evertz 7700 Series User manual

7700 MultiFrame Manual
7707CVR-2-SV S-Video and Analog Audio Fiber Receiver
Revision 0.2
TABLE OF CONTENTS
1. OVERVIEW.......................................................................................................................................... 1
2. INSTALLATION................................................................................................................................... 3
2.1. CARE AND HANDLING OF OPTICAL FIBER............................................................................ 4
3. SPECIFICATIONS............................................................................................................................... 5
3.1. OPTICAL INPUT......................................................................................................................... 5
3.2. S-VIDEO OUTPUTS ................................................................................................................... 5
3.3. ANALOG AUDIO OUTPUTS...................................................................................................... 6
3.4. SYSTEM PERFORMANCE ........................................................................................................ 6
3.5. ELECTRICAL ............................................................................................................................. 6
3.6. PHYSICAL.................................................................................................................................. 6
4. STATUS INDICATORS AND DISPLAYS ........................................................................................... 7
4.1. STATUS INDICATOR LEDS....................................................................................................... 7
4.2. DOT-MATRIX DISPLAY............................................................................................................. 7
4.2.1. Setting the Headphone Jack Channel............................................................................. 8
4.2.2. Displaying the Video Standard........................................................................................ 8
4.2.3. Displaying the Optical Power .......................................................................................... 9
5. CARD EDGE MENU SYSTEM.......................................................................................................... 10
5.1. NAVIGATING THE MENU SYSTEM......................................................................................... 10
5.2. TOP LEVEL MENU STRUCTURE............................................................................................ 11
5.3. SETTING THE VIDEO CONTROLS.......................................................................................... 12
5.3.1. Setting the Video Gain .................................................................................................. 12
5.3.2. Setting the Video DC Offset.......................................................................................... 12
5.3.3. Setting the Video Output Pre-Emphasis........................................................................ 12
5.4. SETTING THE AUDIO CONTROLS......................................................................................... 13
5.4.1. Setting the Audio Volume Level.................................................................................... 13
5.4.2. Muting the Output Audio................................................................................................ 13
5.4.3. Configuring Audio Presence Detection ......................................................................... 13
5.4.3.1. Procedure to Calibrate Audio Presence Detection......................................... 13
5.5. CHANGING THE ORIENTATION OF THE TEXT ON THE DISPLAY....................................... 14
5.6. RESTORING THE FACTORY SETTINGS................................................................................ 14
6. CARD EDGE CONTROLS ................................................................................................................ 15
6.1. MONITORING THE AUDIO ...................................................................................................... 15
7. JUMPERS.......................................................................................................................................... 16

7700 MultiFrame Manual
7707CVR-2-SV S-Video and Analog Audio Fiber Receiver
Revision 0.2
7.1. SELECTING WHETHER LOCAL FAULTS WILL BE MONITORED
BY THE GLOBAL FRAME STATUS........................................................................................ 16
7.2. SELECTING WHETHER MODULE WILL BE CONTROLLED FROM THE
LOCAL CONTROLS OR THROUGH THE VISTALINK
®
INTERFACE...................................... 17
7.3. CONFIGURING THE MODULE FOR FIRMWARE UPGRADES.............................................. 17
8. VISTALINK
®
REMOTE MONITORING/CONTROL........................................................................... 18
8.1. WHAT IS VISTALINK
®
?............................................................................................................... 18
8.2. VISTALINK
®
MONITORED PARAMETERS .............................................................................. 19
8.3. VISTALINK
®
TRAPS.................................................................................................................... 19
8.4. VISTALINK
®
CONTROLLED PARAMETERS ........................................................................... 19
Figures
Figure 1-1: 7707CVR-2-SV Block Diagram ..........................................................................................................2
Figure 2-1: 7707CVR-2-SV Rear Panel................................................................................................................3
Figure 7-1: Location of Jumpers and Card Edge Controls .................................................................................16
Tables
Table 8-1: VistaLINK
®
Monitored Parameters.....................................................................................................19
Table 8-2: VistaLINK
®
Traps...............................................................................................................................19
Table 8-3: VistaLINK
®
Controlled Parameters....................................................................................................20

7700 MultiFrame Manual
7707CVR-2-SV S-Video and Analog Audio Fiber Receiver
Revision 0.2
REVISION HISTORY
REVISION DESCRIPTION DATE
0.1 Preliminary Version Sep 05
0.2
Updated VistaLINK
®
description and fixed format Nov 08
Information contained in this manual is believed to be accurate and reliable. However, Evertz assumes no responsibility for the use thereof nor for
the rights of third parties, which may be affected in any way by the use thereof. Any representations in this document concerning performance of
Evertz products are for informational use only and are not warranties of future performance, either expressed or implied. The only warranty offered
by Evertz in relation to this product is the Evertz standard limited warranty, stated in the sales contract or order confirmation form.
Although every attempt has been made to accurately describe the features, installation and operation of this product in this manual, no warranty is
granted nor liability assumed in relation to any errors or omissions unless specifically undertaken in the Evertz sales contract or order confirmation.
Information contained in this manual is periodically updated and changes will be incorporated into subsequent editions. If you encounter an error,
please notify Evertz Customer Service department. Evertz reserves the right, without notice or liability, to make changes in equipment design or
specifications.

7700 MultiFrame Manual
7707CVR-2-SV S-Video and Analog Audio Fiber Receiver
Revision 0.2
WARNING
Never look directly into an optical fiber. Non-reversible damage to the eye can
occur in a matter of milliseconds.
"
Do not hook up the 7707CVT series DWDM cards and any 7707CVR series
cards directly with a short fiber optic cable. The 7707CVT series DWDM card
produces +7dBm of power which will damage the receiver if connected
directly.
"
Do not hook up the 7707CVT series cards that output more than -7dBm of
power (see 7707CVT series specifications for output power of various laser
types) and 7707CVR series high sensitivity (-H versions) receiver cards
directly with a short fiber optic cable. The 7707CVT series cards that produce
more than -7dBm of power will damage the receiver if connected directly.

7700 MultiFrame Manual
7707CVR-2-SV S-Video and Analog Audio Fiber Receiver
Revision 0.2 7707CVR-2-SV-1
1. OVERVIEW
The 7707CVR-2-SV is a VistaLINK
®
enabled, S-Video and analog audio fiber receiver for broadcast video
quality signals. This single card module accepts a fiber optic input, demultiplexes the signals, and
performs D to A conversion and outputs NTSC or PAL analog video and up to four balanced analog audio
signals. The companion 7707CVT-2-SV S-Video and Analog Audio fiber transmitter, digitizes and
multiplexes the S-Video and up to four analog audio signals and converts them to an optical signal for
transmission.
The 7707CVR-2-SV occupies one card slot and can be housed in either a 1RU frame, which will hold up
to three modules, or a 3 RU frame, which will hold up to 15 modules.
Features:
•Single card fiber demultiplexer for S-Video and audio signals
•Supports both NTSC and PAL video signals
•Broadcast quality S-Video and audio performance
•Adjustable gain and DC offset, and pre-emphasis for up to 300m of Belden 1694 coaxial cable
•Minimal Audio to Video latency
•Comprehensive signal and status monitoring via four-digit card-edge display, or through SNMP
and VistaLINK
®
enabled capability
•Fully hot-swappable from front of frame with no fiber disconnect/reconnect required
•Supports Single mode (8-10 µm) and Multi-mode (50/62.5 µm) fiber optic cable
•Accepts any wavelength in the 1270nm to 1610nm range

7700 MultiFrame Manual
7707CVR-2-SV S-Video and Analog Audio Fiber Receiver
7707CVR-2-SV-2 Revision 0.2
OPTICAL
INPUT
OPTICAL
RECEIVER
CONTROL/
INDICATION
Vista LINK
®
Interface
LOCAL
CONTROL
LOCAL
INDICATION
S-Video
Outputs
Level Control
4 Balanced
Analog Audio
Outputs
RX
INTERFACE
D to A
Converter
D to A
Converter
D to A
Converter
D to A
Converter
D to A
Converter
TDM
DEMUX
D to A
Converter
Buffer
D to A
Converter
Buffer
Luma Chroma
Figure 1-1: 7707CVR-2-SV Block Diagram

7700 MultiFrame Manual
7707CVR-2-SV S-Video and Analog Audio Fiber Receiver
Revision 0.2 7707CVR-2-SV-3
2. INSTALLATION
The 7707CVR-2-SV comes with a companion rear plate that has two BNC connectors, one twelve pin
terminal header with removable terminal block and one SC/PC, SC/PC with cover flap, ST/PC or FC/PC
optical connector. For information on mounting the rear plate and inserting the module into the frame see
the 7700FR chapter section 3.
Figure 2-1: 7707CVR-2-SV Rear Panel
OPTICAL INPUT: SC/PC, SC/PC with cover flap, ST/PC or FC/PC female connector. This wide range
input accepts optical wavelengths of 1310nm accommodating standard or 1270nm
to 1610nm CWDM transmission schemes.
"
Do not hook up the 7707CVT series DWDM cards and any 7707CVR series cards
directly with a short fiber optic cable. The 7707CVT series DWDM card produces
+7dBm of power which will damage the receiver if connected directly.

7700 MultiFrame Manual
7707CVR-2-SV S-Video and Analog Audio Fiber Receiver
7707CVR-2-SV-4 Revision 0.2
"
Do not hook up the 7707CVT series cards that output more than -7dBm of power (see
7707CVT series specifications for output power of various laser types) and 7707CVR
series high sensitivity (-H versions) receiver cards directly with a short fiber optic
cable. The 7707CVT series cards that produce more than -7dBm of power will
damage the receiver if connected directly.
S-VIDEO OUTPUTS: On the 7707CVR-2-SV there are two outputs, Luma and Chroma. Each
output can have cable pre-emphasis applied independently. (Please refer to
section 5.3.3 for information on setting the desired pre-emphasis).
"
NOTE: Video Gain, Offset, and Equalization set for Luma and Chroma must be
configured to the same values. Levels applied to one channel must be applied to the
second channel.
ANALOG AUDIO OUT: Balanced analog audio outputs for 4 channels. Each output (+, -, GND) is
on three of twelve pins on the twelve pin terminal header.
2.1. CARE AND HANDLING OF OPTICAL FIBER
"
Never touch the end face of an optical fiber. Always keep dust caps on optical fiber
connectors when not connected and always remember to properly clean the optical end
face of a connector before making a connection.
The transmission characteristics of the fiber are dependent on the shape of the optical core and therefore
care must be taken to prevent fiber damage due to heavy objects or abrupt fiber bending. Evertz
recommends that the user maintains a minimum bending radius of 5 cm to avoid fiber-bending loss that
will decrease the maximum attainable distance of the fiber cable. The Evertz fiber optic modules come
with cable lockout devices, to prevent the user from damaging the fiber by installing a module into a slot in
the frame that does not have a suitable I/O module. For further information about care and handling of
fiber optic cable see section 3 of the Fiber Optics System Design chapter in the front of the binder.

7700 MultiFrame Manual
7707CVR-2-SV S-Video and Analog Audio Fiber Receiver
Revision 0.2 7707CVR-2-SV-5
3. SPECIFICATIONS
3.1. OPTICAL INPUT
Number of Inputs: 1
Connector: Female SC/PC, SC/PC with cover flap, ST/PC or FC/PC
Operating Wavelength: 1270nm to 1610nm
Max. Input Power:
Standard: 0dBm
High Sensitivity (-H): -7dBm
Optical Sensitivity
Standard: -27dBm
High Sensitivity (-H): -32dBm
3.2. S-VIDEO OUTPUTS
Standard: NTSC, SMPTE 170M or PAL, ITU-R624-4
Number of Outputs: 2 (one Luma, one Chroma)
Connector: BNC per IEC 61169-8 Annex A.
System bandwidth: 5.5 MHz
Output Level: 1 Vp-p nominal, 2 Vp-p maximum
Gain: Unity Gain nominal, adjustable 50% to 150%
Output Impedance: 75 Ohms
Return Loss: > 20 dB
SNR: > 67dB
Differential Gain: < 1.0%
Differential Phase: < 0.7 Degrees
Pre-Emphasis: Cable loss compensation for up to 250m of Belden 1694 (each output
adjustable separately)
Passband Ripple:
NTSC: < +/- 0.1dB to 4.1 MHz
< +/- 0.2dB to 5.5 MHz
PAL: < +/- 0.1dB to 4.8 MHz
< +/- 0.2dB to 5.8 MHz
Chroma/Luma Gain: 98% to 103%
Chroma/Luma Delay:
NTSC: < 5 ns
PAL: < 12 ns
Line Time Distortion: 1.2%

7700 MultiFrame Manual
7707CVR-2-SV S-Video and Analog Audio Fiber Receiver
7707CVR-2-SV-6 Revision 0.2
3.3. ANALOG AUDIO OUTPUTS
Number of Outputs: 4
Type: Balanced analog audio
Connector: 12 pin removal terminal block
Output impedance: 66Ω
Freq. Response: +/-0.1 dB, 20Hz to 20 kHz
THD 20Hz–20Khz: < 0.005%
Channel Phase Diff. +/-1 degree
SNR (weighted): > 85 dB
Output Level Adj: -20 dB to +3 dB
Max Output Level: +24 dBu into 10 kΩ loads
3.4. SYSTEM PERFORMANCE
Video Input to Video Output Delay: < 10µs
Audio Input to Audio Output Delay: < 1.9ms
3.5. ELECTRICAL
Voltage: +12VDC
Power: 12 Watts
EMI/RFI: Complies with FCC regulations for class A devices
Complies with EU EMC directive
3.6. PHYSICAL
7700 or 7701 frame mounting:
Number of slots: 1

7700 MultiFrame Manual
7707CVR-2-SV S-Video and Analog Audio Fiber Receiver
Revision 0.2 7707CVR-2-SV-7
4. STATUS INDICATORS AND DISPLAYS
The 7707CVR has 6 LED Status indicators and a 4 digit alphanumeric display on the front card edge to
show operational status of the card at a glance. The card edge pushbutton and toggle switch are used to
select various displays on the alphanumeric display. Figure 7-1 shows the location of the LEDs and card
edge controls.
4.1. STATUS INDICATOR LEDS
Two large LEDs on the front of the board indicate the general health of the module
LOCAL FAULT: This Red LED indicates poor module health and will be On during the absence of a
valid optical link to a 7707CVT-2-SV module, or if a local input power fault exists
(i.e. a blown fuse). The LOCAL FAULT indication can also be reported to the frame
through the FRAME STATUS jumper.
MODULE OK: This Green LED indicates good module health. It will be On when a valid optical link
to a 7707CVT-2-SV module is present, and board power is good.
There are four small LEDs on the back side of the board that indicate the presence of audio signals above
the detection level (see section 5.4.3 for information about configuring the audio detection).
AUDIO 1 PRESENT: This Green LED indicates the presence of a valid signal on the Audio 1 input.
AUDIO 2 PRESENT: This Green LED indicates the presence of a valid signal on the Audio 2 input.
AUDIO 3 PRESENT: This Green LED indicates the presence of a valid signal on the Audio 3 input.
AUDIO 4 PRESENT: This Green LED indicates the presence of a valid signal on the Audio 4 input.
4.2. DOT-MATRIX DISPLAY
Additional signal and status monitoring and control over the card’s parameters are provided via the 4-digit
alphanumeric display located on the card edge. The card edge toggle switch is used to select whether the
user is displaying status from the card (monitoring mode) or setting control parameters for the card
(control mode). To select one of the display modes, press the pushbutton one or more times to exit the
current display mode and return to the mode select display (The display will show MON or SET). Press the
toggle switch to select monitor mode (MON) or control mode (SET). Once the desired mode is selected,
press the pushbutton to enter that mode. For information about setting up the module in control mode see
section 5.

7700 MultiFrame Manual
7707CVR-2-SV S-Video and Analog Audio Fiber Receiver
7707CVR-2-SV-8 Revision 0.2
While in monitor mode, the toggle switch determines what data is being displayed on the alphanumeric
display. Each time the toggle switch is pressed up/down, the display advances to the next/previous
display. A message indicating what display mode is active is shown for one second. After one second
without the toggle switch being pressed, the selected display data is shown. The card edge pushbutton is
used to return to the mode select menu item. The following display messages indicate what is being
displayed. The details of the each of the displays are described in the sections 4.2.1 to 4.2.3.
PWR Input Optical Power
S/W Software Version
AJCK Set Headphone Jack Audio Channel
STD1 Video Standard in Use
STD2 Video Standard in Use (for CVR-2 only)
4.2.1. Setting the Headphone Jack Channel
The AJCK display allows the user to set a whether audio channels 1/2 or 3/4 will be monitored on the card
edge headphone jack. After one second the display will show a message indicating the current audio
channel being monitored at the headphone jack. When this message is showing, press the pushbutton to
change the audio channel being monitored.
A1/2 Audio channels 1 and 2 will be monitored at the headphone jack.
A3/4 Audio channels 3 and 4 will be monitored at the headphone jack.
4.2.2. Displaying the Video Standard
The 7707CVR-2-SV detects the Video Standard of the input signal and displays this on the four-digit card
edge display. The following list describes possible displays and their meaning:
NTSC SMPTE 170M
PAL ITU-R624-4
LSV Indicates that no valid video signal is present on the input. This message overrides the
normal video standard message.

7700 MultiFrame Manual
7707CVR-2-SV S-Video and Analog Audio Fiber Receiver
Revision 0.2 7707CVR-2-SV-9
4.2.3. Displaying the Optical Power
The 7707CVR-2-SV detects the input optical power and displays this on the four-digit card edge display.
The following list describes possible displays and their meaning:
Standard Version:
OK Indicates optical input power is within acceptable range (> -12 dB).
-13 to –28 Numerical value of optical input power.
<-28 For optical input power < -28dBm (VistaLINK
®
will display “LOW” at these values of
input power).
“-H” version:
-7 to –40 Numerical value of optical input power for “–H” version.
OVR For optical input power > -7dBm for “–H” version.
LOW For optical input power < -40dBm (Link Error may display at slightly higher values.
than –40dBm, VistaLINK
®
will still display “LOW”).

7700 MultiFrame Manual
7707CVR-2-SV S-Video and Analog Audio Fiber Receiver
7707CVR-2-SV-10 Revision 0.2
5. CARD EDGE MENU SYSTEM
5.1. NAVIGATING THE MENU SYSTEM
While in control mode, the toggle switch and pushbutton are used to navigate through a menu system to
set various parameters for the module. To enter the menu system, press the pushbutton one or more
times to exit the current display mode and return to the mode select menu item. The display will show MON
or SET. Press the toggle switch to select control mode (SET) and then press the pushbutton to enter that
control mode main setup menu. Use the toggle switch to move up and down the list of available sub
menus. Once the desired submenu name is displayed, press the pushbutton to select the next menu
level.
Once the user is in the sub menu, there will be a list of parameters to adjust. To adjust any parameter,
use the toggle switch to move up or down to the desired parameter and press the pushbutton. Using the
toggle switch, adjust the parameter to its desired value. If the parameter is a numerical value, the number
will increase if the toggle switch is pressed up and the number will decrease if the toggle switch is pressed
down. If the parameter contains a list of choices, the user can cycle through the list by pressing the toggle
switch in either direction.
Depress the pushbutton once the desired value is reached. This will update the parameter to the selected
value and return to the mode select menu item (the display shows SET). To change another parameter,
press the pushbutton to enter the main menu system again and continue selecting and adjusting other
parameters.
Throughout the descriptions of the Menu items, default values are shown in underlined text.
Each time the toggle switch is pressed up/down, the display advances to the next/previous display. A
message indicating what display mode is active is shown for one second. After one second without the
toggle switch being pressed, the selected display data is shown. The card edge pushbutton is used to
select sub-items where applicable.

7700 MultiFrame Manual
7707CVR-2-SV S-Video and Analog Audio Fiber Receiver
Revision 0.2 7707CVR-2-SV-11
5.2. TOP LEVEL MENU STRUCTURE
The following is a brief description of the top level of the menu tree that appears when the user enters the
On screen menu. Selecting one of these items will take the user down into the next menu level. The
details of the each of the displays are described in the sections 5.3 to 5.5.
G1 Configures the gain of video channel 1 (Luma).
G2 Configures the gain of video channel 2 (Chroma).
OFF1 Configures the DC offset level of video channel 1 (Luma).
OFF2 Configures the DC Offset level of video channel 2 (Chroma).
EQ1 Configures the Pre-emphasis on Video output 1 (Luma).
EQ2 Configures the Pre-emphasis on Video output 2 (Chroma).
VOL1 Configures the Volume of Audio channel 1.
VOL2 Configures the Volume of Audio channel 2.
VOL3 Configures the Volume of Audio channel 3.
VOL4 Configures the Volume of Audio channel 4.
MUT1 Mutes Audio channel 1.
MUT2 Mutes Audio channel 2.
MUT3 Mutes Audio channel 3.
MUT4 Mutes Audio channel 4.
ADET Sub menu allows you to set parameters relating to the Audio detection.
DISP Allows the user to set the orientation of the front panel display.
FRST Resets the module to its factory reset values.

7700 MultiFrame Manual
7707CVR-2-SV S-Video and Analog Audio Fiber Receiver
7707CVR-2-SV-12 Revision 0.2
5.3. SETTING THE VIDEO CONTROLS
5.3.1. Setting the Video Gain
G1
100
50 to 150
The G1 control is used to set the gain of the video output 1 (Luma). The
display shows a range of gain values expressed as a percentage.
Note: values other than 100 are approximate only.
G2
100
50 to 150
The G2 control is used to set the gain of the video output 2 (Chroma). The
display shows a range of gain values expressed as a percentage.
Note: values other than 100 are approximate only.
"
NOTE: Video Gain, Offset, and Equalization set for Luma and Chroma must be
configured to the same values. Levels applied to one channel must be applied to the
second channel.
5.3.2. Setting the Video DC Offset
OFF1
0
-100 to 100
The OFF1 control is used to set the DC offset level of the video output 1 on
the 7707CVR-2-SV (Luma). The display shows a range of offset values
from 0 Volts expressed in millivolts.
OFF2
0
-100 to 100
The OFF2 control is used to set the DC offset level of the video output 2 on
the 7707CVR-2-SV (Chroma). The display shows a range of offset values
from 0 Volts expressed in millivolts.
"
NOTE: Video Gain, Offset, and Equalization set for Luma and Chroma must be
configured to the same values. Levels applied to one channel must be applied to the
second channel.
5.3.3. Setting the Video Output Pre-Emphasis
EQ1
0
0 to 300 The EQ1 control is used to set the Pre-emphasis of video output 1 (Luma).
When it is set to 0 the output frequency pre-emphasis will be flat. It can be
adjusted to compensate for various output cable lengths to achieve a flat
frequency curve at the end of the cable. The display shows a range of
approximate cable length values expressed in meters for Belden 1694 cable
or equivalent.
EQ2
0
0 to 300 The EQ2 control is used to set the Pre-emphasis of video output 2
(Chroma). When it is set to 0 the output frequency pre-emphasis will be flat.
It can be adjusted to compensate for various output cable lengths to achieve
a flat frequency curve at the end of the cable. The display shows a range of
approximate cable length values expressed in meters for Belden 1694 cable
or equivalent.

7700 MultiFrame Manual
7707CVR-2-SV S-Video and Analog Audio Fiber Receiver
Revision 0.2 7707CVR-2-SV-13
5.4. SETTING THE AUDIO CONTROLS
The first group of menu items are used to configure the control items relating to the Audio. The menu
items for each channel are identical so for the sake of simplicity, only the menu items for A1 channel are
shown.
5.4.1. Setting the Audio Volume Level
VOL1
0
–20 to +3 The VOL controls (1 to 4) set the audio volume of each channel level
expressed in dB. The volume level can be adjusted in 0.5 dB increments.
5.4.2. Muting the Output Audio
MUT1
OFF
ON The MUTE controls (1 to 4) allow the user to mute each channel.
5.4.3. Configuring Audio Presence Detection
The ADET sub menu contains 3 menu items (for each audio channel) relating to the Audio detection. The
menu items for each channel are identical so for the sake of simplicity, only the menu items for A1 channel
are shown.
DET1
OFF
ON The DET controls (1 to 4) enable audio presence detection on each of the
channels.
The LVL and DUR controls are used to detect when the audio is considered to be missing. The LVL
control sets the audio level under which the audio is considered to be missing. The audio must be under
the LVL level for the duration set by the DUR control before the audio is considered missing. When audio
is missing, the audio must be over the LVL level for 1 sec. before the audio will be considered present.
LVL1
–67 to 0
-40 The LVL controls (1 to 4) set the audio level under which audio is
considered to be missing. This value is expressed in dBu
DUR1
1 to 20
10
The DUR controls (1 to 4) set the amount of time (in seconds) the audio is
below the level set by the LVL control before the audio is considered
missing.
5.4.3.1. Procedure to Calibrate Audio Presence Detection
1. Supply the 7707CVT-2-SV module that is connected to the 7707CVR-2-SV module being calibrated
with the plant's noisiest audio feed without any audio program material present. This will be a baseline
noise level to calibrate the audio-missing detector.
2. Set the DUR control to 0.5 sec in order to see the results of adjusting the LVL parameter without
getting confused with the detection time.

7700 MultiFrame Manual
7707CVR-2-SV S-Video and Analog Audio Fiber Receiver
7707CVR-2-SV-14 Revision 0.2
3. Adjust the audio LVL control upward from its minimum value until the corresponding AUDIO PRESENT
LED on the card edge goes Off. This will be the noise floor level. Raise the LVL a few dB to make the
detector insensitive to this noise level.
4. Set the DUR control to a time appropriate to the application. This should be set to a value longer than
the worst case acceptable quiet period.
5.5. CHANGING THE ORIENTATION OF THE TEXT ON THE DISPLAY
DISP
VERT
HOR The DISP control allows the user to select a horizontal or vertical orientation
for the displays to accommodate mounting the module in the 3RU or 1RU
frames.
5.6. RESTORING THE FACTORY SETTINGS
FRST
NO
YES The FRST control allows the user to restore the factory values (those
underlined) for the module’s parameters described in sections 5.3 and 5.5.

7700 MultiFrame Manual
7707CVR-2-SV S-Video and Analog Audio Fiber Receiver
Revision 0.2 7707CVR-2-SV-15
6. CARD EDGE CONTROLS
The 7707CVT-2-SV is equipped with a three position, return to center toggle switch which is used to select
the various card-edge displays and menu items and is also used in conjunction with a momentary
pushbutton to select some sub-items of the menu system. See sections 4.2 and 5 for information about
the card edge displays and menu system.
6.1. MONITORING THE AUDIO
A stereo headphone jack located at the front of the module is used to monitor the individual audio channel
pairs. The AJCK menu item is used to select the audio channels currently being monitored (please refer
to section 4.2.1). The monitoring volume level can be adjusted but turning the level potentiometer located
beside the headphone jack.

7700 MultiFrame Manual
7707CVR-2-SV S-Video and Analog Audio Fiber Receiver
7707CVR-2-SV-16 Revision 0.2
7. JUMPERS
Several jumpers, located at the front of the module are used to preset various operating modes. Figure
7-1 shows the location of the card edge controls, status indicators and jumpers.
FRAME STATUS ON/OFF
SERIAL
LOCAL FAULT
DISPLAY
SELECT
PUSH BUTTON
TOGGLE SWITCH
UPGRADE RUN/UPGD MASTER LOCAL/REMOTE
CONTROL1 A / B CONTROL 2 A / B
J4 J5 J6 J7 J8 J9
MODULE OK
HEAD PHONE JACK
AUDIO 2 PRESENT
AUDIO 3 PRESENT
AUDIO 1 PRESENT
AUDIO 4 PRESENT
HEAD PHONE VOLUME
Figure 7-1: Location of Jumpers and Card Edge Controls
7.1. SELECTING WHETHER LOCAL FAULTS WILL BE MONITORED
BY THE GLOBAL FRAME STATUS
The FRAME STATUS jumper J4 determines whether local faults (as shown by the Local Fault indicator)
will be connected to the 7700FR frame's global status bus.
FRAME STATUS: To monitor faults on this module with the frame status indicators (on the Power
Supply FRAME STATUS LED's and on the Frame's Fault Tally output) install this
jumper in the On position. (Default)
When this jumper is installed in the Off position local faults on this module will not
be monitored.
