max. screw-in depth: 5.5 mm !
(max. screw-in depth: 0.21” !)
Thread
M10 x 24
SLG
□45 mm
(1.77”)
6x thread M6 x 6
max. screw-in depth: 6 mm !
(max. screw-in depth: 0.23”! )
Motor cable 2’000 mm (79’’)
With up to 5x Motor extension cable of 1’200 mm (47”)
can be extended up to 8’000 mm (315”)

Operating instruction
Spindle lifting system SLA/SLG 13xx
with SCT4 iSMPS 24V and Exchangeable battery
Document no.: B-00421
Edition 2024 02
Operating instruction EN
Copyright by Ergoswiss AG
Page 13 of 32
Linear unit Type SLA
(drawing in mm)
Linear unit Type SLG
(drawing in mm)

Operating instruction
Spindle lifting system SLA/SLG 13xx
with SCT4 iSMPS 24V and Exchangeable battery
Document no.: B-00421
Edition 2024 02
Operating instruction EN
Copyright by Ergoswiss AG
Page 14 of 32
3.2 Mounting instructions Battery set
Exchangable battery 10 A
The charge status of the exchangable
battery can be checked using the 4
LEDs of power/charging indicator indi-
cator on the battery.
To check the charging status, press the
test button to the right of the LEDs.
From right to left the LEDs show 25 %,
50 %, 75 % and 100 % of charge.
(drawing in mm)
Holder for exchangable battery
2x Slot hole
for screw size M4 (Ø4.2) (Ø0.16”)
Torque max. 2 Nm (1.5 lbf⋅ft)
(e.g.: Button head screw DIN 7981-C,
Ø 3.5 mm (0.14”),head-Ø 6.9 mm (0.27’’))
Screws are not included in the scope of
delivery.
(drawing in mm)
Exchangable battery with Holder
The exchangable battery can be in-
serted into the holder.
If the exchangable battery is plugged into
the holder, the set is in operating status.
(drawing in mm)
NOTE
The mounting location provided for the holder should be easily accessible and chosen in such
a way so that …
→
the exchangeable battery can be easily removed and
→the LED power indicator can be read without removal.

Operating instruction
Spindle lifting system SLA/SLG 13xx
with SCT4 iSMPS 24V and Exchangeable battery
Document no.: B-00421
Edition 2024 02
Operating instruction EN
Copyright by Ergoswiss AG
Page 15 of 32
Docking station
The docking station can be connected
to the electricity using the country
specific charging cable.
A brand new battery must first be acti-
vated. This is done simply by plugging
the battery into the docking station.
After approx. 10 seconds, the
power/charging indicator starts to light
up green and the battery is being
charged.
The charge status of the exchangable
battery can be checked using the 4
LEDs of power/charging indicator indi-
cator on the battery.
To check the charging status, press the
test button to the right of the LEDs.
From right to left the LEDs show 25 %,
50 %, 75 % and 100 % of charge.
Only use the battery when it is fully
(100%) charged.
(drawing in mm)
ATTENTION
Der Akkupack darf nur mit der mitgelieferten Docking Station geladen werden!
Nur diese gewährleistet eine ausreichende Sicherheit.
The exchangable battery may only be charged with the included docking station!
This is the only way to ensure adequate security.

Operating instruction
Spindle lifting system SLA/SLG 13xx
with SCT4 iSMPS 24V and Exchangeable battery
Document no.: B-00421
Edition 2024 02
Operating instruction EN
Copyright by Ergoswiss AG
Page 16 of 32
3.3 Mounting instructions Control box
ATTENTION
During mounting of the control box the power cable needs to be disconnected from the
mains!
NOTE
The control box has an integrated tilting sensor as standard. To ensure the smooth normal
operation, the control box must be fixed rigidly to the system before initial commissioning.
(e.g. below the tabletop)
Mounting the control box at the bottom of a tabletop:
1. Place the control box to the desired location and mark the drill holes with a pen.
2. Pre-drill 3 holes (Ø 2.5 mm / 0.1’’) .
Be careful not to drill through the table top!
3. Mount the control box with 3 screws.
(e.g.: Button head screw DIN 7981-C, Ø 3.9 mm
(0.15”) , head-Ø 7.5 mm ( 0.33’’)) .
NOTE
When tightening the screws do not exceed a maximum torque of 2 Nm
(1.5 lbf⋅ft) !
NOTE
The motor cable has a length of 1’800 mm (71’’) . If needed, up to 5 motor extension cables
can be connected. They have a length of 1’200 mm
(47’’) each.

124.00137: Extension cable Motor SCT/Compact 1.2m (47’’)
NOTE
The cable of the hand switch has a length of 1’800 mm (71’’) . If needed it can be expanded
with up to 3 extension cables. They have a length of 1’000 mm
(39’’) each.
124.00290: Extension cable Hand switch SCT 1m (39’’)

Operating instruction
Spindle lifting system SLA/SLG 13xx
with SCT4 iSMPS 24V and Exchangeable battery
Document no.: B-00421
Edition 2024 02
Operating instruction EN
Copyright by Ergoswiss AG
Page 17 of 32
Control box SCT4 iSMPS 24V
ATTENTION
Connecting homemade products to the control box is prohibited!
Only use supplied components.
4. Connect the motor cables to the control box in the correct order from 1to 4.
(Automatic plug detection on all sockets)
5. Connect the hand switch to the control box.
If necessary, optional components can now be connected (e.g. safety strips, sync cable).
6. Connect the Holder for exchangable battery to the control box.
NOTE
Before connecting the Exchangeable battery onto the Holder the following must be verified:
→ Does the mains voltage correspond to the value on the name plate of the control box?
→ Are the plugs of the motor cable connected to the correct sockets (1to 4)?
→ Is the entire lifting system assembled according to the assembly instructions?
7. Connect the Exchangeable battery onto the Holder.
Connection for Safety strip
Connection for Safety strip
Connection for Hand switch
Connection for Sync cable
Motor socket 1
Motor socket 2
Motor socket 3
Motor socket 4

Operating instruction
Spindle lifting system SLA/SLG 13xx
with SCT4 iSMPS 24V and Exchangeable battery
Document no.: B-00421
Edition 2024 02
Operating instruction EN
Copyright by Ergoswiss AG
Page 18 of 32
3.4 Mounting instructions Hand switch
3.4.1 Hand switch Memory
1. Position the hand switch underneath the table plate.
The control panel must overhang below the work sur-
face!
2. Fasten the hand switch using the mounting screws.
Be careful not to drill through the table top!
3.4.2 Hand switch Up-Down
1. Position the hand switch underneath the table plate.
The control panel must overhang below the work sur-
face!
2. Fasten the hand switch using the mounting screws.
Be careful not to drill through the table top!

Operating instruction
Spindle lifting system SLA/SLG 13xx
with SCT4 iSMPS 24V and Exchangeable battery
Document no.: B-00421
Edition 2024 02
Operating instruction EN
Copyright by Ergoswiss AG
Page 19 of 32
4Initial operation
ATTENTION
Danger of squeezing during height adjustment!
ATTENTION
It must be possible to fully retract the lifting element to its lower block position at any time
(also in the operating state).
If the lifting element cannot retract completely and hits a stop before it reached its lower
block position, the zero position is set incorrectly. This leads to a collision when moving up to
the upper block position.
ATTENTION
The system may only be fully loaded after the initial operation has been completed.
During the initial operation, the lifting system may be loaded with max. 50% of the system
load.
NOTE
During the initial operation, the lifting system drives with half the speed.
1. Keep the buttons and pressed simultaneously to drive the lower block position.
The system moves downwards at half speed. Upward movement is disabled.
2. After reaching the block position, the system will drive out a few millimeters.
Afterwards the control box will emit 3 signal sounds.
3. let go of the buttons and .
After reaching the block position, the lower and the upper position will be stored automatically.
The initial operation is completed.
NOTE
The lower position is 3 mm (0.12’’) higher than the block position. The upper position depends
on the lifting element type, resp. of the control box software.
4.1 Plug detection
The control box can detect whether a lifting element is plugged into the relevant socket.
The control box only recognizes during the lifting movement whether a lifting element has been removed.
After plugging out or replacing a lifting element the system must be reset to synchronize all connected lifting
elements.
4.2 Duty cycle monitoring
The duty cycle monitoring checks the ratio between the operation time and standstill time. To avoid over-
heating of the system a duty cycle of 1/9 (ON/OFF) should be maintained.
The maximum continuous operating time is 1 minutes. Afterwards a pause of at least 9 minutes needs to be
observed before the system can be operated again.

Operating instruction
Spindle lifting system SLA/SLG 13xx
with SCT4 iSMPS 24V and Exchangeable battery
Document no.: B-00421
Edition 2024 02
Operating instruction EN
Copyright by Ergoswiss AG
Page 20 of 32
5Operation with Hand switch Type Memory
5.1 Drive Up / Down
This function is used for easy height adjustment of the system.
Press the button or .
Keep the button pressed until the desired working height is reached.
5.2 Saving and approaching a memory position
With this function it is possible to memorise a certain position/height and approach it at a later time by
pushing one button. With the 3 memory buttons up to 3 different positions can be stored and approached.
1. Drive to the desired position and press the button M3 times.
2. Press one of the buttons
1
2
3
within 5 seconds.
After saving the control box will emit 1 signal sound.
The memory position is now stored under the pressed button.
To approach a stored memory position:
Keep one of the buttons
1
2
3
pressed until the desired working height is reached.
