EVA Logik ZW97 User manual

1: ADD/REMOVE
--Manual add mode: Press the button 3 times
--Auto-add mode: LED will blink within 30 seconds aer power on
press 1x: On/Off the Le outlet
press 2x: On/Off the Right outlet
hold 3s: On/Off simultaneously.
2: Factory reset:
Manual : Click the button 2 times quickly, and hold for at least
10 seconds
Host reset: Remove it from the host and the device is factory reset.
3: Association
Support 3 groups, each group max support 2 devices
(LED flashes 2 times when the configuration parameter changed.)
Group 1 lifeline
Group 2 le outlet send basic set
Group 3 right outlet send basic set
4: LED Indicator
(LED flashes 2 times when the configuration parameter changed.)
quickly press 6x: change parameter
--Parameter =1, size =1 byte, value=00(default)output on, LED on
--Parameter =1, size =1 byte, value=01 output on, LED off
--Parameter =1, size =1 byte, value=02 LED no work
5: Auto Turn-Off Timer
(LED flashes 2 times when the configuration parameter changed.)
--Parameter =2, size=4 byte, value= 1 – 65535 (Min), le outlet off
--Parameter =3, size=4 byte, value= 1 – 65535 (Min), right outlet off
6: Auto Turn-On Timer
(LED flashes 2 times when the configuration parameter changed.)
--Parameter =4, size=4 byte, value= 1 – 65535 (Min), le outlet on
--Parameter =5, size=4 byte, value= 1 – 65535 (Min), right outlet on
7:Restores state aer power failure(quickly press 10x: change Parameter)
(LED flashes 2 times when the configuration parameter changed.)
Parameter=6,Size=1,Value=0 output off
Value=1 output on
Value=2 out put the state aer power(default)
Parameter Settings
Outdoor Smart Plug
( 2 channel )
Specifications
+
Meet your new smart plug !
(A) Manual / Program button
Those are your smart outlets that will be
included to your smart Hub/Gateway.
(B/C) Smart Outlet
press 1x: On/Off the Le outlet
press 2x: On/Off the Right outlet
hold 3s: On/Off simultaneously.
Put the Z-wave interface controller into “Add” mode, triple press
the Program button (A). It will be included to network. (Once your
controller confirmed, refresh the Z-Wave network to optimize
performance. )
Put the Z-Wave interface controller into "Remove" mode, triple
press the Program button (A). It will be excluded to network.
Manual reset: Click the button 2 times quickly, and hold for at least
10 seconds.
Host reset: Remove it from the host and the device is factory reset.
Note: This should only be used in the event your network’s primary
controller is missing or otherwise inoperable.
Add to Z-Wave Network
Remove from Z-Wave Network
To return your switch to factory defaults
Note:
Include the device to the network
within 10 feet of the controller when
adding to the controller then
relocate it to the desired position in
your home, no more than 100 feet
distance from controller. Be sure to
refresh the network while the device
is included in this manner.
One Z-Wave controlled AC outlet for standard incandescent
lighting, CFL/LED. Total load capacity for both outlets is
15A(1800W) Resistive.
Plug the device you want to control into the Z-Wave Smart plug
controlled outlet .
NOTE: Plug directly into outlet, do not use with extension cords.
Model: ZW97
Power: 120VAC, 60Hz
Loading : 15 Amp Smart Outlet*2
Total(Both Outlets): 15 Amp Max
Frequency: 908.42 MHz
Operating Temperature: -4° F~122° F
A
B
C
100 feet
Introduction
The EVA LOGIK ZW97 is a Z-Wave enabled 15A receptacle designed for
using of most residential lighting and motor applications. It's compatible
with LED, halogen, incandescent, xenon, fluorescent and compact
fluorescent bulbs.The ZW97 fully works with the Fibaro, Smartthings,
Wink hub as well as all other certified Z-Wave controllers.
The Internet of Things offers tremendous promise to consumers by
enabling remote control and management of an ever-growing variety
of connected devices—from home security systems to energy manage-
ment, appliances and lighting, and remote home monitoring, just to
name a few categories.
Analysts predict that billions of devices will be connected to the
Internet of Things in the coming years. One key consideration is how
all of these devices will be integrated and controlled, and common
standards are key to enabling simple, straight forward installation and
management of devices in the connected home.
The Z-Wave protocol is an interoperable, wireless, RF-based communi-
cations technology designed specifically for control, monitoring and
status reading applications in residential and light commercial
environments. Mature, proven and broadly deployed (with over 100
million products sold worldwide), Z-Wave is by far the world market
leader in wireless control, bringing affordable, reliable and
easy-to-use ‘smart’ products to many millions of people in every
aspect of daily life.
Z-Wave Internet
• ZW97 •
• White LED indicator
For outdoor use
IP65 rated
Plug * 1
Screw * 1
Plastic Anchor * 1
Manual * 1

OTHER WARNINGS
Risk of Fire
Risk of Electrical Shock
Risk of Burns
Z-wave Interoperability
Command Class Information
NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment
generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions may cause
harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
Important note: To comply with the FCC RF exposure compliance
requirements, no change to the antenna or the device is permitted. Any
change to the antenna or the device could result in the device exceeding
the RF exposure requirements and void user’s authority to operate the
device.
FCC / IC
This device complies with part 15 of the FCC and Industry Canada
license-exempt RSS standard(s). Operation is subject to the following two
conditions:
(1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may
cause undesired operation.
— Reorient or relocate the receiving antenna.
— Increase the separation between the equipment and receiver.
— Connect the equipment into an outlet on a circuit different from that
to which the receiver is connected.
— Consult the dealer or an experienced radio/TV technician for help
FCC NOTE: The manufacturer is not responsible for any radio or TV
interference caused by unauthorized modifications to this equipment.
Such modifications could void the user’s authority to operate the
equipment.
CAUTION - PLEASE READ!
This device (ZW97) is intended for installation in accordance with the
National Electric Code and local regulations in the United States, or
the Canadian Electrical Code and local regulations in Canada. If you
are unsure or uncomfortable about performing this installation
consult a qualified electrician.
CONTROLLING APPLIANCES
Please exercise EXTREME CAUTION when using Z-Wave devices to
control appliances. Reason being is because the appliance you want to
control may be in a separate room and if unintentional behavior occurs
(such as adevice turning on or off - either intentionally via schedules, or
unintentionally via network error) this event may lead to a hazardous
condition. For these reasons, please note the following suggestions:
1) Do not include Z-Wave devices in Groups or Scenes if they control
appliances.
2) Do not use Z-Wave devices to control electric heaters or any other
appliances which may present a hazardous condition due to unattend-
ed, unintentional, or automatic power control
WARNING - SHOCK HAZARD
TURN OFF THE POWER to the circuit for the switch and lighting fixture
at the service panel (circuit breaker) prior to installation.
ALL WIRING CONNECTIONS MUST BE MADE WITH THE POWER OFF
to avoid personal injury and/or damage to the switch.
MEDICAL EQUIPMENT
Please DO NOT use this switch to congrol Medical or Life Support
equipment. Z-Wave devices should never be used to control the On/Off
status of Medical and/or Life Support equipment.
This product can be included and operated in any Z-Wave
network with other Z-Wave certified devices from other
manufacturers and/or other applications. All non-battery
operated nodes within the network will act as repeaters
regardless of vendor to increase reliability of the network.
This Device supports lifeline (association group 1)
supporting 1 node for lifeline communication.
Group 1 must be assigned the Node ID of the primary
controller where unsolicited notifications will be sent.
The Z-Wave controller should set this association
automatically aer inclusion.
Lifeline association only supports the “Device Reset
Locally” function. Refer to the instructions of your
controller for any available details on how this can be set.
GRNERIC DEVICE CLASS:
10 - GENERIC_TYPE_SWITCH_BINARY
SPECIFIC DEVICE CLASS:
01 - SPECIFIC_TYPE_POWER_SWITCH_BINARY
COMMANDCLASS:
5E - COMMAND_CLASS_ZWAVEPLUS_INFO
25 - COMMAND_CLASS_SWITCH_BINARY
85 - COMMAND_CLASS_ASSOCIATION
8E - COMMAND_CLASS_MULTI_CHANNEL_ASSOCIATION
59 - COMMAND_CLASS_ASSOCIATION_GRP_INFO
55 - COMMAND_CLASS_TRANSPORT_SERVICE
86 - COMMAND_CLASS_VERSION
72 - COMMAND_CLASS_MANUFACTURER_SPECIFIC
5A - COMMAND_CLASS_DEVICE_RESET_LOCALLY
73 - COMMAND_CLASS_POWERLEVEL
70 - COMMAND_CLASS_CONFIGURATION
9F - COMMAND_CLASS_SECURITY_2
60 - COMMAND_CLASS_MULTI_CHANNEL
6C - COMMAND_CLASS_SUPERVISION
7A - COMMAND_CLASS_FIRMWARE_UPDATE_MD
www.nie-tech.com
V1.0
Our Products warrants this product to be free from manufacturing defects for a period of one year from the original date of consumer
purchase. This warranty is limited to the repair or replacement of this product only and does not extend to consequential or inciden-
tal damage to other products that may be used with this product. This warranty is in lieu of all other warranties, expressed or implied.
Some states do not allow limitations on how long an implied warranty lasts or permit the exclusion or limitation of incidental or
consequential damage, so the above limitations may not apply to you. This warranty gives you specific rights, and you may also have
other rights which vary from state to state.
WARRANTY
