Esp Apwifids2 User manual

x 1

Power Adapter DC Power Cable

x 1

Black

Red

Dry/Wet Contact Cable

x 2

Black

Screw Pack

x 1

Screw Pack

x 1

Quick Start Guide

Door Station &

MicroSD

x 1

Wall-Bracket

x 1

HARDWARE OVERVIEW

I/O Pin Connector

1.B2/B1: Dry Contact I/O for door lock

2. V-/V+: Power Input I/O*

3. RD+/RD-/TD+/TD-: Ethernet Cable I/O*

4. C2/C1: Dry Contact I/O for door chime

Reset Button

Memory Card Slot

Push Button

Microphone

Light sensor

*Power input jack can be safely connected

with DC 9~48V power cable in any polarity.

AC power input not supported.

*Ethernet cable not included in the package.

Full HD Camera

Speaker

1. Fasten the wall-mount bracket to the wall by using 2pcs screws provided.

2. Connect power cable to the power input I/O pins by through the water-resistant cover.

3. Place the device on the wall-mount bracket.

4. Apply power to the device

1. The SD card will be pre-installed, if upgrading the SD card:

2. Slide the metal housing down and camera up to seperate the camera with back cover.

3. Remove the rubber cover of the SD Card slot on the left side of the camera.

4. Insert the SD Card and put back the rubber cover.

INSTALLATION

21 3 4

Note:

Battery AA 1.5V

x 3x 1

Door Chime

4 2 1

QUICK START GUIDE

APWIFIDS2 APWIFIDSBLK2

INSTALLATION OVERVIEW

Prior to installation, please ensure that a strong and stable Wi-Fi signal

can be achieved at the installation position. A 2.4GHz Wi-Fi connection is required

For additional guidance refer to the notes in the back of this guide.

Power cable

Water-resistant

cover

1 2

4. After supplying power, the boot up process will begin (around 2 minutes),

the push button LED will flash once the boot up process is complete and registration ready

(check connectors and power source if red LED do not come on).

CONTENT

3. System Setup via APP

name starting with HD-XXXXXX (xxxxxx=Camera ID numbers).

Enter the default password 12345678 if required.

2. Launch the app and tap “+” to add the device.

3. Follow the on screen instructions to complete the registration

process.

Note: If the Door Station fails to add several times please press and hold the “Reset” button for

5 seconds to reset it, before the next attempt at system setup.

(1) After complete the Wi-Fi setup procedure on Door Station.

(2) Insert three pieces of AA batteries into the Door Chime.

(3) Adjust the desired volume of Door Chime by pressing the volume key on the side of

the Door Chime.

(4) Select the desired melody by pressing the melody key on the side of the Door Chime.

(5) Open APP and go to advanced settings, and chooes Sensor Setup, then tap

and tap Door Chime icon.

(6) Remove and reinsert the batteries into the

Door Chime to start pairing process

(you have 30s to complete this action),

the blue LED will flash until pairing is complete.

(7) Once the Door Chime has paired to the video

door phone; Door Chime will ring with the ringtone

melody which you have chosen, showing the paring

is now completed.

(8) Name your device and tap “Next” to complete the pairing.

SETUP THE DOOR CHIME W/ DOOR STATION

Adjust volume

Melody selection

LED indicator

1. Go to the Wi-Fi setting in your smartphone. Choose the Wi-Fi

APP DOWNLOAD AND INSTALL

- Please download and install the "ESP Smart” APP to your device.

Live Preview

Advanced Menu

Default security code: 123456

Default admin password: 123456

Both default codes need to be changed for full functionality,

in addition, after set up is complete the system will undergo initialisation for the first 2-3 minutes.

Lorem ipsum

BEST PEFORMANCE NOTES

Network Connection

Wi-Fi devices rely on a strong and stable signal from the network. Performance and reliability of Wi-Fi devices can become unpredictable if the signal strength

is not sufficient for whatever the reason.

If Wi-Fi signal is a possible issue, one solution is the numerous Wi-Fi signal enhancing devices on the market to improve a network’s performance or reposi-

tion the device to improve signal.

In addition, network connection for all devices (Wi-Fi or LAN) is limited by the bandwidth allowance of the network, ensure that the bandwidth is suitable for the

number of devices which are being supported.

Please note; APERTA requires 2.4GHZ Wi-Fi signal band.

APP Connection

Viewing from a mobile phone relies on a strong mobile or Wi-Fi signal.

It is recommended that the APP is left running in the background in order to benefit from the best performance.

General

ESP are unable to guarantee that every device on the market will be compatible with any ESP product and software supplied.

Specific models of phone, tablet or other device, the hardware it contains, the updates installed, APP store requirements, the service provider, the type of data
