Euroclean Zero Bend Steristeem User manual

USER MANUAL
1615299
Available exclusively through the trained Direct Sales Specialist of Eureka Forbes.
To know more or for a personal demonstration,
Call on 1860 266 1177 or visit us at www.eurekaforbes.com
EUREKAFORBES LIMITED, B1/B2, 701, Marathon Innova, Marathon NextGen, Off Ganpatrao Kadam Marg,
Lower Parel, Mumbai -- 400 013. India.
Fax: [phone], Email: [email protected]
Colour of the product may vary from that shown on the user manual.

INDEX
Why Euroclean? 1
Welcome to the World of Euroclean Zero Bend Series 2
Euroclean Zero Bend Series Advantage 3
Product Overview 4
Product Features 5-6
Installing Euroclean Zero Bend Series Steristeam
- Getting Ready 7
- Using Your Steam Mop 7
- Using the Steam Pod 8
Operating Euroclean Zero Bend Series Steristeam 9-14
Troubleshooting 15
Technical Specifications 16
Safety Information 17
Warranty Terms & Conditions 18-19

Thank you for trusting Zero Bend Series Steristeam from Euroclean as your household cleaning
partner.
Euroclean Zero Bend Series is a breakthrough that helps you clean even tricky corners and
hidden surfaces under beds and sofas, without bending.
Your versatile Zero Bend Series Steristeam is designed ergonomically to perform, dual cleaning
actions (Sweeping and Steam sanitisation) at the same time. Its chemical-free steam eliminates
99.9% germs and bacteria, and disinfects the surface.
Explore the range of handy extras for its portable handheld pod to clean multiple surfaces with
absolute convenience.
Go ahead, take household cleaning to the next level... without bending now.
WELCOME TO THE WORLD
OF EUROCLEAN
ZERO BEND SERIES
We, at Eureka Forbes, firmly believe that a quality life is the right of every individual. Which is
why we endeavour to offer you only the best of health and technology with our diverse and
innovative range of products – designed for your every need. Be it safe drinking water,
pollution-free air, spotless surroundings or secure homes, we have invested in it all – for your
well-being.
Coming to you from the pioneers and leaders in vacuum cleaners, water purifiers and air
purification systems, Euroclean is designed to take care of your home cleaning needs.
• Trusted by over 5 million satisfied customers
• Developed by a state-of-the-art R&D facility with high-end testing equipments
• Offers a wide range of products & accessories developed after extensive consumer research
and usage
• Highest selling vacuum cleaners in India, for over 36 years
• Largest network of service technicians, ensuring 100% service within a 5 km radius
Thank you for choosing us as your partner in good health!
WHY EUROCLEAN?
1 2

1. Handle
2. Cord Clip
3. Power Cord
4. Water Cup
5. Easy Touch Digital Controls™ – LO/HI Steam
6. Water Tank with Easy Fill Opening
7. Swivel Steering
8. Steam Mop Foot
9. Microfibre Mop Pads
10. Fragrance Discs
11. Extension Hose
12. Window Squeegee
13. Flat Surface Tool
14. Brass Bristle Brush
15. Fabric Steam Tool
16. Multi-Purpose Brush - Black
17. Kitchen Brushes - Red/Green
18. Tool Connector
19. Angled Concentrator
20. Grout Brush
21. Flat Scraping Tool
22. Steam Trigger
PRODUCT OVERVIEW
PRODUCT OVERVIEW
5
16
13
19
15
21
12
18
14
20
11
EUROCLEAN ZERO BEND
SERIES ADVANTAGE
6
7
8
22
2
1
9
10
17
3
4
The Zero Bend Series is a breakthrough in household cleaning. It cleans without bending. The
Euroclean Zero Bend Series is ergonomically designed for maximum user convenience while
carrying out daily chores.
Now, cleaning tricky corners and stealthy surfaces (below beds and sofas) becomes simple, smooth
and painless.
With striking looks and, myriad features, the Euroclean Zero Bend Series (ZBS) takes household
cleaning to the next level.
Smart Clean Fingertip Controls
The ZBS series comes with smart clean fingertip controls to make cleaning hassle-free. It enables the
user to operate the machine with ease.
Range of Accessories
ZBS comes with a state-of-the-art range of accessories for different cleaning needs. It provides
solutions for efficient and hassle-free cleaning needs of users. The accessories provided are simple
to use and convenient to store.
Multi-Mode Cleaning Technology
The ZBS series is designed in such a way that it caters to all the cleaning needs of the user. The
machines are purely cleaning experts and powered with multiple modes, i.e. one machine– multiple
cleaning solutions.
Hands-free Easy Waste Disposable Mechanism
The ZBS series gives you convenience to dispose dust, wet waste, etc., without touching the waste.
3 4

PRODUCT FEATURES
Steri Steam Kills up to 99.9% of Germs and Bacteria*
The powerful steam kills up to 99.9% of germs and bacteria. Sanitize all kinds of
hard floors without chemicals and only the use of water. Easily kill germs, bacteria,
viruses and eliminate mould, dust mites and all other pathogens, using nothing
but the most natural cleaning method – superheated steam – perfect for cleaning
and disinfection.
*Using microfibre mop pads. Use as directed, results may vary. Tested under controlled lab conditions.
Steam POD
The steam POD mode gives the user the convenience to convert the steam
cleaner into an handheld device, which can be easily carried to perform cleaning
chores with ease. The steam POD can smartly be utilized to clean up surfaces like
windows, mirrors, kitchen ovens, grills, etc.
S2 – Sweep & Steam Mop in One Go
Achieve hygienic results in one go with the Sweep and Steam combined action.
This saves you time and effort. The special microfibre cloth attracts and removes
dirt, dust and all kind of crumbs, while the steaming function sanitizes on the go.
You can use each option separately as well, or combine them to clean your floors
in one go.
Aroma Diffuser
Release fragrance with steam with the help of the scent discs, creating a soothing
atmosphere.
Reusable Microfibre Pads
The soft microfibre material gently loosens, lifts, and absorbs dust and dirt.
Removing dirt effectively and gently.
PRODUCT FEATURES
Eco-Friendly
It works with water only. It does not leave any kind of chemical residue on your
floor.
Smart Touch
Ease of use to control steam and power, through a smart-looking digital panel.
Multi-purpose Cleaning Kit
Provides durable accessories and comes packed with a 13-piece cleaning kit. All
accessories were engineered to be durable and to provide you with the right tool
for every imagined steam cleaning job.
Vario Steam Power
Features two electronic setting that lets you adjust steam as per cleaning
requirement.
Steri Steam Kills up to 99.9% of Germs and Bacteria*
The powerful steam kills up to 99.9% of germs and bacteria. Sanitize all kinds of
hard floors without chemicals and only the use of water. Easily kill germs, bacteria,
viruses and eliminate mould, dust mites and all other pathogens, using nothing
but the most natural cleaning method – superheated steam – perfect for cleaning
and disinfection.
*Using microfibre mop pads. Use as directed, results may vary. Tested under controlled lab conditions.
Steam POD
The steam POD mode gives the user the convenience to convert the steam
cleaner into an handheld device, which can be easily carried to perform cleaning
chores with ease. The steam POD can smartly be utilized to clean up surfaces like
windows, mirrors, kitchen ovens, grills, etc.
S2 – Sweep & Steam Mop in One Go
Achieve hygienic results in one go with the Sweep and Steam combined action.
This saves you time and effort. The special microfibre cloth attracts and removes
dirt, dust and all kind of crumbs, while the steaming function sanitizes on the go.
You can use each option separately as well, or combine them to clean your floors
in one go.
Aroma Diffuser
Release fragrance with steam with the help of the scent discs, creating a soothing
atmosphere.
Reusable Microfibre Pads
T
h
e
R
e
m
Eco-Friendly
It works with water only. It does not leave any kind of chemical residue on your
floor.
Multi-purpose Cleaning Kit
Provides durable accessories and comes packed with a 13-piece cleaning kit. All
accessories were engineered to be durable and to provide you with the right tool
for every imagined steam cleaning job.
Smart Touch
Ease of use to control steam and power, through a smart-looking digital panel.
Vario Steam Power
Features two electronic setting that lets you adjust steam as per cleaning
requirement.
5 6

1.
2a.
Extension Hose
Tool Connector
4. Grasp by steam mop handle and detent to begin mopping.
5. Begin cleaning by slowly moving the unit over the floor surface. Moisture on the
floor is normal when cleaning.
6. When the Zero Bend Series Steristeam stops emitting steam, turn the unit off
and unplug. Verify if there is water in the tank. If empty, refill the water tank.
IMPORTANT: Sanitizing on timber floors is not recommended, as prolonged
application of steam in one area increases the risk of damage to the surface
treatment on timber floors, especially in areas with regular foot traffic and
direct sunlight, which will wear down timber floor surface treatments, making
it more susceptible to steam damage.
USING THE STEAM POD
NOTE: When changing from mopping to hand pod use, press the On/Off
button to turn the steam OFF and wait ten seconds.
1. Make sure the steam is OFF and wait ten seconds.
2. Press the Lift-off release button and pull the hand pod out by the handle.
3. With the connector or extension hose attached to hand pod, connect the tool
to the opening.
4. Turn the tool in order to lock into place.
5. Press the ON/OFF button. Once the ready light stops blinking and is solid, the
heat up is completed.
6. Press the Hi/Lo button, depending on volume of steam desired.
7. ONLY then will the hand-held unit steam.
NOTE: The handheld steam pod will not operate without the proper
attachments. You must have the connector or extension hose attached for the
steam to emit. A safety feature has been designed to prevent steam emission
without the connector or extension hose.
NOTE: Turn the steam OFF before removing or connecting tools and
accessories.
Use of distilled or demineralized water is recommended, to prolong the life of your hard floor cleaner.
Tip
Use of distilled or demineralized water is recommended, to prolong the life of your hard floor cleaner.
Tip
GETTING READY
1. Attach pad to the mop foot. (Elastic band will secure pad on the foot.) *This may
already be attached.
2. Fill the water tank.
a. The water tank opening is located on the side of the water tank. Remove the
cover and use water cup to fill. NOTE: Do not overfill or water may spill. Room
temperature water may provide better results.
b. Close the tank cover and press down firmly.
3. Pull and twist the cord holder clockwise to unwrap the power cord completely
and plug into an outlet as described on the Important Safety Instructions page.
NOTE: Do not use chemicals in the water tank of your Zero Bend Series
Steristeam.
NOTE: Upon the first use of your Zero Bend Series Steristeam or first use after
refilling the water tank, the pump may make a ‘knocking’ sound. This is normal
and could last up to 30 seconds.
USING YOUR STEAM MOP
The floor mop can be used on hard floors. For best results, vacuum the floor first to
clear dust and small debris before using your steam mop. Your Zero Bend Series
Steristeam floor cleaner is designed to clean hard flooring, such as ceramic tile, vinyl,
marble, stone and sealed hard wood floors. Use on waxed or some unwaxed floors
may result in a diminished glossiness. The Zero Bend Series Steristeam is not for use
on unsealed wooden floors. For best results, test in an inconspicuous area and check
the care instructions from your flooring manufacturer.
1. Plug
the unit in and wait 30 seconds for it to heat up. The “ready” light will blink
while the steam mop heats up. The “ready” light will be solid and lit up when heat
up is complete. Press the On/Off button first. Then choose HI or LO steam. HI (for
durable floors or sticky messes) or LO (for delicate floors or everyday cleaning).
2. Trigger is ‘steam on demand’. When steam is wanted, pull trigger. When you do
not want steam, release trigger.
3. To be sure to sanitize an area of your floor, use the microfibre cloth pads and slowly
and evenly stroke your steam mop back and forth at least three times over the area,
using continuous steam. For best results, remove the pad and wash after use.
INSTALLING EUROCLEAN
ZERO BEND SERIES STERISTEAM
INSTALLING EUROCLEAN
ZERO BEND SERIES STERISTEAM
7 8

12
345
687
OPERATING EUROCLEAN
ZERO BEND SERIES STERISTEAM
ASSEMBLY
9 10
12
345
60C
OPERATING EUROCLEAN
ZERO BEND SERIES STERISTEAM
FILLING WATER

10
9
12 13 14
15 16
11
17
OPERATING EUROCLEAN
ZERO BEND SERIES STERISTEAM
12
4
67 8
53
:30
:30
OPERATING EUROCLEAN
ZERO BEND SERIES STERISTEAM
GETTING THE
STEAM READY
11 12

2
345
6
1
MAINTENNCE OF EUROCLEAN
ZERO BEND SERIES STERISTEAM
TROUBLESHOOTING
Problem Possible causes
Reduced
steam or
no steam
Water tank empty
Steam level not selected
ON/OFF button not pressed
Pod not assembled into pocket
correctly
No Steam to
Steam Pod
Tool or Hose connector is not
installed
Remedies
Fill tank
Select steam level by pushing
steam level button
Select by pushing the ON/OFF
button once Ready Light illuminates
Make sure Lift-off pod is securely
pushed into place
Install Tool or Hose connector and
tool to use
13 14

This model is for household use only.
• Unplug from electrical socket when not in use and before servicing.
• This appliance can be used by persons with reduced physical, sensory or mental capabilities or lack of
experience and knowledge, if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
• Children should be supervised to ensure that they do not play with the appliance.
• If the supply cord is damaged, it must be replaced by an authorised Eureka Forbes service division, its
service agent or similarly qualified persons, in order to avoid a hazard.
• Liquid or steam must not be directed towards equipment containing electrical components.
• The appliance should not be left unattended while it is connected to the supply mains.
• The appliance is not to be used if it has been dropped, if there are visible signs of damage or if it
is leaking.
• Keep the appliance out of reach of children when it is energized or cooling down.
• The foot surfaces are liable to get hot during use. » Do not leave appliance when plugged in.
• Do not modify earthed plug.
• To reduce the risk of electric shock: Use indoors only. Do not expose to rain. Store indoors.
• Do not allow to be used as a toy.
• Use only as described in this user guide.
• Use only manufacturer’s recommended attachments.
• Do not use with damaged cord or plug.
• Do not immerse in water or liquid.
• If appliance is not working as it should, has been dropped, damaged, left outdoors, or dropped into
water; do not attempt to operate it and have it repaired at an authorised Eureka Forbes service centre.
• Do not pull or carry by cord, use cord as a handle, close door on cord, or pull cord around sharp edges
or corners.
• Do not run appliance over cord.
• Keep cord away from heated surfaces.
• To unplug, grasp the plug, not the cord.
• Do not handle plug or appliance with wet hands.
• Do not put any object into openings.
• Turn off all controls before unplugging.
• Use extra care when cleaning on stairs.
• Do not use appliance in an enclosed space filled with vapours given off by oil base paint, paint thinner,
some mothproofing substances, flammable dust, or other explosive or toxic vapours.
• Keep appliance on a level surface.
SAFETY INFORMATION
TECHNICAL SPECIFICATIONS
15 16
Voltage AC 220/240V Frequnecy 50 Hz
Input power 1,600 Watts
Tank capacity 0.4 Litres
Heater type Flash Heater Technology
Net weight 4.17Kg
Dimensions (WxDxH) in cm 28x34x113.5 cm

WARRANTY TERMS &
CONDITIONS
WARRANTY
Euroclean Zero Bend Series Vacuum Cleaners are warranted against defects arising from faulty
workmanship and materials for a period of 2 years.
• The customer will notify the Company in writing promptly of any defects noticed and give
the Company or its authorized agent adequate opportunity to inspect, test and remedy
them for which the customer will deposit the goods if so required by the Company, with the
Company's Office/Service Centre along with original Invoice, in the city where they are sold.
• Inspection and Test Report of the Company's Office/Service Centre will be final and binding
under the Warranty for determining defects, repairs/alterations which are required or carried
out for certifying working of the goods thereafter.
• The Company or its authorized agent will be entitled to retain any defective part replaced
under the Warranty.
• Notwithstanding anything to the contrary contained in or implied by this.
WARRANTY
• The Company's liability under this Warranty shall be limited to the first sale of the goods by
the Company to the Customer and will not apply or extend to any secondary sale of any of
these goods by the Customer.
• The Company's liability under terms of Warranty shall be limited only to defects in the goods
which occur under the conditions of normal operation of the goods and their proper and
prescribed use. This Warranty does not cover or extend to defects which are determined by
the company or its authorized agents as occurring or resulting from or attributable to
negligence, abuse, misuse, faulty care operation or maintenance or repairs, alterations to the
goods or any part thereof by others or the use of the goods on electric supply for which they
are not designed or suffer damage caused by lightning or any other electrical disturbance or
interruption which may occur. The rectification/replacement of the motor shall be at the
company's discretion.
• The Customer will have no claim against the Company, its employees and its authorized
agents or franchisees under or pursuant to this Warranty in respect of death or injury to the
Customer or any other person or loss or damage to any property caused by or due to
equipment failure, breakdown or accident, fire or operation or utilization of the goods
otherwise than in accordance with the User Guide or by or due to any other cause or
circumstance beyond the control of the Company.
17 18
WARRANTY TERMS &
CONDITIONS
• The Company's liability under this Warranty shall in no event and under no circumstances
exceed the price paid by the Customer to the Company for the goods stated in the invoice.
GENERAL
For the purpose of this Warranty, the following expressions shall have the following meanings
respectively:
• The Goods' shall mean the goods described in the Order Form.
• The Customer' shall mean the original purchaser of the mentioned goods from the Company.
• The Company' shall mean the Company ‘EUREKA FORBES LIMITED'.
• General Terms and Conditions' shall mean the Terms and Conditions agreed upon by the
Customer and the Company which are printed on the Order.
• Invoice' shall mean the invoice issued by the Company to the Customer describing the goods
and indicating, inter alia, the total purchase price thereof and the name of the Customer.
• User Guide' shall mean the instructions for installation, use and maintenance contained in the
leaflet, which is supplied by the Company.
POST-WARRANTY
• The Customer may be offered a yearly Service Contract based on the prevailing Company
Rates and Terms.
• In case the Customer does not wish to enter the Service Contract, he has the option of calling
our Service Centre and having his Euroclean Vacuum Cleaner serviced on an actual basis, i.e.
by paying for Labour Cost and Spares needed to attend to that Service/Complaint call at the
prevailing Company rates. Such service will be rendered by the Company in towns/places
where there are Service Centres.
• The Company will provide free servicing of the goods brought to the Service Centre by the
Customer, provided that all expenses of transporting the goods to and from the Service
Centre shall be borne by the Customer directly. If during such servicing it is necessary for the
Company to replace or repair defective components or parts, the Customer shall be required
to pay for the same as per the Company's prevailing price list.
