7705EO-HD SMPTE292M Re-Clocking Electrical to Fiber Converter
TABLE OF CONTENTS
1. OVERVIEW......................................................................................................................................... 1
2. INSTALLATION.................................................................................................................................. 2
2.1. CARE AND HANDLING OF OPTICAL FIBER.......................................................................... 3
2.1.1. Safety ............................................................................................................................. 3
2.1.2. Assembly........................................................................................................................ 3
2.1.3. Labeling.......................................................................................................................... 3
2.1.4. Handling and Connecting Fibers.................................................................................... 3
3. SPECIFICATIONS.............................................................................................................................. 4
3.1. SERIAL VIDEO INPUT.................................................................................................................... 4
3.2. SERIAL VIDEO OUTPUTS .............................................................................................................. 4
3.3. OPTICAL OUTPUT ........................................................................................................................ 4
3.4. ELECTRICAL ................................................................................................................................5
3.5. PHYSICAL................................................................................................................................. 5
4. STATUS LEDS ................................................................................................................................... 5
5. JUMPERS AND USER ADJUSTMENTS ........................................................................................... 5
5.1. SELECTING RECLOCK OR NON-RECLOCK MODE.............................................................. 6
5.2. SELECTING WHETHER LOCAL FAULTS WILL BE MONITORED
BY THE GLOBAL FRAME STATUS......................................................................................... 7
5.3. SETTING THE EQUALIZER WARNING THRESHOLD............................................................ 7
Figures
Figure 1: 7705EO-HD Block Diagram ................................................................................................................. 1
Figure 2: 7705EO-HD Rear Panel....................................................................................................................... 2
Figure 3: Reproduction of Laser Certification and Identification Label ............................................................... 3
Figure 4: Jumper Locations for Rev A and Rev 1 DA Cards .............................................................................. 5
Figure 5: Jumper Locations for Rev B DA Cards ................................................................................................ 6
Figure 6: Jumper Locations for Rev C DA Cards................................................................................................ 6
Revision 1.7

7700 MultiFrame Manual
7705EO-HD SMPTE292M Re-Clocking Electrical to Fiber Converter
This page left intentionally blank
Revision 1.7

7700 MultiFrame Manual
7705EO-HD SMPTE292M Re-Clocking Electrical to Fiber Converter
REVISION HISTORY
REVISION DESCRIPTION DATE
1.0 Original Version June 99
1.1 Added section on adjusting the EQ threshold, Sept 99
Bypass mode now called non-reclock mode, Figure 1 updated, Figure 3, 4 added
1.2 Added Safety notice Mar 00
1.3 Added jumper locations for Rev C board (Figure 5 added) July 00
Added ST/PC and FC/PC connector options
Specifications updated
1.4 Added information about new versions for CWDM applications Nov 00
1.5 Specifications updated Feb 01
1.6 Added 8 new CWDM wavelengths Dec 02
1.7 Updated safety section and added assembly and labeling sections July 05
Information contained in this manual is believed to be accurate and reliable. However, Evertz assumes no responsibility for the use thereof nor for
the rights of third parties, which may be effected in any way by the use thereof. Any representations in this document concerning performance of
Evertz products are for informational use only and are not warranties of future performance, either express or implied. The only warranty offered by
Evertz in relation to this product is the Evertz standard limited warranty, stated in the sales contract or order confirmation form.
Although every attempt has been made to accurately describe the features, installation and operation of this product in this manual, no warranty is
granted nor liability assumed in relation to any errors or omissions unless specifically undertaken in the Evertz sales contract or order confirmation.
Information contained in this manual is periodically updated and changes will be incorporated into subsequent editions. If you encounter an error,
please notify Evertz Customer Service department. Evertz reserves the right, without notice or liability, to make changes in equipment design or
specifications.

7700 MultiFrame Manual
7705EO-HD SMPTE292M Re-Clocking Electrical to Fiber Converter
WARNING
Never look directly into an optical fiber. Non-reversible damage to the eye can
occur in a matter of milliseconds.
Revision 1.7

7700 MultiFrame Manual
7705EO-HD SMPTE292M Re-Clocking Electrical to Fiber Converter
1. OVERVIEW
The 7705EO-HD Electrical to fiber converter provides an economical method of connecting in-plant
coaxial distribution and longer distance optical distribution for SMPTE 292M (1.5 Gb/s) HDTV serial digital
signals. The companion 7705OE-HD Fiber to Electrical converter facilitates conversion back to coaxial
distribution at the destination. The 7705EO-HD converter features one auto-equalized coaxial input with
two reclocked serial digital outputs and one reclocked fiber output. The 7705EO-HD has been designed to
be used primarily as a reclocking 1.5Gb/s distribution amplifier and converter, however, it can also be
used as a non-reclocking SMPTE 310M (19.4 Mb/s), DVB-ASI or SMPTE 259M(143 to 540 Mb/s)
distribution product.
The 7705EO-HD is available in different versions to meet a variety of applications. (See specifications for
complete information)
7705EO13-HD 1310 nm MQW Suitable for distances up to 6 Km @ 1.5 Gb/s
7705EO13-HD-L 1310 nm DFB Suitable for distances up to 40 Km @ 1.5 Gb/s
7705EO15-HD 1550 nm DFB Suitable for distances up to 50 Km @ 1.5 Gb/s
Features:
• Reclocking mode for SMPTE 292M (1.5 Gb/s) signals
• Non-reclock mode for SMPTE 310M (19.4 Mb/s), SMPTE 259M (143 to 540 Mb/s) or DVB-ASI, or
most other bit rates less than 1.5 Gb/s
• Fully hot-swappable from front of frame with no fiber or BNC disconnect required
• Independent isolated output drivers to ensure no cross channel loading effects and maintain polarity
from input to output for DVB-ASI applications
• Automatic cable equalization to 130 m
• Operation with multi-mode or single-mode fiber
• SC/PC, ST/PC or FC/PC connector options
• Tally output on Frame Status bus upon loss of input signal
2 Serial Outputs
1.5 Gb/s
(SMPTE 292M)
¾¾
Signal
Present
Equalizer
EQ.
Warning
Re-
clock
Non-
reclock
Cable Drivers
*Note: Non-reclock Mode will operate 19.4 Mb/s to 1.5 Gb/s.
Serial Input
1.5 Gb/s
(SMPTE 292M)
Optical Driver
Optical Output
1.5 Gb/s
(SMPTE 292M)
Figure 1: 7705EO-HD Block Diagram
Revision 1.7 7705EO-HD-1

7700 MultiFrame Manual
7705EO-HD SMPTE292M Re-Clocking Electrical to Fiber Converter
2. INSTALLATION
The 7705EO-HD comes with a companion rear plate that has three BNC connectors and one SC/PC
(shown), ST/PC or FC/PC optical connector. For information on mounting the rear plate and inserting the
module into the frame see the 7700FR chapter section 3.
Figure 2: 7705EO-HD Rear Panel
HD INPUT Input BNC connector for 10-bit serial digital video signals compatible with the SMPTE 292M
standard. The 7705EO-HD can also be used in non-reclock mode with SMPTE 310M
(19.4 Mb/s), SMPTE 259M (143 to 540 Mb/s) or DVB-ASI, or most other signals with bit rate
less than 1.5 Gb/s. See section 5.1 for information on operating the module in non-reclock
mode.
HD OUTPUT There are two BNC connectors with reclocked serial component video outputs, compatible
with the SMPTE 292M standard. In non-reclock mode these outputs contain an equalized copy
of the input signal.
There is one SC/PC (shown) ST/PC or FC/PC female connector with reclocked serial
component video outputs, compatible with the SMPTE 292M standard. This connector is the
optical output from the 7705EO-HD as shown in section 3.3.
7705EO-HD-2 Revision 1.7

7700 MultiFrame Manual
7705EO-HD SMPTE292M Re-Clocking Electrical to Fiber Converter
2.1. CARE AND HANDLING OF OPTICAL FIBER
2.1.1. Safety
!
CLASS 1 LASER PRODUCT
Background colour: yellow
Triangular band: black
Symbol: black
2.1.2. Assembly
Assembly or repair of the laser sub-module is done only at Evertz facility and performed only by qualified
Evertz technical personnel.
2.1.3. Labeling
Certification and Identification labels are combined into one label. As there is no enough room on the
product to place the label it is reproduced here in the manuals.
• There is no date of manufacture on this label as it can be traced by bar code label placed on the
Printed circuit board of each Evertz plug-in module
• The Model number is one of: 7705EO13-HD, 7705EO13-HD-L, 7705EO15-HD
Figure 3: Reproduction of Laser Certification and Identification Label
2.1.4. Handling and Connecting Fibers
"
Never touch the end face of an optical fiber. Always keep dust caps on optical fiber
connectors when not connected and always remember to properly clean the optical
end face of a connector before making a connection.
Revision 1.7 7705EO-HD-3

7700 MultiFrame Manual
7705EO-HD SMPTE292M Re-Clocking Electrical to Fiber Converter
The transmission characteristics of the fiber are dependent on the shape of the optical core and therefore
care must be taken to prevent fiber damage due to heavy objects or abrupt fiber bending. Evertz
recommends that you maintain a minimum bending radius of 5 cm to avoid fiber-bending loss that will
decrease the maximum attainable distance of the fiber cable. The Evertz fiber optic modules come with
cable lockout devices, to prevent the user from damaging the fiber by installing a module into a slot in the
frame that does not have a suitable I/O module. For further information about care and handling of fiber
optic cable see section 3 of the Fiber Optics System Design section of this manual binder.
3. SPECIFICATIONS
3.1. SERIAL VIDEO INPUT
Standards:
Normal: SMPTE 292M
Non-Reclock Mode: SMPTE 310M (19.4 Mb/s) or
SMPTE 259M A, B, C, D, or
DVB-ASI or most other bit rates less than 1.5 Gb/s
Connector: 1 BNC per IEC 169-8
Equalization: Automatic to 130m @ 1.5Gb/s with Belden 1694 or equivalent cable
Return Loss: > 15 dB up to 1 Gb/s, > 12 dB up to 1.5 Gb/s
3.2. SERIAL VIDEO OUTPUTS
Number of Outputs: 2 Per Card-Reclocked.
Standards: same as input
Connectors: 2 BNC per IEC 169-8
Signal Level: 800mV nominal
DC Offset: 0V ±0.5V
Rise and Fall Time: 200 ps nominal
Overshoot: <10% of amplitude
Return Loss: > 15 dB up to 1 Gb/s, > 12 dB up to 1.5 Gb/s
Wide Band Jitter: < 0.15 UI (reclocked)
3.3. OPTICAL OUTPUT
Standard: SMPTE 292M
Number of Outputs: 1 reclocked
Connector: SC/PC, ST/PC or FC/PC female housing
Return Loss: < 14 dB
Rise and Fall Time: 200 ps nominal
Wide Band Jitter: < 0.2 UI (reclocked)
Fiber Size: 9 µm core / 125 µm overall
Optical Characteristics
7705EO-HD-4 Revision 1.7

7700 MultiFrame Manual
7705EO-HD SMPTE292M Re-Clocking Electrical to Fiber Converter
3.4. ELECTRICAL
Voltage: + 12VDC
Power: 6 Watts.
EMI/RFI: Complies with FCC regulations for class A devices.
Complies with EU EMC directive.
3.5. PHYSICAL
7700 or 7701 frame mounting:
Number of slots: 1
4. STATUS LEDS
MODULE OK This Green LED will be On when the module is operating properly
LOCAL FAULT This Red LED will be On when input video is lost or when there is a fault in the
module power supply.
CARRIER PRESENT: This Green LED will be On when there is a valid signal present at the module
input.
CABLE LENGTH WARNING: This Yellow LED will be On when the cable equalizer detects that the cable
length is greater than a preset threshold. (factory set for 125 meters of Belden 1694
or equivalent cable). See section 5.3 for information on adjusting the cable
equalizer warning threshold.
5. JUMPERS AND USER ADJUSTMENTS
LOCAL FAULT / MODULE OK
CARRIER PRESENT
CABLE LENGTH WARNING J8
RATE
HD / BYPASS
J9
J20
FRAME
STATUS
SFF POWER
+12V
EQ
R28
EVERTZ (A) 7700DA-HD
RATE
HD / BYPASS
Figure 4: Jumper Locations for Rev A and Rev 1 DA Cards
Revision 1.7 7705EO-HD-5

7700 MultiFrame Manual
7705EO-HD SMPTE292M Re-Clocking Electrical to Fiber Converter
LOCAL FAULT / MODULE OK
CARRIER PRESENT
CABLE LENGTH WARNING
EVERTZ (B) 7700DA-HD
J8
RATE
HD / BYPASS
J9
SFF POWER
+12V
J20
FRAME
STATUS
EQ
R28
ON
RATE
HD / BYPASS
7705EO-HD-6 Revision 1.7
Figure 5: Jumper Locations for Rev B DA Cards
LOCAL FAULT / MODULE OK
CARRIER PRESENT
CABLE LENGTH WARNING J8
J9
NON-RCLK
SFF POWER
+12V
J20
FRAME
STATUS
EQ
R28
ON
NON
RCLK
RCLK
RCLK
EVERTZ (C) 7700DA-HD
Figure 6: Jumper Locations for Rev C DA Cards
5.1. SELECTING RECLOCK OR NON-RECLOCK MODE
There are two jumpers J8 and J9 that determine whether the module will operate as a reclocking
distribution amplifier with SMPTE 292M (1.5 Gb/s) video signals or as a non-reclocking distribution
amplifier with other data rates.
For the A and B revision of the board:
HD / BYPASS To select the normal reclocking mode remove both of these jumpers. For convenience you
may re-install the jumper so that only one side is connected.
To select the non-reclocking mode install both of these jumpers.
For the C revision and later of the board:
RCLK/NON-RCLK To select the normal reclocking mode put both of these jumpers in the RCLK
position. To select the non-reclocking mode install both of these jumpers in the NON-RCLK
position.

7700 MultiFrame Manual
7705EO-HD SMPTE292M Re-Clocking Electrical to Fiber Converter
5.2. SELECTING WHETHER LOCAL FAULTS WILL BE MONITORED
BY THE GLOBAL FRAME STATUS
The FRAME STATUS jumper located at the front of the module determines whether local faults (as shown
by the Local Fault indicator) will be connected to the 7700FR frame's global status bus.
FRAME STATUS To monitor faults on this module with the frame status indicators (on the PS FRAME
STATUS LED's and on the Frame's Fault Tally output) install this jumper in the On position.
On Rev A and B boards install the jumper. (default)
When this jumper is installed in the Off position local faults on this module will not be
monitored. On rev Rev A and B boards remove the jumper and re-install it so that only one
side is connected.
5.3. SETTING THE EQUALIZER WARNING THRESHOLD
The EQ trimpot R28 located near jumper J8 is used to set the threshold of the cable equalizer warning.
The equalizer warning is factory set to 125 meters of Belden 1684 cable, but may be adjusted for other
cable types or cable lengths. To adjust the cable equalizer warning threshold, connect a signal to the
input of the DA using the required length of cable. Adjust the trimpot slowly until the Equalizer warning
LED comes on. You can verify that the equalizer warning is operating correctly by removing a few meters
of cable from the input. The LED should go off.
Revision 1.7 7705EO-HD-7

7700 MultiFrame Manual
7705EO-HD SMPTE292M Re-Clocking Electrical to Fiber Converter
This page left intentionally blank
7705EO-HD-8 Revision 1.7
