1 INTRODUCTION
1.1 This user manual
Congratulations on the purchase of yourDorado Small Instant.
This machine has been developed and produced using state-of-the-art
technology. This, combined with the ISO 9001 certification that applies
to all our products, means you can rest assured that you are the owner
of a high quality product.
This manual is intended for authorised and trained users and contains
all the information required to operate the machine safely and to carry
out regular maintenance and cleaning tasks. Read the relevant user
manual carefully before using your machine.
☞Ensure that the user manual is kept with the machine to
ensure that all procedures are carried out correctly.
1.2 Pictograms and safety symbols on the machine
The following pictograms are used on the Dorado Small Instant:
• Electrical hazard
• Risk of fingers being trapped
Figure 1-1
Figure 1-2
WARNING
DISCONNECT THE
MAINS SUPPLY BEFORE
REMOVING COVER
Figure 1-3
DANGER
Follow service
procedure as
in manual.

6
© ETNA Coffee Equipment b.v.
Technical manual Dorado Small Instant
COFFEE TECHNOLOGIES
1.3 Pictograms and safety symbols in the manual
These pictograms are used in the manual:
General warning. Damage to the machine or personal
injury can occur.
ᏘElectrical hazard
hBurning hazard
☞Remarks, suggestions and advice
1.4 Conventions and definitions
Throughout the document, reference is made to the "left", "right",
"front" and "rear" of the machine. Where a component or specific part
of the machine is referred to, this is described from the user's viewpoint
facing the selection panel.
1.5 Service and technical support
Please contact your dealer for further information on settings,
maintenance and/or repair activities that are not dealt with in this
manual. Your dealer will be pleased to assist you.
If you contact your dealer, always have the following information at
hand:
• model number
• serial number
• software versions

Technical manual Dorado Small Instant
7
© ETNA Coffee Equipment b.v.
COFFEE TECHNOLOGIES
1.6 Machine identification on outside of the machine
1. Model number
2. Voltage
3. Frequency
4. Power rating
5. Serial number
6. Water pressure
The identification plate is on the rear of the machine.
Figure 1-4
5
23
6
14
Model: xxxxxxx
Voltage: a.c. xxxv xx Hz x kw
Water: xxx - xxx kPa
012540E1
ETNA Coee Technologies BV
Doetinchem Holland

8
© ETNA Coffee Equipment b.v.
Technical manual Dorado Small Instant
COFFEE TECHNOLOGIES
1.7 Machine identification inside the machine
1. Model number
2. Voltage
3. Frequency
4. Power rating
5. Serial number
6. Water pressure
The identification plate is on the inside of the left-hand frame plate.
1.8 Used Machinery and the Environment
jAsk your local authority for information on ways to recycle
materials safely and in an environmentally friendly
manner.
aAsk your local authority for information on ways to dispose
of materials safely and in an environmentally friendly
manner.
Figure 1-5
23
6
14
Model: xxxxx
Voltage: a.c. xxxv xx Hz x kw
Water: xxx - xxx kPa
012540E1
ETNA Coee Technologies BV
Doetinchem Holland
5

Technical manual Dorado Small Instant
9
© ETNA Coffee Equipment b.v.
COFFEE TECHNOLOGIES
1.9 General safety instructions and restrictions
The manufacturer does not accept liability for any damage caused by
any failure to (strictly) observe the safety instructions or by
carelessness during use and cleaning of the machine and any
associated accessories.
Depending on the specific operating conditions or accessories used,
additional safety instructions may apply. Please contact your dealer
immediately if you encounter any hazards when using the machine.
The user of the machine is fully responsible at all times for
observing locally applicable safety regulations and
guidelines.
1.9.1 Operating and cleaning instructions
• All those using and/or cleaning the machine must be familiar with
and follow the operating and cleaning instructions closely. The
owner must ensure that personnel are informed of the operating
and cleaning instructions contained in this manual and that they
comply with these regulations and instructions.
• Never change the order in which activities are carried out.
• Always keep these instructions in the vicinity of the machine.
1.9.2 Icons and instructions
The icons, symbols and instructions attached to the machine form part
of the safety instructions. Therefore, they must not be covered or
removed. They must be kept within reach and be clearly legible
throughout the entire service life of the machine.
• If icons, symbols or instructions are illegible, ring your supplier
straightaway to rectify this.
1.9.3 Users
The daily, weekly and monthly maintenance and cleaning activities
may only be carried out by users who have received training from the
installer or owner of the machine. These individuals will be familiar with
the potential risks of opening the machine.
1.9.4 Technical specifications
• The technical specifications may not be modified.
1.9.5 Modifications
• Modifications may not be made to the machine (or parts of the
machine).

10
© ETNA Coffee Equipment b.v.
Technical manual Dorado Small Instant
COFFEE TECHNOLOGIES
1.9.6 Intended use
The intended use1of the machine is designed exclusively for
dispensing beverages as indicated on the selection panel. Use of the
machine for any other purpose falls outside the terms of conditions of
use. The manufacturer does not accept responsibility for any damage
or injury that may result from improper use.
The machine meets current standards and directives.
• The machine may only be used in perfect technical condition for the
purposes indicated above.
1.10 Available documentation
The following documentation is available for this machine:
•Usermanual
• Technical manual
• Parts book
1. "Intended use" as meant in EN 292-1 is the application for which this technical product has
been made, as specified by the manufacturer – including references in sales brochures. In case
of doubt, use can be derived from the construction, model and functions of the technical product
the assumed normal use. Use of the product within the confines of the intended use also
includes complying with the instructions in the user manual.

Technical manual Dorado Small Instant
11
© ETNA Coffee Equipment b.v.
COFFEE TECHNOLOGIES
2 DESCRIPTION OF THE MACHINE
2.1 General description
This machine prepares and dispenses various hot drinks.
The drinks are dispensed in the cups intended for this purpose and
that are placed on the machine cup stand. The cups must be placed on
the cup stand manually.
The display on the machine indicates that:
• a drink can be selected
• a drink is being prepared
• a fault has occurred.
• the machine is performing a function.
2.2 Main components
2.2.1 Front view
1. window light
2. Display
3. Selection panel
4. Dispenser water
5. Dispenser hot drinks
6. Cup sensor
7. Cup standard (double)
8. Drip tray
Figure 2-1
6
1
3
4
5
2
7
8

12
© ETNA Coffee Equipment b.v.
Technical manual Dorado Small Instant
COFFEE TECHNOLOGIES
2.2.2 Interior view
1. Ingredient containers
2. Dispensing spout
3. Mixer parts
4. Dispenser holder
5. On/off switch
Figure 2-2
1
2
3
4
5

Technical manual Dorado Small Instant
13
© ETNA Coffee Equipment b.v.
COFFEE TECHNOLOGIES
2.3 Container layout
The various types are fitted with the following containers.
2.4 Operating principle
After a selection is made, the machine mixes water with the ingredients
from the containers to dispense the drink.
• The water is supplied via the boiler (heated).
• Instant products or liquid concentrate are dosed from the containers
into the mixer and/or the ground coffee is dosed from the grinder
into the brewer group.
• The water and the ingredients are mixed in the mixer or
compressed by the brewer group.
• The drink is dispensed through the dispenser nozzle into the cup
placed on the cup stand.
Machine Instantcontainer
32 3
11 1
11 1
Figure 2-3

14
© ETNA Coffee Equipment b.v.
Technical manual Dorado Small Instant
COFFEE TECHNOLOGIES
2.5 Switching on and off
• I pressed in = ON (switch lights up)
• 0 pressed in = OFF
2.6 Operating the machine
The standard version of the machine has no payment mechanism. The
machine can also be optionally fitted with a payment mechanism (for
installation instructions, see the instructions for use supplied with the
payment mechanism).
2.6.1 Strength selector (if applicable)
Select the drink by pressing the button.
The strength can be changed by pressing the selected drink again.
This is also an option when adding items such as sugar and milk, if the
machine allows for this.
Figure 2-4
Figure 2-5

Technical manual Dorado Small Instant
15
© ETNA Coffee Equipment b.v.
COFFEE TECHNOLOGIES
2.6.2 Selecting jug function (if applicable)
If the jug function is switched on, the cup sensor is
switched off.
The Jug function button allows you to select several cups at the same
time. This button works with all available drinks. The procedure for
selecting several cups is described below.
1. Push the cup stand up and place a jug under the dispensing spout.
2. Press the Jug button several times for the required number of cups.
3. Press the button for the required drink.
4. Press the START selection button.
If you want to reduce the number of cups while the machine is
dispensing, press the Jug button several times until the required
number is displayed. The machine will then stop after the cup that is
currently being dispensed.
If the machine is equipped with a coin mechanism and a key switch for
the jug function, you can activate the free drink dispensing mode by
placing the key in the slot (the switch) and turning it to the right.
2.6.3 Stand by
Stand by mode is indicated by the following:
• The display shows a standby position.
Press any button to bring the machine out of stand by.

16
© ETNA Coffee Equipment b.v.
Technical manual Dorado Small Instant
COFFEE TECHNOLOGIES
3USE
3.1 Safety instructions - use
• Inspect the machine before use and check for any damage and
defects.
Please contact your supplier if there is any damage to the machine.
• Please keep all packaging out of reach of children.
• Put the machine in a horizontal position.
• Put the machine in a location where it can be supervised by trained
staff.
• The machine is not suitable for outdoor use.
• The machine may not be used by persons (including children) with
a physical, mental or emotional handicap, or persons who have
insufficient knowledge and experience to operate the machine
without supervision or instructions, until they have been approved
by a person responsible for their safety.
• Supervision of children must be maintained to ensure they do not
play with the machine.
• Protect the machine from water and/or moisture.
• Do not clean the machine using a high pressure water jet.
• Do not install the machine in an area where a high pressure water
jet may be used.
• Keep the buttons free from dirt and grease and clean them
periodically.
• Use the machine only when the top valves are shut and all the
plates are mounted.
• Never use sharp objects to operate the buttons.
• Only use the cups and pots availabe at reception.
• Make sure that the electricity connection point (wall socket with
earth connection) and the water connection point remain accessible
during use. In case of emergency, the mains plug can then be
removed quickly and the water supply can be shut off immediately.
• When the machine is not used for a long period of time. remove the
holders, disinfect the pipes, clean the machine by hand, clean and
disinfext the mixing parts thoroughly, empty the boiler, disengage
the water supply and the electricity supply. No water should be
present in the machine or its parts.
• When you intend to use the machine after a long period of non-use,
you need to first thoroughly clean the mixing parts and the
preparation group. Place the mixing parts back where they were,
carry out the cleaning programme at least three times and fill all the
holders before using the machine.
hThe drinks prepared by this machine are very hot and
could cause burn wounds.
ᏘIn case of danger, disconnect the power supply by
removing the plug from the wall socket. Do not pull the
plug out of the wall socket by the cable.
Disregarding the above instructions can jeopardise the
safe use of the machine.

Technical manual Dorado Small Instant
17
© ETNA Coffee Equipment b.v.
COFFEE TECHNOLOGIES
3.2 Filling containers
The containers contain the ingredients for preparing the drinks. There
are 2 ways of filling these containers:
• by opening the top lid and filling the container in the machine;
• by filling the container outside of the machine.
3.2.1 Filling the container in the machine
1. Open the door of the machine.
2. Open the lid on the container that needs refilling. Refill the container
with the correct ingredients.
3. Close the upper lid.
4. If the container was completely empty, the supply will need refilling.
• Hold the container above the waste bucket. Turn the spindle of
the container until the ingredient runs out of it.
3.2.2 Filling the ingredient containers outside the machine
The containers hold the ingredients required to prepare drinks.
Ensure that no fingers are trapped when filling the
containers.
☞Make sure that the right ingredient is put in the correct
container.
➭See the label on the inside of the door for an overview of
the maintenance functions.
1. Open the door of the machine.
2. Open the upper lid.
3. Closes the container spout, by pushing the button until it clicks. (zie
figuur 0-1)
4. Lift the containers being filled out of the holder and pull them
towards you.
5. Fill the container with the required ingredient.
6. Replace the container in the machine in its original position. Ensure
that the coupling of the container latches onto the gear.
7. Open the container by pushing the cover down until it clicks open.
(zie figuur 0-2)
8. Repeat this procedure for the other ingredients containers.
9. Close the cover.
10.Place a 1.5 l cup under the dispensing spout.
11.Press button *00* on the service panel; clean valves = rinse mixers.
The valves will be rinsed with water. Repeat if necessary (if
applicable).
12.Close the door of the machine.
Figure 3-1
A
B

18
© ETNA Coffee Equipment b.v.
Technical manual Dorado Small Instant
COFFEE TECHNOLOGIES
4 MAINTENANCE AND CLEANING
Accurate maintenance and in particular careful cleaning are basic
conditions for good product quality and smooth operation.
This device is designed so that the owner or license holder is able to
clean and maintain it thoroughly in a relatively short time.
☞First read paragraph 4.1 before performing any
maintenance work on the device. The maintenance work
described may only be carried out by trained and
authorised users.
4.1 Safety instructions - maintenance and cleaning
• See also par. 3.1.
• Carry out the procedures taking into account the hygiene
regulations.
• Repairs may only be carried out on the machine by trained service
engineers.
• Maintenance work on the electrical system may only be carried out
by trained service engineers with a background in electrical
engineering.
hWarning with respect to burns: parts within the machine
can be very hot.
• After cleaning or maintenance activities, the machine must not be
used until all the removed parts have been correctly reinstalled.
Then inspect and check the inside of the machine:
• The dispenser holder must be aimed at the middle of the cup.
• The ingredient containers must be correctly placed.
• The mixer components must be in the correct position.
• The waste container must be in the correct position. (if applicable)
• The brewer group must be in the correct position. (if applicable)
4.2 Perishable ingredients
The ingredients have been supplied with a use by date.
The following therefore needs to be taken into account:
• Comply with the use by date printed on the product packaging.
• Do not use ingredients, which are approaching the use by date.
• Replace any ingredients whose use by date has passed.
• Do not use opened ingredients for longer than the use by date
indicated.
• Replace any opened ingredients whose use by date has passed.
• Only use the cleaning agents referred to in the cleaning schedule
and follow the instructions on the packaging.

Technical manual Dorado Small Instant
19
© ETNA Coffee Equipment b.v.
COFFEE TECHNOLOGIES
4.3 Service panel
The service panel will become visible when the door is opened. The
following maintenance activities can be carried out via the service
panel (if present):
4.4 Maintenance
The quality of the drinks is only guaranteed if the machine is properly
maintained on a regular basis. A number of essential components in
the machine are highly sensitive to dirt. Use of this machine requires
both daily and weekly maintenance.
4.5 Daily maintenance
Carry out the following operations on a daily basis:
• Check the contents of the ingredient containers and refill them if
necessary.
• Clean and empty the drip tray.
• Rinse the mixers and clean the valves (at least 2x a day).
• Clean the outside of the machine, including the selection panel.
When cleaning, pay attention to the following:
• Clean the machine and parts with a damp, clean cloth or paper
tissue.
• Always put the cleaned parts straight back in the machine.
• Clean the machine more frequently than specified if necessary;
more frequent cleaning will be required when the machine is
subject to heavy use.
4.5.1 Checking the ingredient containers
1. Open the door.
2. Check whether the ingredient containers still contain sufficient
ingredients.
3. If necessary, prime the containers as described in (see chapter
3.2).
4. Shut the door of the machine.
Figure 4-1
Button Function
*00* Clean valves + rinse mixers
*05* Toggle paiment modeg
*07* Read counters
*08* Fill pump (liquid only)
*09* Reset ingredient counters (only liquid)
*10* Change light

20
© ETNA Coffee Equipment b.v.
Technical manual Dorado Small Instant
COFFEE TECHNOLOGIES
4.5.2 Cleaning drip tray
The drip tray must not be washed in a dishwasher.
1. Take the drip tray out of the machine carefully.
2. Empty the drip tray and clean it with water.
3. Put the drip tray back in the machine.
4.5.3 Clean valves and rinse the mixers.
Rinsing the mixers:
1. Open the door.
2. Use the service key (if available).
3. Place a jug (min. 1,5 l) under the dispenser holder.
4. Press *00* of the service panel (on the inside of the door) to clean
the valves + rinse the mixers.
5. Remove the cup and the service key (if available) and close the
door.
6. Empty the cup.
4.5.4 Clean the exterior
Clean the outside of the machine with a damp, clean cloth or paper
towel. Pay special attention to:
• The selection panel
• The area around the drink dispenser unit.
• The bottom of the door.
4.6 Weekly maintenance
Carry out the following operations on a weekly basis:
• Clean the mixer components
Figure 4-2
Figure 4-3
1,5
L
Figure 4-4
