ETCR 6100 User manual

CONTENT
Warning....................................................................................................1
I Introduction ...........................................................................................3
II ElectricalSigns....................................................................................3
IVTechnicalSpecifications....................................................................4
VStructure...............................................................................................5
VI LCD Display .......................................................................................5
VII OperatingMethod.............................................................................6
1. Start-up, Shutdown........................................................................6
2. AC/DCmeasurementswitch.........................................................6
3. DCCalibration..............................................................................6
4. CurrentMeasurement....................................................................7
5. PeakHolding.................................................................................8
6. Hold,StorageandAccess Reading ...............................................8
7. DataUpload..................................................................................9
HowtoChangeBattery...................................................................9
ⅨAccessories.....................................................................................10

-1-
Warning
Thankyou forpurchasing ourcompany's HighAccuracyAC/DC Clamp
Leaker,forbetteruseofthisproduct, please:
Readcarefullytheuser'smanual.
Followstrictlysafetyrulesandnoteslistedinthismanual.
uUnderanycircumstances,pleasepayspecialattention toyoursafetyin
the
courseofusing thisleaker.
uGiveheedtolabeltextsandsymbolsonpanelandbackplateofthis
leaker.
uPleasebemorecarefulifthelinevoltageisabove60VDCor30VAC.
uPutthetestedwirethroughthegeometricalcenterofjawwhenmeasuring
ACcurrent,errorwillincreaseifdeviatethecenter.
uPleasedon'tplaceandstorethisleakerinhotand humidcondition,
locationswithmoisturecondensationandunderdirectsunlightforalong
time.
uIncasevoltageofbatterywaslow, pleasereplacebatteries.
uIncasethisleakerwouldnotbeusedforalongtime,pleasetakeout
batteries.
uWhenchanging batteries,pleasepayattentiontopolarityofbattery.
uUse, disassemblyandmaintenanceofthisleakershallbeoperatedby
authorizedpersonnel.
uIncasedangerswouldhavewithcontinuesuseof thisleaker,pleasestop
touseitand sealitforsafekeeping immediately;and then,send itfor
disposalof authorizedagency.

-2-
uUsersshallcarryoutoperation basedon dangersigns ”on leaker
and
manual.
uUsersshallcarryout safetyoperationbasedoninstructionslistedinthis
manual, e.g. ”anddangersignsonthismanual.
uPleaseuse am totestleakagecurrent(testbyclamping groundingline,
single-phaselinetogether).

-3-
I Introduction
High AccuracyClampLeakerisspeciallydesignedformeasurementof
AC/DC current;byadoptingup-to-dateCTtechnologyanddigitalintegration
technology.Thereisno exposedmetalon clamphead,non-contact
measurement,toensuresafeoperation.Itisaproductwithrelativelysmall
size,highaccuracy and perfectfunction comparedwithsimilarleakersinthe
world.Theleakercouldbewidelyappliedinthosefieldsaselectricity,
communications,meteorology,railroad,oilfield,construction,measurement,
scientific&researchteaching institutes,industrialandminingestablishments.
it isanessentialtoolforelectriciansafetytesting
ThisHighAccuracyClampLeakerhavethosefunctionsaspeaking
holding,dataholdinganddatastorage.Itobtainsone RS232 interface,
communication cableand monitoring software,throughwhichon-line
monitoring,historicaldatainquiryisavailable.It alsohavefunctionssuchas
activecurvedrawing,indicationofmax,minandaveragevalue,alarmsetting
and indication,savingtodocumentsandprintingwhenconnectedtoPC.
II Electrical Signs
Extremelydangerous! Operatorsshallstrictlyobservesafety
rules;otherwisetherewouldbedangersofelectricshock to
causepersonalinjuriesorcasualties.
Dangerous！Operatorsshallstrictlyobservesafetyrules;
otherwisetherewouldbedangersofelectricshocktocause
personalinjuriesorcasualties.
Warning！Operatorsshall strictlyobservesafetyrules;
otherwisepersonalinjuriesorequipmentdamagesmightbe
caused.
Doubleinsulation
AC
DC

-4-
. Rangeand Accuracy
Function Range Accuracy Resolution
DC current 0.0A～1000ADC
±2%rdg±3dgt 0.1A
AC current 0.0A～1000AAC
±2%rdg±3dgt 0.1A
(Condition：23℃5℃，below75%rh,wireinthecenterofjaw)
IVTechnicalSpecifications
Function MeasurementofAC/DCcurrent, Peakvaluehold,
On-linemonitoring
PowerSupply Zn-Mndrybattery,6F22,9V
TestMode Clip-onCT，integralmode
DisplayMode FourdigitsLCDdisplay
Dimension LWH：175mm×70mm×38mm
LCD Dimension 35mm×21.5mm；displaydomain：32mm×15mm
SamplingRate 2times/s
Frequency 50/60HzAutomatically
Polarity
Indication DC current autoidentifiedand display ”
ClampSize 30mm×35mm
TestPosition Testedwireinthejawcenter;Errorwillincreaseto
1.5%rdgmaxifdeviatethecenter
RangeShift Automatically
LineVoltage AC600V
RS232 Interface
DatastoredinthememoryofthemeterviaRS232
uploadtoPC,oron-linemonitoring
Com-Configure Baud rate:9600，databit:8，stopbit:1
DataMemory 99units，FULLblinkswhenthememoryisfull
Peak Hold Push HOLD withoutrelease,themeterwill showthe
peakvalueduringthepushing period
ReadingHold DH indicatingthereadingishold
OutofRange OL indicatingthecurrentisoutofrange
AutoPower-off 5Minutesafterpoweron,itwillpoweroff
automaticallytolowerthepowerconsumption
BatteryVoltage Indicatingthebatteryvoltageislowerthan
7.2V.Thenthebatteryhavetobechanged

-5-
Weight 180g（includingthebattery）
Consumption 10mW
Temperatureand
Humidity Working:-10 ～50,below80%rh Storage:-10 ～60,below70%rh
Maxerrorrefer
toenvironment -10℃～0℃,40℃～50℃,Errorwill increasemaxto 1%rdg
Insulating
Strength AC2kV/rms(betweenthealloyof theclampandthe housing)
Applicable
safetyrules IEC1010-1,IEC1010-2-032,Pollutionlevel2,CAT Ⅲ(600V)
VStructure
1. Doubleinputtoroid
2. Toroidopeninglever
3. POWER key
4. LCD
5. RS232 interface
6. Positivedirection
7. HOLD Key
8. AC/DC switchkey
9. DCAZERO Adjust0key
10. Housing Screws(3PCS)
11. Batterycoverscrew
12. Batterycover
VI LCD Display
1.DCindication 2.ACindication
3. Negativepolarityindication
4. Lowbatterysymbol
5. Dataholdindication
6. Storeddatacode

-6-
VII Operating Method
1.Start-up,Shutdown
Press POWER keytostartup,LCDwillbegintodisplay;Press the
POWER keyagain,theleakerwill shutdown.Afterstartingupfor5
minutes,LCDwillflick notesthat theleakerwill shutdownautomatically;
afterflickeringfor30s,itwill shutdownformallytoreducebattery
consumption.Incaseyouhavepressed POWER keywhenLCD was
flickering,theleakerwillcontinuetoworkfor5minutes.If LCDwasvery
darkafterstartingup,itmightbecausedbylow-voltagebattery,inthis
case, pleasechangebatteryimmediately.
2. AC/DCmeasurementswitch
ThetesterdefaulttoDC measurementafterbootup.Press to
switchtheAC/DCfunction.LCDwilldisplayDC orACtocorresponding
switchfunction.
3. DCCalibration
BeforemeasuringDC current,press DCAZEROkeytoreducethe
residualmagnetismtoZero,and thenconductmeasurement.Rational
usageofthisAdjustZerofunctionwill maketheresultsmoreaccurate.
Forexample,afterboot,beforemeasurement, wecan takethe jawclose
totheDC currentwire.LCDwill showaninductivecurrent.Press DCA
ZEROto calibrate, whichdeducttheinductivevalue.Showingbelow:

-7-
4. CurrentMeasurement
High voltage,extremelydangerous!Operatorsshall
strictlyobservesafetyrules;otherwisetherewouldberisk
ofelectricshocktocausepersonalinjuriesorcasualties.
Dangerous Pleasedon’tuseittomeasurecurrenthigher
than300A;otherwisetherewouldberiskofelectricshock
tocause personalinjuriesorequipmentdamages.
1）Poweron
2）Press toDC orACmeasurement. Conduct Adjust Zerobefore
measureDC current.
3）Releasethetoroidlevertoopeninputtoroidandclampmeasured
conductors.Beattentionthatthetwoinputtoroidmustbetotallyclosed
and themeasuringwirepassingthroughthecenterofthejaw.
4)Read LCDdisplaydata.Incase OLam symbolwasdisplayed,it
meansthat current ofmeasuredlineisbeyondthemaximumlimitofthis
leaker;withthiscase,pleasechooseleakerwithmuchhigherrange
limit.

-8-
5. Peak Holding
Pressing HOLD keycontinuallyinthecourseofmeasurement(More
than 3seconds), theleakerwilldisplay PEHd andcapturecurrentpeak
valuesoflinesinthisperiodoftime;releasethekey,itthenwill return
tomeasuringstate.
6. Hold, StorageandAccess Reading
1）Pressing HOLD keyforashorttimeinthecourseofmeasurement
(less than3seconds), DH symbolwilldisplay,theleakerwillhold
currentmeasuring dataand automaticallystoredinthememorywith
acode;press HOLD keyagaintoreleasetheholdstate,and the
leakercontinuesitsmeasuring;incasestoreddatareachedto60
groups, press HOLD keyagain,the FULL”symbolwilldisplay,which
meansstoragememoryisfull;press HOLD keytocancelFULL”
flickeringandreturntomeasuringmode.
Attention!Foryoursafety,whenmeasuringheavy
current,afterconfirmedthecompletionofcorrect
operatingtest,please movetheleakerawayfrom
measuredconductor.
Inlocationswithdifficultytoreadoutdata, please use
thedataholdingfunction.If[DH]symboldisplayed,
pleasedischargedataholdingstatefirst,andthendo
thetest.

-9-
2）Press HOLD+POWER keys toenterintodataaccessmodeand
displayUnit 1storagedataautomatically;and thenpress HOLD key
againtoturnthepageof storeddata; NULL willdisplaywhenthereis
no datainstoredinthememory,press POWER keytoexitdata
access mode.
3）Afterenteringintodataaccess mode,press HOLD keyformorethan
3secondswillclean upallstoreddata;whentheleakerdisplaying
dEL”symbol,itmeansthatithasfinishedcleanup process,and
thenreturntomeasuringstateautomatically.
7. DataUpload
Makegood connectionofcompanywithRS232communication wireof
theTester,switchon theTesterandrun monitoringsoftware,andifthe
softwaredisplaysthatinterfaceisopenandtheconnectionissuccessful,
thenitcan read thestoredhistoricaldata,uploadtocompanyand preserve.
Monitoringsoftwarehasthefunctionofonlinereal-timemonitoring and
historicalinquiry,dynamicdisplay,withthemaximum,minimum,and
averagevalueindication, withalarmvaluesettingsand alarmindicator,and
thefunctionofhistoricaldataaccess,reading,preserve,printand other
functions.
ⅧHowtoChangeBattery
Warning!Itisdangeroustocarryouttestwhenthe
batterycoverplatewasnotonitsposition.
Pleasepayattentiontopolarityofbatterytoavoid
damagingtheleaker.
Chang thelowbatteryintime
Ifnotusethemeterforalongtime,pleasegetoffthe
batterytostorage.

-10-
1）”symbolmeansthebatteryisunderchargeandneedtobe
replaced.
2）Press POWER keytoshutdowntheleaker;beforeopeningthebattery
cover,pleaseconfirmtheleakerisinoffposition,andthen replace
withqualifiednewbattery;specialattentionshallbepaidtopolarityof
battery;at last,coverbatterycoverplate.
ⅨAccessories
Clamptester 1pc
RS232 Comcable 1pc
Software 1disk
Battery（6F229V）1pc
UserManual 1copy
Warrantycard/Certification 1copy

Manufacturedby
ETCR ElectronicTechnologyCo.,Ltd
Address:F-3F,No.4PengshangZhifuRoad,Jiahe,Baiyun
District,Guangzhou,Guangdong,China
PostCode:510440
Tel:(86-20)6219955662199553
Fax:[phone]
E-mail: [e-mail]
Website: www.etcr.cc
