ETC Desire series User manual

Part Number: 7410M1200-1.8.0 Rev: G
Released: 2017-11
Desire®Series by ETC
D22, D40, D40XT, D60, D60X
User Manual
Version 1.8.0

ETC
®
is a registered trademark of Electronic Theatre Controls, Inc. in the United States and other
countries.
All other trademarks, both marked and not marked, are the property of their respective owners.
ETC intends this document, whether printed or electronic, to be provided in its entirety.This
product is intended for professional use only. Read this entire document before using this product.
This product is protected by one or more of the following U.S. patents: 6,016,038, 6,150,774,
6,788,011, 6,806,659, 6,683,423, 7,023,543, 8,384,294, 8,403,523, 8,593,074, 8,633,649,
8,723,450, 8,878,455, and 9,041,308.
This product is protected by one or more of the following EU patents: 2638781 and 602011015730.
Other US and international patents pending.

Table of Contents i
Table of Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . 1
Quick Setups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Vivid, Lustr+, Fire and Ice, Studio HD . . . . . . . . . . . . . . . . . . . .1
Studio Daylight and Studio Tungsten . . . . . . . . . . . . . . . . . . . .1
Models. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Applications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Document Conventions . . . . . . . . . . . . . . . . . . . . . . . . .3
Notices. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Typography Used in This Guide . . . . . . . . . . . . . . . . . . . . . . . . .4
Safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Contacts. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Chapter 1 Quick Start . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Install . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Connect (D40, D40XT, D60, and D60X) . . . . . . . . . . . . .6
Connect (D22 Portable) . . . . . . . . . . . . . . . . . . . . . . . . .6
Connect (D22 Canopy and Track) . . . . . . . . . . . . . . . . .6
Focus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Set DMX Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Quick Color (Vivid, Lustr+, Fire and Ice, Studio HD) . . .7
Quick Setups Menu. . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Quick Setups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Studio Quick Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Advanced Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Chapter 2 Installation and User Interface . . . . . . . . . 10
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Typical Power Consumption (D22) . . . . . . . . . . . . . . .12
Typical Power Consumption (D40 and D40XT) . . . . . .13
Typical Power Consumption (D60) . . . . . . . . . . . . . . .14
Typical Power Consumption (D60X) . . . . . . . . . . . . . .15
Note About LED Fixtures . . . . . . . . . . . . . . . . . . . . . . .16

ii Desire Series v1.8.0 User Manual
Color Rendering Index and Color Quality
Scale Ratings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Mounting Hardware. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Aim Adjustment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
D40, D40XT, D60, D60X, D22 Portable . . . . . . . . . . . . . . . . . .18
D22 Canopy and Track . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Installation Clearances . . . . . . . . . . . . . . . . . . . . . . . . .19
Cooling and Duty Cycle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Dimensions and Hanging Clearances . . . . . . . . . . . . .20
Safety Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Fixture Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Power and Data Cabling Requirements . . . . . . . . . . .22
Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Data (D40, D40XT, D60, D60X) . . . . . . . . . . . . . . . . . . . . . . . .22
Data (D22) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
D40, D60 Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
D40XT, D60X Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . .25
D22 Portable DMX/RDM Connections . . . . . . . . . . . . . . . . . . .25
Termination . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Indicator Lights . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
DMX Addressing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
DMX Profiles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Vivid, Lustr+, Fire and Ice, and Studio HD Profiles . . . . . . . . .27
Studio Daylight and Studio Tungsten Profiles . . . . . . . . . . . .31
Fan Control (D60) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
DMX Footprints and Channel Mapping . . . . . . . . . . .32
D22, D40, D40XT, D60 and D60X (Studio Tungsten and
Daylight) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .32
D22 (Lustr+ and Studio HD) . . . . . . . . . . . . . . . . . . . . . . . . . . .32
D40 (Vivid, Lustr+, Fire, Ice, Studio HD). . . . . . . . . . . . . . . . . .33
D60 (Vivid, Lustr+, Fire, Ice, Studio HD)
D60X (Vivid, Lustr+, Studio HD) . . . . . . . . . . . . . . . . . . . . . . . .33
Quick Color (Vivid, Lustr+, Fire and Ice, Studio HD) . . . . . . . .34
DMX Profile Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .35
Install Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39

Table of Contents iii
Chapter 3 Basic Menu Navigation . . . . . . . . . . . . . . . 40
User Interface Overview. . . . . . . . . . . . . . . . . . . . . . . .40
LCD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .40
Keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .41
Keypad Lockout . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Status Indicators . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Screen Navigation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .42
Status (Home) Screens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .43
Menu Navigation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .44
Chapter 4 Operation. . . . . . . . . . . . . . . . . . . . . . . . . .45
Home Screen Displays. . . . . . . . . . . . . . . . . . . . . . . . . .45
Vivid, Lustr+, Fire and Ice, Studio HD . . . . . . . . . . . . . . . . . . .45
Studio Daylight and Studio Tungsten . . . . . . . . . . . . . . . . . . .45
Main Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
DMX Start Address . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .46
Quick Setups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
Advanced Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
Advanced Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .47
DMX Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .48
LED Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52
Presets & Sequences . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .56
Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66
Local Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .70
Copy All Settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73
Studio Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .73
Vivid, Lustr+, Fire and Ice, Studio HD . . . . . . . . . . . . . . . . . . .73
Studio Daylight and Studio Tungsten . . . . . . . . . . . . . . . . . . .76
Configure D60X using RDM . . . . . . . . . . . . . . . . . . . . .77
Connect using Gadget II. . . . . . . . . . . . . . . . . . . . . . . .78
Connect using a DMX/RDM Gateway . . . . . . . . . . . . .79
Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .79
Error Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .80
Software Updates . . . . . . . . . . . . . . . . . . . . . . . . . . . . .80
ETC Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .80
Routine Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . .81
Appendix A Menu Flow Chart . . . . . . . . . . . . . . . . . . . . 82
Home and Main Menus (Vivid, Lustr+, Fire
and Ice, Studio HD). . . . . . . . . . . . . . . . . . . . . . . . . . . .82

iv Desire Series v1.8.0 User Manual
Home and Main Menus (Studio Daylight and
Studio Tungsten) . . . . . . . . . . . . . . . . . . . . . . . . . . . . .83
Advanced Menu (Vivid, Lustr+, Fire and Ice,
Studio HD). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .84
Advanced Menu (Studio Daylight and Studio
Tungsten) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .85
Presets (Vivid, Lustr+, Fire and Ice, Studio HD) . . . . . .86
Presets Menu (Studio Daylight and Studio
Tungsten) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .87
Sequences and Quick Color Menus
(Vivid, Lustr+, Fire and Ice, Studio HD) . . . . . . . . . . . .88
Diagnostics Menu . . . . . . . . . . . . . . . . . . . . . . . . . . . . .89
Diagnostics Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .90
Diagnostics Recalibrate Fixture . . . . . . . . . . . . . . . . . .91
Appendix B RDM Commands . . . . . . . . . . . . . . . . . . . . 92

Introduction 1
Introduction
Congratulations on your purchase of a Desire Series by ETC product.
Desire’s x7 Color System™ seven-hue technology produces a light and color quality that
conventional LED systems cannot duplicate. This unique color system produces bright, broad-
spectrum whites and intense colors equally well, rendering pigments, objects, and skin tones
in a natural way.
Fire and Ice fixtures use elements of the x7 Color System for superior performance in deep
saturated colors.
Studio Daylight and Studio Tungsten fixtures use high-output white LEDs for maximum
brightness and efficacy. Studio Tungsten interacts very well with incandescent sources, while
Studio Daylight easily replaces a variety of HMI lamps and natural sunlight.
Quick Setups
You can use any one of the Quick Setups and fine-tune settings for either console operation
via DMX protocol or stand-alone operation. For advanced users, an expanded user interface
provides easy navigation to all settings and options.
Vivid, Lustr+, Fire and Ice, Studio HD
Some of the options include:
• Multiple DMX profiles ranging from a simple 3-channel RGB profile to 8-channel native color and
intensity control.
• Multiple dimming curve options.
• Preset colors and sequences for stand-alone operation.
• White point selection; white light and color behavior based on a specific color temperature white
light such as 3200K or 5600K.
• Loss-of-data behavior options.
• Power regulation modes; three output options that offer a choice between maximum light
output for lower duty cycles and maximum thermal stability and output consistency for higher
duty cycles.
Studio Daylight and Studio Tungsten
Some of the options include:
• Multiple dimming curve options.
• Presets and sequences for stand-alone operation.
•Strobe.
• Loss-of-data behavior options.
• Power regulation modes; three output options that offer a choice between maximum light
output for lower duty cycles and maximum thermal stability and output consistency for higher
duty cycles.

2Desire Series v1.8.0 User Manual
Figure-1.1 Components of a D40 Fixture
Figure-1.2 Components of the Rear Panel. D40 and D60 shown.
Figure-1.3 Keypad Button Functions
For more information about the user interface, see User Interface Overview on page 40 .
LED array
Accessory
holder
Yoke
Accessory
retainer
Yoke locking
knob
Safety cable
loop
PUSH
Power In
Power Thru
DMX In
DMX Thru
Status indicators
LCD
Keypad
Light Bulb
Enter
Down
Up
Back
Home

Introduction 3
Models
Each member of the Desire Series product line is unique and optimized for a specific lighting
task. All fixtures feature narrow optics for the longest throws.
Vivid (D40, D40XT, D60, D60X)
• Full 7-color x7 LED array
• Optimized for high-output deep pastels and strong saturated colors—an all-around workhorse
for vibrant color washes
Lustr+ (D22, D40, D40XT, D60, D60X)
• Specialized x7 LED array with 6 colors plus white
• Broad-spectrum color optimized for the best white and light tints across the entire white and
pastel range
• Beautifully illuminates skin tones and other objects—ideal for theatrical lighting
Fire and Ice (D40, D40XT, D60)
• Optimized for saturated colors at the red end (Fire) or blue end (Ice) of the spectrum
• Strongest output for high-intensity washes and theatrical environments
Studio HD (D22, D40, D40XT, D60, D60X)
• Precise mix of warm white and cool white LEDs plus additional strategic colors for fuller spectral
power
• Continuously variable color temperature white light
• Extreme CRI and high-definition illumination of skin tones from 2700K to 6500K
Studio Daylight (D22, D40, D40XT, D60, D60X)
• 5,700K nominal correlated color temperature
•70CRItypical
Studio Tungsten (D22, D40, D40XT, D60, D60X)
• 3,000K nominal correlated color temperature
•85CRItypical
Applications
Document Conventions
Notices
Throughout this manual, the following are used to alert you to notes and safety notices.
WARNING: • Do not link more than nine fixtures when using Power Thru (non-dimming, 100 to
240 VAC, 50/60 Hz). Power Thru is not available on all Desire Series fixtures.
• Up to 32 devices can be daisy-chained together per data run.
•Theaters •Convention centers
•Studios •Theme parks
•Schools •Museums
•Houses of worship •Temporary events
•Hotels •Outdoor (D40XT and D60X only)
Note:
Notes are helpful hints and information that is supplemental to the main text.

4Desire Series v1.8.0 User Manual
Typography Used in This Guide
Menu items and commands you must perform are indicated in bold text. Keypad buttons are
indicated in bold [brackets]. Menu selections or commands appear in bold. For example:
Press []to select Sequences and then press [].
Safety
The Desire series fixtures are intended for professional use only. Read entire User Manual
before using equipment.
CAUTION:
A Caution statement indicates situations where there may be undefined or
unwanted consequences of an action, potential for data loss or an equipment
problem.
WARNING: A Warning statement indicates situations where damage may occur, people
may be harmed, or there are serious or dangerous consequences of an action.
WARNING: RISK OF ELECTRIC SHOCK! This warning statement indicates situations where
there is a risk of electric shock.
WARNING: • Do not mount the Desire series fixture on or near a flammable surface.
• Use the D22, D40, and D60 fixtures in dry locations only, where humidity
does not exceed 90 percent (non-condensing). These fixtures are not
intended for outdoor use. (Only the D40XT and D60X are approved for
outdoor use.)
• Mount and support the fixture only by the primary suspension holes in the
yoke or floor standing yoke.
• Suspend the fixture from a suitable structure using only the hardware
rated for the weight of the fixture.
• In addition to primary suspension, attach a safety cable (ETC Model 400SC
or other approved safety cable or device) to the fixture housing.
Appropriate attachment point (hole) is provided in the protruding tab on
the fixture housing.
• Disconnect the unit from power and from DMX before all cleaning and
maintenance.
• Maximum recommended ambient operating temperature: Ta=40°C (104°F)
• Maximum anticipated external surface temperature: Tmax=80°C (158°F)
• External temperature after 5 minutes of full-brightness operation and
23°C (74°F) ambient: 38°C (100°F)
• External Temperature (steady state achieved) at 23°C (74°F): 70°C (158°F)

Introduction 5
Contacts
If you have questions about your Desire series fixture that are not answered in this manual,
please contact the supplier of your ETC equipment or ETC Technical Services. For general
information, your most convenient resources are the references provided in this manual. To
search more widely try the ETC web site at etcconnect.com.
For technical questions about Desire series fixtures, contact ETC Technical Services directly at
one of the offices listed below. Emergency service is available from all ETC offices outside of
normal business hours.
Please e-mail comments about this manual to: [email protected].
Americas United Kingdom
ETC, Inc. ETC Ltd
Technical Services Department Technical Services Department
3031 Pleasant View Road 26-28 Victoria Industrial Estate
Middleton, WI 53562 Victoria Road,
800-775-4382 (USA, toll-free) London W3 6UU England
[phone] [phone]
[email protected] [email protected]
Asia Germany
ETC Asia ETC GmbH
Technical Services Department Technical Services Department
Room 1801, 18/F Ohmstrasse 3
Tower 1, Phase 1 Enterprise Square 83607 Holzkirchen, Germany
9 Sheung Yuet Road [phone]
Kowloon Bay, Kowloon, Hong Kong [email protected]
[phone]
[email protected]

6Desire Series v1.8.0 User Manual
Chapter 1
Quick Start
This section details the steps for a quick fixture setup. For more comprehensive information, see
Operation on page 45 .
Install
1: Hang or mount the fixture using the provided hardware and approved hardware accessories.
2: Attach an approved safety cable when applicable.
3: Insert secondary lenses with the smooth side out, if desired.
4: Insert additional accessories (top hat, egg crate, etc.) into the holder, if desired.
Connect (D40, D40XT, D60, and D60X)
1: Attach the power cable to the Power In connector.
2: Attach 5-pin XLR cable to the DMX In connector (if using external control).
3: Plug the power cable into AC power (100 to 240VAC, 50/60 Hz) on a non-dimming circuit.
4: Plug the XLR cable (if using) into the DMX source or data daisy-chain.
5: Link additional fixtures via the Power Out and DMX Out connectors using the following
guidelines.
• No more than nine total D40, D60X, or D40XT fixtures on Power Thru.
• Up to 32 device loads on the DMX daisy-chain.
Connect (D22 Portable)
1: Attach 5-pin XLR cable to the DMX In connector (if using external control).
2: Plug the power cable into AC power (100 to 240VAC, 50/60 Hz) on a non-dimming circuit.
3: Plug the XLR cable (if using) into the DMX source or data daisy-chain.
Connect (D22 Canopy and Track)
For installation and connection information, refer to Desire Series D22 Installation Guide . ETC manuals
are available for download at etcconnect.com.
WARNING: Do not link more than nine fixtures when using Power Thru (non-dimming,
100 to 240 VAC, 50/60 Hz). Power Thru is not available on all Desire Series
fixtures.
Up to 32 devices can be daisy-chained together per data run.

Quick Start 7
Focus
1: With power supplied, wait for the fixture to boot up. This will take approximately ten seconds.
2: Press []to open the Presets & Sequences menu.
3: Select Focus and then press []. This turns on the LED array to enable focusing.
4: Adjust the fixture’s position as needed.
5: When focusing is complete, press []to restore the fixture to its original preset.
6: Select []to return to the home screen.
For information about the user interface, see
User Interface Overview on page 40 .
Set DMX Address
1: From the main screen, press []to open the Main Menu.
2: On the Main Menu, scroll to DMX Start Address and then press [].
3: Use []or []to scroll to the desired address.
4: Press []to select the address number.
5: Press []to return to the home screen.
A DMX address is not required if using stand-alone or master/slave control.
Quick Color (Vivid, Lustr+, Fire and Ice, Studio HD)
Quick Color allows you to easily select a color and its intensity from a predefined menu. This feature
overrides any presets or sequences previously selected and is only available when there is no external
DMX signal to the fixture. For a list of available colors, see
Presets (Vivid, Lustr+, Fire and Ice, Studio HD)
on
page 57 .
1: Press the []to access the Presets and Sequences screen.
2: Scroll to Quick Color within the Presets and Sequences screen.
3: Press [].
4: Scroll to Color and press [].
5: Press []or []to select the desired color
6: Press []to commit the selection.
7: Scroll to Intensity and press [].
8: Press and hold []or []to adjust the fixture’s intensity.
9: Press []to commit the selection.
• To set the Intensity to 0, press []. Pressing []a second time will return the fixture to its
previously set intensity.
• If power to the fixture is lost while in Quick Color mode, the fixture will return to the Quick
Color menu when power is restored.
Note:
Exiting the Quick Color menu will return the fixture to the state it was in prior to
entering the menu.

8Desire Series v1.8.0 User Manual
Quick Setups Menu
Various pre-programmed combinations of operational settings are available to quickly get you started.
These settings are specifically created for different situations and are easily accessible on the fixture’s
user interface. Individual settings within each quick setup can be accessed via the Advanced menu in
order to take advantage of all the possible control features.
Quick Setups
1: On the Main Menu, scroll to Quick Setups.
2: Press [].
3: Scroll to the desired setup and then press [].
An asterisk (*) next to the setup name indicates that setup is active.
4: Press []to return to the home screen.
Quick
Setup Description Profile Features
General
• For general lighting
• All-purpose settings for most lighting
applications
• The default setup for the Lustr+ and
Series 2 Lustr
Direct
control
• Standard dimming curve
• Regulated output for brightness
consistency
• Individual color channels plus master
intensity control
• Allows for native color space crossfades
• Output is NOT color-calibrated
Stage
• For theatrical lighting
• Tungsten-like performance and precise
color-control
• Uses the most DMX channels of all
quick setups
HSI
Plus
Seven
enabled
• Incandescent dimming curve
• Regulated output for brightness
consistency
• White point: 3200K
XT Arch
• Longevity and reliability in applications
with limited access and extreme
environments
• High degree of output consistency and
protection against temperature swings
HSI
• Standard dimming curve
• Protected output for high-heat
environments
• Reduced overall brightness
• White point: 3200K
High
Impact
• For concerts and high impact lighting
• Enables quickest response, simple RGB
control and strobe channel for
maximum effect usage
RGB
• Quick dimming response
• Boosted output for maximum intensity
• Reduced consistency of output
• White point: 5600K

Quick Start 9
Studio Quick Setup
From the home screen:
•ToadjusttheIntensity, press []or [].
The range is 0 to 100%.
•ToadjusttheWhite Point, press []or [].
The range is 2700 to 6500K.
•ToadjusttheTint, press []&[]or [].
[]increases magenta and []increases green.
• To return to the Main Menu, press [].
Advanced Settings
1: From the Main Menu press []to scroll to Advanced Settings.
2: Press [].
3: Access the individual settings via additional menus.
4: Press []to return to the home screen.
Once you are familiar with your Desire fixture, you may alter any of the numerous individual settings
from the Advanced Settings menu. For more information, see
Advanced Menu on page 47 .
Studio
• For video or film lighting
• Enables quick, comprehensive control
of white light via DMX or the fixture’s
onboard user interface
• High-quality white-light output
Studio
• Linear dimming curve
• Regulated output for brightness
consistency
• Variable white point 2700K–6500K
• Variable + or – green (tint) with the
Vivid, Lustr+, Fire and Ice, Studio HD
The Studio Quick Setup is operational in
all fixtures for excellent white light
performance. It is the default setting for
Series 2 Daylight HD, Series 2 Tungsten
HD and Studio HD fixtures. In addition,
Studio Quick Setup enables stand-alone
operation from the User Interface on the
back of the fixture if no console is
present.
For more information, see
Studio Settings
on
page 73 .
Quick
Setup Description Profile Features

10 Desire Series v1.8.0 User Manual
Chapter 2
Installation and User Interface
Specifications
Physical
• Rugged die-cast aluminum construction
• Easy-access slots for secondary lenses and
standard 7.5 inch PAR accessories (D40 and
D40XT)
• 5.5 inch accessories (D22)
• 8.875 inch accessories (D60 and D60X)
• Advanced thermal management systems for
long LED life
• Ambient operating temperature:
– D22: 0°C–40°C (32°F–104°F)
– D40XT and D60X: -20°C–40°C (-4°F–104°F)
– D40, and D60: 0°C–40°C (32°F–104°F)
• Continuous operation at 40°C (104°F)
• D40XT and D60X rated IP66 for exterior use
• Hanging yoke standard. Optional yoke and floor
stand available
• D22, D40, D40XT, and D60X models feature
noise-free, fan-less convection cooling for
acoustically sensitive installations
• Available in black (standard), white (optional),
silver, or custom colors (contact factory)
• D60 model features ultra-quiet cooling fan for
use in high ambient temperature situations
• See
Fixture Weight on page 21
• See Dimensions and Hanging Clearances on page
20
Electrical
• 100V to 240V 50/60 Hz universal power input
• Up to nine D60, or D60X fixtures (15A max) may
be linked on Power Thru
• Up to ten D40 or D40XT (15A max) may be
linked on Power Thru
• D22 has 1.8m flying lead with an Edison
connector, no thru
• D40 and D60 models include Neutrik®
powerCON® in and thru connectors
• 5-foot Neutrik powerCON to bare-end power
input lead or parallel blade U-ground (Edison)
connector
(D40, D60)
• Optional 5-foot powerCON to 20A two pin and
ground (stage pin) or grounded 20A twistlock
connector (excluding D40XT and D60X)
• D40XT and D60X model includes a 5-foot power
cable with waterproof IP66 connector
•Note: D40XT has optional power leads available
including Molex to bare end. Please see the
D40XT datasheet for more information.
• Requires power from non-dimmable source
LEDs
• 22 Luxeon® Rebel™ ES LED emitters (D22
Studio Daylight and Studio Tungsten)
• 40 Luxeon Rebel LED emitters (D40 and D40XT
Vivid, Lustr+, Fire and Ice, Studio HD)
• 22 Luxeon Rebel LED emitters (D22 Lustr+ and
Studio HD)
• 60 Luxeon Rebel LED emitters (D60 Vivid, Lustr+,
Fire and Ice, Studio HD, and D60X)
• 40 Luxeon Rebel ES LED emitters (D40 and
D40XT Studio Daylight and Studio Tungsten)
• 60 Luxeon Rebel ES LED emitters (D60 and D60X
Studio Daylight and Studio Tungsten)
• See
Note About LED Fixtures on page 16
• 50,000-hour LED life

Installation and User Interface 11
Optical
• Tight primary field angle of 17°
(Vivid, Lustr+, Fire and Ice, Studio HD)
• Tight primary field angle of 24°
(Studio Daylight and Studio Tungsten)
• Combine linear lenses for desired beam spread
• Secondary lenses available for multiple beam
spread options including round, oblong, and
linear patterns
• Slots for secondary lenses
Color
• Specialized capabilities from different LED array
options based on x7 color-mixing expertise:
Vivid: Optimized for strong, saturated colors at
maximum brightness
Lustr+: x7 Color System array with a high-intensity
white LED for an ideal theatrical wash light
Full range color, with an emphasis on lighter colors
and white
Fire and Ice: Optimized for high-intensity saturated
colors in either the warm, red end of the spectrum
(Fire) or the cool, blue end of the spectrum (Ice)
(not available with D60X fixtures)
Studio HD: Optimized for variable color
temperature white light
• Interacts seamlessly with conventional sources
• Achieves excellent 3200° or any other Correlated
Color Temperature white light from 2000 to
10,000°K (except Fire or Ice) (CCT adjustment
not available on Studio Daylight and Studio
Tungsten)
• Beautifully illuminates skin tones and other
objects
• Deeply saturated colors across an exceptionally
wide gamut
Control
• DMX512-A compliant
• DMX in and thru via 5-pin XLR connectors (D40,
D40XT, D60, D60X)
• DMX in and thru via 5-pin XLR connectors
(Portable) or DMX termination board (Canopy).
DMX in via Eutrac MultiAdapter track adapter
(Track). (D22)
• Onboard user interface with a high-resolution
LCD (not available with D60X)
• Optional DMX-based fan control (D60 only) for
predictable noise levels
• Optional strobe channel
• Stand-alone, studio stand-alone, and console-
free presets and sequences
• Master/slave mode
• Multiple profile options for different levels of
control
• 15-bit virtual dimming engine for smooth, high-
quality theatrical fades
• See
DMX Addressing on page 26

12 Desire Series v1.8.0 User Manual
Typical Power Consumption (D22)
Lustr+
Studio Daylight
Studio Tungsten
Studio HD
100V 120V 230V
Idle Power / Current 7.8W / 0.111A 7.6W / 0.111A 7.4W / 0.094A
100% Boost Power / Current 56.8W / 0.578A 56.5W / 0.475A 55.1W / 0.288A
100V 120V 230V
Idle Power / Current 7.3W / 0.093A 7.2W / 0.091A 7.3W / 0.124A
100% Boost Power / Current 55.2W / 0.556A 55W / 0.462A 53.8W / 0.268A
100V 120V 230V
Idle Power / Current 7.6W / 0.011A 7.6W / 0.011A 7.2W / 0.094A
100% Boost Power / Current 52.4W / 0.532A 51.8W / 0.445A 50.9W / 0.276A
100V 120V 230V
Idle Power / Current 6.7W / 0.095A 6.7W / 0.098A 6.7W / 0.118A
100% Boost Power / Current 55W / 0.555A 54.6W / 0.464A 53.3W / 0.271A

Installation and User Interface 13
Typical Power Consumption (D40 and D40XT)
Vivid
Lustr+
Fire
Ice
Studio HD
Studio Daylight
Studio Tungsten
100V 120V 240V
Idle Power / Current 10.5W / 0.135A 11W / 0.098A 12.7W / 0.078A
100% Boost Power / Current 102W / 1.12A 98W / 0.82A 95.6W / 0.403A
100V 120V 240V
Idle Power / Current 10.3W / 0.125A 10.5W / 0.094A 12.2W / 0.074A
100% Boost Power / Current 104W / 1.16A 102W / 0.861A 99.7W / 0.418A
100V 120V 240V
Idle Power / Current 10.5W / 0.125A 10.8W / 0.096A 12.5W / 0.076A
100% Boost Power / Current 91.2W / 1.02A 88.2W / 0.74A 87.2W / 0.369A
100V 120V 240V
Idle Power / Current 11.0W / 0.123A 11.2W / 0.099A 12.8W / 0.077A
100% Boost Power / Current 104.2W / 1.17A 102.2W / 0.867A 99.5W / 0.42A
100V 120V 240V
Idle Power / Current 11.1W / 0.134A 11W / 0.097A 12.8W / 0.077A
100% Boost Power / Current 106.2W / 1.19A 103.5W / 0.883A 101.3W / 0.426A
100V 120V 240V
Idle Power / Current 10.6W / 0.123A 10.6W / 0.095A 12.4W / 0.076A
100% Boost Power / Current 105.1W / 1.12A 103.3W / 0.878A 100.8W / 0.424A
100V 120V 240V
Idle Power / Current 10W / 0.111A 10.1W / 0.093A 11.9W / 0.075A
100% Boost Power / Current 104W / 1.05A 103.1W / 0.872A 100.3W / 0.422A

14 Desire Series v1.8.0 User Manual
Typical Power Consumption (D60)
Vivid
Lustr+
Fire
Ice
Studio HD
Studio Daylight
Studio Tungsten
100V 120V 240V
Idle Power / Current 7.6W / 0.083A 7.7W / 0.083A 9.2W / 0.087A
100% Boost Power / Current 139W / 1.41A 136.1W / 1.15A 130.3W / 0.549A
100V 120V 240V
Idle Power / Current 7.3W / 0.1A 7.4W / 0.77A 9W / 0.086A
100% Boost Power / Current 143W / 1.46A 140.1W / 1.21A 135.1W / 0.57A
100V 120V 240V
Idle Power / Current 7.9W / 0.105A 7.9W / 0.086A 9.4W / 0.089A
100% Boost Power / Current 129W / 1.35A 126.5W / 1.35A 122.7W / 0.52A
100V 120V 240V
Idle Power / Current 7.3W / 0.095A 7.4W / 0.081A 9W / 0.085A
100% Boost Power / Current 148.5W / 1.53A 147W / 1.28A 140.2W / 0.592A
100V 120V 240V
Idle Power / Current 7.2W / 0.086A 7.3W / 0.082A 8.9W / 0.086A
100% Boost Power / Current 146W / 1.5A 143.7W / 1.24A 138.2W / 0.58A
100V 120V 240V
Idle Power (W) 7.5W / 0.09A 7.6W / 0.084A 9.3W / 0.089A
100% Boost Power (W) 145.5W / 1.48A 142.8W / 1.22A 136W / 0.573A
100V 120V 240V
Idle Power (W) 7.4W / 0.088A 7.5W / 0.083A 9.1W / 0.088A
100% Boost Power (W) 145.8W / 1.49A 143.3W / 1.23A 137.1W / 0.577A
