Whittier Wood 1137AFGSPd User manual

P.O. Box 2827
Eugene, OR 97402 USA
Production Code:
VN 07/13
Model #
1137AFGSPd;
1137AFCAFd
Pacific 9-Drawer
Dresser
AFGSP = Glazed Spice finish
AFCAF = Caffè finish
Assembly Instructions
Congratulations!
This fine piece of furniture will make a gorgeous addition to
your home. For the best results, read the Assembly
Instructions before you begin your project.
IMPORTANT NOTES:
For normal household use only. Not recommended for commercial use.
Do not climb, sit or stand on this piece of furniture.
Do not overload the drawers.
Unload items before you move this unit.
Before you load or move this unit, tighten all screws and supports.
Before you begin your project, completely read the Assembly
Instructions.
Store this item: 1- in its box; 2- in a dry place; 3- in temperatures that
range from 40°F to 90°F (not on a cold and possibly damp cement
floor).
Periodically inspect your furniture for any loose glue joints, screws or
any other problem that might affect the stability of your furniture.
Tighten or repair as needed.
This assembly requires two people.
WARNING
Serious or fatal crushing injuries can occur from furniture tip-over. Use of
tip-over restraints may only reduce but not eliminate the risk of tip-over.
To help prevent tip-over:
Place heaviest items in the bottom drawers.
Unless specifically designed to accommodate, do not set TVs or other
heavy objects on top of this product.
Never allow children to climb or hang on drawers, doors or shelves.
Never open more than one drawer at a time.
Warning: At least one tipping restraint kit was included with your piece of
Whittier Wood Furniture. When you receive your furniture, be sure to find
and properly install the tipping restraint(s). If you cannot locate the
restraint(s), please contact us immediately for replacement.
Notice to California Customers
California Prop 65 requires consumer goods to be labeled if any one of
850+ different chemicals or substances, including wood dust, is present
even in trace amounts. Drilling, sawing, sanding or machining wood
products generates wood dust, a substance known to the State of
California to cause cancer. Warning: This product contains a chemical
or substance known to the State of California to cause cancer, birth
defects or other reproductive harm. California Health and Safety Code
Section 25249.6
DESIGN SUBJECT TO CHANGE WITHOUT NOTICE.
CALL US FIRST! Do not return this item to the store
Service Policy: We will replace any part that is defective,
missing or damaged during assembly. For a replacement
part, directly contact Whittier Wood Products customer
service department by phone, fax, mail or email.
Hours: Our friendly customer service staff can be reached
Monday-Friday 7:00 a.m. to 5:00 p.m. (Pacific Time). You
may leave a message 24 hours a day, seven days a week.
To Order: Provide the finish and furniture model number
(upper portion of this page), the part letter, production
code, quantity needed, reason for replacement and your
full name, address and telephone number.
Parts ship from our Eugene, Oregon factory within one or
two business days from the time we receive your request.
Please allow five to ten business days for delivery.
800-653-3336 •Outside the U.S. or Canada: 541-687-0213 • Fax: [phone]
www.whittierwood.com • P.O. Box 2827 • Eugene, Oregon 97402, U.S.A.

1137AFGSPd; 1137AFCAFd Pacific 9-Drawer Dresser
Parts List
1137AFGSPd_1137AFCAFd —Page 2 —07/13
Please identify the parts and check that quantities received match those on this list.
If you need to replace a part, refer to the following letter and part name.
Part
Description
Quantity
A
Top Assembly (attached)
1
Bc
Case
1
C
Medium Left Drawer
1
D
Medium Right Drawer
1
E
Large Left Drawer
3
F
Large Right Drawer
3
G
Small Drawer with secret storage
1
I
Medium Drawer Face (installed)
2
J
Large Drawer Face (installed)
6
K
Small Drawer Face (installed)
1
L
Knob (attached)
3
M
Handle (attached)
6
O
Drawer Slides (pre-installed sets)
9
Vb
Hinged Drawer Stop (attached)
1
Y
Small Adjustable Glide (installed)
4
ZD
#8 x 1-1/4" Pan Head Screw (inserted)
8
ZE
#8 x 1-1/4" Black Screw (inserted)
37
ZH
#8 x 1-5/8" Black Screw (inserted)
6
ZI
#8 x 2" Black Screw (inserted)
2
ZJ
#6 x 3/4" Philtruss Screw (inserted)
54
ZK
#6 x 1/2" Philtruss Screw (inserted)
54
ZL
#6 x 5/8" Undercut Screw (inserted)
2
ZO
M4 x 10mm Insert Nut (inserted)
4
ZP
Hex Bumper (attached)
2

1137AFGSPd; 1137AFCAFd Pacific 9-Drawer Dresser
Parts List
1137AFGSPd_1137AFCAFd —Page 3 —07/13
Part
Description
Quantity
ZQ
Pad Strip (attached)
1
ZR
#8 x 1" Lo-Profile Screw (inserted)
48
ZS
#8 x 1-1/8" Lo-Profile Screw (inserted)
10
ZT
1/4" x 20mm Insert Nut (inserted)
4
ZU
#8 x 1-5/8" Machine Screw (installed)
15
ZV
#8 x 1-3/8" Lo-Profile Screw (inserted)
9
ZW
Adjustable Glide with Hex Nut (installed)
1
ZX
Assembled Foot (attached)
1
ZY
5/16" x 3/4" Insert Nut (inserted)
1
TR
Furniture Tipping Restraint
2 sets

1137AFGSPd; 1137AFCAFd Pacific 9-Drawer Dresser
Assembly Instructions
1137AFGSPd_1137AFCAFd —Page 4 —07/13
Tool Required: Phillips Screwdriver
1. Place the unit at its final destination. Rotate the Small Adjustable Glides (Y) found at the corners
of the unit and the Adjustable Glide with Hex Nut (ZW) at the bottom of the Assembled Foot
(ZX) until the unit is level. See Figure 1.
2. Tipping restraint: Locate two studs in the wall behind the unit. Attach a Clip (T1) to one wall
stud with two #8 x 2" Black Screws (T3). See Figure 2a. Attach a second clip to the unit with two
#6 x 5/8" Philtruss Screws (T5). See Figure 2b. Connect the two clips with the Nylon Restraint
Strap (T2). Pull the Nylon Restraint Strap (T2) tight so there is no slack. See Figures 2c and 2d.
Repeat this procedure to attach the second tipping restraint. If you cannot locate two studs,
purchase the proper wall attachment hardware for your type of wall and secure the unit.
Fig. 2a
T1
T3
Pull tight
Fig. 2d
T1
T2
T5
Fig. 2c
Pull the Nylon Restraint
Strap (T2) tight
so there is no slack.
T3
T5
T1
Fig. 2b
Fig. 1
ZX
ZW
Y
Y

1137AFGSPd; 1137AFCAFd Pacific 9-Drawer Dresser
Assembly Instructions
1137AFGSPd_1137AFCAFd —Page 5 —07/13
3. There is a secret storage area in the Small Drawer (G). To access this storage, open the top
Large Right drawer (F). Reach in until you find the Hinged Drawer Stop (Vb) that is attached to
the bottom right side of the Small Drawer (G). Pull the Hinged Drawer Stop forward and then
pull the Small Drawer (G) out far enough so you can access the concealed storage space.
To close the drawer, just push it shut. See Figure 3.
Fig. 3
G
Vb
G
F
1137 Pacific 9-Drawer Dresser
