Sonoma 71SRRCU13 User manual

Page 1/3
PART LIST QUANTITY
A1 PC
B1 PC
C1 PC
D1 PC
E10 PCS + 1 PC
F10 PCS + 1 PC
G1 PC
H2 PCS
I2 PCS
SEAT
SONOMA ACADIA LOVESEAT ASSEMBLY INSTRUCTIONS
ASSEMBLE ON A FLAT, PROTECTED SURFACE.
STYLE #:
BACK CUSHION
BACK
FLAT WASHER
71SRRCU13
FIGURE
DESCRIPTION
RIGHT ARM/LEG
SAVE THESE INSTRUCTIONS
SEAT CUSHION
LEFT ARM/LEG
BOLT
(M6*15MM)
ALLEN WRENCH

Page 2/3
71SRRCU13
STYLE #:
ASSEMBLY INSTRUCTIONS (CONTINUED)
STEP 3
-
A. CONNECT LEFT ARM/LEG (B) TO SEAT (C) WITH
BOLTS (E) AND FLAT WASHERS (F) USING ALLEN
WRENCH (G). DO NOT TIGHTEN COMPLETELY.
STEP 2
-
A. CONNECT BACK (D) TO SEAT (C) WITH BOLTS (E)
AND FLAT WASHERS (F) USING ALLEN WRENCH
(G). DO NOT TIGHTEN COMPLETELY.
STEP 1
A. PLACE RIGHT ARM/LEG (A) ON A FLAT,
PROTECTED SURFACE.
B.
CONNECT SEAT (C) TO RIGHT ARM/LEG (A) WITH
BOLTS (E) AND FLAT WASHERS (F) USING ALLEN
WRENCH (G). DO NOT TIGHTEN COMPLETELY.

Page 3/3
CUSHION: SPOT CLEAN WITH A SOFT CLOTH.
DO NOT STAND OR CLIMB ON LOVESEAT.
TO ASSIST YOU BETTER, PLEASE GATHER THE FOLLOWING INFORMATION BEFORE CALLING CUSTOMER SERVICE:
PRODUCT NAME AND STYLE NUMBER, DESCRIPTION AND OR IMAGES OF THE ISSUE, ORIGINAL STORE PURCHASE
RECEIPT.
1 YEAR LIMITED WARRANTY FOR FRAME.
CUSTOMER SERVICE: PLEASE NOTE - DO NOT RETURN THIS ITEM TO THE RETAILER.
CUSTOMER SERVICE HOT LINE: 1-866-905-4107
WEBSITE: WWW.YOTRIOINT.COM
STEP 5
A. PLACE SEAT CUSHIONS (H) ON LOVESEAT AND
ATTACH WITH TIES TO BACK CROSSBAR.
B. PLACE BACK CUSHIONS (I) ON LOVESEAT.
C. ASSEMBLY IS COMPLETE.
WARRANTY
FRAME: WIPE CLEAN WITH A MILD SOAP AND WATER SOLUTION, RINSE WITH CLEAN WATER, AND DRY THROUGHLY.
CARE AND CLEANING
IN ORDER TO PROLONG THE LIFE OF YOUR LOVESEAT, PLEASE STORE IN DRY SHELTERED PLACE WHEN NOT IN USE OR
DURING INCLEMENT WEATHER.
500 LBS
STEP 4
A. ROTATE LOVESEAT TO THE UPRIGHT POSITION.
B. CONNECT BACK (D) TO RIGHT ARM/LEG (A) AND
LEFT ARM/LEG (B) WITH BOLTS (E) AND FLAT
WASHERS (F) USING ALLEN WRENCH (G).
C. TIGHTEN ALL BOLTS.
-
ASSEMBLY INSTRUCTIONS (CONTINUED)
WEIGHT LIMIT
** WE RECOMMEND THAT YOU SAVE THE ALLEN WRENCH AND PERIODICALLY TIGHTEN ALL BOLTS.
STYLE #:
71SRRCU03

Page 1/2
PART LIST QUANTITY
A1 PC
B4 PCS
C4 PCS + 1 PC
D4 PCS + 1 PC
E4 PCS + 1 PC
F1 PC
STYLE #:
71SRRCU13
FIGURE
DESCRIPTION
WRENCH
SAVE THESE INSTRUCTIONS
SONOMA ACADIA COFFEE TABLE ASSEMBLY INSTRUCTIONS
TOP
BOLT
(M8*50MM)
FLAT WASHER
LOCK WASHER
ASSEMBLE ON A FLAT, PROTECTED SURFACE.
LEG

Page 2/2
1 YEAR LIMITED WARRANTY FOR FRAME.
TO ASSIST YOU BETTER, PLEASE GATHER THE FOLLOWING INFORMATION BEFORE CALLING CUSTOMER SERVICE:
PRODUCT NAME AND STYLE NUMBER, DESCRIPTION AND OR IMAGES OF THE ISSUE, ORIGINAL STORE PURCHASE
RECEIPT.
165 LBS
CUSTOMER SERVICE: PLEASE NOTE - DO NOT RETURN THIS ITEM TO THE RETAILER.
CUSTOMER SERVICE HOT LINE: 1-866-905-4107
STEP 2
A. ROTATE TABLE TO UPRIGHT POSITION.
B. ADJUST LEVELERS ON BOTTOM UNTIL THE TABLE
IS STABLE.
C. ASSEMBLY IN COMPLETE.
STEP 1
A. PLACE TOP (A) UPSIDE DOWN ON A FLAT,
PROTECTED SURFACE.
B. CONNECT LEGS (B) TO TOP (A) USING BOLT (C),
FLAT WASHER (E) AND FLAT WASHER (D) WITH
WRENCH (F). TIGHTEN COMPLETELY.
STYLE #:
ASSEMBLY INSTRUCTIONS (CONTINUED)
WEBSITE: WWW.YOTRIOINT.COM
IN ORDER TO PROLONG THE LIFE OF YOUR TABLE, PLEASE STORE IN DRY SHELTERED PLACE WHEN NOT IN USE OR
DURING INCLEMENT WEATHER.
CARE AND CLEANING
WIPE CLEAN WITH A MILD SOAP AND WATER SOLUTION, RINSE WITH CLEAN WATER, AND DRY THROUGHLY.
DO NOT SIT, STAND, OR CLIMB ON THE TABLE.
WARRANTY
** WE RECOMMEND THAT YOU SAVE THE ALLEN WRENCH AND PERIODICALLY TIGHTEN ALL BOLTS.
WEIGHT LIMIT
71SRRCU13
