7700 MultiFrame Manual
7707OE-DS3/E3 Optical to Electrical Converter for DS3/E3 Signals
Revision 1.5
TABLE OF CONTENTS
1. OVERVIEW.......................................................................................................................................... 1
2. INSTALLATION................................................................................................................................... 2
2.1. 7707OE-DS3 CONNECTIONS ................................................................................................... 2
2.2. 7707OE-E3 CONNECTIONS......................................................................................................3
2.3. CARE AND HANDLING OF OPTICAL FIBER........................................................................... 4
2.3.1. Safety.............................................................................................................................. 4
2.3.2. Handling and Connecting Fibers..................................................................................... 4
3. SPECIFICATIONS............................................................................................................................... 5
3.1. 7707OE-DS3 SPECIFICATIONS................................................................................................ 5
3.1.1. Optical Input.................................................................................................................... 5
3.1.2. Electrical Outputs............................................................................................................ 5
3.1.3. Electrical.......................................................................................................................... 5
3.1.4. Physical........................................................................................................................... 5
3.2. 7707OE-E3 SPECIFICATIONS.................................................................................................. 6
3.2.1. Optical Input.................................................................................................................... 6
3.2.2. Serial Video Outputs....................................................................................................... 6
3.2.3. Electrical.......................................................................................................................... 6
3.2.4. Physical........................................................................................................................... 6
4. STATUS LEDS.................................................................................................................................... 7
4.1. DOT-MATRIX DISPLAY............................................................................................................. 7
4.1.1. Displaying the Optical Power.......................................................................................... 7
5. JUMPERS AND USER ADJUSTMENTS............................................................................................ 8
5.1. SELECTING WHETHER LOCAL FAULTS WILL BE MONITORED
BY THE GLOBAL FRAME STATUS.......................................................................................... 8
5.2. SELECTING THE OUTPUT MODE............................................................................................ 9
5.3. SETTING THE TRANSMIT LEVEL............................................................................................ 9
5.4. SELECTING WHETHER MODULE WILL BE CONTROLLED FROM THE
LOCAL CONTROLS OR THROUGH THE VISTALINK
®
INTERFACE ....................................... 9
5.5. CONFIGURING THE MODULE FOR FIRMWARE UPGRADES ............................................. 10
6. VISTALINK
®
REMOTE MONITORING/CONTROL........................................................................... 11
