Ergotron YES BASIC YESBASGMPW4 User manual

1 of 13
888-24-362-G-00 rev. B • 09/17
YES BASIC Charging Cart
Model Part #YESBASGMPW4
ENGLISH
Built with Anthro-DNA™
For the latest User Installation Guide please visit: www.ergotron.com
User's Guide
Ergotron's Yes Cart for Mini-laptops is designed to automatically charge and store 1-36 tablet, smart phone,
and mini-laptop devices safely and efficiently. Adjustable shelves customize shelf height in 1" increments to
fit a range of device heights; adjustable bays slide left to right to fit even the largest cases.
Please review this manual before installing your equipment to learn how to use the cart safely.
AC input: 120V~ 60 Hz. Max Amps: 10A.

2 of 13
888-24-362-G-00 rev. B • 09/17
ENGLISH
These symbols alert users of a safety condi-
tion that demands attention. All users should
be able to recognize and understand the
significance of the following Safety Hazards
if encountered on the product or within the
documentation. Children who are not able
to recognize and respond appropriately to
Safety Alerts should not use this product with-
out adult supervision!
Hazard Symbols
Review
Symbol Signal Word Level of Hazard
NOTE A NOTE indicates important information that helps you
make better use of this product.
CAUTION
A CAUTION indicates either potential damage to
hardware or loss of data and tells you how to avoid the
problem.
WARNING A WARNING indicates either potential for property dam-
age, personal injury, or death.
ELECTRICAL
An Electrical indicates an impending electrical hazard
which, if not avoided, may result in personal injury, re
and/or death.
Safety
Important Safeguards - We want you to be safe!
These carts are electrical devices. Use care with them and follow these important safeguards:
• Intended for institutional use.
• Electrical devices are not toys. Children are often unaware of the hazards associated with electrical devices, so this unit must always be used by adults or with adult supervision.
• Liquids should not be stored in, set on or placed inside this unit.
• Never unplug this product from the outlet when your hands are wet.
• Be careful with the power cord. Do not jam the power cord against sharp edges. Do not use the unit if the cord appears to be damaged or if the ground prong is missing. When
the unit is not plugged in, wrap the power cord around cord wraps.
Inadequate repair can create signicant hazards to users and is not covered by the warranty. Repairs should always be performed by an Ergotron service representative or a
qualied electrician.
• Mechanical Loading - Mounting of the equipment in the cart should be such that a hazardous condition is not achieved due to uneven mechanical loading.
There are specic risks associated with the use of Cart when moving or stationary (for charging or storage). You must be aware of, and avoid these risks when the Cart is located in
close proximity to children.
WARNING: Failure to observe the following Cart Use Safety notices may result in serious personal injury or equipment damage.
Only Adults should move this cart.
• Do not allow anyone to sit, stand, or climb on the Cart.
• Do not lift the Cart from the bottom.
• Do not block the vent openings. To prevent overheating, leave at least 127 mm (5-inch) clearance around vents.
The Cart is designed to be used indoors only.
• Do not use the Cart to transport or store equipment other than what has been noted in this guide.
• Do not use the Cart to store liquids or cleaning supplies.
• Do not place heavy objects on the Cart surface or shelf.
– The maximum weight capacity of the top surface is 11.4 kg (25 lb).
– The maximum weight capacity of each device shelf is 27.2 kg (60 lb).
Moving the Cart
• Before moving the Cart:
1. Disconnect the power cable from the wall.
2. Make sure the cable is wrapped and secure.
3. Close and lock the doors.
4. Remove items from the top work surface.
5. Unlock the front rotational locking casters.
• Push (do not pull) the Cart for optimum maneuverability and to prevent muscle strain.
• Do not move the Cart across rough, uneven or irregular surfaces such as gravel.
Parking the Cart
Observe these safety alerts for times when the cart is stationary:
• Do not park the Cart in areas of heavy trac.
• Do not run cables through doorways, holes in ceilings, walls, or oors.
• Do not run cables across hallways, classrooms, or other areas where they will be walked on.
• Do not leave Cart unattended in areas where children have access.
• Keep Cart doors closed and locked whenever it is unattended or parked for charging or storage.
• Keep Cart front rotational locking casters locked whenever it is unattended.

3 of 13
888-24-362-G-00 rev. B • 09/17
ENGLISH
CAUTION: Observe all the safety precautions related to the operation and maintenance included in this reference guide! Failure to follow the safety precautions may result
in injury or damage to equipment.
CAUTION: No TV/Monitor to be used on top of cart.
CAUTION: There is no on/o switch on this equipment; the only power disconnect is the AC power cable.
Therefore, the socket outlet should be easily accessible and should be installed near the equipment.
WARNING – Death or serious injury may occur when children climb on audio and/or video equipment furniture. A remote control or toys placed on the furnishing may
encourage a child to climb on the furnishing and as a result the furnishing may tip over on to the child.
WARNING – Relocating audio and/or video equipment to furniture not specically designed to support audio and/or video equipment may result in death or serious injury
due to the furnishing collapsing or over turning onto a child.
There are specic risks associated with the use of equipment having power cables. You must be aware of, and avoid these risks when the Cart is located in close
proximity to children.
WARNING: Failure to observe the following Electrical Safety notices can result in re or death by electric shock.
Electrical: Electrical cables can be hazardous. Misuse can result in re or death by electrical shock.
• Inspect power cables thoroughly before each use.
• Do not use cables that are damaged.
• Insert the plug completely into the outlet.
• Grasp the plug to remove from the outlet.
• Do not unplug by pulling on the cable.
• Do not use excessive force to make connections.
• Do not plug the cable into an extension cable.
• Do not remove, bend or modify any metal prongs or pins of cable.
• Do not drive, drag or place objects over the cable.
• Do not walk on the cable.
• Avoid overheating. Uncoil the cable and do not cover it with any material.
• Do not run cable through doorways, holes in ceilings, walls or oors.
Electrical: Keep the Cart away from water.
• Do not use it when wet.
• Do not place the Cart in close proximity to ammable liquids or gases.
Equipment Electrical Safety
DANGER!
Risk of Electric Shock
DANGER! Electrical cables can be hazardous.
Misuse can result in fire or death by electrical shock.

4 of 13
888-24-362-G-00 rev. B • 09/17
4
310
1
11
5
2
9
8
7
6
1x 1x
4x 36x
4mm
ENGLISH
Front Locking Door Latch with Padlock Bracket
Cord Wrap with Detachable Power Cord
Ergonomic Handle
4”Total-Lock Casters
Control Box and Circuit Breakers
Removable Device Dividers
with Cable Channels and Width Adjustment
Shelves with Height Adjustment
Center Panel with Power Outlets
and Cord pass through openings
Power Adapter Storage Panels
Top Shelf with 1/4” High Lip
Corner Bumpers
1
2
3
4
5
6
7
8
9
10
11
Shelf labels (1-40)
Features & Specifications
Components

5 of 13
888-24-362-G-00 rev. B • 09/17
1
2
d
4mm
abc
a
bc
ENGLISH
Unlock and open front door.
Remove back panel.
a. Unlock with Key.
b. Lift handle up.
c. Rotate handle clockwise.
d. Open door.

6 of 13
888-24-362-G-00 rev. B • 09/17
3
4
a
b
ab
ENGLISH
a. Route device cables into dividers.
b. Route adapters through cart to back of cart and plug into outlets.
a. Insert device into divider.
b. Plug power cable into device.

7 of 13
888-24-362-G-00 rev. B • 09/17
5
6
ab
4mm
ENGLISH
a. Bundle cables and attach bundle to panel with cable tie.
The bundles for the bottom set of outlets are stored on bottom shelf.
b. Replace back panel.
Plug power cord into base of cart and into wall outlet.

8 of 13
888-24-362-G-00 rev. B • 09/17
1
12
2
ENGLISH
How to Remove Dividers
How to Replace Dividers

9 of 13
888-24-362-G-00 rev. B • 09/17
1
2
3
4
5
4mm
ENGLISH
How to Adjust Shelf Height

10 of 13
888-24-362-G-00 rev. B • 09/17
ENGLISH
Power System
120V~ 60Hz. Max Amps: 10A
Physical Dimensions
Height: 106 cm (41.7-inches)
Length: 73 cm (28.7-inches)
Width: 64 cm (25-inches)
Weight (without Mobile Devices) 80 kg (176 lb)
Weight Capacity:
Top Surface 11.3 kg (25 lb)
Shelves (Top, Middle, Bottom) ea. 27.2 kg (60 lb)
Adapter Shelves (ea.) 5.4 kg (12 lb)
Generally compatible with most 13" display devices and
some 14" devices.
Environmental
Temperature range:
Operating 0° to 30°C (32° to 86°F)
Storage -29° to 60°C (-20° to 140°F)
Relative humidity (maximum):
Operating 10%–90% (non condensing)
Storage 5%–95% (non condensing)
Altitude (maximum): 2000 m (6,562 ft)
Specifications
Elevated Operating Ambient - Consideration should be given to installing the cart in an environment
compatible with the maximum ambient temperature Tma of 30 degree C.
Operational Storage
-29 °C
-20 °F
60 °C
140 °F
Relative
Humidity
Range
5-95% rH
0 °C
32 °F
30 °C
86 °F
10-90% rH
Relative
Humidity
Range

11 of 13
888-24-362-G-00 rev. B • 09/17
ENGLISH
Troubleshooting Guide
There is no switch or indicator light.
The best option is to use a electrical test meter or something like a lamp.
There are 3 outlet banks(channels) with only one channel on at any time. The power control module sequences through each of the 3
channels at ~6 minute intervals starting at the top, then middle and bottom last, then going back to the top bank.
The devices are all plugged in, but they won’t charge. What do I do?
First disconnect the main power cord from the wall and inspect the cord and plug to make sure that they’re undamaged. Plug the cord
into a working power outlet. Next, check the devices: Verify that each device is connected to its power adapter and that each adapter is
plugged into the internal outlet. Look at the circuit breaker and push the button in if it is extended out. Still need some help? Call
Ergotron at 800-888-8458.
Someone tried to break into the unit and damaged a door. Can it be replaced?
Yes, you can order a replacement. Contact Customer Care. We’ll ask you for the cart's model number and whether it’s for the front or
back of the unit.
My power cord/plug is damaged. Are they under warranty?
For warranty information visit: www.ergotron.com/warranty
When I plug in the unit it trips the circuit breaker in my building. Help!
The carts are designed to run on a 15 amp circuit. If you have other items plugged into the same circuit you may be overloading it.
Have a qualified electrician check that adequate power is available.
My unit was damaged during shipment. What should I do?
Please contact Customer Care and we’ll work with you.
How do I find the unit's serial number?
The serial number label is on the outside of the cart, next to the power cord inlet.
Can I remove a bay divider?
Yes! See the instructions - including helpful pictures - on page 8!
How can I make the cart easier to steer?
This cart has two directional lock casters to make the cart easier to steer. How? Directional lock casters don't swivel - they lock the
direction of the casters so they move in a straight line. Press the tabs of these casters (located under the handle) when you need to
move the cart more than a few feet. When you need to maneuver into tight spaces, release the tabs so the casters swivel.

12 of 13
888-24-362-G-00 rev. B • 09/17
ENGLISH
WARNING: Failure to observe the following safety notices may result in serious personal injury or equipment damage.
Inspect for damage, dirt and debris on a regular basis. All paint and plastic components used in the Cart will withstand cleaning by most
commonly used, diluted, non-abrasive solutions such as quaternary ammonia compounds, ammonia enzyme cleaners, bleach, or alcohol
solutions. It is recommended that any cleaning solution be tested on a small, inconspicuous area to ensure it does not harm the surface of the
Cart.
• Marks from permanent marker, dry-erase marker, and pens can be removed with 91% isopropyl alcohol and a soft cloth.
• Iodine stains can be removed with commonly used cleaners and a soft cloth.
• Do not use steel wool or other abrasive materials that may damage the surface nish.
Electrical: To avoid risk of electric shock, do not expose electrical components to water, cleaning solutions or other potentially corrosive
liquids or substances.
Electrical: Do not immerse Cart or Cart components in liquid or allow liquids to ow into the Cart. Wipe all cleaners o surface
immediately using a damp cloth. Dry the surface thoroughly after cleaning.
Electrical: Do not use ammable cleaners on Cart surfaces.
CAUTION: Adjustment, Service, Replacement - DO NOT attempt to adjust, service or replace any part of the Cart unless directed to do so
through Ergotron-approved documentation (i.e. installation instructions). Only Ergotron, Inc. or an Ergotron-certied entity may adjust, service
or replace Cart components. If any component on the Cart is missing or damaged, the Cart must not be used. Contact Ergotron immediately
to request a replacement part.
CAUTION: Casters - Check casters periodically to make sure they are clean and free of debris that would prevent smooth travel. Avoid
moving Cart across uneven, dirty, or damaged surfaces.
CAUTION: Customer Equipment- Make sure equipment is balanced and installed securely to Cart. Contact Ergotron for information about
moving Cart components.
CAUTION: Changes or Modications not expressly approved by Ergotron could void the user’s authority to operate the equipment.
Cleaning and Maintenance

13 of 13
888-24-362-G-00 rev. B • 09/17
© 2017 Ergotron, Inc. All rights reserved.
All trademarks are the property of their respective companies. Anthro is a registered trademark and brand of Ergotron Inc.
Anthro-DNA is a trademark of Ergotron Inc.
ENGLISH
FCC Compliance Statement
This has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used
according to the instructions, may cause harmful interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which
case the user will be required to correct the interference at their own expense.
Operation of this equipment is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
FCC Caution: Changes or Modications not expressly approved by Ergotron could void the user’s authority to operate the equipment.
This Class A digital apparatus complies with Canadian CAN ICES-3(A)/NMB-3(A). / Cet appareil numérique de la classe A est conforme à la norme CAN ICES-3(A)/NMB-3(A) du Canada.
Regulatory Information
For local customer care phone numbers visit: http://contact.ergotron.com
For Service visit: www.ergotron.com
For Warranty visit: www.ergotron.com/warranty
NOTE: When contacting customer
service, reference the serial number.
Table of contents
Other Ergotron Batteries Charger manuals

Ergotron
Ergotron YES 40 User manual

Ergotron
Ergotron Tablet Management Cart / Module User manual

Ergotron
Ergotron PowerShuttle User manual

Ergotron
Ergotron DM12-1006 Instruction Manual

Ergotron
Ergotron Adjusta YES24 User manual

Ergotron
Ergotron Zip12 User manual

Ergotron
Ergotron Zip40 User manual

Ergotron
Ergotron Yes 20 User manual

Ergotron
Ergotron LTSC30 Series User manual

Ergotron
Ergotron LiFeKinnex FBC-1116 User manual
