Etac Molift Smart 150 User manual

Molift Smart 150
BM09299 Rev. A 2021-01-27
Contents
User manual - English - 3
Gebrauchsanweisung - Deutsch - 19
Brukermanual - Norsk - 35
Bruksanvisning - Svenska - 51
Käyttöohje - Suomi - 67
Manual utente - Italiano - 83
Manual d`utilisation - Francais - 99
Manual de usuarioo - Español - 115
Handleiding - Nederlands - 131
Brugsvejledning - Dansk - 147

Molift Smart 150
EN - User manual
BM09201 Rev. G 2021-02-02
User manual - English

4
Molift Smart 150 / www.etac.com
Important
This user manual contains important safety
instructions and information regarding the use of
the lifter and accessories.
In this manual the user is the person being lifted.
The assistant is the person operating the lifter.
Warning!
This symbol indicates important
information related to safety.
Follow these instructions carefully.
Read User Manual before use!
It is important to fully understand
the content of the user manual
before attempting to use the
equipment.
Visit www.etac.com for download of documenta-
tion to ensure you have the latest version.
English manual

5
Molift Smart 150 / www.etac.com
ENNO DEFR ITES FI SVNLDA
Molift Smart 150
Molift Smart 150 is a foldable mobile lifter
intended for lifting and transferring a person from/
to bed, floor, chair, wheelchair or toilet with a
sling. The lifter is made of light-weight materials,
has castors and electric actuator and is powered
by a battery. It has manual adjustable legs and a
lifting capacity of 150 kg ( 330 lbs).
It is ideal for hospitals and institutional care
settings, and can also be used in privates homes.
The lifter should only be used for transfers across
short distances, such as between a chair and a
bed or into bathroom / rest room. The lifter is
not intended to transport the user over longer
distances.
About Molift Smart 150
Lifter components:
Lifting arm
Push/pull
handles
Motor /
actuator
Emergency
stop
Legs
Electric
emergency
lowering
Chassis
Suspension
Battery
Lifting
column
Manual
emergency
lowering
Hand
control
Wheel / castor
(rear with brake)
Battery
indicator
Pedals for leg
adjustment
Locking handle
Service
indicator

6
Molift Smart 150 / www.etac.com
Product label
The Product labels barcode contain article number,
serial number and production date.
Warning labels and symbols
Symbols used on the product, explained in more
detail:
Product identification
General
Declaration of conformity
The Molift Smart 150 and related accessories described in this operator manual are CE
marked in accordance with EU Council Directive 93/42/EEC concerning medical devices, class
1, and has been tested and approved by a third party according to standards IEC 60601-1, IEC
60601-1-2 and NS-EN ISO 10535:2006.
Conditions for use
Lift and transfer of a person will always pose a certain risk, and only trained personnel are allowed to
use the equipment and accessories covered by this user manual.
Modifications and use of components made by other manufacturers.
We recommend only using Molift components and spare parts. Declaration of conformity is not valid
and Etac is not responsible for warranty if any modifications are made to the product. Etac shall not be
liable for faults or accidents that can occur when using components made by other manufacturers.
Only certified personnel are allowed to open lifter or accessories to perform service
or repair. Risk of injury from rotating parts and electric shock.
The lifter is not intended to be operated by the person being lifted.
Warranty
2-year warranty against defects in workmanship and materials of our products.
For Terms and conditions, see www.etac.com
Type BF applied part Battery light
CE marked
60601-1
Certification body mark
Refer to user manual Manufacturer
Indoor use only
YYYY-MM-DD
Date of manufacture
Do not dispose in
general waste Catalogue number
Emergency lowering Serial number
Service light Medical Device

7
Molift Smart 150 / www.etac.com
ENNO DEFR ITES FI SVNLDA
Safe Working Load (SWL)
150 kg (330 lbs)
Weight of unit
Ex. battery: 25 kg / incl. battery: 25,8 kg
Battery:
Art: 0541000
14.4 V NiMH 2.6 Ah
Battery charger:
100-240 V AC, 50-60 Hz
0,9 A output
Lifting speed
50,7 mm/second (1.99 inches/second)
with 75kg (165 lbs) load
Protection class
Hand control IP24
Lift motor IP24
Maximum A-weighted sound power level
LWA = 49,4 dB
Operating forces button
Buttons on handset: 3.4 N
Material:
Aluminum, plastic, steel
Motor
Lifting motor/actuator: 12 V DC
Turning diameter:
1300 mm (51,2 inches)
Number of lifts with fully charged battery:
40 lifts ( 75 kg / 165 lbs, 50 cm / 20 inches)
Expected Lifetime:
The lifter has an expected lifetime of 30 000
cycles or 10 years.
Measurements folded (LxWxH):
1160 x 475 x 355mm (45.66 x 18.7 x 14”)
Technical data
1 Highest position 1860mm
2 Maximum reach position 1260mm
3 Lowest position 400mm
A Maximum reach at 600 mm 610mm
B Maximum reach from base 630 mm
C Reach from base with legs spread to 700 mm 240mm
D Base height 105mm
E Base clearance 45mm
F Min. distance from wall to CSP (1) 455mm
G Min. distance from wall to CSP (2) 200mm
H Min. distance from wall to CSP (3) 885mm
K Maximum height of CSP 1880mm
L Minimum height of CSP 410mm
M Hoisting range 1450mm
P Maximum internal width 925mm
Q Internal width at maximum reach 860mm
R Minimum internal width 545mm
Fig 1,12,14 ISO 10535
w=700
h=600
CSP
1665 mm
(65
/in )
1905 mm (75in)
1030 mm (40
/in
)
925 mm (36
/in
)
660 mm (25
/
)
545mm (21
/in
)
820 mm
(32
/in )
1180 mm
(46 /in )
1065 mm
(41
/in )
530 mm
(20
/in )
215 mm
(8
/in )
1315 mm (51
/in
)
1200 mm (47 /in )
W190mm
7 / in
110mm
(4
/in )
1860 mm (73
/in )
1260 mm (49
/in )
400 mm (15
/in )
610 mm
(24
/in )
630 mm
(24 /in )
240 mm
(9
/in )
455 mm
(17
/in )
200 mm
(7
/in )
885 mm
(34
/in )
1880 mm (74
/in
)
410 mm
(16
/in )
1450 mm (57
/in
)
860 mm
(33
/in )
545 mm
(21
/ )
1 Highest position:
2 Max reach:
3 Lowest position:
1
2
3
475 mm (18
/
)

8
Molift Smart 150 / www.etac.com
Assembly
Charge the battery. The battery must not be in
the battery holder on the lifting column during
assembly or folding.
Assembly
Remove the transport elastic band.
Engange the break on the rear castors by step-
ping on the left pedal set. Open the legs.
Lift up the lifting column and slide it down into
the bracket on the chassis. Make sure it is placed
completely in the bottom of chassis.
The column must be fixed with the locking handle
on the back of the chassis. Pull the suspension
out of the transport hook
Be careful not to get legs/arms/hands
caught between the parts when rais-
ing/folding down the lifting column.
Battery and Hand control
1. Connect hand control to bottom of battery
holder.
2. Insert battery with terminals facing down.
3. Pull out elastic band and guide hand control
through. Pull some of the cable through so
the hand control does not fall to the floor
when dropped.
Folding (Transport mode)
Run the lifting arm all the way down, and remove
battery. Fold the lifter in reverse order of assembly.
Fix the suspension back into the hook.
It is possible to split the lifter into two separate
parts by lifting the column from the chassis
completely.
Checklist after assembly
Do not use the product until you
have checked all points in the
checklist below
Use this checklist to verify that the lifter is properly
installed and can operate correctly and safely
before use.
Ensure that the lifting arm, lifting column and
suspension are properly fixed and that there
are no loose parts on the lifter.
Make sure battery is charged (no lights on the
battery indicator).
Check that the lifter has no apparent damage
or other faults.
Perform a lift with load (approximately 50 kg)

9
Molift Smart 150 / www.etac.com
ENNO DEFR ITES FI SVNLDA
How to use Molift Smart 150
The hand control has 2 buttons, one for lifting
and another for lowering of lifting arm. The
hand control has an indicator that will illuminate
when battery level is low and the battery requires
charging.
Hand Control 2 buttons
Art. no. 0440002
Lifting Arm - Up / Down
Leg spread mechanism is mechanical, and oper-
ated by two pedals. One pedal for legs inwards
and one pedal for legs outwards. Step on selected
pedal to open or close legs.
Legs - In / Out
NB! Open legs provides increased stability and
better access to chair or toilet.
Hand control
General safety precautions
Use only accessories and slings that are adjusted to
fit the user, type of disability, size, weight and type
of transfer.
Working pause ratio/Duty Cycle.
Molift Smart 150 should not be run constantly for
more than 2 minutes (with maximum load), and
rest for minimum 18 minutes.
Duty cycle 10% intermittence.
Safe working load (SWL)
The lifter is marked with Safe Working Load (SWL)
The lowest SWL shall always be used
if safe working load (SWL) differs
between lifter, suspension and body
support unit
Molift lifters shall only be used to lift
persons. Never use the lifter to lift or
move objects of any kind.
Inspection to be performed daily or before use:
Make sure lifter has no visible damage, defects
or deformations
Make sure battery indicator is not illuminated
and service indicator is green
Make sure wheels are rolling freely and lifter is
easy to manouvre
Inspection to be performed monthly:
Test all the lifters functions and make sure
lifter does not make any abnormal sounds
Test emergency stop button and emergency
lowering
If there are any faults or defects, the lift needs to
be taken out of operation and marked ”out of
order”
Before use / Daily check / Monthly

10
Molift Smart 150 / www.etac.com
Safety devices
Molift Smart 150 is equipped with several safety
devices, which are intended to prevent damage to
personnel and equipment in the case of incorrect
use.
The lifter has an overload sensor preventing the
lifter to be operated if the load exceeds SWL.
The lifting arm is hinged to prevent the arm
and suspension from squeezing the user. The
actuator will not produce any force when moving
downwards.
The legs are folded together during transport to
make the lifter as small as possible. When assem-
bling the lifter, the legs must be opened to work-
ing position. The lifting column will not fix into
the bracket if the legs are not adjusted beyond
transport position - a safety feature ensures this.
The electronics are disabled if overheated. Wait
until the lifter has cooled down before using it
again.
Push / Pull handles
Use the pull handles to move the lifter.
Do not push or pull the user,
lifting arm or actuator.
This may cause instability and
lifter may tip over.
The lifter shall only be used for movement
over short distances. It is not a replacement
for wheelchair or similar.
Brakes
Rear castors are equipped with brakes. Step on
pedal to lock brakes. Flip up to unlock.
Emergency Stop / Emergency lowering
Emergency stop
The emergency stop shuts off the power when
pushed in. Turn clockwise to reset (OK to operate
when the green ring is visible).
Electrical emergency lowering
Push and hold button for electrical emergency
lowering to lower lifting arm. The electrical emer-
gency lowering function does not work when the
emergency stop is activated.
Manual emergency lowering
Pull handle on the actuator upwards to start
emergency lowering, and the lifting arm moves
downwards when loaded. The lowering will
increase in speed the higher the handle is pulled.
Release the handle gently. Releasing the handle
too quickly may cause person injury or damage to
the lifter.
The manual emergency lowering function on the
actuator should only be used when the electrical
emergency lowering does not work.
Emergency
stop
Electrical
Emergency
lowering
Manual
Emergency
lowering
