Eryone ER-20 Operator's manual

Eryone ER-20
Quick Starter Guide
Shenzhen Eryone Technology Co.,Ltd

Quick Assembly Overview
1. Base Frame
2. Printing Surface
3. Extruder
4. Gantry Frame
5. Ery Sensor
6. Extruder Stepper Motor
7. SD Card Slot
8. Power Switch
9. Power Cable Port
10. LCD Screen
11. USB Cable Port
12. Filament Spool Holder
11

Prepare
1. Base Frame Half Assembly
2. Gantry Frame Half Assembly
3. Lead Screw
4. All-in-One Toolkit Pack
1 2
3 4

Tools and Accessories
Tool
•Slant Edge Scraper
•Shear Cutter
•Cross Screwdriver
•7# Wrench
•19# Wrench
•M3 Hex Key Allen Wrench
•M4 Hex Key Allen Wrench
•M5 Hex Key Allen Wrench
Assemble Accessories
•M5X35 Round Head Hexagon Socket Screw
•M4X16 Round Head Hexagon Socket Screw
•M3X6 Cap Head Hexagon Socket Screw
•M5 Spring Pad
•Glass Hot Bed Clips
•Knob
•Filament Spool Holder
USB Cable
Power Cable
Accessory Gifts
•Nozzle Cleaner Needle
•M3 x 6 Cap Head Hexagon Socket Screw
•M3 x 12 Cap Head Hexagon Socket Screw
•Blue Inner BoreTube Connector
•Black Inner Bore Tube Connector
•Nozzle
•Belt Fixing Copper Plate
•8G Micro-SD Card
•Card Reader
•Belt
•Teflon Tube
•Filament

Assembly
You can find the assembly video of Eryone ER-20 from here:
https://www.youtube.com/c/Eryone3D
Step 1: Assemble the Gantry Frame
1. Assemble the Lead Screw: Take out the T8 x 8 lead screw and gantry frame
parts, and insert the lead screws through the lead screw copper nuts by rotating.
2. Assemble the Extruder: After assembling the gantry frame parts, take out
your M3X6 screws, use the hex key allen wrench to fix the extruder.
3. Assemble the Gantry Frame: Prepare the gantry frame parts, base, M5X35
round head hexagon socket screw x 4, M5 hex key allen wrench.
•M5X35 round head hexagon
socket screw at the bottom
•Insert the lead screw
and tighten the screw

4. Connect Flat Cables: According to the cable mark, connect the bus, E0
and X-axis motor cable.
5. Assemble the Filament Spool Holder: Prepare the filament holder, M4
x 16 round head hexagon socket screw x 2, M4 hex key allen wrench, and
put the filament spool on the holder.
E0
Bus
X

Test Before Print
Click “Motion” → “Auto Home” to execute the homing (home position: on the
left side of the bed).
Choose “Temperature” → “Preheat PLA”. Observe the temperature of nozzle
and bed.
Choose “Motion” → “Disable Stepper”. After unlocking the motor, we move it to
the center of the X axis.
We observe and judge whether the two ends of X axis get the same reading on the
scale mark bars (on the left and right sides). (You can skip this step if your printer
already has the same reading on the two sides.) Now,start your calibration and
rotate the couplings simultaneously till the two ends of X axis get the same reading.
-Movement test
-Preheat hotend and heated bed

Choose “Configuration” → “Calibrate Z”. Choose “Yes”.
After you finish the homing, the Z axis height of the nozzle displays on the LCD
in real time. Now turn down the height of the nozzle. Place the A4 paper
between the nozzle and the glass platform. After that, you can push and pull
this paper till you can fell the slight friction. Otherwise, you need to
recalibrate Z axis.
Printing
The printeris nowready to print, we can print the test gcode at first.
1) You need to insert the SDcard to printer.
2) Then click LCD button→Print fromSD card→Select “Test_1.gcode”
Aftertest model is complete. You need to learn howto slicetill files to be able to
print your ownmodel.
If you want to learn more about 3d print. You can refer to “Eryone ER-20 User Manual”.
-Calibrate Z Axis
