Ergoswiss PA 2830 User manual

Operating instruction
Hydraulic lifting system with Hand crank
Documant no.: B-00011
Edition 2022 08
Operating instruction EN
Copyright by Ergoswiss AG
Page 1of 13
Operating instruction – Hydraulic system with Hand crank
It is essential to read this operating instruction thoroughly before commissioning the system.
This operating instruction has to be stored in the immediate vicinity of the system.
Hand crank
Pump
Hydraulic tubing
Lifting element (Cylinder, Linear unit, Table leg)
Errors and technical changes reserved.
Ergoswiss AG does not assume any liability for operating errors or
using the products outside of the intended purpose use.
At the time of delivery Ergoswiss AG will replace or repair defect
products within accordance with the warranty provisions. In addi-
tion, Ergoswiss assumes no other liability.
For your questions and special custom demand Ergoswiss AG will
be at your disposal.
Ergoswiss AG
Nöllenstrasse 15
CH-9443 Widnau
Tel.: [phone]
Fax: [phone]
[e-mail]
www.ergoswiss.com
2
4
3
1

Operating instruction
Hydraulic lifting system with Hand crank
Documant no.: B-00011
Edition 2022 08
Operating instruction EN
Copyright by Ergoswiss AG
Page 2of 13
This operating instruction applies to:
Pump PA/PB/PF with Hand crank
e.g.: Pump PA 2830 with Hand crank – (Article no.: 310.20003)
e.g.: Pump PF 4830 with Hand crank – (Article no.: 313.20033)
e.g.: Pump PB 6830 with Hand crank – (Article no.: 312.20043)
Description
Standard variations
PF
Type of pump
PA, PB, PF
4830
Number of driven cylinders
1, 2, 3, 4, 5, 6, 7, 8, 9, 0 = 10
4830
Code for piston diameter
4 = 14 mm, 8 = 18 mm, 6 = 26 mm
4830
Stroke of cylinder on the 14xx-series in cm
15, 20, 30, 40, 50, 60, 70 cm
Other versions
Description
No tox
with food grade hydraulic oil
GS
milled pusher block
GZ
milled center plate
AL
Aluminum center plate
s01-s99
Special variation: special stroke, special front panel, color, special oil, etc.
Notes over the operating instruction:
Lifting systems from Ergoswiss AG are intended for installation in an overall system (e.g. assembly table)
and classified under the category of incomplete machines in accordance with the Machinery Directive
2006/42/EC.
This operating instruction contain information on the commissioning, handling and safety of the lifting sys-
tem and are aimed at the further-user and manufacturer of the entire system. The further-user of this lifting
system is obliged to create an operating manual with all usage information and hazard warnings for the en-
tire system.
The declaration of incorporation is only valid for the Ergoswiss lifting system and not for the overall system
created by the further-user.

Operating instruction
Hydraulic lifting system with Hand crank
Documant no.: B-00011
Edition 2022 08
Operating instruction EN
Copyright by Ergoswiss AG
Page 3of 13
Table of content
1System description .................................................................................................................. 4
1.1 Explanations of the symbols and notes ..................................................................................... 4
2System description .................................................................................................................. 5
2.1 In general............................................................................................................................... 5
2.2 Intended purpose use ............................................................................................................. 5
2.2.1 General safety instructions................................................................................................... 5
2.3 Target group and prior knowledge ........................................................................................... 6
2.4 Performance characteristics ..................................................................................................... 7
2.4.1 Lifting element.................................................................................................................... 7
2.4.2 Pump ................................................................................................................................. 7
2.4.3 System data ....................................................................................................................... 8
3Mounting instructions.............................................................................................................. 9
3.1 Mounting instructions Lifting element ....................................................................................... 9
3.2 Mounting instructions Pump..................................................................................................... 9
3.3 Mounting instructions Lifting system......................................................................................... 9
4Operation ............................................................................................................................... 10
4.1 Extending the lifting system................................................................................................... 10
4.2 Retracting the lifting system .................................................................................................. 10
4.3 Folding hand crank – Only with Hand crank foldable! .............................................................. 11
4.4 Remove hand crank – Only with Hand crank removable! ......................................................... 11
5Maintenance and disposal ..................................................................................................... 12
5.1 Maintenance and cleaning ..................................................................................................... 12
5.2 Repairs and spare parts......................................................................................................... 12
5.3 Disassembly and disposal ...................................................................................................... 12
5.4 Trouble-shooting................................................................................................................... 12
6Declaration of Incorporation ................................................................................................. 13

Operating instruction
Hydraulic lifting system with Hand crank
Documant no.: B-00011
Edition 2022 08
Operating instruction EN
Copyright by Ergoswiss AG
Page 4of 13
1System description
The safety instructions must be paid attention to! If the system is operated improperly or not in accordance
with the intended use, there may be a risk to persons and property!
Before installing and operating the lifting system, this operating instruction must be read and understood.
The manual must be kept in the close proximity to the system for future reference.
1.1 Explanations of the symbols and notes
Please pay attention to the following explanations of the symbols and notes. They are classified according to
ISO 3864-2 (ANSI Z535.4).
DANGER
Indicates an immediate threatening danger.
Non-compliance with this information can result in death or serious personal injuries
(invalidity).
WARNING
Indicates a possible dangerous situation.
Non-compliance with this information can result in death or serious personal injuries
(invalidity).
ATTENTION
Indicates a possible dangerous situation.
Non-compliance with this information can result in damage to property or light to medium
per-sonal injuries.
NOTE
Indicates general notes, useful operator advice and operating recommendations which do not
affect safety and health of the user.

Operating instruction
Hydraulic lifting system with Hand crank
Documant no.: B-00011
Edition 2022 08
Operating instruction EN
Copyright by Ergoswiss AG
Page 5of 13
2System description
2.1 In general
The basic functionality of a hydraulic lifting system by Ergoswiss AG is the lifting and lowering of work sur-
faces, machine parts, profile systems, etc.
An operative hydraulic lifting System consists of a minimum of following components:
→Lifting element (Table leg Tx, Linear unit Lx, Cylinder Cx) with tubing
→Pump (PA, PB, PF) with Hand crank
The hand crank moves an internal spindle drive inside the pump, which forces the volume of oil from the
pump through the tubing into the lifting elements.
2.2 Intended purpose use
Scope of application
NOT scope of application
→Height adjustment of worktops
→
Height adjustment of machine parts
→
Height adjustment of profile systems
→
… the list is not exhaustive
→Clamping tool
→
Press (or counterhold for press)
→
Passenger transport
→
Security component
→
… the list is not exhaustive
2.2.1 General safety instructions
ATTENTION
The safety instructions must be paid attention to! If the system is operated improperly or not
in accordance with the intended use, there may be a risk to persons and property!
The lifting system may be used if:
→it is located in closed rooms, in a dry and non-explosive environment.
→the ambient temperature is between +10 °C and +40 °C.
→This device can be used by children aged 8 and over and by persons with reduced physical, sensory or
mental abilities or lack of experience and knowledge if they are supervised or have been instructed in
the safe use of the device and the resulting dangers to understand.
The lifting system must not be:
→operated outside of the performance data (max. compressive, bending moment loads).
→subjected to tensile loads (lifting system is a single acting hydraulic system).
→subjected to impulse, impact and impact forces (e.g. setting down loads).
→operated on unstable or sloping ground.
→operated with impermissible or non-designated components.
→operated with damaged components.
→opened, reworked or rebuilt.
→Children must not play with the device. Cleaning and user maintenance shall not be made by children
without supervision.

Operating instruction
Hydraulic lifting system with Hand crank
Documant no.: B-00011
Edition 2022 08
Operating instruction EN
Copyright by Ergoswiss AG
Page 6of 13
When installing and operating the lifting system, the intended use of the entire system must be adhered to.
Commissioning is prohibited until the entire system complies with the provisions of the EC Directives
2006/42/EC (Machinery Directive). For this purpose, it is essential to perform a risk analysis, so that possible
residual hazards can be reacted to (e.g. through constructive measures or through instructions in the oper-
ating instructions and/or through safety indication on the system). In the event of improper use, the liability
of Ergoswiss AG and the general operating permit for the lifting system will expire.
2.3 Target group and prior knowledge
Before installing and operating the lifting system, this operating instruction must be read and understood.
The manual must be kept in close proximity to the system for future reference.
This operating instruction addresses the following groups of people:
The manufacturer of the overall system who integrates this lifting system into an overall system and
integrates these operating instructions into the operating instructions for the overall system.
The commissioning personnel who install the lifting system in a workplace, a machine, etc. and put it
into operation. For commissioning basic mechanical and electrical knowledge are required.

Operating instruction
Hydraulic lifting system with Hand crank
Documant no.: B-00011
Edition 2022 08
Operating instruction EN
Copyright by Ergoswiss AG
Page 7of 13
2.4 Performance characteristics
2.4.1 Lifting element
Lifting element 14xx
Lifting element 18xx
Lifting element 16xx
Cross-section Cylinder
Piston Ø = 14 mm
Piston Ø = 18 mm
Piston Ø = 26 mm
Cross-section Guiding

see technical drawing
Standard stroke length
150, 200, 300, 400, 500, 600, 700 mm
(5.9”, 7.9”, 11.8”, 15.7”, 19.6”, 23.6”, 27.6”)
Installation length

see technical drawing
Weight

see technical drawing
Max. allowed pressure
load per lifting element
1'500 N (337 lbf) 2'500 N (562 lbf) 5'200 N (1'169 lbf)
Max. allowed system load

see system combination table
Lifting speed

see system combination table
Max. allowed tensile load
0 N (0 lbf)

Reset force
per lifting element 
see system combination table
Max. bending moments

see technical drawing

Tested product life span
10'000 double strokes, with max. stroke & system load
Single acting hydraulic system; cannot absorb any tensile force, requires reset force
stat. = during standstill; dyn. = during stroke movement
NOTE
For further information on the lifting element, see the system combination table and technical
drawings.
2.4.2 Pump
Pump PA
Pump PF
Pump PB
Number of connections
for lifting elements
1 … 2 3 … 4 3 … 10
Cross-section Pump
35 x 85 mm
(1.38” x 3.35”)
65 x 60 mm
(2.56” x 2.36”)
60 x 120 mm
(2.36” x 4.72”)
Standard stroke length
150, 200, 300, 400, 500, 600, 700 mm
(5.9”, 7.9”, 11.8”, 15.7”, 19.6”, 23.6”, 27.6”)
Installation length

see technical drawing
Weight

see technical drawing
Max. allowed system load

see system combination table
Protection class
(DIN EN 60529)
IP 41; PA, PF, PB 3xxx-6xxx
IP 10; PB 7xxx-0xxx
Tested product life span
10'000 double strokes, with max. stroke & system load
NOTE
For further information on the pump, see the system combination table and technical
drawings.

Operating instruction
Hydraulic lifting system with Hand crank
Documant no.: B-00011
Edition 2022 08
Operating instruction EN
Copyright by Ergoswiss AG
Page 8of 13
2.4.3 System data
An excerpt of the system combination table is shown below.
# Lifting
elements
Max. system
load
Stroke
length
Lifting
element
Pump Stroke per turn
[kg] (lbs)
[mm] (in)
Type
Type
[mm/U] (in/ T)
1 100 (220)
150 (6’’)
1415
PA 1815
5 mm/U
(0.2’’/T)
200 (8’’)
1420
PA 1820
300 (12’’)
1430
PA 1830
400 (16’’)
1440
PA 1840
500 (20’’)
1450
PA 1850
600 (24’’)
1460
PA 1860
700 (28’’)
1470
PA 1870
2
300 (660)
150 (6’’)
1415
PA 2815
5 mm/U
(0.2’’/T)
200 (8’’)
1420
PA 2820
300 (12’’)
1430
PA 2830
400 (16’’)
1440
PA 2840
500 (20’’)
1450
PA 2850
600 (24’’)
1460
PA 2860
700 (28’’)
1470
PA 2870
500 (1’100)
90 (3.5’’)
1815
PA 2815
3 mm/U
(0.12’/T)
110 (4.3’’)
1815
PA 2820
180 (7.1’’)
1820
PA 2830
240 (9.4’)
1830
PA 2840
300 (12’’)
1830
PA 2850
400 (16’’)
1840
PA 2866
3 … 10
350 (770)
150 (6’’)
1415
PF/PB x815
5 mm/U
(0.2’’/T)
200 (8’’)
1420
PF/PB x820
300 (12’’)
1430
PF/PB x830
400 (16’’)
1440
PF/PB x840
500 (20’’)
1450
PF/PB x850
600 (24’’)
1460
PF/PB x860
700 (28’’)
1470
PF/PB x870
600 (1’320)
110 (4.3’’)
1815
PF/PB x820
3 mm/U
(0.12’’/T)
180 (7.1’’)
1820
PF/PB x830
240 (9.4’)
1830
PF/PB x840
300 (12’’)
1830
PF/PB x850
400 (16’’)
1840
PF/PB x866
800 (1’760)
110 (4.3’’)
1815
PF/PB x418
1.8 mm/U
(0.07’’/T)
180 (7.1’’)
1820
PF/PB x430
240 (9.4’)
1830
PF/PB x440
Cylinder (CB, CD, CE, …), Linear unit (LA, LD, …) or Table leg (TA, TL, TT, ...)
NOTE
The lifting system can be subjected to uneven loads as long …
→
the max. load on the single lifting element is not exceeded,
→
the max. bending torque of the lifting element is not exceeded,
→
the entire system is located on sufficient safe ground
… and the entire plant has been constructed in accordance with the provisions of the mechan-
ical equilibrium. Conducting a risk analysis
ATTENTION
High pulse / impact forces due to the discontinuation of loads are not allowed.
(e.g. discontinuation of loads in feed with crane or forklift)

Operating instruction
Hydraulic lifting system with Hand crank
Documant no.: B-00011
Edition 2022 08
Operating instruction EN
Copyright by Ergoswiss AG
Page 9of 13
3Mounting instructions
3.1 Mounting instructions Lifting element
NOTE
The hydraulic tubing is to be assembled to the lifting element in accordance with the assembly
instructions. Information on mounting the lifting element can be found in the technical draw-
ings.
3.2 Mounting instructions Pump
NOTE
The lifting element is to be assembled to the pump in accordance with the assembly instruc-
tions. Information on mounting the pump can be found in the technical drawings.
NOTE
To all connections of the pump a lifting element must be connected to, otherwise the pump
will block and the lifting system will be damaged.
3.3 Mounting instructions Lifting system
NOTE
The pump with hand crank is to be assembled to the existing system in accordance with the
assembly instructions. Information on mounting the pump with hand crank and the lifting ele-
ments can be found in the technical drawings.
NOTE
The minimum tubing bending radius is 25 mm. The tubing must be routed in such a way that
it is not exposed to any mechanical stress, no aggressive media (chemicals), no direct sunlight
(UV radiation) and no heat.

Operating instruction
Hydraulic lifting system with Hand crank
Documant no.: B-00011
Edition 2022 08
Operating instruction EN
Copyright by Ergoswiss AG
Page 10 of 13
4Operation
ATTENTION
Danger of squeezing during height adjustment!
ATTENTION
The entire lifting area of the lifting element must always remain free. The lifting element is
not allowed to hit a stop before it reached its upper and lower block positions. Otherwise air
will be pulled into the system or too much pressure will build up.
4.1 Extending the lifting system
By turning the hand crank clockwise the lifting elements are extended.
Turn the crank until the desired working height is reached.
NOTE
The hand crank may be actuated with a maximum torque of 18 Nm!
The system must not be driven towards the end position with momentum!
4.2 Retracting the lifting system
By turning the hand crank counter-clockwise the lifting elements are retracted.
Turn the crank until the desired working height is reached.
NOTE
The hand crank may be actuated with a maximum torque of 18 Nm!
The system must not be driven towards the end position with momentum!
Max. 18 Nm
Max. 18 Nm

Operating instruction
Hydraulic lifting system with Hand crank
Documant no.: B-00011
Edition 2022 08
Operating instruction EN
Copyright by Ergoswiss AG
Page 11 of 13
4.3 Folding hand crank – Only with Hand crank foldable!
NOTE
The Hand crank foldable (113.00005) cannot be removed.
This can be folded, for example under a table top.
The crank body can be folded down by pulling the hand crank handle.
After folding back the crank body again, the pump can be operated again.
4.4 Remove hand crank – Only with Hand crank removable!
NOTE
The Hand crank removable (113.00013) cannot be folded down.
This can be pulled completely away from the pump and then attached again.
By pulling on the hand crank, it can be pulled away from the spindle shaft of the pump.
After reconnecting the hand crank, the pump can be operated again.

Operating instruction
Hydraulic lifting system with Hand crank
Documant no.: B-00011
Edition 2022 08
Operating instruction EN
Copyright by Ergoswiss AG
Page 12 of 13
5Maintenance and disposal
5.1 Maintenance and cleaning
The lifting system is maintenance-free during normal operation resp. when complying with the intended use.
Therefore a service is not required.
5.2 Repairs and spare parts
Repairs must only be conducted by specialists. Only original replacement parts may be used. For all repair
work the system must always be unloaded.
5.3 Disassembly and disposal
The system consists of components that can be fully recycled and thus they are quite safe from an environ-
mental protection perspective.
5.4 Trouble-shooting
ATTENTION
The lifting system must not be opened, reworked or operated by impermissible components.
Error
Cause
Rectification
Hand crank cannot be turned
Not all lifting elements were con-
nected to the pump
Mount all lifting elements on the
pump according to the assembly
instructions
System overloaded
Remove load from the system
Hand crank can be turned,
pump does not work
Clamping pin of the hand crank
broken Contact the customer service
Oil loss
Pump, tubing or lifting element
defective
Remove load from the system,
Contact the customer service

Operating instruction
Hydraulic lifting system with Hand crank
Documant no.: B-00011
Edition 2022 08
Operating instruction EN
Copyright by Ergoswiss AG
Page 13 of 13
6Declaration of Incorporation
