ETC Releve Spot Mounting instructions

Relevé Spot
User Operations Manual
Version 1.1
Part Number: 2510M1200-1.1.0 Rev: B
Released: 2019-08

To view a list of ETCtrademarks and patents, go to etcconnect.com/ip. All other trademarks, both marked
and not marked, are the property of their respective owners.
ETC intends this document, whether printed or electronic, to be provided in its entirety. This product is
intended for professional use only. Read this entire document before using the product.

Table of Contents
Table of Contents i
Introduction 1
About This Manual 1
Other References 1
Document Conventions 1
Help fromTechnical Services 2
Warranty Service 3
Compliance 3
Declaration of Conformity 4
Safety Notices 5
Storage and Transporting 5
Unpacking Instructions 5
Overview 6
LED Source 6
Color System 6
Optical 6
Iris 7
Rotating Gobos 7
Ani-gobo Wheel 7
Frost 8
Pan and Tilt Movement 9
Pan and Tilt Locks 9
Control 10
DMX512-A 10
User Interface 10

Display 10
Button Controls 11
Auxiliary Battery 11
Power Requirements 11
Input Power Voltage Range 11
Power Receptacle/Connector Specification 12
Environment 12
Acoustic Performance 13
Weights and Dimensions 14
Weight 14
Dimensions 14
Mounting 15
Safety 16
Luminaire Overview 17
Top Level 17
Sub Assemblies 18
Installation 21
Attach Clamp Mounting Rails 21
Spacing Requirements 22
Floor Mounting 22
Rigging 23
Connect Data and Power 23
Connect DMX-512 23
Terminate DMX-512 24
Connect Power In and Thru 24
Power Up 25
Homing 25
User Interface 26
Auxiliary Battery 26
Display 26
ii Relevé Spot User Operations Manual

Button Controls 26
Menu Navigation 27
Status Screen 28
Menu System 29
Control Settings 30
Defaults 30
Options Menu 31
Pan/Tilt 31
LED Output Freq 31
Display 32
Reset Defaults 32
Home/Test 33
Re-home Fixture 33
Fixture Test 33
Lens Cleaning Access 34
Diagnostics 34
DMX Monitor 34
Board Firmware 34
Update Firmware 35
Update Firmware with USB Drive 35
Update Firmware with Push Firmware Feature 36
Advanced 36
Operation 37
DMX Channel Mode 37
DMX Start Address 38
Replace a Gobo 39
Remove the Effects Module 39
Remove a Gobo 41
Install a Gobo 42
Install the Effects Module 43
Table of Contents iii

Maintenance 45
Clean the Fan Filter 46
Remove and Reinstall Covers 47
Remove the Head Covers 47
Reinstall the Head Covers 48
Clean the Lenses 48
Replace the Effects Module 49
Replace the Optics Module 51
Remove the Optics Module 51
Install the Optics Module 53
Remove Clamp Mounting Rails 54
DMX Channel Map 55
Standard 56
Direct 63
Strobe 69
Technical Specifications 76
Source 76
Color 76
Optical 76
Control 76
Electrical 76
Thermal 76
Physical 76
Safety and Compliance 76
Note about LED luminaires 77
iv Relevé Spot User Operations Manual

Introduction 1
Introduction
Congratulations on your purchase of the Relevé Spot automated luminaire fromETC.
Relevé Spot is an LED-based automated spot luminaire that
provides high-quality color control, predictable smooth pan and tilt
control, and unparalleled zoom optics.
Relevé Spot builds on the legendary color control of ETC LED
products and provides a reliable, full-featured automated
luminaire of the highest quality.
About This Manual
This manual provides information required for safe installation,
operation, and scheduled maintenance of the Relevé Spot
automated luminaire. For your safety, read this entire manual prior
to installing, operating, or servicing the Relevé Spot luminaire.
Other References
Relevé Spot videos are available for viewing from the ETC website etcconnect.com/ReleveSpot.
Document Conventions
This document uses the following conventions to draw your attention to important information.
Note: Notes are helpful hints and information that is supplemental to the main text.
CAUTION: A Caution statement indicates situations where there may be
undefined or unwanted consequences of an action, potential for data loss or
an equipment problem.
WARNING: A Warning statement indicates situations where damage may
occur, people may be harmed, or there are serious or dangerous
consequences of an action.
WARNING: RISK OF ELECTRIC SHOCK! This warning statement indicates
situations where there is a risk of electric shock.
All ETC documents are available for free download from our website etcconnect.com.
Please email comments about this manual to [e-mail].

2 Relevé Spot User Operations Manual
Help fromTechnical Services
If you are having difficulties, your most convenient resources are the references given in this
user manual. To search more widely, try the ETC website at etcconnect.com or the ETC support
website at support.etcconnect.com.
If none of these resources is sufficient, contact ETC Technical Services directly at one of the
offices identified below. Emergency service is available from all ETC offices outside of normal
business hours.
When calling for help, take these steps first:
•
Prepare a detailed description of the problem
•
Go near the equipment for troubleshooting
•
Find your notification number if you have called in previously
•
Locate the product model and serial number
•
Know your power source
•
Know your control source
Americas United Kingdom
ETC, Inc. ETC Ltd
Technical Services Department Technical Services Department
3031 Pleasant View Road 26-28 Victoria Industrial Estate
Middleton, WI 53562 Victoria Road,
800-775-4382 (USA, toll-free) London W3 6UU England
[phone] [phone]
[e-mail] [e-mail]
Asia Germany
ETC Asia ETC GmbH
Technical Services Department Technical Services Department
Room 1801, 18/F Ohmstrasse 3
Tower 1, Phase 1 Enterprise Square 83607 Holzkirchen, Germany
9 Sheung Yuet Road [phone]
Kowloon Bay, Kowloon, Hong Kong [e-mail]
[phone]
[e-mail]
France
ETC France
62-64 rue Danielle
Casanova
Saint-Denis Cedex,
F93200
[phone]
[e-mail]

Introduction 3
Warranty Service
ETC warranty terms and conditions are available on the ETC website etcconnect.com.
Compliance
Relevé Spot has been tested to, is listed under, or complies with the following regulatory
compliance and standards:
cETLus
•
Tested to UL 1573 and CSA C22.2 No. 166 - Stage and Studio Luminaires with additional
compliance to UL 8750, LED luminaire
IEC 62471
•
LED Risk Group 1 - the luminaire LEDs do not pose a hazard due to normal behavioral
limitations on exposure
FCC - Part 15 Class A
•
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received; including interference that may cause undesired
operation.
Note: This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to Part 15 of the FCC rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses and can
radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. Operation of
this equipment in a residential area is likely to cause harmful interference, in which
case the user will be required to correct the interference at his own expense.
CE
•
EN 55015:2013 + A1:2015
•
EN 61547:2009
•
EN 61000-3-2:2014
•
EN 61000-3-3:2008
•
EN 60598-2-17:1989
•
EN 60598-1:2015
•
EN 62471:2008
C-TICK
•
N4241

4 Relevé Spot User Operations Manual
Declaration of Conformity
EC DECLARATION OF CONFORMITY
Informational notes: The product(s) named herein have been found to comply with the testing and marking requirements of Australia and New Zealand and are suitable
for importation into those countries.
To ensure Compliance of this product with the stated Directives it must be installed and operated for its intended use according to the manufacturer’s instructions
London, United Kingdom Mr Adam Bennette
(Place of issue) (Name of authorised person)
8th Nov 2018
(Date of Issue) (Signature of authorised person)
Printed 8 November 2018
Page 1 of 1
Declaration:
Previous issue: 8th Nov 2018
Filename: master declaration 2018_2.docx
233 A
We, Electronic Theatre Controls Limited
declare under sole responsibility that the product(s):
Product name:
Relevé Automated luminaire
Product type/model:
Relevé RELSPOT
to which this declara!on relates is/are in conformity with the following Direc!ves by the applica!on of
the quoted Standards.
Low Voltage Direc!ve (LVD) 2014/35/EU:
EN 60598-1:2015 Luminaires. General requirements and tests
EN 60598-2-17:1989 Luminaires. Par!cular requirements. Specifica!on for luminaires for stage
ligh!ng, television, film and photographic studios (outside and indoor)
EN 62471:2008 Photobiological safety of lamps and lamp systems
Electromagne!c Compa!bility Direc!ve (EMCD) 2014/30/EU:
EN 55015:2013+A1:2015 Limits and methods of measurement of radio disturbance characteris!cs of
electrical ligh!ng and similar equipment
EN 61547:2009 Equipment for general ligh!ng purposes. EMC immunity requirements
EN 61000-3-2:2014 Electromagne!c compa!bility (EMC). Limits. Limits for harmonic current
emissions (equipment input current up to and including 16 A per phase)
Class A
EN 61000-3-3:2008 Electromagne!c compa!bility (EMC). Limits. Limita!on of voltage changes,
voltage fluctua!ons and flicker in public low-voltage supply systems, for
equipment with rated current <= 16 A per phase and not subject to
condi!onal connec!on
Restric!on of the Use of Certain Hazardous Substances in Electrical and Electronic Equipment Direc!ve
(RoHS2) 2011/65/EU:
These product(s) do not contain any of the following substances, or they contain trace amounts below
allowable or measureable levels in each component or mechanically separable part:
Lead (Pb), Mercury(Hg), Cadmium (Cd), Hexavalent Chromium (Cr6+),
Polybrominated Biphenyls (PBB), Polybrominated Diphenyl Ether (PBDE)
