evertz 7700 Series User manual

7700 MultiFrame Manual
PKG7771MFD-HD Multi-format Decompression CODEC
TABLE OF CONTENTS
1. OVERVIEW......................................................................................................................................... 1
2. INSTALLATION.................................................................................................................................. 2
2.1. VIDEO CONNECTIONS ............................................................................................................ 2
2.2. DATA CONNECTIONS.............................................................................................................. 2
2.3. AUDIO CONNECTIONS ............................................................................................................ 3
2.4. GENERAL PURPOSE OUTPUT CONNECTION ...................................................................... 3
3. SPECIFICATIONS.............................................................................................................................. 4
3.1. SERIAL VIDEO INPUT: .................................................................................................................. 4
3.2. SERIAL VIDEO OUTPUT: ............................................................................................................... 4
3.3. AES AUDIO OUTPUTS: ................................................................................................................ 4
3.4. MONITORING ANALOG AUDIO OUTPUTS: ...................................................................................... 5
3.5. SYSTEM DELAY (COMPRESS + DECOMPRESS): ............................................................................ 5
3.6. GPO:.......................................................................................................................................... 5
3.7. ELECTRICAL:...............................................................................................................................5
3.8. PHYSICAL:................................................................................................................................... 5
3.9. ORDERING INFORMATION:............................................................................................................ 5
3.10. ORDERING OPTIONS: ................................................................................................................... 5
3.11. ENCLOSURES: ............................................................................................................................. 5
4. STATUS INDICATORS AND DISPLAYS .......................................................................................... 6
4.1. PKG7771MFD STATUS AND INDICATOR LEDS .................................................................... 6
4.1.1. Module Status LEDs.......................................................................................................6
4.1.2. SDTi Audio and VANC Present LEDs............................................................................ 7
4.1.3. HD Output Embedded Audio Present LEDs................................................................... 7
4.1.4. DOT-MATRIX DISPLAY................................................................................................. 7
Revision 1.0

7700 MultiFrame Manual
PKG7771MFD-HD Multi-format Decompression CODEC
4.2. 7771MFCD-D STATUS AND INDICATOR LEDS .....................................................................8
4.2.1. Module Status LEDs.......................................................................................................8
4.2.2. Video Present LED.........................................................................................................8
4.3. GPO FUNCTION........................................................................................................................... 8
5. CARD EDGE CONTROLS .................................................................................................................8
5.1. SELECTING THE OUTPUT VIDEO STANDARD (SET A) .......................................................9
5.2. SELECTING HOW THE AUDIO WILL BE OUTPUT (SET A).................................................10
5.3. SELECTING AUDIO DELAY CONFIGURATIONS (SET A) ...................................................10
5.4. SELECTING THE ANALOG AUDIO SOURCE CHANNEL (SET A) ......................................10
5.5. SELECTING HOW THE AUDIO WILL BE OUTPUT (SET B).................................................10
5.6. SELECTING IF AUDIO GROUP 2 IS ENABLED OR DISABLED (SET B) ............................ 11
5.7. AUDIO OUTPUT AUTO/MANUAL SELECTION (SET B).......................................................11
5.8. ANALOG AUDIO MONITOR VOLUME ...................................................................................... 12
6. JUMPERS.........................................................................................................................................13
6.1. SELECTING WHETHER LOCAL FAULTS ON THE BOTTOM BOARD OF THE PKG7771MFD
WILL BE MONITORED BY THE GLOBAL FRAME STATUS ................................................14
6.2. SELECTING WHETHER LOCAL FAULTS ON THE TOP BOARD OF THE PKG7771MFD WILL
BE MONITORED BY THE GLOBAL FRAME STATUS.......................................................... 14
6.3. CONFIGURING THE PKG7771MFD MODULE FOR FIRMWARE UPGRADES....................14
6.4. CONFIGURING THE 7771MFCD-D MODULE FOR FIRMWARE UPGRADES .....................15
Figures
Figure 1: PKG7771MFD-HD Block Diagram....................................................................................................... 1
Figure 2: PKG7771MFD-HD Rear Panel ............................................................................................................ 2
Figure 3: LED and Switch Locations ................................................................................................................... 6
Figure 4: Location of Jumpers Bottom Board (PKG7771MFD) ........................................................................ 13
Figure 5: Location of Jumpers Top Board (PKG7771MFD).............................................................................. 13
Figure 6 Location of Jumpers (7771MFCD-D).................................................................................................. 13
Revision 1.0

7700 MultiFrame Manual
PKG7771MFD-HD Multi-format Decompression CODEC
Tables
Table 1: 9 Pin D Connector Pin Definitions......................................................................................................... 3
Table 2: Video Output Formats ........................................................................................................................... 4
Table 3: Bottom Board DIP Switch Functions (Set B)......................................................................................... 9
Table 4: Top Board DIP Switch Functions (Set A) .............................................................................................. 9
Table 5: Video Standard Switch Settings ............................................................................................................ 9
Table 6: AES Output Sample Rate Converter Enable/Disable Switch Settings ............................................... 10
Table 7: Audio Source Select DIP Switch Settings ........................................................................................... 10
Table 8: Audio Destination DIP Switch Select .................................................................................................. 10
Table 9: Video Standard Switch Settings .......................................................................................................... 10
Table 10: Audio Group 1 Destination Selection Switch Settings ...................................................................... 11
Table 11: Audio Group 2 Destination Selection Switch Settings ...................................................................... 11
Table 12: Audio Group 2 Enable/Disable Switch Settings ................................................................................ 11
Table 13: Auto/Manual Audio Output Switch Settings ...................................................................................... 11
Revision 1.0

7700 MultiFrame Manual
PKG7771MFD-HD Multi-format Decompression CODEC
REVISION HISTORY
REVISION DESCRIPTION DATE
1.0 Released Version January 2005
Information contained in this manual is believed to be accurate and reliable. However, Evertz assumes no responsibility for the use thereof nor for
the rights of third parties, which may be effected in any way by the use thereof. Any representations in this document concerning performance of
Evertz products are for informational use only and are not warranties of future performance, either express or implied. The only warranty offered by
Evertz in relation to this product is the Evertz standard limited warranty, stated in the sales contract or order confirmation form.
Although every attempt has been made to accurately describe the features, installation and operation of this product in this manual, no warranty is
granted nor liability assumed in relation to any errors or omissions unless specifically undertaken in the Evertz sales contract or order confirmation.
Information contained in this manual is periodically updated and changes will be incorporated into subsequent editions. If you encounter an error,
please notify Evertz Customer Service department. Evertz reserves the right, without notice or liability, to make changes in equipment design or
specifications.
Revision 1.0

7700 MultiFrame Manual
PKG7771MFD-HD Multi-format Decompression CODEC
1. OVERVIEW
The PKG7771MFD-HD, HDTV Decompression Codec converts a 270Mb/s SDTi (SMPTE 305M) input
signal containing HDCAM compressed data with embedded AES audio, into a SMPTE 292M (1.485Gb/s)
component serial digital stream with embedded or separate AES audio. An additional stereo analog audio
channel is also available for local monitoring. The PKG7771MFD-HD supports 1080i/59.94,
1080p/29.97sF, 1080p/23.97sF, 1035i/59.94, and 720p/59.94 video formats.
The PKG7771MFD-HD is composed of two sets of cards, the PKG7771MFD and the 7771MFCD-D.
The PKG7771MFD-HD occupies four card slots and is housed in the standard Evertz 3RU frame that
holds up to 15 modules.
Features:
Industry proven HDCAM video decompression for origination quality video•
•
•
•
•
•
•
•
•
•
Supports 720p/59.94, 1080i/59.94, 1080p/29.97sF, 1080p/23.98sF and 1035i/59.94 formats
Automatic detection of 720p/1035i/1080i active lines
Detection of uncompressed SD or compressed HD input stream and outputs GPO control for
downstream equipment.
Outputs up to four channels of uncompressed embedded AES audio
Audio delay processing to match video compression/decompression delay
Four separate stereo AES unbalanced outputs
One stereo analog audio output
Re-embeds original VANC data in outgoing HD-SDI stream
Fully hot swappable from front of frame
HD SDI Output
(SMPTE 292M)
Status
LED
Status
LED Status
LED
Status
LED
Audio
Deformatter
Format
Display
SDTI Input 270 Mb/s
(SMPTE 305M)
Analog Audio
Mon Out and GPO
CPU
SDTI
Deformatter
CPU Control
External AES
Audio
HD SDI Output
(SMPTE 292M)
Audio
I/F
DB9
S/P De-Compressor
P / S
Figure 1: PKG7771MFD-HD Block Diagram
Revision 1.0 PKG7771MFD-HD-1

7700 MultiFrame Manual
PKG7771MFD-HD Multi-format Decompression CODEC
2. INSTALLATION
The PKG7771MFD-HD comes with a companion rear plate that has nine BNC connectors, and one DB-9
connector occupying four slots in the 7700FR frame. For information on mounting the rear plate and
inserting the module into the frame see the 7700FR chapter section 3.
Figure 2: PKG7771MFD-HD Rear Panel
2.1. VIDEO CONNECTIONS
Connect a source of SDTi compressed HD serial component video, compatible with the SMPTE 259M and
SMPTE 305M standards, to the BNC labeled SDTi INPUT. See Table 2 for a list of the video formats
supported. Uncompressed HD video output, compatible with the SMPTE 292M standard, is available on
the HD OUTPUT BNCs.
2.2. DATA CONNECTIONS
The PKG7771MFD-HD requires an external BNC jumper in order to transfer the Video/Audio DATA from
the PKG7771MFD card to the 7771MFCD-D card. See Figure 2 dotted line as reference. Connect the
DATA OUTPUT BNC from the PKG7771MFD to the DATA INPUT BNC of the 7771MFCD-D.
PKG7771MFD-HD-2 Revision 1.0

7700 MultiFrame Manual
PKG7771MFD-HD Multi-format Decompression CODEC
2.3. AUDIO CONNECTIONS
The PKG7771MFD-HD has the ability to de-embed up to 4 uncompressed AES audio streams (8
channels) from 2 groups on the compressed video input. The de-embedded audio can be either re-
embedded on the HD video output or output as AES audio on the 4 BNCs labeled AES OUTPUT.
Selection of the audio destination and embedding group is done by DIP switch (see section 5.5).
A 9 pin D connector labeled ANALOG AUDIO OUT contains 2 balanced analog audio outputs. The
connector pinout is shown in Table 1. See sections 5.4 to 5.8 for more information about the analog audio
outputs.
Pin
#
Name Description
1 A1- Audio 1 (Left) - Output
2 Gnd Signal Ground
3 A2+ Audio 2 (Right) + Output
4 Gnd Signal Ground
5 Gnd Signal Ground
6 A1+ Audio 1 (Left) + Output
7 A2- Audio 2 (Right) - Output
8 GPO General Purpose Output
9 Gnd Signal Ground
Table 1: 9 Pin D Connector Pin Definitions
2.4. GENERAL PURPOSE OUTPUT CONNECTION
A pair of pins on the 9 pin D connector labeled ANALOG AUDIO OUT contains a general purpose output.
The connector pinout is shown in Table 1. See section 4.3 for more information about the operation of the
general purpose output.
Revision 1.0 PKG7771MFD-HD-3

7700 MultiFrame Manual
PKG7771MFD-HD Multi-format Decompression CODEC
3. SPECIFICATIONS
3.1. SERIAL VIDEO INPUT:
Standard: SMPTE 259M-C (270Mb/s)
SMPTE 305M data formatting
Number of Inputs: 1
Connector: BNC per IEC 60169-8 Amendment 2
Signal Level: 800mV nominal
DC Offset: 0V ±0.5V
Return Loss: >15dB @ 270Mb/s
3.2. SERIAL VIDEO OUTPUT:
Standard: SMPTE 292M (1.485Gb/s)
Number of Outputs: 2
Connector: BNC per IEC 60169-8 Amendment 2
Signal Level: 800mV nominal
DC Offset: 0V +/- 0.5V
Rise and Fall Time: <200ps nominal
Overshoot: <10% of amplitude
Return Loss: >15dB up to 1.0Gb/s
SDTi
Input HD Output
Common
Name
Pixels /
Active Lines
Frame
Rate
Progressive
/Interlace
SMPTE
Standard
525/29.97 1080i/59.94 1920 x 1080 29.97 I 274M
525/29.97 1080p/29.97sF 1920 x 1080 29.97 P (sF) 274M
525/29.97 720p/59.94 1280 x 720 29.97 P 296M
625/25 1080p/25sF 1920 x 1080 25 P (sF) 274M
525/23.98 1080p/23.98sF 1920 x 1080 23.98 P (sF) 274M
525/29.97 1035i/59.94 1920 x 1035 29.97 I 260M
Table 2: Video Output Formats
3.3. AES AUDIO OUTPUTS:
Standard: SMPTE 276M, single ended AES, Dolby E
Number of Outputs: 4
Connector: BNC per IEC 60169-8 Amendment 2
Sampling Rate: 48khz
Impedance: 75Ω
Resolution: 24-bit
PKG7771MFD-HD-4 Revision 1.0

7700 MultiFrame Manual
PKG7771MFD-HD Multi-format Decompression CODEC
3.4. MONITORING ANALOG AUDIO OUTPUTS:
Number of Outputs: 2
Type: Balanced analog audio
Connector: Female DB-9
Output impedance: 66Ω
Signal Level: 0db FS >20dB, into high impedance load
(>10K Ω)
Not good for low impedance loads (i.e. 600Ω)
Frequency Response: 50Hz to 20khz: +/- 0.20dB
SNR: >85dB (50Hz to 20kHz)
THD+N: 65dB @ 1kHz, 0dB FS, typical
3.5. SYSTEM DELAY (COMPRESS + DECOMPRESS):
Video: 9 Frames
Audio: 9 Frames
3.6. GPO:
Number of Outputs: 1
Connector: 1 pin on DB9
Type: TTL
3.7. ELECTRICAL:
Voltage: +12VDC
Power: 16 Watts
EMI/RFI Complies with FCC Part 15 Class A
EU EMC Directive
3.8. PHYSICAL:
7700 frame mounting: 4 slots
3.9. ORDERING INFORMATION:
PKG7771MFD-HD Multi-Format HDTV (720p/1035i/1080i) to
270Mb/s SDTi De-compression CODEC Package
3.10. ORDERING OPTIONS:
Rear Plate must be specified at time of order
Eg: Model + 3RU
Rear Plate Suffix
+3RU 3RU Rear Plate for use with 7700FR-C Multiframe
3.11. ENCLOSURES:
7700FR-C 3RU Multiframe which holds 15 modules
Revision 1.0 PKG7771MFD-HD-5

7700 MultiFrame Manual
PKG7771MFD-HD Multi-format Decompression CODEC
4. STATUS INDICATORS AND DISPLAYS
The PKG7771MFD-HD has 14 LED Status indicators and a 4 digit alphanumeric display on the front card
edge to show operational status of the card at a glance. Figure 3 shows the location of the LED’s, display
and card edge DIP switches.
Red Failure LED
Green OK LED
A
lpha-numeric
Display
SDTi Audio Group LEDs
Card Extractor
PKG7771MFD
Red Failure LED
Green OK LED
1
DIP switches, set "B"
Video
A
udio
1
DIP switches, set "A"
12VANC
HD Embedded Audio LEDs
1 2 3 4
Card Extractor
7771MFCD-D
Toggle switch
Red Failure LED
1
Green OK LED
Video OK LED
Pushbutton
Figure 3: LED and Switch Locations
4.1. PKG7771MFD STATUS AND INDICATOR LEDS
4.1.1. Module Status LEDs
Two large LED’s on the front of the bottom board for the PKG7771MFD indicate the general health of the
module
LOCAL FAULT: This Red LED indicates poor module health and will be On during the absence of
valid embedded audio in group 1 or group 2 of the SDTi input or if a local input
power fault exists on the bottom board (i.e.: a blown fuse). The LOCAL FAULT
indication can also be reported to the frame through the FRAME STATUS jumper on
the bottom board.
MODULE OK: This Green LED indicates good module health. It will be On when both audio groups
1 and 2 are present, and board power is good.
Two large LED's on the front of the top board indicate the presence of video to the module. DIP switches
1 to 3 on the top board are used to select the video standard (see section 5.1). The alphanumeric display
will show the video standard in use (see section 4.1.4).
PKG7771MFD-HD-6 Revision 1.0

7700 MultiFrame Manual
PKG7771MFD-HD Multi-format Decompression CODEC
VIDEO FAULT: This Red LED will be On during the absence of valid video input of the selected
standard or if a local input power fault exists on the top board (i.e.: a blown fuse).
This condition can also be reported to the frame through the FRAME STATUS
jumper on the top board.
VIDEO OK: This Green LED will be On when a valid video signal of the selected standard is
present.
4.1.2. SDTi Audio and VANC Present LEDs
There are three small LED's on the back side of the top board that indicate the presence of embedded
audio groups 1 and 2 and embedded VANC on the SDTi input.
GROUP 1 PRESENT: This Green LED indicates the presence of Group 1 embedded audio.
GROUP 2 PRESENT: This Green LED indicates the presence of Group 2 embedded audio.
VANC PRESENT: This Green LED indicates the presence of VANC data in either Group 3 or group 4.
4.1.3. HD Output Embedded Audio Present LEDs
There are four small LED’s on the backside of the bottom board that indicate the presence of embedded
audio on the HD video output.
GROUP 1 PRESENT: This Green LED indicates the presence of Group 1 embedded audio.
GROUP 2 PRESENT: This Green LED indicates the presence of Group 2 embedded audio
GROUP 3 PRESENT: This Green LED indicates the presence of Group 3 embedded audio
GROUP 4 PRESENT: This Green LED indicates the presence of Group 4 embedded audio
4.1.4. DOT-MATRIX DISPLAY
The 4-digit alphanumeric display located on the card edge of the top board is used to display the video
standard in use. If manual video standard selection is set (DIP switch 1 On) then the display will always
display the selected standard. If auto standard selection is set (DIP switch 1 Off) the alpha-numeric
display will read AUTO until a valid input standard is detected. When valid input video is detected the
detected standard will be displayed. The following messages will be displayed.
AUTO Auto video standard selected, and no video present
59 1080i/59.94 or 1080p/29.97sF
720 720p/59.94
35 1035i/59.94
23 1080p/23.98sF
SD SDI input, not an SDTi compressed stream
Revision 1.0 PKG7771MFD-HD-7

7700 MultiFrame Manual
PKG7771MFD-HD Multi-format Decompression CODEC
4.2. 7771MFCD-D STATUS AND INDICATOR LEDS
4.2.1. Module Status LEDs
Two large LED’s on the front of the bottom board for the 7771MFCD-D indicate the general health of the
module. See Figure 3: LED and Switch Locations
LOCAL FAULT: This Red LED indicates poor module health and will be On during the absence of
valid embedded audio in group 1 or group 2 of the SDTi input or if a local input
power fault exists on the bottom board (i.e.: a blown fuse).
MODULE OK: This Green LED indicates good module health. It will be On when both audio groups
1 and 2 are present, and board power is good.
4.2.2. Video Present LED
The Green LED on the top board of the 7771MFCD-D module is on when valid Data is received from the
PKG7771MFD board. See Figure 3: LED and Switch Locations
4.3. GPO FUNCTION
The GPO output (pin 8 on the 9 pin D connector) is for use in switching downstream equipment between
SD and HD mode. When the PKG7771MFD-HD detects a non SDTi (i.e. SDI) video in it will set this output
to 5V. At this time “SD” will be displayed on the dot-matrix display. When SDTi input video is found this
output will be 0V (ground).
5. CARD EDGE CONTROLS
The PKG7771MFD-HD is equipped with two 8 position DIP switches on the PKG7771MFD, to allow the
user to select various functions. The DIP switch on the bottom card (SET B) is used to control the
embedding of audio on the SDTi input. The DIP switch on the top card (SET A) is used to set the input
video standard. All positions are assigned sequentially such that the first position is located at the top of
the DIP switch (farthest from to the card ejector). The On (closed) position is down, or closest to the
printed circuit board. The Off (open) position is up, or farthest from the printed circuit board.
Table 3 and Table 4 give an overview of the DIP switch functions. Sections 5.1 to 5.8 oulines each DIP
switch function.
Please refer to Figure 3: LED and Switch Locations for card edge LED and Switch locations.
PKG7771MFD-HD-8 Revision 1.0

7700 MultiFrame Manual
PKG7771MFD-HD Multi-format Decompression CODEC
DIP Switch Function
1 Group 1 Source Select
2
3 Group 1 mapping from Input Embedded Groups
4 Group 2 Source Select
5
6
Group 2 mapping from Input Embedded Groups
7 Group 2 enable/disable
8 Auto/Manual Audio selection
Table 3: Bottom Board DIP Switch Functions (Set B)
DIP Switch Function
1 Auto/Manual Video Format Selection
2
3 Video Standard Selection
4 AES input’s Sample Rate Converter enable/disable
5
6 Embedded and External Audio Delay Control
7
8
Analog monitor audio channel source
Table 4: Top Board DIP Switch Functions (Set A)
5.1. SELECTING THE OUTPUT VIDEO STANDARD (SET A)
DIP switches 1 to 3 on the top card control the selection of the output video format. DIP switch 1 selects
whether the input video format will be automatically detected or set using DIP switches 2 and 3.
DIP 1 DIP 2 DIP 3 Video Standard
Off --- --- Auto
On Off Off 1080p/23.98sF
On Off On 1035i/59.94
On On Off 720p/59.94
On On On
1080i/59.94 or
1080p/29.97sF
Table 5: Video Standard Switch Settings
Revision 1.0 PKG7771MFD-HD-9

7700 MultiFrame Manual
PKG7771MFD-HD Multi-format Decompression CODEC
5.2. SELECTING HOW THE AUDIO WILL BE OUTPUT (SET A)
DIP switch 4 on the top card controls whether sample rate conversion is enabled on the AES outputs.
DIP 4 AES output sample rate converter
Off Disabled
On Enabled
Table 6: AES Output Sample Rate Converter Enable/Disable Switch Settings
5.3. SELECTING AUDIO DELAY CONFIGURATIONS (SET A)
The PKG7771MFD-HD will automatically compensate for delay when either External or Embedded Audio
is required. DIP 5 must be set to match the AES Audio Source input configuration of the PKG7771MFC-
HD and the AES Audio output of the PKG7771MFD-HD.
Eg. If HD-SDI video with 4 External Audio is compressed with the PKG7771MFC-HD and HD-SDI video
with embedded audio is required on the output of the PKG7771MFD-HD de-compressor, DIP 5 should be
set OFF, and DIP 6 should be set ON. Please note that DIP 5 and 6 do not turn these audio features on
or off. The are used to configure the audio delay to resolve any “lip sync” issues.
DIP 5 PKG7771MFC-HD Audio Source Select
Off AES External Audio
On Embedded Audio
Table 7: Audio Source Select DIP Switch Settings
DIP 6 PKG7771MFD-HD Audio Destination
Select
Off AES External Audio
On Embedded Audio
Table 8: Audio Destination DIP Switch Select
5.4. SELECTING THE ANALOG AUDIO SOURCE CHANNEL (SET A)
The PKG7771MFD-HD supports two groups of audio or 4 stereo pairs however only has one stereo pair of
analog monitor output. DIP switches 7 and 8 on the top card select which of the four stereo channels
transported is output to the analog monitor channels.
DIP 8 DIP 7 Monitor source
On On Group one, channel one
On Off Group one, channel two
Off On Group two, channel one
Off Off Group two, channel two
Table 9: Video Standard Switch Settings
Volume Control
5.5. SELECTING HOW THE AUDIO WILL BE OUTPUT (SET B)
Up to 2 groups of 4 audio channels can be de-embedded from the 270 Mb/s SDTi bit stream and either be
re-embedded on the HD video output or output as AES audio. DIP switch 1 on the bottom board controls
PKG7771MFD-HD-10 Revision 1.0

7700 MultiFrame Manual
PKG7771MFD-HD Multi-format Decompression CODEC
whether group 1 will be output as AES1 and AES2 or embedded on the HD output. When DIP switch 1 is
set for HD embedded audio, DIP switches 2 and 3 are used to select which group on the HD output will be
used to embed the audio according to Table 10
DIP 1 DIP 2 DIP 3 Audio Group 1 Destination
Off --- --- AES outputs 1 and 2
On Off Off HD Output group 1
On Off On HD Output group 2
On On Off HD Output group 3
On On On HD Output group 4
Table 10: Audio Group 1 Destination Selection Switch Settings
DIP switch 4 on the bottom board controls whether group 2 will be output as AES3 and AES4 or
embedded on the HD output. When DIP switch 4 is set for HD embedded audio, DIP switches 5 and 6 are
used to select which group on the HD output will be used to embed the audio according to Table 11.
DIP 4 DIP 5 DIP 6 Audio Group 2 Destination
Off --- --- AES Outputs 3 and 4
On Off Off HD Output group 1
On Off On HD Output group 2
On On Off HD Output group 3
On On On HD Output group 4
Table 11: Audio Group 2 Destination Selection Switch Settings
5.6. SELECTING IF AUDIO GROUP 2 IS ENABLED OR DISABLED (SET B)
DIP switch 7 on the bottom board allows the second audio group to be output or not (whether embedded
in HD or output as AES). When audio selection is manually controlled this switch should reflect the
encoders setting.
DIP 7 Audio Group output
Off Disabled
On Enabled
Table 12: Audio Group 2 Enable/Disable Switch Settings
5.7. AUDIO OUTPUT AUTO/MANUAL SELECTION (SET B)
DIP switch 8 on the bottom board controls whether the destination for the embedded audio data is
determined automatically or by DIP switches 1 through 7 on the bottom board. Note: if VANC transport on
the encoder is turned off or an SDTi stream from another product is input and this switch is set to auto (off)
then group 1 will be embedded to group 1 of the HD output video and group 2 if it is present will be
embedded to group 2 of the HD output video.
DIP 8 Auto Audio destination
Off enabled
On disabled
Table 13: Auto/Manual Audio Output Switch Settings
Revision 1.0 PKG7771MFD-HD-11

7700 MultiFrame Manual
PKG7771MFD-HD Multi-format Decompression CODEC
5.8. ANALOG AUDIO MONITOR VOLUME
The toggle switch is used to control the volume of the analog audio outputs. Pressing the switch up (away
from the card ejector) increases the volume, and pressing the switch down (towards the card ejector)
decreases the volume.
PKG7771MFD-HD-12 Revision 1.0

7700 MultiFrame Manual
PKG7771MFD-HD Multi-format Decompression CODEC
6. JUMPERS
Several jumpers, located at the front of the modules are used to preset various operating modes. Figure
4, Figure 5, and Figure 6 Location of Jumpers (7771MFCD-D) show the location of the jumpers on the
bottom and top boards.
MODULE STATUS
SFF POWER +12V
Run
Upgrade
J16
J24
J22
FRAME
STATUS
ON
OFF GND
EVERTZ (C) 7700PH4
(Upgrade jumper on
underside of board)
Figure 4: Location of Jumpers Bottom Board (PKG7771MFD)
MODULE STATUS
SFF POWER
+12V
FRAME STATUS
ON OFF
GND
J8
EF IN
TERMINATION
Disp1
Figure 5: Location of Jumpers Top Board (PKG7771MFD)
SFF POWER
UPGRD RUN
MODULE STATUS
UPGRADE PORT
Figure 6 Location of Jumpers (7771MFCD-D)
Revision 1.0 PKG7771MFD-HD-13

7700 MultiFrame Manual
PKG7771MFD-HD Multi-format Decompression CODEC
6.1. SELECTING WHETHER LOCAL FAULTS ON THE BOTTOM BOARD OF THE
PKG7771MFD WILL BE MONITORED BY THE GLOBAL FRAME STATUS
The FRAME STATUS jumper J4 on the bottom board determines whether local faults (as shown by the
Local Fault indicator) on the bottom board will be connected to the 7700FR frame's global status bus.
FRAME STATUS To monitor faults on this module with the frame status indicators (on the Power
Supply FRAME STATUS LED's and on the Frame's Fault Tally output) install this jumper in the
On position. (Default)
When this jumper is installed in the Off position local faults on this module will not be
monitored.
6.2. SELECTING WHETHER LOCAL FAULTS ON THE TOP BOARD OF THE PKG7771MFD
WILL BE MONITORED BY THE GLOBAL FRAME STATUS
The FRAME STATUS jumper J4 on the top board determines whether local faults (as shown by the Local
Fault indicator) on the top board will be connected to the 7700FR frame's global status bus.
FRAME STATUS To monitor faults on this module with the frame status indicators (on the Power
Supply FRAME STATUS LED's and on the Frame's Fault Tally output) install this jumper in the
On position. (Default)
When this jumper is installed in the Off position local faults on this module will not be
monitored.
6.3. CONFIGURING THE PKG7771MFD MODULE FOR FIRMWARE UPGRADES
"
The UPGRADE jumper J16 is installed on the underside of the PKG7771MFD
bottom board.
UPGRADE The UPGRADE jumper J16 on the bottom board is used when firmware upgrades are being
done to the module. For normal operation it should be installed in the RUN position. See the
Upgrading Firmware chapter of this manual for more information.
To upgrade the firmware in the module unit pull it out of the frame. Move the UPGRADE
jumper into the UPGD position. Install the Upgrade cable provided (located in the vinyl pouch
in the front of this manual) onto the SERIAL header at the card edge. Re-install the module
into the frame. Run the upgrade as described in the Upgrading Firmware section of this
manual. Once the upgrade is completed, remove the module from the frame, move the
UPGRADE jumper into the RUN position, remove the upgrade cable and re-install the module.
The module is now ready for normal operation.
PKG7771MFD-HD-14 Revision 1.0

7700 MultiFrame Manual
PKG7771MFD-HD Multi-format Decompression CODEC
6.4. CONFIGURING THE 7771MFCD-D MODULE FOR FIRMWARE UPGRADES
"
The UPGRADE jumper J15 is installed on the underside of the 7771MFCD top
board.
UPGRADE The UPGRADE jumper J15 on the top board is used when firmware upgrades are being
done to the module. For normal operation it should be installed in the RUN position. See the
Upgrading Firmware chapter of this manual for more information.
To upgrade the firmware in the module unit pull it out of the frame. Move the UPGRADE
jumper into the UPGD position. Install the Upgrade cable provided (located in the vinyl pouch
in the front of this manual) onto the SERIAL header at the card edge. Re-install the module
into the frame. Run the upgrade as described in the Upgrading Firmware section of this
manual. Once the upgrade is completed, remove the module from the frame, move the
UPGRADE jumper into the RUN position, remove the upgrade cable and re-install the module.
The module is now ready for normal operation.
Revision 1.0 PKG7771MFD-HD-15
