Erica Synths BLACK User manual

THANK YOU FOR PURCHASING THIS
ERICA SYNTHS BLACK SERIES
MODULE! These are high-end modules
with unique functionality. Only the
highest quality components are used
and all inputs and outputs are
protected against undesired
overvoltage. When designing the Black
Series, we did not economise on the
module width, we put design and
usability first. Big knobs are assigned to
functions that make dierence in sound.
The Erica Black series are a range of
modules that together make an entire
synthesizer. Enjoy!
THE Erica Black Output Module is a
high quality output mixer and stereo
panner with balanced outputs and
headphone amplifier for monitoring
your modular masterpieces. All inputs
are buered, we use stereo
potentiometers (found in high quality
studio mixers) for panning, IN3 has a
CV controlled autopan function. You will
find 6.3mm jacks for balanced outputs
and headphones.
SPECS:
Input level………………….............-10V - +10V
Pan CV input level……......………-10V - +10V
Phone amp out power ..................100mW
Power consumption…..... +65mA, -45mA
Module width………...............……………14HP
Module depth……….........……………..30mm
BLACK OUTPUT MODULE
These knobs are for manual
stereo panning for INPUT1
and INPUT2
These knobs adjust input
signal level
Patch audio signals form
three dierent sources
here!
Apply INPUT3 panning
CV here!
INPUT3 has CV controlled
autopan option, and this
knobs attenuates panning
CV level
Adjust master output
level
Adjust phones volume
independently from
master level
Plug monitor
headphones with
6.3mm jack here!
These are balanced
outputs for Left and
Right stereo channels

Please follow the instructions for use of this Erica
Synths module below, ‘cause only this will guarantee
proper operation of the module and ensure
warranty from Erica Synths.
Water is lethal for most of the electric devices, unless
they are made waterproof. Erica Synths module is
NOT intended for use in a humid or wet
environment. No liquids or other conducting
substances must get into the module. Should this
happen, the module should be disconnected from
mains power immediately, dried, examined and
cleaned by a qualified technician.
Do not expose the module to temperatures above
+50° C or below -20° C.
Transport the instrument with modules installed
carefully, never let it drop or fall over. Warranty does
not apply to modules with visual damages.
The module has to be shipped in the original
packaging only. Any module shipped to us for
return, exchange and/or warranty repair has to be
in its original packaging. All other deliveries will be
rejected and returned to you. Make sure you keep
the original packaging and technical
documentation.
You will find Erica Synths terms of warranty at
www.ericasynths.lv.
Items for return, exchange and/or warranty repair have
to be sent to: Erica Synths Andrejostas Str. 4a, room T8-C,
Riga, Latvia, LV-1045
This device complies to the EU guidelines and is
manufactured RoHS conforming without use of led,
mercury, cadmium and chrome. Nevertheless, this device is
special waste and disposal in household waste is not
recommended.
Designed and made in Latvia.
User manual by Girts Ozolins@Erica Synths.
Design by Ieva Andrupe.
Copying, distribution or any commercial use in any way is
prohibited and needs the written permission by Erica Synths.
Specifications are subject to change without notice.
In case of any questions, feel free to contact us through
www.ericasynths.lv or via e-mail [e-mail].
CHECK THE DEMOS OF OTHER ERICA SYNTHS
MODULES ON WWW.ERICASYNTHS.LV
SAFETY INSTRUCTIONS
