eTIGER S4 Combo Secual User manual

www.etiger.com
Security Kit / Security Kit Plus - S4 Cell + Line
GSM and Landline Alarm System
EN

Features
- GSM/PSTN transmitter
- Supports up to 30 remote controls, 50 wireless accessories and 50 RFID tags
- Can store up to 5 phone numbers, 5 SMS numbers, and 2 CMS numbers (for systems
connected to a Central Monitoring System)
- Arm / disarm the system by SMS, phone call, or App (on iOS or Android)
- Can be disarmed by RFID tag
- Built-in siren (100dB) and call function from the panel
- SMS alerts for power failure, power recovery and low battery
- Audio surveillance of the site from distance
- 2 x 800mAh lithium batteries included (8h battery life in standby mode)
Specications
Product name
Security Kit - S4 Cell + Line
SKU
S4-CL
Control panel power supply
Input: AC 110-240V / 50-60 Hz
Output: DC 12V / 800 mA
GSM working frequency
850 / 900 / 1800 / 1900 mHz
Radio-frequency
315 MHz (±75KHz)
Standby current
110 ma
Alarm current
340 mA
Backup batteries
Lithium Batteries: 3.7V / 800 mAh x 2 (BL-5B)
Internal siren
100 dB
Housing material
ABS plastic
Operating conditions
Temperature: 14ºF ~ 131°F
Humidity: ≤ 80% (non-condensing)
Control panel dimensions (L x W x H)
7.4" x 5.2" x 1.0"
Box Content
S4 Control Panel x1
Motion Detectors x2
Door / Window Contacts x2
Remote Controls x2
RFID Tags x2
PSTN Cable x1
PSTN Adaptor x1
AC Adaptors x1
Documentation x1
Security Kit Plus - S4 Cell + Line
+ IP Camera x 1 (with AC Adaptor and manual)

Quick Start-up

Accessories Safety and Troubleshooting
4
Quick start-up Control Panel Operations SMS Operations
Control Panel Layout (Front)
Call
RFID Tag Reader
Arm
Disarm
Stay (Home Mode)
LCD Display
SOS
LED Status Indicator
(armed / disarmed)
Control Panel Layout (Back)
Monitoring MIC
Speaker
Power Supply Interface
Tamper Switch
Power Switch
Telephone Interface
Battery
Compartment
SIM card Slot
Power On/O
Adapter interface
Electronic lock
VCC
Z1
GND
SP
GND
LOCK P1
Wired siren 500mA
Wired sensors (24h zone)
Output for
wired sensors

Accessories Safety and Troubleshooting
5
Quick start-up Control Panel Operations SMS Operations
Connect your System
The Security Kit - S4 Cell + Line features a dual GSM and PSTN transmitter. This means that the
control panel of your alarm system will communicate with you either through a SIM card (GSM
module) or through your telephone landline (PSTN module).
a. Using the PSTN transmitter (telephone landline)
Connect the smaller connector of the telephone cable
(supplied with your system) to the landline interface
in the battery compartment at the back of the panel.
Connect the other end of the telephone cable to the
signal output provided by your landline carrier or to the
phone connector of your ADSL box.
b. Using the GSM transmitter (SIM card)
Open the battery compartment at the back of the control panel and insert a SIM card in the
control panel.
Important
Before using the Security Kit - S4 Cell + Line in GSM mode, you need to purchase a SIM card that
works on the GSM network with 850 / 900 / 1800 / 1900 MHz frequency. We recommend you
to subscribe to a plan with unlimited texts and one hour of voice. For more information, please
contact your local reseller.
Important
Make sure the SIM card does not require any PIN code. For more information, please contact
your local reseller.
Turning your System On
1. Plug the AC adaptor to an AC socket.
2. Plug the output connector of the AC adaptor into the
adaptor interface in the battery compartment at the
back of the control panel.
3. Turn the power switch to "ON" (in the battery
compartment at the back of the control panel).

Accessories Safety and Troubleshooting
6
Quick start-up Control Panel Operations SMS Operations
Mount the Control Panel
Before mounting the control panel on the wall, make sure the reception of the GSM signal is sucient.
Fix the wall-mounting bracket on the wall with screws. Wedge the panel on the bracket, make
sure they t well.
First Operations
Select GSM / PSTN Mode
Refer to the instructions page 11 to deactivate the mode you do not want to use.
GSM mode only (SIM card required, sold separately): set "LINECUT ALARM" to "OFF"
PSTN mode only (connection to your telephone landline required): set "GSM FAIL TIP" to "OFF"
By default, both GSM and PSTN are activated.
Store a phone number
To interact with the control panel by SMS, by phone call and/or from the app, at least one phone
number must be stored in the control panel. Please refer to the instructions on page 10 of this
manual.
Change the language
By default the language of the S4 control panel is set to English. If you wish to change the
system language, refer to the instructions on page 22 of this manual. "System language"
refers to the language of the SMS you receive from the control panel, and the menu of the
LCD display.
Arm / Disarm the System
The alarm system can be armed or disarmed on the control panel, by SMS, by App and by phone call.
On the control panel: Refer to the instructions on page 9 of this manual.
By RFID tag (disarm only): swipe the RFID tag in front of the RFID reader of the control panel.
To start receiving SMS notications when the system is disarmed by RFID tag, you must store an
SMS number and rename the RFID tags as explained respectively on page 18 and page 19 of
this manual (up to 4 RFID tags can be renamed). If you have stored several SMS numbers, only the
rst number stored will receive SMS notications when your system is disarmed by RFID tag.
By SMS (in GSM mode only):
To arm the system: send “1” by SMS to the number of the SIM card in the control panel.
To disarm the system: send “0” by SMS to the number of your system’s SIM card.
By app (in GSM mode only): Click on“Arm”in the app. The app is available for download on the
App Store and Google Play (more information on etiger.com).

Accessories Safety and Troubleshooting
7
Quick start-up Control Panel Operations SMS Operations
Register Wireless Accessories & RFID Tags
1. Type your admin code followed by“Enter”on the control panel to enter the setup menu.
2. Enter the Connection Mode by navigating through the menu:
"ACCESSORIES" --> "WIRELESS SENSORS" , "RFID TAG" or "REMOTE" --> "ADD A NEW"
3. Trigger the accessory once within the next 15 seconds (for the RFID tag, swipe it in front of the
RFID reader of the control panel). You hear one beep: the registration is successful.
Default admin code is 123456. To change the admin code, refer to the instructions "Admin Code" on page
11.
If the accessory has already been registered, the control panel will beep twice. The rst accessory
registered is assigned to zone 1, the second accessory registered is assigned to zone 2, etc. Zones
1 to 9 can be renamed. Zones 10 to 50 cannot be renamed (refer to the instructions on page 19
to learn how to rename zones).
Speed Dial
Press the Call button“ ”on the control panel for 3 seconds: the panel auto-dials the rst stored
phone number. Press the Call button“ ” to end the call.
Hands-free Phone Call from the Panel
Through PSTN
Press the Call button“”on the control panel, type the phone number you wish to call and press“Enter”.
Through GSM
Press the Call button“”on the control panel, type the phone number you wish to call and press
the Call button“”again.
Hard Reset
Turn the control panel o. Press and hold the " " key while turning the control panel on. Then
enter "123456" on keyboard.
Settings will be restored to default values. Stored phone numbers and connected accessories
will be cleared.

Control Panel Operations

Accessories Safety and Troubleshooting
9
Quick start-up Control Panel Operations SMS Operations
9
Arm the System
Press the Arm button " " on the control
panel. The control panel beeps once: the
system is armed.
Note
If the Entry / Exit Delay is activated, only the
Delay zone will be armed after the delay set
(refer to the instructions on page 11 of this
manual“Entry / Exit Delay”).
Disarm the System
Type your user code and press the Disarm
button " " on the control panel. The control
panel beeps twice: the system is disarmed.
Default user code: 1234
Home Mode
Press the Stay button " " on the control
panel. The control panel beeps once: the
system is armed in Home Mode.
All the sensors assigned to the Normal zone
are armed. The sensors assigned to the
Home zone are disarmed.
For more information on zone setup, please
refer to the instructions on page 14 of this
manual.
Emergency Mode
Hold the “#SOS” button for 3 seconds. The
alarm is triggered immediately and the
siren rings out. At the same time, the control
panel dials the stored phone numbers.
Setup from the Control Panel
The control panel of your alarm system
features an LCD display that enables you to
navigate through the menu of the control
panel and set up your alarm system.
To enter the setting menu, type [your admin
code + Enter] on the control panel.
Default admin code: 123456
In the table on the next page, each column
represents a menu or a sub menu. Each
menu or submenu will be displayed on one
of the two lines of the LCD display. On the
LCD display, the current menu, submenu, or
setting is shown on the line at the bottom,
while the previous menu or submenu is
shown on the line at the top.
Navigate and select the setting you wish
to modify with the keys “ ” or “ ”, and enter
each menu or sub menu by pressing“Enter”.
How to use the keyboard
“ “ = delete
“” = move forward
“ ” = move backward
“Enter”= select / conrm
“Esc” = back / previous step in the menu /
cancel
The tables on the next pages summarize
all the settings that can be accessed and
modied on the control panel.

Accessories Safety and Troubleshooting
10
Quick start-up Control Panel Operations SMS Operations
Main Menu Sub Menu 1 Sub Menu 2 Sub Menu 3 Comments Note
PHONE NUMBERS
PHONE 1~5 IS:

Select the phone or SMS number you want to edit, type in the phone
number and conrm with the key "Enter". Use the key " " to clear.
5 phone numbers, 5 SMS numbers and 2 CMS numbers can be
stored in the control panel.
If you want to set a CMS center phone
number, please refer to the instructions
on page 14 of this manual.
SMS NUM 1~5 IS:
CMS NUM 1~2 IS: 
ACCESSORIES REMOTE
ADD A NEW 
The LCD screen displays “PLS CONNECT 30”: press any button on
the remote control within the next 30 seconds (the countdown is
indicated on the screen after "PLS CONNECT", in seconds). You hear
one beep, the LCD screen displays “ADD OK! REMOTE [01~30]”: the
connection is successful.
DELETE ALL? 1=YES 0=NO
DELETE ONE ENTER 0130: Select the remote control you wish to delete.
ACCESSORIES RFID TAG
ADD A NEW PLS CONNECT
The LCD screen displays“PLS CONNECT 30”: swipe the RFID tag
in front of the RFID reader on the control panel within the next
30 seconds (the countdown is indicated on the screen after "PLS
CONNECT", in seconds). You hear one beep, the LCD screen displays
“ADD OK! RFID [01~50]”, the connection is successful
DELETE ALL? 1=YES 0=NO
DELETE ONE ENTER 0150 Select the RFID tag you wish to delete
ACCESSORIES WIRELESS
SENSORS
ADD A NEW
NORMAL SENSOR
HOME SENSOR
DELAY SENSOR
24 HOUR SENSOR
Select the sensor type you wish your sensor to be assigned to
(Normal Sensor, 24 Hour Sensor, Delay Sensor, or Home Sensor),
press“Enter”to conrm.
The LCD screen displays“PLS CONNECT 30”: trigger the detector
once within the next 30 seconds (the countdown is indicated on
the screen after "PLS CONNECT", in seconds). You hear one beep, the
LCD screen displays“ADD OK! SENSOR 01~50”, the connection is
successful.
For more information on zone setup,
refer to the instructions on page 14.
DELETE ALL? 1=YES 0=NO
DELETE ONE ENTER 0150:
ACCESSORIES TEST MODE 
Trigger the sensors you have previously connected to the control
panel. You hear 1 beep, the LCD screen displays the signals that have
been respectively sent by each sensor triggered. Make sure all the
sensors you have triggered are mentioned on the LCD screen. Press
“Esc” to exit the test mode.
This mode enables you to test if the sen-
sors have been connected successfully
to the control panel.

Accessories Safety and Troubleshooting
11
Quick start-up Control Panel Operations SMS Operations
Main Menu Sub Menu 1 Sub Menu 2 Sub Menu 3 Comments Note
SYSTEM SETTINGS DATE AND TIME YYYYMMDD TIME e.g. 20140620 14H30
SYSTEM SETTINGS ENTRY EXIT DELAY
ENTRY DELAY 000300 This function can be used if you do not want to bring a remote
control or RFID tag with you. When the system is armed, you hear
one beep every second to remind you to leave. The beep rhythm
speeds up during the last 10 seconds. If an intruder is detected, the
alarm will be delayed accordingly.
Time is calculated in seconds. The Entry and Exit Delay can be set
from 0 to 300 seconds.
The entry and exit delay is only for sensors
connected as Delay Zone accessories (see
"Wireless" on page 10).
The Entry Delay gives you time to disarm
the system on the control panel without
triggering an alarm.
The Exit Delay gives you time to arm the
system on the control panel and leave
your home without triggering an alarm.
EXIT DELAY 000300
SYSTEM SETTINGS AUTO ARM / DISARM
AUTO ARM TIME <00:00>
You can set up the system to arm and disarm automatically at a
dened time every day.
Setting Auto Arm and Auto Disarm to
the exact same time will deactivate the
function.
AUTO DISARM TIME <00:00>
ON OR OFF?
SYSTEM SETTINGS CONTROL BY PHONE ON / OFF 
You can activate or deactivate the control of your system by phone
call. Activating the control by phone call enables you to arm and
disarm the system and monitor your home by phone call.
See instructions on page 13 for more
information on the control of the system
by phone call.
SYSTEM SETTINGS LINECUT ALARM ON / OFF 
If the linecut alarm is on, the alarm will be triggered if your
telephone line is down. The rst SMS number stored receives a
notication by SMS (only in GSM mode).
Deactivate this function if you want
to use the alarm system in GSM mode
only.
SYSTEM SETTINGS GSM FAIL TIP ON / OFF Notication of SIM/ GSM signal problem. Deactivate this function if you want to
use the alarm system in PSTN mode only.
SYSTEM SETTINGS KEYPAD TONES ON / OFF Activate or deactivate the sound when typing on the keyboard of
the control panel.
SYSTEM SETTINGS ACCESS CODE
ADMIN CODE 123456 Your admin code enables you to enter the setup menu.
Default admin code: 123456
It is recommended to change all codes
before using your system for the rst
time and to keep your codes secret
USER CODE 1234
Your user code enables you to disarm the system on the control
panel. The user code is the access code requested when you call
the control panel.
Default user code: 1234
DURESS CODE 0000
In case of emergency, when you are requested to disarm the sys-
tem by force, it is recommended to disarm your system with your
Duress Code. The panel will silently dial the stored phone numbers.
Default duress code: 0000
OPEN DOOR CODE 8888 You can open electronic doors using this code. The door must be
wired to the [LOCK] interface on the back of the control panel.

Accessories Safety and Troubleshooting
12
Quick start-up Control Panel Operations SMS Operations
Main Menu Sub Menu 1 Sub Menu 2 Sub Menu 3 Comments Note
SYSTEM SETTINGS RINGING TIMES <09>  This function enables you to determine the number of times the control
panel will ring before taking your call (for control by phone call).
SYSTEM SETTINGS SIREN SETUP
WIRED SIREN
SIREN SWITCH
<ON OR OFF?> Wired siren refers to a siren connected
to the control panel by wire.
ARM/DISARM TONE
<ON OR OFF?>
IN SIREN VOLUME 01 0=MUTE
SIREN ALERT TIME 3 MIN Siren ringing time is calculated in minutes, default setting is 3
minutes. If you set the ringing time to 0, the siren will not ring out.
BUILTIN SIREN
SIREN SWITCH
<ON OR OFF?> Built-in siren refers to the siren featured
in the control panel.
ARM/DISARM TONE
<ON OR OFF?>
WIRELESS SIREN
SIREN SWITCH
<ON OR OFF?> Wireless siren refers to a siren
connected to the control panel by
radio-frequency.
ARM/DISARM TONE
<ON OR OFF?>
SYSTEM SETTINGS USER ID 4 DIGITS:0000  More information on page 14 of this manual
This information is supplied by your CMS
center. After having stored the user ID, the
CMS center will be able to determine your
exact location according to your ID number.
SYSTEM SETTINGS
ARM UPLOAD ON / OFF If "ON", you receive a notication by SMS when the system is armed. This function is only available in GSM
mode (SIM card required).
DISARM UPLOAD ON / OFF If "ON", you receive a notication by SMS when the system is disarmed.
SYSTEM SETTINGS CALL RECYCLE <09>
When the alarm is triggered, the control panel dials the numbers
you have stored. If you do not disarm the system, the control
panel will call you again (up to 9 times). The “Call Recycle” function
enables you to dene the number of times the control panel
attempts to call you.
SYSTEM SETTINGS BACKLIGHT TIME 030 S Press “Enter” to adjust the time during which the LCD screen is lit. Backlight time can be set from 0 to 300 s
SYSTEM SETTINGS LANGUAGE   Change the language of the system. Languages available may vary depending
on the version of your product.
SYSTEM SETTINGS RESET   All system settings will be restored to default setting.
Stored phone numbers and connected accessories will be cleared.
SYSTEM SETTINGS ABOUT ABOUT JUN 4 2014
HISTORY -- - Choose the event log you need to track, press“Enter”. The control panel keeps in record the
latest 150 event logs.

Accessories Safety and Troubleshooting
13
Quick start-up Control Panel Operations SMS Operations
Control by Phone Call
This feature is available only after having enabled it from the control panel, as explained on page
11 of this manual.
Method 1
When an alarm has been triggered, the control panel dials the stored phone numbers. When
you pick up the phone, follow the voice instructions to control the panel from distance (refer
to the instructions in the table below).
Method 2
1. Dial the telephone number of your control panel (either the number of the SIM card in your
control panel or the number of the landline to which your panel is connected). After getting
through, the voice instructions will guide you to enter your access code.
2. Enter your access code (user code), followed by ”#”.
3. A voice gives you the options you can select.
4. Select the operations to control the panel (see instructions in the table below).
Note
The call will end automatically if you do not send any command within 30 seconds.
Table of commands for control by phone call
Command Function Comment
Press “1“ Arms the system Voice prompt “System armed”
Press “0“
- Disarms the system and turns the
siren o
- Stops monitoring without hanging up
- Ends the phone call without hanging
up
Voice prompt “System disarmed”
Press “ “Audio monitoring Press “ ” to extend the monitoring time
Press “3“ Phone call with control panel -
Press “6“ Turns the siren o -
Press “9“ Turns the siren on -
Press “#“
- Disarms the system and turns the
siren o
- Exits control by phone call
Hanging up also exits the control by
phone call.
Note
In GSM mode, the audio monitoring is not limited in time.
In PSTN mode (connected to your landline), the audio monitoring is limited to 80 seconds. If
you wish to extend the time of audio monitoring, press the “ ” on your phone before the end
of the 80 seconds.

Accessories Safety and Troubleshooting
14
Quick start-up Control Panel Operations SMS Operations
Zone Setup of Accessories
Every detector can be assigned to 4 dierent categories of zones: Home Zone, Delay Zone,
Normal Zone and 24-H Zone. To assign a detector to a zone, follow the instructions on page
10 of this manual (the zone will be assigned at the time of connection of the accessory).
Normal zone
When the system is armed, if a sensor is triggered, the siren rings out. When the system is
disarmed, sensors do not trigger an alarm.
24h zone
Regardless the system is armed or disarmed, sensors assigned to the 24h zone can trigger an
alarm. It is recommended to assign smoke detectors, gas detectors and outdoor beam sensors to
the 24-H zone.
Delay zone
If you want to set up the entry and exit delay functions, corresponding sensors must be
assigned to the Delay zone. Once the delay time has been set up, the sensors will not trigger
the alarm during the delay set. Refer to the instructions “Entry and Exit Delay” on page 11 of
this manual. It is recommended to assign the Door / Window Contact to the Delay zone.
Home zone
When the system is armed in Home Mode, the sensors assigned to the Home zone do not
trigger an alarm. It is recommend to assign motion dectors to the Home zone so that you can
have your system armed in Home Mode when you are home and move inside your home without
triggering any alarm.
Connect to CMS Center
Ignore this step if you are not connected to a CMS center. If you are connected to a CMS center,
the control panel will upload your contact ID to the CMS center automatically if an intrusion
is detected.

SMS Operations
...

Accessories Safety and Troubleshooting
16
Quick start-up Control Panel Operations SMS Operations
SMS Operations
IMPORTANT: BEFORE USING FOR THE FIRST TIME
INSERTASIMCARDINTHECONTROLPANELBEFORE STARTING SMS OPERATIONS.
MAKE SURE THE SIM CARD DOES NOT REQUIRE ANY PIN CODE.
SAVE A SMS NUMBER IN THE CONTROL PANEL USING THE CONTROL PANEL.
Only stored numbers can control and congure the system.
Refer to the instructions page 10)
Each SMS operation dened in this user manual will be illustrated as follows:
You send:
SMS Command
The control panel replies:
Control panel’s reply
The rst blue speech bubble is the SMS
command sent by the user.
The rst grey speech bubble is the reply sent
by the control panel.
The speech bubbles that follow are the
dialogue between the user and the control
panel (SMS sent by the user are in blue, SMS
sent by the control panel are in grey).
The system is in English by default. To change the system language, refer to the
instructions on page 22 of this manual.
Important
When replying to the control panel by SMS, make sure no space follows punctuation marks
like "." or ":". For examples, to store SMS numbers, your SMS must be formatted as follows:
SMS numbers:
1.067890033
2.067890022
3.067890011
4.067890000
5.
No space after "1."

Accessories Safety and Troubleshooting
17
Quick start-up Control Panel Operations SMS Operations
Disarm the System
Send:
0
System disarmed.
Arm the System
Send:
1
System armed.
Home Mode
Send:
2
System in home mode.
Settings Enquiry
Send:
00
System:Disarmed
AC power:on
Note
The values indicated hereinabove will
change after having set up the system.

Accessories Safety and Troubleshooting
18
Quick start-up Control Panel Operations SMS Operations
Store Phone Numbers
Send:
5
Phone numbers:
1.
2.
3.
4.
5.
Copy, paste, then edit
(case sensitive):
Phone numbers:
1. 067890033
2. 067890022
3. 067890011
4. 067890000
5.
Ok
Store Phone Numbers for SMS
Notications
Send:
6
SMS numbers:
1.
2.
3.
4.
5.
Copy, paste, then edit
(case sensitive):
SMS numbers:
1. 067890033
2. 067890022
3. 067890011
4. 067890000
5.
Ok
Note
The rst SMS number will receive SMS
notications when the system is disarmed
by RFID tag. To start receiving these
notications, you must rename the RFID
tags. Up to 4 RFID tags can be renamed.
Other tags will be attributed a number
based on the order of registration to the
control panel. Refer to the instructions on
page 10 to learn how to register an RFID
tag in the control panel.

Accessories Safety and Troubleshooting
19
Quick start-up Control Panel Operations SMS Operations
Rename Zones
Send "91~99". For example for zone 1, send:
91
Zones names:
1.
Copy, paste, then edit
(case sensitive):
Zones names:
1.Entrance door sensor
Ok
Note
Zones 1 to 9 can be renamed. The name of
the zone cannot consist of more than 30
Latin characters. Zones 10 to 50 cannot be
renamed.
SMS Alert for Accessory Low Battery
(available for two-way acessories such as
Motion Detectors)
For accessories assigned to zones that have
been renamed, an SMS will be sent under
the format “Zone name + low battery”.
Bedroom PIR low battery
For accessories assigned to zones that
have not been renamed, an SMS will be
sent under the format “Zone number + low
battery”.
Zone 10 low battery.
SMS Alert for Accessory Tamper
Alarm
(available for two-way acessories such as
Motion Detectors)
For accessories assigned to zones that have
been renamed, an SMS will be sent under
the format “Zone name + tamper alarm”.
Bedroom PIR tamper alarm.
For accessories assigned to zones that have
not been renamed, an SMS will be sent
under the format “Zone number + tamper
alarm”.
Zone 10 tamper alarm.

Accessories Safety and Troubleshooting
20
Quick start-up Control Panel Operations SMS Operations
Rename RFID Tag
Send:
10
Rename RFID tags:
1.
2.
3.
4.
Copy, paste, then edit
(case sensitive):
Rename RFID tags:
1. Tom
2. Nurse
3. Nancy
4. David
Ok
Note
The rst SMS number will receive SMS
notications when the system is disarmed
by RFID tag. To start receiving these
notications, you must rename the RFID
tags. Up to 4 RFID tags can be renamed.
Other tags will be attributed a number
based on the order of registration to the
control panel. Refer to the instructions on
page 10 to learn how to register an RFID
tag in the control panel.
Entry and Exit Delay Time
Send:
11
Entry delay time(0-300sec):0
Exit delay time(0-300sec):0
Copy, paste, then edit
(case sensitive):
Entry delay time(0-300sec):10
Exit delay time(0-300sec):20
Ok
Note
This function will only aect detectors
assigned to the Delay zone. Refer to the
instructions on "Wireless" on page 10 of this
manual to learn how to set up your sensor to
the Delay zone.
This function can be used if you do not want to
bring a remote control or a RFID tag with you.
When you arm the system, the system
will be armed after the delay set. When
you disarm the system, the system will be
disarmed after the delay set.
When arming the system, you hear one
beep every second to remind you to leave.
The beep rhythm speeds up during the last
10 seconds. If an intruder is detected, the
alarm will be delayed accordingly.
