Etzinger etz-l User manual

GUIDE
Grinder Parts
1 Grinder Body (Housing) w/ Crank Handle
2 Lid (magnetically attached)
3 Adjustment Ring w/ Coneholder & Cone burr
4 Magnetic Collection Cup
ETZINGER AG (FL-9492 ESCHEN) - Phone: [phone] - www.etzinger-ag.com - Email: [e-mail]
Thank you for choosing our coffeegrinder etz-I, an innovative handgrinder facilitating manual grinding not just in regards of handling and adjusting.
Open the box and carefully pull out the grinder. Make sure to check the delivery content before getting your grinder ready for use. To get started, please follow our instructions and
pictures. To clean your grinder, use a soft cloth and/or a brush. Do not clean the burrs with water and avoid to touch them with wet fingers.
For more information, please visit our Website (for Warranty policy, see „Good to know“).
THANK YOU –ENJOY THE GRIND!!
Specifications
Burr Size : 32mm (Diameter Cone Burr)
Burrs : Hardened Steel (62 HRC)
Weight : 805g (Regular), 685g (Trim)
Diameter : 55mm (Regular), 47mm (Trim)
Collection Cup: 60mm Outer Diameter / 55mm Opening
Height : 225mm (Handle retracted
Body (Housing): Anodised Aluminum
Movable parts: Fibreglas reinforced plastic (FRP)
High-precision Handgrinder for grinding whole, roasted coffee beans
1
2
3
4
etz-I®

GET STARTED
CRANK ADJUSTMENT CLEANING
GRINDING
Pull out crank handle
(Fig. 1) in vertical
direction. Press it
down horizontally (Fig.
3) until snapped into
place.
To fill in beans, press down lid (Fig. 4 and
5) and remove it. Add beans (Fig. 6,
around 30g), position lid and move slightly
until snapped into place.
To grind, please turn crank handle
counterclockwise (=CCW, see Fig. 3).
Beware of Catch-up being magnetically
attached.
Ergonomic handle to be held with 3 fingers
(beware of indentation for thumb, index
finger and middle finger).
Turn the black ring (=Adjustment Ring, Fig. 2) to the left (marking to be in line with
arrow, Fig. 6). Pull down and out (if tight, please follow instructions on next page).
Clean coneholder and burrs with a brush, then reassemble in reverse order before
moving black ring to the right / back to the stepped part or your initial setting.
Please also make sure to read the more detailed instructions on the next page.
ATTENTION / ACHTUNG
No grinding within the DO NOT GRIND-section(Fig. 6). Turning the Adjustment
beyond this section, will separate Grinder Housing from Adjustment Ring.
Fig. 1 Fig. 2 Fig. 3 Fig. 4 Fig. 5 Fig. 6
ETZINGER AG
Wirtschaftspark 44
FL-9492 ESCHEN Phone: [phone] - www.etzinger-ag.com Email: [email protected]
The Adjustment (Fig. 2) consists of 88 slightly
stepped increments (à 0.02mm), marked 1-
23.
To adjust grind setting, move the black ring
between COARSE (Setting 23) and FINE
(Setting 1) accordingly (beware of marking
line).
Recommended settings
Espresso: 3-7
Filter: 9-13
Point of Reference : 1
Fig. 7
Fig. 5
etz-I®

Disassembly and cleaning
1. Remove magnetically attached Collection Cup by gently pulling it down, turn it around
2. Bottomside of Collection Cup may now be used as tool
3. Fit bottomside of Collection Cup into Adjustment Ring and make sure for it to engage
4. Once engaged, slightly move Collection Cup back and forth to release remains of coffee
powder from within
5. Turn Collection Cup with Adjustment Ring to the left (versus COARSE). Make sure for
marking to be in line with arrow before pulling Adjustment Ring off
6. Clean coneholder and cone burr with a brush. Brush out ring burr affixed to the grinder
body
7. Reposition Adjustment with coneholder and cone burr at indicated arrow (make sure for
arrow and marking to be aligned). Groove must engage properly before you can press up
Adjustment Ring and move it to the right, back to the stepped part or your initial setting
3
ETZINGER AG
Wirtschaftspark 44
FL-9492 ESCHEN
Phone: [phone]
Website: www.etzinger-ag.com
Email: [e-mail]
Unterseite
1
Nut
Ring
Konushalter
Einstellring
Mahlkegel
2
3
3
4-5
6
Ansetzen und Einrasten
etz-I®

Warranty Information for EU Countries / Switzerland and Liechtenstein
The warranty for coffee grinders purchased from Etzinger AG covers a period of 24 months (domestic) / 12 months (commercial) from the date of purchase under EU Directives . This warranty covers all
damage to material and processing and shall not apply to improper operation, improper cleaning, misuse, normal wear and tear, inaccuracy when implementingsettings, foreign objects in the beans
(stones, screws, plastic parts, etc.) as well as in the event of use that is inconsistent with the intended use, i.e., the grindingof complete, roasted coffee beans.
In the event of shortcomings within the warranty obligation, please contact your dealer or send us an e-mail at [e-mail] call us on [phone].
International Warranty
Warranty, service, and maintenance in all countries outside of Switzerland, Liechtenstein, and the EU or in countries with authorized Dealers are the responsibility of your authorized Dealer from whom
you purchased the device. To find your nearest Dealer, please contact us by e-mail at [e-mail].
etz-I® SAFETY INSTRUCTIONS
Carefully read the instructions in this guide as well as the information below. It contains important safety information for this grinder. Please keep these instructions for future reference.
✓Only use the grinder for its intended purpose, the grinding of roasted whole coffee beans.
✓This grinder can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the grinder in a safe way and understand the hazards involved.
✓Improper and negligent handling of packaging elements with sharp edges can lead to injury and may be hazardous. Store packaging elements out of reach of children, persons with limited physical,
mental and/or sensory capacities and pets.
✓Make sure not to have children playing with the handgrinder, its parts or packaging. Children can become entangled or suffocate while playing.
✓Never use inappropriate objetcs (cutlery, scissors, needles, etc.) to clean the handgrinder or remove coffee beans/grounds.
✓Avoid for the burrs to get in contact with water, do not use chemicals or aggressive cleaning products to clean the grinder, check for foreign objects before grinding so to avoid damage to the
burrs.
✓Cleaning and user maintenance shall not be made by children without supervision by a qualified person. Maintenance and repair work to be carried out by manufacturer, its service agent or
qualified persons only.
✓Safe materials: all materials used for the production and assembly of etzinger® products and getting in contact with coffee will not result, directly or indirectly, in their becoming a component of or
otherwise affecting the characteristics of foods.
