EURO EAGL700S User manual

1
Rangehood
Instruction Manual
EAGL700S
EAGL90SX
EURO APPLIANCES BY EUROSTYLE GROUP

2
CONTENT
1 .............................................. Notice
2 .............................................. Installation Requirements
3 .............................................. Installation –Fitting the Rangehood.
4 .............................................. Safety Warning
5 .............................................. Instructions for Use
6 .............................................. Maintenance
7 .............................................. Troubleshooting

3
(1) Notice
1. Thank you for choosing our Rangehood. Please read this
instruction manual carefully before use.
2. The installation work must be undertaken by a qualified and
competent installer in compliance with applicable Australian
Standards.
3. Euro Appliances disclaims all liability for any damage or
injury caused as a result of not following these instructions for
installation.
This Rangehood is suitable for connection to a 240V, 50Hz
power supply with a proper earth.
Contents
1 x Rangehood
1 x Packet of Screws & Fittings
2 x plastic flaps
1 x Set of Chimney Pieces (Upper & Lower)
1 x Operating & Installation Instructions

4
(2) Installation - Requirements
Warning: This Rangehood is suitable for indoor installation only in
accordance with the following:
Installation must be performed by a qualified competent installer.
If installed above a barbecue, the minimum distance from the
cooking grid/plate is 120cm.
If installed above a cooking appliance, the minimum distance
from the cooking surface is 65cm.
1. Before installation, please ensure the area is clean to avoid
suction of any debris such as bits of broken wood, sawdust,
etc.
2. Flexible duct bending should be ≥120°.
3. There shall be adequate ventilation of the room when the
Rangehood is used at the same time as appliances burning gas
or other fuels (not applicable to appliances that only discharge
the air back into the room).
4. The air must not be discharged into a flue that is used for
exhausting fumes from appliances burning gas or other fuels
(not applicable to appliances that only discharge the air back
into the room).
5. Regulations concerning the discharge of air have to be
fulfilled.

5
(3). Installation –Fitting the Rangehood.
This Rangehood must be placed at a distance of 65cm minimum from the
cooking surface of a cooker/hotplate and 120cm minimum from the
cooking surface of a BBQ.
3.1 Fit the supplied Hook to the wall using the 36mm long screws
supplied (refer to Pic 1). Fixing method to the wall must be capable of
supporting the weight of the Canopy.
3.2 Fit the Inside Chimney Bracket against the ceiling (refer to Pic 1).
3.3 Fit the plastic flaps to the outlet vent of the canopy by deforming
the flaps slightly so that the ends fit into the holes (refer to Pic 2 for
location of the flaps).
3.4 Lift the Canopy onto the Hook and make sure both left and right
hand hooks are engaged (refer to Pic 3).
3.5 Fit the Flexible Duct (not supplied) to the outlet (refer to Pic 2).
3.6Exhaust the Flexible Duct to the outdoors and fit a one way valve
to prevent rain & dust entering into the Canopy.
3.7 Fit the glass to the Rangehood with 20mm countersunk screws &
rubber collars supplied (refer to Pic 4). Do not over-tighten screws.
3.8 Fit the Outside Chimney on top of the Rangehood, line up the holes
with the Outside Chimney Bracket and fix the bracket to the wall using
the 36mm long screws supplied (refer to Pic 5).
3.9 Pull up the Inside Chimney up to align it with the holes on the
Inside Chimney Bracket and fit the 9mm screw supplied through each
side (refer to Pic 6).
3.10 Drill two Ø3.5mm holes in line with the Outside Chimney Bracket
through both the Outside and Inside Chimneys and fit a 9mm long screw
supplied on each side to fix them together.
3.12 Fix the Canopy with two 30mm safety screws. The two safety
screw holes are positioned on the back casing (refer to Pic 6).

6
Warning: Failure to install the screws or fixing device in accordance
with these instructions may result in electrical hazards.
After installation, make sure that the canopy is level to avoid
grease collecting at one end.
Note: If you do not have an outlet to the outside, you can install the
Rangehood so that it recirculates the air. The installation is the same as
above except that you do not install the flexible duct. For recirculating
installations, we recommend that you fit the activated carbon filters.

7
Activated carbon filter can be used to trap odors for recirculating
installations.
In order to install the activated carbon filter, the metallic anti-grease filter
should be detached first. Press the lock and pull it downward.
Plug the activated carbon filter into the unit and turn it in anti-clockwise
direction. Repeat the same on the other side.
Make sure the filter is securely locked. Otherwise, it could loosen and
cause damage to the unit.
When activated carbon filter is attached, the suction power will be
reduced.
(4) Safety Warning
This Rangehood is for domestic use only, it is not suitable for
commercial purposes.

8
Please ensure that installation is performed by a qualified
competent installer.
The Rangehood and its filter mesh should be cleaned regularly
in order to keep it in good working order.
Before cleaning, please switch the power off at the main
supply.
Clean the Rangehood according to the instruction manual.
There is a fire risk if cleaning is not carried out in accordance
with the instructions.
If there is any fault with the appliance, please switch off
immediately, disconnect and call the service department to
arrange a service.
DO NOT flambé under the Rangehood.
CAUTION: Accessible parts may become hot when used with
cooking appliances
This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of
the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play
with the appliance. Never let the children operate the
Rangehood.
If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons
in order to avoid a hazard.

9
（5）Instructions for Use
5.1 Push Button
Switch on the power to the Canopy.
51.1. Push the low button, the indicating light around the
button will illuminate and the motor runs at low speed. Push it
again and the motor will stop and the light will switch off.
5.1.2 Push the middle button, the indicating light around the
button will illuminate and the motor runs at mid speed. Push it
again and the motor will stop and the light will switch off.
5.1.3 Push the high button, the indicating light around the
button will illuminate and the motor runs at high speed. Push it
again and the motor will stop and the light will switch off.
5.1.4 Push the light button; the indicating light around the
button will illuminate and the two lighting lamps will switch on.
Push it again and the lamps will switch off.
Low Speed
Mid Speed
High Speed
Light

10
5.2 LCD Electronic button
5.2.1 Switch on the power to the Rangehood. The backlight is lit
displaying a 24 hour clock and the Rangehood is in standby mode.
Backlight will be extinguished within 15 seconds without any
operation. When the backlight is not illuminated, the Rangehood is
off. Press any button and the backlight will illuminate.
5.2.2 To switch on lights, touch any button to enter standby
mode. Press “ ” button, the symbol “ ” will appear on the LCD
screen. Press “ ” button again, the symbol “ ” will disappear
and the lights will switch off.
5.2.3 To operate the Rangehood, touch any button to enter
standby mode. Press “ ” button once, the symbol “ ” is
displayed on the LCD screen and the motor operates at low speed.
Press “ ” button once more and the motor operates at medium
speed. Press “ ” button once more and the motor operates at hight
speed. While “ ” is displayed, the“ ” button is illuminated.
5.2.4 To stop the motor, press “ ” button once. When the
Rangehood is in standby mode, press “ ” button once. The motor
will operate at the speed it last operated and the LCD screen will

11
display “ ”. Press “ ” button again and the motor will stop
operating and “ ” will disappear from LCD.
5.2.5 To set the clock, touch any button to enter standby mode.
Make sure that the “ ” and “ ” symbols are not displayed.
Press and hold “ ” button for 2 to 3 seconds, will be
displayed with the flashing. Press “ ” button to increase the
hour setting and press “ ” to decrease the hour setting. Note: hour
can be set from 00 to 23.
When the correct hour is set, press “ ” button. The second 2
segments of the LCD screen will flash. Press “ ” button to
increase the minute setting and press “ ” to decrease the minute
setting. Note: minutes can be set from 00 to 59.
When the correct time is displayed, press “ ” button. The time is
now set and the Rangehood is in standby mode.
Once in time set mode after pressing and holding “ ” button for 2
to 3 seconds, you must press “ ” button two more times to exit
time set mode. While in time set mode, you cannot hold “ ” button
for 2 to 3 seconds to re-enter time set mode, you must exit first.
5.2.6 To set the Timer for the Rangehood to switch off
automatically, press “ ” button to set motor speed. The
Rangehood can be set to switch off after 1 –60 minutes.
Press “ ” button once, the LCD screen will display the last timer
setting in minutes. Press “ ” button to increase the minutes, press
“ ” button to decrease the minutes. Once the desired timer setting
is displayed, press “ ” button to set the timer. The Rangehood will
continue to operate and the display will count down in minutes and
seconds. When the LCD display counts down to 0:00 the motor

12
switches off and the Rangehood is in standby mode. Rangehood will
go into off mode within 15 seconds.
While in timer mode, you can adjust the motor speed and operate the
lights. Please note that only the motor is switched off by the timer,
the light is not controlled by the timer.
To cancel the timer “ ” button at any time.
Next time you use the Timer, if you want to use delay timer function
with the same time delay setting as last time, then press “ ” button,
don’t change the minutes, the timer will automatically count down
the minutes after 5 seconds have passed.
(6) Maintenance
6.1 Cleaning the filters
The filter mesh is made of high-density stainless steel. Please do not
use corrosive detergent on it. Keeping this filter clean will keep the
appliance running correctly. Please strictly follow the guidelines
below.
Method 1: Put the mesh into a sink of clean water, pour on
detergent, and soak for 2-3 minutes. Wear gloves and clean with a
soft brush. Please do not apply too much pressure, as the mesh is
delicate and can be easily damaged.
Method 2: Wash in a dishwasher with the temperature set to around
60 degrees.

13
6.2 Cleaning the Rangehood
1. To protect the main body from corrosion, the Rangehood
should be cleaned with hot water plus non corrosive
detergents every two months.
2. Please do not use abrasive detergent because it will damage
the Rangehood.
3. Keep water away from motor and other electrical parts as
this will cause damage to the appliance.
4. Before cleaning the appliance please remember to shut off
the power and disconnect the plug.
5. Do not expose the carbon filter to heat.
6. Please don’t tear open the fixed bar around the carbon filter.
7. If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
(7) Troubleshooting
Warning: Service must be performed by an authorised
competent person.
Fault
Cause
Solution
Light on, but motor
does not work
The flaps are blocked
Remove the blockage.
The capacitor is damaged
Call for service.
The motor is jammed due to
bearing damage
Call for service.
There is a bad smell coming
from the motor
Call for service.
Light does not work,
motor does not work
Beside the above mentioned, check the following:
Light damaged
Call for service.
Power cord not connected
Check plugged in and
switched on that power is
available.

14
Oil leakage
Filters saturated with cooking
oils.
Clean the filters.
Leakage between the
connection of U-shaped
section and Rangehood
Remove U-shaped
section and seal
Vibrations
The flaps are damaged and
causes shaking
Call for service.
The motor is not fixed
securely to the Rangehood
body
Call for service.
The Rangehood body is not
fixed securely to the wall
Notify your installer.
Insufficient suction
The distance between the
Rangehood and the cooking
surface is too much
Notify your installer.
Too much ventilation from
open doors or windows
Close doors or windows,
choose an alternative
location, if possible,
away from draughts.
The Rangehood
inclines
The fixing screws are not
tight enough
Notify your installer.
The hanging screws are not
tight enough
Notify your installer.
Eurostyle Group trading as Euro Appliances
Warranty Service Line: 1300 440 335
Fax: [phone]
Email: [e-mail]
