EverFocus EZH5040 Technical manual

Operation Instruction
HDcctv Megapixel 720p
3-Axis Outdoor IR Vandal-Proo
Bullet Camera
E
EZ ZH H5 50 04 40 0
EverFocus

2
E V E R F O C U S E L E C T R O N I C S C O R P O R A T I O N
Operation Instruction
 2011 EverFocus Electronics Corp
Please rea this manual first for correct installation an operation. This manual shoul be retaine for
future reference. The information in this manual was current when publishe . The manufacturer reserves
the right to revise an improve its pro ucts. All specifications are therefore subject to change without
notice.
All rights reserve . No part of the contents of this manual may be repro uce or transmitte in any form or by
any means without written permission of the EverFocus Electronics Corporation.

3
PRECAUTIONS
1. Do not install the camera near electric or magnetic fields.
Install the camera away from TV/ra io transmitters, magnets, electric motors, transformers
an au io speakers since the electromagnetic fiel s generate from these evices may
istort the vi eo image or otherwise interfere with camera operation.
2. Ne er disassemble the camera beyond the recommendations in this manual nor
introduce materials other than those recommended herein. Improper isassembly or
intro uction of corrosive materials may result in equipment failure or other amage.
3. Try to a oid facing the camera toward the sun.
In some circumstances, irect sunlight may cause permanent amage to the sensor an /or
internal circuits, as well as creating unbalance illumination beyon the capability of the
camera to compensate.
4. Keep the power cord away from water and other liquids and ne er touch the power
cord with wet hands. Touching a wet power cor with your han s or touching the power
cor with wet han s may result in electric shock.
5. Ne er install the camera in areas exposed to oil, gas or sol ents.
Oil, gas or solvents may result in equipment failure, electric shock or, in extreme cases, fire.
6. Cleaning
For cameras with interchangeable lenses, o not touch the surface of the sensor irectly
with the han s. Use lens tissue or a cotton tippe applicator an ethanol to clean the
sensor an the camera lens. Use a amp soft cloth to remove any irt from the camera
bo y. Please o not use complex solvents, corrosive or abrasive agents for cleaning of any
part of the camera.
7. Do not operate the camera beyond the specified temperature, humidity or power
source ratings. This camera is suitable for indoor and outdoor operation. Use the
camera at temperatures within -10°C~50°C (14°F~122°F) an in an IP67 compliant
environment; this evice is not rate as submersible. The input power source is
12VDC/24VAC. The use of properly fused or Class 2 power limited type supplies is
highly recommended.
8. Mounting
Use care in selecting a soli mounting surface which will support the weight of the camera
plus any win , snow, ice or other loa ing, an securely attach the camera to the mounting
surface using screws an anchors which will properly support the camera. If necessary
(e.g. when mounting to rop ceilings) use a safety wire to provi e a itional support for the
camera.

4
ATTENTION!
This is a class A pro u
ct which may cause ra io interference in a omestic
environment; in this case, the user may be urge to take a equate measures.
Federal Communication Commission Interfere
nce Statement
This equipment has been teste an foun to comply with the limits for a Class B igital
evice, pursuant to Part 15 of the FCC Rules. These limits are esigne to provi e
reasonable protection against harmful interference in a resi ential installation. This
equipment generates, uses an can ra iate ra io frequency energy an , if not installe
an use in accor ance with the instructions, may cause harmful interference to ra io
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment oes cause harmful interference to ra io or
television reception, which can be etermine by turning the equipment off an on, the
user is encourage to try to correct the interference by one of the following measures :
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment an receiver.
•Connect the equipment into an outlet on a circuit ifferent from that to which the receiver
is connecte .
•Consult the ealer or an experience ra io/TV technician for help.
FCC Caution: Any changes or mo ifications not expressly approve by the party
responsible for compliance coul voi the users’ authority to operate this equipment.

5
Table of Contents
1. PRODUCT OVERVIEW...................................................................................................................... 6
1.1 F EATURES ........................................................................................................................................... 6
1.2 A CCESSORY P ARTS L IST ...................................................................................................................... 7
1.3 S PECIFICATIONS .................................................................................................................................. 8
1.4 D IMENSIONS ........................................................................................................................................ 9
2. INSTALLATION .............................................................................................................................. 100
3. OSD MENU & CONFIGURATION................................................................................................ 133

6
1. Product Overview
The EZH5040 is an HDcctv 3-Axis out oor bullet camera with True Day/Night capability in an
IP67 van al resistant housing. Base on a Sony 1.3 megapixel progressive scan sensor for HD
720p resolution 100% igital images, it elivers vastly superior vi eo quality compare to
tra itional CCTV images. This superior resolution not only captures more critical evi entiary
information, but the inherent ability for megapixel vi eo also exten s the area of coverage,
expe ites completion of investigations, resolves complaints an re uces both capital an
operational costs. Designe with long lifespan IR LEDs, the EZH5040 can capture images at up
to 45m (~150 ft.) in low or no light environments.
No major upgra e to the IT network is require to eploy this powerful technology; HDcctv cameras
communicate at igital spee s up to 1.5Gb/s over existing or new coaxial cable (RG59 or other types
for longer istances), using in ustry stan ar BNC connectors. With its 3-Axis positioning an vari-
focal 3-9mm megapixel auto iris lens the EZH5040 elivers flexible, robust coverage in a wi e range of
eman ing surveillance environments while elivering stunning HD image quality.
1.1 Features
HDcctv Alliance Base Line Compliance
HDcctv Megapixel real time 1280x720 HD vi eo over coax
Supports vi eo outputs of 720p25/30/50/60 (fiel select)
True ay/night operation with automatic ICR mo ule
 Inclu es DNR to improve picture clarity while enabling DVRs to improve isk storage
utilization
3-Axis positioning for flexible mounting an aiming
3~9mm AI VF megapixel lens captures the esire fiel of view
Exten e IR range of up to 45m (~150 ft.)
Easy to use OSD setup menu
SD TV Out for aim an focus using a stan ar han hel test monitor
Dual Voltage Power Source 12VDC/24VAC
Van al Resistant
Weather Proof IP67 rate
The HDcctv Alliance states
Look for the unique HDcctv logo to be sure:
100m transmission over even low-gra e RG59
Plug-an -play interoperability with other compliant pro ucts
Forwar compatibility with future versions of the stan ar
See www.hi efcctv.org for etails
Ch
apter
1

7
1.2Accessory Parts List
Please be careful when you unpack the box ue to the electronics evices insi e. Check an
make sure that you have all the items liste below insi e the original box:
HD CCTV
Digital V ideo
Camera
SER VICE VIDEO
OUTPUT TEST
CABL
E
L WRENCH
OPERATION
MANUAL
SCREW - 4ea
Plastic anchors - 4ea
Please Note: If an item appears to have been amage in shipment, replace it properly in its carton
an notify the shipper. If any items are missing, notify your EverFocus Electronics Corp. Sales
Representative or Customer Service. The shipping carton is the safest container in which the unit may
be transporte . Save it for possible future use.

8
1.3 Specifications
Pickup Device 1/3” Sony Megapixel Color Progressive CMOS Sensor
Sensitivity 1lux/F=1.4; 0lux(IR LED ON)
S/N Ratio Max. 50 B
Vi eo Format Main Output HDcctv 1.5Gb/s igital system
Resolution Main Output 1280x720
Vi eo Mo e Main Output Fiel select 720p25, 720p30, 720p50, 720p60
Main Output Connector BNC
Vi eo Format Test Output NTSC/PAL selectable
Test Output Connector Pin hea er; a apter cable to BNC supplie
Exposure Control via lens DC iris
Lens Type Vari-focal lens, Auto Iris, f=3~9mm
True Day/Night Control Yes (Auto IR cut filter removal)
Back Light Compensation On/Off selectable
Auto Gain Control Yes (level 0~150)
Auto White Balance ATW/Push/Manual
DNR Off/Low/Mi /High selectable
OSD Menu Yes (controlle from 5-Axis joystick control)
Image Flip Off/H Flip/V Flip/HV Flip
IR Wavelength 850nm
IR Range Up to 45m (~150 ft.)
Power Source & Consumption 24VAC: 12W max. (~500mA)
12VDC: 1.1A max.
Dimensions 196mm(L) x 83mm(H) x 110mm Diameter(W)
12.9in.(L) x 3.26in.(H) x 4.33in. Diameter(W)
Weight 2kg /4.4 lbs
Operating Temperature -10°C~50°C ; 14°F~122°F
Weather Proof IP67 rate
Van al Resistant Yes
Certifications FCC/CE; HDcctv Alliance Base Line Compliance

9
1.4 Dimensions

10
2. Installation
Adjusting camera mounting position
Chapter
2

11
External Zoom & Focus Adjustment

12
Service Vi eo Out & OSD Control
**NOTE:
1. Separate two parts of the power a aptor
2. Remove the part with the screws
3. Attach it to the wire
4. Reconnect to en of cable
HDcctv DVR or other
HDcctv signal equipment
** NOTE
to HDcctv DVR

13
3. OSD Menu & Con iguration
This chapter intro uces how to configure the camera OSD menu.
Chapter
3

14

15

16

17

18

19

20
