evertz 7721AE4-B-HD User manual

7700 MultiFrame Manual
7721AE4-(B)-HD HDTV 4 Channel AES Audio Embedder
Revision 1.5
TABLE OF CONTENTS
1. OVERVIEW.......................................................................................................................................... 1
2. INSTALLATION................................................................................................................................... 3
3. SPECIFICATIONS............................................................................................................................... 5
3.1. SERIAL VIDEO INPUT ............................................................................................................... 5
3.2. SERIAL VIDEO OUTPUTS WITH EMBEDDED AUDIO ............................................................. 5
3.3. AES AUDIO INPUTS .................................................................................................................. 5
3.4. SYSTEM PERFORMANCE ........................................................................................................ 5
3.5. ELECTRICAL ............................................................................................................................. 5
3.6. PHYSICAL.................................................................................................................................. 6
4. STATUS LEDS.................................................................................................................................... 7
4.1. MODULE STATUS LEDS........................................................................................................... 7
4.2. AUDIO GROUP AND MODE STATUS LEDS............................................................................. 7
5. CARD EDGE CONTROLS .................................................................................................................. 9
5.1. SELECTING THE AUDIO GROUPS THAT WILL BE EMBEDDED............................................ 9
5.2. SELECTING THE AUDIO DELAY............................................................................................ 11
5.3. SELECTING HOW EXISTING EMBEDDED AUDIO WILL BE HANDLED
AND WHERE THE EMBEDDED AUDIO WILL BE PLACED................................................... 11
5.4. SELECTING AES LOCKED GROUP MODE............................................................................ 12
5.5. SELECTING SAMPLE RATE CONVERSION FOR AES INPUTS............................................ 13
5.6. SELECTING FUNCTION OF THE MODULE OK STATUS LED............................................... 13
5.7. SELECTING OPERATION WHEN THERE IS NO VIDEO INPUT............................................. 13
5.8. SELECTING WHETHER THE MODULE WILL BE CONTROLLED FROM THE
LOCAL CONTROLS OR THROUGH THE VISTALINK
®
INTERFACE...................................... 14
6. JUMPERS.......................................................................................................................................... 15
6.1. SELECTING WHETHER LOCAL FAULTS WILL BE MONITORED
BY THE GLOBAL FRAME STATUS........................................................................................ 15
6.2. CONFIGURING THE MODULE FOR FIRMWARE UPGRADES.............................................. 15
7. VISTALINK
®
REMOTE MONITORING/CONTROL........................................................................... 16
7.1. WHAT IS VISTALINK
®
? ........................................................................................................... 16
7.2. VISTALINK
®
MONITORED PARAMETERS .............................................................................. 16
7.3. VISTALINK
®
CONTROLLED PARAMETERS ........................................................................... 17

7700 MultiFrame Manual
7721AE4-(B)-HD HDTV 4 Channel AES Audio Embedder
Revision 1.5
7.4. VISTALINK
®
TRAPS.................................................................................................................. 17
Figures
Figure 1-1: 7721AE4-HD Block Diagram..............................................................................................................2
Figure 2-1: Rear Panels........................................................................................................................................3
Figure 6-1: Location of Jumpers .........................................................................................................................15
Tables
Table 4-1: Audio Group and Mode Status LEDs...................................................................................................8
Table 5-1: Toggle Switch Function Overview .......................................................................................................9
Table 5-2: Embedder 1 Enable Switch Settings .................................................................................................10
Table 5-3: Embedder 1 Group Switch Settings...................................................................................................10
Table 5-4: Embedder 2 Enable Switch Settings .................................................................................................10
Table 5-5: Embedder 2 Group Switch Settings...................................................................................................11
Table 5-6: Audio Delay Switch Settings..............................................................................................................11
Table 5-7: HANC Handling Mode Switch Settings..............................................................................................11
Table 5-8: Lock Group Mode Switch Settings.....................................................................................................12
Table 5-9: Sample Rate Conversion Switch Settings.........................................................................................13
Table 5-10: Module OK Status LED Switch Settings..........................................................................................13
Table 5-11: Loss of Video Mode Switch Settings ...............................................................................................13
Table 5-12: VistaLINK
®
Control Switch Settings.................................................................................................14
Table 7-1: VistaLINK
®
Monitored Parameters.....................................................................................................16
Table 7-2: VistaLINK
®
Controlled Parameters....................................................................................................17
Table 7-3: VistaLINK
®
Traps...............................................................................................................................17

7700 MultiFrame Manual
7721AE4-(B)-HD HDTV 4 Channel AES Audio Embedder
Revision 1.5
REVISION HISTORY
REVISION DESCRIPTION DATE
1.0 First Release Version Mar 04
1.1 Return loss specifications updated Aug 04
1.2 Updated Group Lock control and added VistaLINK
®
DIP switch information Nov 05
1.3 Fixed format and updated VistaLINK
®
description Jun 08
1.4 Updated programmable audio delay spec Jun 08
1.5 Added 7721AE4-B-HD rear plate drawing and information Mar 09
Information contained in this manual is believed to be accurate and reliable. However, Evertz assumes no responsibility for the use thereof nor for
the rights of third parties, which may be affected in any way by the use thereof. Any representations in this document concerning performance of
Evertz products are for informational use only and are not warranties of future performance, either expressed or implied. The only warranty offered
by Evertz in relation to this product is the Evertz standard limited warranty, stated in the sales contract or order confirmation form.
Although every attempt has been made to accurately describe the features, installation and operation of this product in this manual, no warranty is
granted nor liability assumed in relation to any errors or omissions unless specifically undertaken in the Evertz sales contract or order confirmation.
Information contained in this manual is periodically updated and changes will be incorporated into subsequent editions. If you encounter an error,
please notify Evertz Customer Service department. Evertz reserves the right, without notice or liability, to make changes in equipment design or
specifications.

7700 MultiFrame Manual
7721AE4-(B)-HD HDTV 4 Channel AES Audio Embedder
Revision 1.5
This page left intentionally blank

7700 MultiFrame Manual
7721AE4-(B)-HD HDTV 4 Channel AES Audio Embedder
Revision 1.5 Page-1
1. OVERVIEW
The 7721AE4-HD Audio Embedder inserts AES audio signals into a 1.5Gb/s SDI video signal as specified
in SMPTE 299M. The companion 7721AD4-HD Audio De-embedder facilitates audio demultiplexing at the
destination.
SMPTE 299M allocates four groups of four audio channels that can be embedded into the SMPTE 292M
bitstream. The 7721AE4-HD embeds up to 4 AES audio into two selectable groups on the SDI outputs for
discrete 5.1 audio applications. The 7721AE4-HD is Dolby E compliant when the sample rate converters
are turned off.
VistaLINK
®
enables control and configuration capabilities via Simple Network Management Protocol
(SNMP). This offers the flexibility to manage the module status monitoring and configuration from SNMP
enabled control systems such as Evertz VistaLINK
®
Pro locally or remotely.
Features:
•Automatic detection of video input format
•Bypass relay protection on one HD SDI output for power failures
•24-bit AES input and audio embedding
•Individual audio group assignment for each group
•Group lock mode maintains phase relationship between the groups for 5.1 audio applications
•Sample rate conversion disabled on AES inputs to permit Dolby E embedding
•Programmable audio delays (up to 7 frames in ½ video field resolution) using DIP switches or (up
to 1365.313 ms in 1 sample increments) via VistaLINK
®
•Ancillary packet cleaning mode removes all audio before embedding
•Ancillary packet reformatting mode left justifies and removes unused packets before embedding
•Embeds audio on internally generated black or blue video when there is no video input
•VistaLINK
®
control capabilities for module configuration. VistaLINK
®
capabilities are available
when modules are used with the 3RU 7700FR-C frame and a 7700FC VistaLINK
®
Frame
Controller module in slot 1 of the frame
•Front panel LEDs indicate video and audio signal presence and module fault

7700 MultiFrame Manual
7721AE4-(B)-HD HDTV 4 Channel AES Audio Embedder
Page-2 Revision 1.5
Equalizer S / P
Audio Present
Serial Input
1.5 Gb/s
(SMPTE 292M)
AES Inputs
(SMPTE 276M)
Serial Output
1.5 Gb/s
with SMPTE 299M
embedded Audio
Cable
Driver
P / S
By Pass Relay
Sample Rate
Converter
1
Audio
Delay
Sample Rate
Converter
2
Audio
Delay
Sample Rate
Converter
3
Audio
Delay
Sample Rate
Converter
4
Audio
Delay
Control
Card
Edge
Embedder
Warning
Module
Status
Video
Present
Audio
Present
VistaLINK
®
Interface
Embedder
Figure 1-1: 7721AE4-HD Block Diagram

7700 MultiFrame Manual
7721AE4-(B)-HD HDTV 4 Channel AES Audio Embedder
Revision 1.5 Page-3
2. INSTALLATION
The 7721AE4-HD modules each come with a companion rear plate that has 7 BNC connectors. For
information on mounting the rear plate and inserting the module into the frame see section 3 of the
7700FR chapter.
Figure 2-1: Rear Panels
HD INPUT: Input BNC connector for 10-bit serial digital video signals compatible with the
SMPTE 292M standard.
HD OUTPUT: There are two BNC connectors with reclocked serial component video outputs, compatible
with the SMPTE 292M standard. These outputs contain the input video with the audio
present at AES inputs 1 to 4 embedded in accordance with the SMPTE 299M standard.
On the 7721AE4-HD the top SDI output is protected by a bypass relay, which will activate
in the event of power loss to the module. The remaining output is not bypass protected.

7700 MultiFrame Manual
7721AE4-(B)-HD HDTV 4 Channel AES Audio Embedder
Page-4 Revision 1.5
AES INPUT 1: AES audio input for AES pair 1 (channel 1 and 2) of the audio group selected for
embedding by embedder 1.
AES INPUT 2: AES audio input for AES pair 2 (channel 3 and 4) of the audio group selected for
embedding by embedder 1.
AES INPUT 3: AES audio input for AES pair 1 (channel 1 and 2) of the audio group selected for
embedding by embedder 2.
AES INPUT 4: AES audio input for AES pair 2 (channel 3 and 4) of the audio group selected for
embedding by embedder 2.
On the 7721AE4-B-HD, there is a 2 x 6 pin terminal strip containing the balanced AES input embedded
from the video.

7700 MultiFrame Manual
7721AE4-(B)-HD HDTV 4 Channel AES Audio Embedder
Revision 1.5 Page-5
3. SPECIFICATIONS
3.1. SERIAL VIDEO INPUT
Standard: SMPTE 292M (1.5Gb/s),
1080i/60, 1080i/59.94, 1080i/50, 1080p/30sF, 1080p/29.97sF, 1080p/25sF,
1080p/24sF, 1080p/23.98sF, 720p/60, 720p/59.94, 720p/50)
Connector: BNC per IEC 61169-8 Annex A
Equalization: Automatic 100m @ 1.5 Gb/s with Belden 1694A or equivalent cable
Return Loss: > 10 dB up to 1.5 Gb/s
3.2. SERIAL VIDEO OUTPUTS WITH EMBEDDED AUDIO
Standard: Same as input
Number of Outputs: 2 (1 output bypass relay protected)
Embedded Audio: SMPTE 299M – 24 bit 48 kHz synchronous
Connectors: BNC per IEC 61169-8 Annex A
Signal Level: 800mV nominal
DC Offset: 0V ±0.5V
Rise and Fall Time: 200ps nominal
Overshoot: <10% of amplitude
Return Loss: > 10 dB up to 1.5 Gb/s
Wide Band Jitter: < 0.2 UI
3.3. AES AUDIO INPUTS
Number of Inputs: 4
Standard: SMPTE 276M, single ended AES
Connector: BNC per IEC 61169-8 Annex A
Resolution: 24 bits
Sampling Rate: 32 to 96 kHz synchronous or asynchronous
(48 kHz synchronous AES required when sample rate converter is disabled)
Impedance: 75 Ohms unbalanced
Signal Level: 1V p-p ±0.1V
3.4. SYSTEM PERFORMANCE
Embedding Latency: 1.3 to 3.0 msec
Audio Delay:
DIP Switch Control: up to 7 frames, ½ frame increments (delay applied to all AES channels)
VistaLINK
®
or Serial Port Control: up to 1365.313 ms in 1 sample increments (independent control of
delay for each channel)
3.5. ELECTRICAL
Voltage: + 12VDC
Power: 11 Watts
EMI/RFI: Complies with FCC Part 15, class A and EU EMC directive

7700 MultiFrame Manual
7721AE4-(B)-HD HDTV 4 Channel AES Audio Embedder
Page-6 Revision 1.5
3.6. PHYSICAL
7700 or 7701 frame mounting:
Number of slots: 1
Stand Alone Enclosure:
Dimensions: 14 “L x 4.5 “W x 1.9 “H
(355 mm L x 114 mm W x 48 mm H)
Weight: approx. 1.5 lbs. (0.7 Kg)

7700 MultiFrame Manual
7721AE4-(B)-HD HDTV 4 Channel AES Audio Embedder
Revision 1.5 Page-7
4. STATUS LEDS
The location of the status LEDs is shown in Figure 6-1.
4.1. MODULE STATUS LEDS
MODULE OK: This Green LED will be On when the module is operating properly. Depending on
the Status LED mode chosen, the LED will be On solid when input video or audio, or
both video and audio, is present (please refer to section 5.6).
LOCAL FAULT: This Red LED makes it easy to identify one module in a frame that is missing an
essential input or has another fault.
The LED will blink On and Off if the microprocessor is not running.
Depending on the Status LED mode chosen, the LED will be on solid when input
video or audio is missing from all AES inputs, or both video and audio are missing.
In addition, this LED will be On when there is a fault in the module power supply.
VIDEO PRESENT: This Green LED will be On when there is a valid video signal present at the module
input.
AUDIO PRESENT: This Green LED will be On solid when there is a valid AES audio signal present at
any of the AES inputs.
ERROR: This Yellow LED will be On when there are errors in the embedding process (for
example, FIFO underflow).
4.2. AUDIO GROUP AND MODE STATUS LEDS
Four LEDs located on the lower end of the module (opposite the DIP switch) indicate the status of the
audio groups when the DIP switches are all set to the OFF condition. LED 1 is located closest to the
center of the module. When the DIP switches are set to other values, these LEDS are used to indicate
various operational modes of the module (please refer to Table 4-1).

7700 MultiFrame Manual
7721AE4-(B)-HD HDTV 4 Channel AES Audio Embedder
Page-8 Revision 1.5
Table 4-1: Audio Group and Mode Status LEDs
DIP Switch LED
2 3 4 5 6 7 8 Control
Description Value Description 1 2 3 4
Off Off Off Off Off Off Off --- AES1 Present On
AES2 Present On
AES3 Present On
Audio Present
AES4 Present On
On Off Off Off Off Off Off --- Minimum Off Off Off Off
½frame OnOff Off Off
1frame Off On Off Off
1½frames OnOnOff Off
2frames Off Off On Off
2½frames OnOff On Off
3frames Off On On Off
3½frames OnOnOnOff
4frames Off Off Off On
4½frames OnOff Off On
5frame Off On Off On
5½frames OnOnOff On
6frames Off Off On On
6½frames OnOff On On
Audio Delay
7 frames Off On On On
Off On Off Off Off Off Off --- Disable Off Off Off Off
Embedder 1 Enable On On On On
On On Off Off Off Off Off --- Group 1 On Off Off Off
Group 2 Off On Off Off
Group 3 Off Off On Off
Embedder 1
Group Group 4 Off Off Off On
Off Off On Off Off Off Off --- Disable Off Off Off Off
Embedder 2 Enable On On On On
On Off On Off Off Off Off --- Group 1 Off Off Off Off
Group 2 Off On Off Off
Group 3 Off Off On Off
Embedder 2
Group Group 4 Off Off Off On
Off On On Off Off Off Off --- Clean & embed Off Off Off Off
HANC
Handling Reformat and embed On On On On
On On On Off Off Off Off --- Independent Groups Off Off Off Off
Lock Groups Locked Groups On On On On
Off Off Off On Off Off Off --- Disable Off Off Off Off
Sample Rate
Converter Enable On On On On
On Off Off On Off Off Off --- Video Only On Off Off Off
Audio Only Off On Off Off
Status LED
Mode Video/ Audio On On Off Off
Off On Off On Off Off Off --- Black Off Off Off Off
Loss of Video
Mode Blue On On On On

7700 MultiFrame Manual
7721AE4-(B)-HD HDTV 4 Channel AES Audio Embedder
Revision 1.5 Page-9
5. CARD EDGE CONTROLS
The 7721AE4-HD is equipped with an 8 position DIP switch to allow the user to select various functions.
All positions are assigned sequentially such that the first position is located at the left side of the DIP
switch (farthest from to the card ejector). When the switches are set to Off the LED status indicators near
the DIP switch indicate the presence of the AES audio. When other DIP switch combinations are
selected, various operation modes of the module can be set using the toggle switch. The LED Mode
indicators near the DIP switch indicate the settings of each of these modes as shown in Table 4-1. The On
position is down, or closest to the printed circuit board. Sections 5.1 to 5.8 show the assigned DIP switch
functions.
DIP Switch
1 2 3 4 5 6 7 8 Control
Description
Off Off Off Off Off Off Off Off Audio Present
On Off Off Off Off Off Off Off Audio Delay
Off On Off Off Off Off Off Off Embedder 1 Enable
On On Off Off Off Off Off Off Embedder 1 Group
Off Off On Off Off Off Off Off Embedder 2 Enable
On Off On Off Off Off Off Off Embedder 2 Group
Off On On Off Off Off Off Off HANC Handling
Mode
On On On Off Off Off Off Off Lock Groups
Off Off Off On Off Off Off Off Sample Rate
Converter Mode
On Off Off On Off Off Off Off Status LED Mode
Off On Off On Off Off Off Off Loss of Video Mode
--- --- --- --- --- --- --- On VistaLINK
®
or
Remote Control
Table 5-1: Toggle Switch Function Overview
5.1. SELECTING THE AUDIO GROUPS THAT WILL BE EMBEDDED
The SMPTE 299M standard permits up to 4 groups of 4 audio channels to be embedded into the 270 Mb/s
video bitstream. Model 7721AE4-HD has two separate embedders that will embed up to four audio
channels (two AES pairs) into one of the groups. The Embedders can be treated as two independent
embedders for unrelated audio content or can be locked together where the audio in both groups is related
and hence its phase must be maintained (for example, 5.1 surround sound audio).
" Some legacy equipment may not be compatible with two embedded audio groups
present in the video stream.

7700 MultiFrame Manual
7721AE4-(B)-HD HDTV 4 Channel AES Audio Embedder
Page-10 Revision 1.5
The source for Embedder A is the audio coming in on the AES IN 1 and 2 connectors. The source for
Embedder B is the audio coming in on the AES IN 3 and 4 connectors. There are separate DIP switch
settings that are used to enable or disable each embedder as well as to set the audio groups where the
embedders will place the audio on the SDI output.
When the DIP switches are set as shown in Table 5-2, the toggle switch is used to enable or disable
Embedder 1. Each time the toggle switch is pressed up or down the Embedder 1 Enable mode will
change as indicated by the LEDs in Table 5-2.
When set to Disable, embedder 1 will be disabled. When set to Enable, the embedder destination can be
set when the DIP switches are set as shown in Table 5-3. Channels 1 and 2 from AES input 1 will be
embedded into channels 1 and 2 of the selected group. Channels 1 and 2 from AES input 2 will be
embedded into channels 3 and 4 of the selected group. If audio is not present on one or both of the AES
inputs, the respective channels of the selected audio group will be mute.
DIP Switch LED
1 2 3 4 5 6 7 8 Control
Description Value Description 1 2 3 4
Off On Off Off Off Off Off Off Disable Off Off Off Off
Embedder 1 Enable On On On On
Table 5-2: Embedder 1 Enable Switch Settings
DIP Switch LED
1 2 3 4 5 6 7 8 Control
Description Value Description 1 2 3 4
On On Off Off Off Off Off Off Group 1 On Off Off Off
Group 2 Off On Off Off
Group 3 Off Off On Off
Embedder 1
Group Group 4 Off Off Off On
Table 5-3: Embedder 1 Group Switch Settings
When the DIP switches are set as shown in Table 5-4, the toggle switch is used to enable or disable
Embedder 2. Each time the toggle switch is pressed up or down the Embedder 2 Enable mode will
change as indicated by the LEDs in Table 5-4.
When set to Disable, embedder 2 will be disabled. When set to Enable, the embedder destination can be
set when the DIP switches are set as shown in Table 5-5. Channels 1 and 2 from AES input 3 will be
embedded into channels 1 and 2 of the selected group. Channels 1 and 2 from AES input 4 will be
embedded into channels 3 and 4 of the selected group. If audio is not present on one or both of the AES
inputs, the respective channels of the selected audio group will be mute.
DIP Switch LED
1 2 3 4 5 6 7 8 Control
Description Value Description 1 2 3 4
Off Off On Off Off Off Off Off Disable Off Off Off Off
Embedder 2 Enable On On On On
Table 5-4: Embedder 2 Enable Switch Settings

7700 MultiFrame Manual
7721AE4-(B)-HD HDTV 4 Channel AES Audio Embedder
Revision 1.5 Page-11
DIP Switch LED
1 2 3 4 5 6 7 8 Control
Description Value Description 1 2 3 4
On Off On Off Off Off Off Off Group 1 On Off Off Off
Group 2 Off On Off Off
Group 3 Off Off On Off
Embedder 2
Group Group 4 Off Off Off On
Table 5-5: Embedder 2 Group Switch Settings
5.2. SELECTING THE AUDIO DELAY
When the DIP switches are as shown in Table 5-6, the toggle switch is used to select one of fifteen delays
which can be added to the audio before it is embedded. This delay allows the user to resynchronize the
audio back to the video to accommodate video processing delays. The delay is applied to all AES
channels prior to embedding.
DIP Switch LED
1 2 3 4 5 6 7 8 Control
Description Value Description 1 2 3 4
On Off Off Off Off Off Off Off Minimum Off Off Off Off
½frame OnOff Off Off
1frame Off On Off Off
1½frames OnOnOff Off
2frames Off Off On Off
2½frames OnOff On Off
3frames Off On On Off
3½frames OnOnOnOff
4frames Off Off Off On
4½frames OnOff Off On
5frame Off On Off On
5½frames OnOnOff On
6frames Off Off On On
6½frames OnOff On On
Audio Delay
7 frames Off On On On
Table 5-6: Audio Delay Switch Settings
5.3. SELECTING HOW EXISTING EMBEDDED AUDIO WILL BE HANDLED
AND WHERE THE EMBEDDED AUDIO WILL BE PLACED
When the DIP switches are set as shown in Table 5-7, the toggle switch is used to select how existing
HANC packets will be handled by the embedder.
DIP Switch LED
1 2 3 4 5 6 7 8 Control
Description Value Description 1 2 3 4
Off On On Off Off Off Off Off Clean & embed Off Off Off Off
HANC
Handling Reformat and embed On On On On
Table 5-7: HANC Handling Mode Switch Settings

7700 MultiFrame Manual
7721AE4-(B)-HD HDTV 4 Channel AES Audio Embedder
Page-12 Revision 1.5
When Clean and embed is selected, all incoming HANC packets and embedded audio data will be
removed; and new audio data will be embedded after EAV. The remaining H blanking period is filled with
default blanking value.
When Reformat and embed is selected, pre-existing embedded audio contents will be extracted. All
packets with "Marked Packet for Deletion" or containing the same selected audio groups that are selected
for embedding will be removed. The remaining packets are left justified and new audio will be embedded
after these packets.
5.4. SELECTING AES LOCKED GROUP MODE
For audio that is synchronous to video there is exactly 8008 audio samples (48kHz sampling rate) in 5
frames of NTSC, 525 line video. Most audio embedders will spread these samples as evenly as possible
throughout the 5 frames of video. Because the 8008 samples do not divide evenly into 5 frames of video,
there is a sequence that only repeats every 5 frames. In all video standards it is possible for the phase of
the audio being embedded by two separate embedders to be out of phase with respect to each other. In
order to transport 8 channels of audio (4 AES pairs) through an embedded link with exactly the same
delay on each channel, both the embedder and the de-embedder must lock the FIFOs of both groups of
audio together. Failing to do so will cause a phase difference between the audio from the two groups.
When the DIP switches are set as shown in Table 5-8, the toggle switch is used to select whether the
embedders will be operated separately or locked together for embedding related audio (such as 5.1
surround sound).
DIP Switch LED
1 2 3 4 5 6 7 8 Control
Description Value Description 1 2 3 4
On On On Off Off Off Off Off Independent Groups Off Off Off Off
Lock Groups Locked Groups On On On On
Table 5-8: Lock Group Mode Switch Settings
When Independent group mode is selected, Embedder 1 and Embedder 2 are operated independently of
each other as if two separate embedder devices are being used. The FIFOs are not locked together and
the output phases of the two groups of embedded audio do not have any specific relationship to each
other.
When Locked group mode is selected, the Embedder FIFOs are locked together maintaining the phase
relationship between all 4 AES channel pairs in the embedded audio.
"
To maintain a guaranteed audio phase relationship through a complete SDI link, the
audio de-embedder MUST also provide the same locked FIFO management
functionality.
"
For firmware releases 2.3 build 3 and newer, Locked Group mode is ALWAYS active
regardless of the DIP switch setting. Changing the settings will have NO effect on
the mode.

7700 MultiFrame Manual
7721AE4-(B)-HD HDTV 4 Channel AES Audio Embedder
Revision 1.5 Page-13
5.5. SELECTING SAMPLE RATE CONVERSION FOR AES INPUTS
When the DIP switches are as shown in Table 5-9, the toggle switch is used to select whether the sample
rate conversion for the AES inputs is enabled or not.
DIP Switch LED
1 2 3 4 5 6 7 8 Control
Description Value Description 1 2 3 4
Off Off Off On Off Off Off Off Disable Off Off Off Off
Sample Rate
Converter Enable On On On On
Table 5-9: Sample Rate Conversion Switch Settings
When the Sample Rate converters are Enabled, the AES inputs are sample rate converted at 48 kHz
which is synchronous to the input video. AES inputs can be either synchronous or asynchronous to the
video source.
When the Sample Rate converters are Disabled, the content of AES inputs is preserved without any loss,
and directly embedded into the input video. AES inputs must be synchronous to the video source. This
setting is required when embedding Dolby E.
5.6. SELECTING FUNCTION OF THE MODULE OK STATUS LED
When the DIP switches are set as shown in Table 5-10, the toggle switch is used to select the function of
the Module OK LED status indicator (please refer to section 4.1).
DIP Switch LED
1 2 3 4 5 6 7 8 Control
Description Value Description 1 2 3 4
On Off Off On Off Off Off Off Video Only On Off Off Off
Audio Only Off On Off Off
Status LED
Mode Video/ Audio On On Off Off
Table 5-10: Module OK Status LED Switch Settings
In the Video only mode the Module OK status LED will be On when there is video present.
In the Audio only mode the Module OK status LED will be On when there is audio present on at least one
of the AES inputs.
In the Video and Audio mode the Module OK status LED will be On when there is video present and there
is audio present on at least one of the AES inputs.
5.7. SELECTING OPERATION WHEN THERE IS NO VIDEO INPUT
When there is no input video, the 7721AE4-HD will generate its own video and embed the audio onto it.
When the DIP switches are set as shown in Table 5-11, the toggle switch is used to select whether the
module will generate black or blue video.
DIP Switch LED
1 2 3 4 5 6 7 8 Control
Description Value Description 1 2 3 4
Off On Off On Off Off Off Off Black Off Off Off Off
Loss of Video
Mode Blue On On On On
Table 5-11: Loss of Video Mode Switch Settings

7700 MultiFrame Manual
7721AE4-(B)-HD HDTV 4 Channel AES Audio Embedder
Page-14 Revision 1.5
5.8. SELECTING WHETHER THE MODULE WILL BE CONTROLLED FROM THE
LOCAL CONTROLS OR THROUGH THE VISTALINK
®
INTERFACE
DIP switch 8 selects whether the module will be controlled from the local user controls or through the
VistaLINK
®
interface.
DIP Switch LED
1 2 3 4 5 6 7 8 Control
Description Value Description 1 2 3 4
On
VistaLINK
®
or
Remote
Control
Table 5-12: VistaLINK
®
Control Switch Settings
When the DIP switch 8 is turned Off, the card functions are controlled through the card edge controls (for
example, DIP switches).
When the DIP switch 8 is turned On, the card functions are controlled through the VistaLINK
®
interface
(please refer to section 7) and the card edge controls (for example, DIP switches).

7700 MultiFrame Manual
7721AE4-(B)-HD HDTV 4 Channel AES Audio Embedder
Revision 1.5 Page-15
6. JUMPERS
MODULE STATUS
SIGNAL PRESENT
SFF POWER +12V
AUDIO Run
Upgrade
J16
J24
J22
FRAME
STATUS
ON
OFF
J8
GND
EVERTZ (C) 7700PH3
A7700AES4-2
ERROR
Figure 6-1: Location of Jumpers
6.1. SELECTING WHETHER LOCAL FAULTS WILL BE MONITORED
BY THE GLOBAL FRAME STATUS
FRAME STATUS: The FRAME STATUS jumper located at the front of the module determines whether
local faults (as shown by the Local Fault indicator) will be connected to the 7700FR
frame's global status bus.
To monitor faults on this module with the frame status indicators (on the Power
Supply FRAME STATUS LED's and on the Frame's Fault Tally output) install this
jumper in the On position. (Default)
When this jumper is installed in the Off position, local faults on this module will not be monitored.
6.2. CONFIGURING THE MODULE FOR FIRMWARE UPGRADES
UPGRADE: The UPGRADE jumper J16 located at the front of the module is used when firmware
upgrades are being done to the module. For normal operation it should be installed in
the RUN position. See the Upgrading Firmware chapter in the front of the binder for
more information.
To upgrade the firmware in the module unit pull it out of the frame. Move Jumper J16
into the UPGRADE position. Install the Upgrade cable provided (located in the vinyl
pouch in the front of this manual) onto header J24 at the card edge. Re-install the
module into the frame. Run the upgrade as described in Upgrading Firmware chapter
in the front of the binder. Once the upgrade is complete, remove the module from the
frame, move J16 into the RUN position, remove the upgrade cable and re-install the
module. The module is now ready for normal operation.

7700 MultiFrame Manual
7721AE4-(B)-HD HDTV 4 Channel AES Audio Embedder
Page-16 Revision 1.5
7. VistaLINK
®
REMOTE MONITORING/CONTROL
7.1. WHAT IS VISTALINK
®
?
VistaLINK
®
is Evertz’s remote monitoring and configuration platform which operates over an Ethernet
network using Simple Network Management Protocol (SNMP). SNMP is a standard computer network
protocol that enables different devices sharing the same network to communicate with each other.
VistaLINK
®
provides centralized alarm management, which monitors, reports, and logs all incoming alarm
events and dispatches alerts to all the VLPro Clients connected to the server. Card configuration through
VistaLINK
®
PRO can be performed on an individual or multi-card basis using simple copy and paste
routines, which reduces the time to configure each module separately. Finally, VistaLINK
®
enables the
user to configure devices in the network from a central station and receive feedback that the configuration
has been carried out.
There are 3 components of SNMP:
1. An SNMP manager, also known as a Network Management System (NMS), is a computer running
special software that communicates with the devices in the network. Evertz VL-Fiber demo Manager
graphical user interface (GUI), third party or custom manager software may be used to monitor and
control Evertz VistaLINK
®
enabled fiber optic products.
2. Managed devices, (such as 7721AE4-HD), each with a unique address (OID), communicate with the
NMS through an SNMP Agent. Evertz VistaLINK
®
enabled 7700 series modules reside in the 3RU
7700FR-C MultiFrame and communicate with the manager via the 7700FC VistaLINK
®
frame controller
module, which serves as the Agent.
3. A virtual database, known as the Management information Base (MIB), lists all the variables being
monitored, which both the Manager and Agent understand. Please contact Evertz for further
information about obtaining a copy of the MIB for interfacing to a third party Manager/NMS.
For more information on connecting and configuring the VistaLINK
®
network, see the 7700FC Frame
Controller chapter.
7.2. VISTALINK
®
MONITORED PARAMETERS
The following parameters can be remotely monitored through the VistaLINK
®
interface:
Parameter Description
Input Signal Present Indicates the presence of a valid video and audio input signal (the
state of the VIDEO and AUDIO present LEDs).
Local Mode Indicates whether the Embedder module is under VistaLINK
®
or local
control.
Table 7-1: VistaLINK
®
Monitored Parameters
