Evolution Technologies Trillium User manual

Walker Manual
Manuel de I’ambulateur
BY / PAR EVOLUTION
BY / PAR EVOLUTION
4. Régler la hauteur de la poignée. Insérer la molette de réglage. Serrer jusqu’à
entendre un clic. Attention : ne pas trop serrer.
3. Assemblage du dossier :
a. À l’aide d’un tournevis Philips, retirer les vis, les rondelles et les écrous de leurs
points d’ancrage du support dorsal.
b. Insérer le support dorsal sur un côté et aligner les trous du support dorsal avec le
point d’ancrage (schéma 1).
c. Insérer une vis, une rondelle et un écrou puis bien serrer (schéma 2).
d. Refaire la même opération avec l’autre côté.
Pour installer la panière pliable, replier le Trillium, puis desserrer les deux boulons de serrage de
la panière. Serrer le support sur le cadre puis serrer le boulon.
Informations sur les réparations en usine>>
La devise d’Evolution est de « s’engager à fournir une qualité et un service inégalés ». Notre but est
de vous offrir le meilleur service du secteur. Si vous rencontrez des problèmes avec votre ambula-
teur Evolution ou que vous avez besoin d’aide, veuillez:
1. Examinez votre documentation: Des documents imprimés seront envoyés avec votre ambula-
teur Evolution Trillium. Ils contiennent les guides d’entretien et les informations d’installation.
2. Appelez ou rendez visite à votre concessionnaire Evolution: Il pourra vous aider et
déterminer si la garantie de votre ambulateur est admissible.
3. Communiquez avec le service à la clientèle d’Evolution au:
1-8000-556-2558 (États-Unis et Canada)
Pour le service de garantie, des réparations ou un remplacement:
Si vous devez renvoyer votre ambulateur à Evolution pour le service de garantie, veuillez appeler
ou visiter votre concessionnaire Evolution et il sera heureux de vous aider. Si vous devez localiser
un concessionnaire Evolution près de chez vous, veuillez nous contacter au 1-800-556-2558.
Préparez-vous à fournir 1) le numéro de modèle de l’appareil, 2) le numéro de série et 3) une
description du problème.
Pour les services et réparations hors garantie:
Si votre ambulateur n'est plus sous garantie ou ne donne pas droit à la garantie, votre concession-
naire Evolution sera heureux de vous fournir une estimation pour la réparation de votre ambulateur.
Plusieurs choses à ne pas oublier:
Si les problèmes rencontrés avec votre ambulateur sont considérées comme étant le résultat
d’une utilisation inappropriée, comme heurter les bordures de trottoir, heurter les portes pour les
ouvrir, etc., il ne sera pas couvert par la garantie. Nous nous réservons le droit de déterminer si
votre ambulateur a été utilisé de façon inappropriée. Votre concessionnaire Evolution sera heureux
de vous aider à organiser le retour de votre ambulateur. Nous effectuerons la réparation dans les
2 jours ouvrables après réception de votre ambulateur et il vous sera expédié. Si nous ne pouvons
pas réparer votre ambulateur dans un délai de 2 jours après sa réception, nous vous enverrons
un nouveau!
Accessoires optionnels pour plus de commodité>>
MONTE-
TROTTOIR >
Permet de franchir
les trottoirs et
autres obstacles
plus facilement.
FREIN DE
RALENTISSEMENT >
Sécurité et protection
supplémentaires pour
les pentes, les
descentes et les côtes.
ÉTAPE UN>>
Assemblage de votre ambulateur:
1. Lorsque vous recevez votre ambulateur, vérifiez soigneusement le contenu. Signalez
immédiatement à votre concessionnaire ou à Evolution tout article manquant:
2. Le contenu de tous les ambulateurs « Evolution » est le suivant:
a. Ambulateur complet replié avec siège et poignées préinstallés.
b. Un panier souple pliable.
c. Dossier.
d. Carte d’enregistrement de la garantie
e. Manuel d’utilisation
f. Coussin de siège souple
ÉTAPE DEUX>>
Vérification des freins et des roues:
1. Le système de freinage d’Evolution est sécuritaire et simple d’utilisation. Tenez
(en tirant) les poignées de frein pour stationner.
2. Vérifiez le système de freinage. Les roues devraient rester verrouillées lorsque les
freins de stationnement sont enclenchés.
3. N’enclenchez pas les freins de stationnement lorsque l’ambulateur est en mouvement.
Ceci pourrait endommager les roues de manière permanente.
4. Enclenchez toujours les freins de stationnement avant d’utiliser le siège.
ÉTAPE TROIS>>
Entretien et soins de votre ambulateur Trilli-
1. Vérifiez l’herméticité de l’écrou et des boulons régulièrement.
2. Vérifiez l'intégrité du cadre et des pneus au moins une fois par mois.
Pliage, dépliage et transport de votre ambulateur:
Pour REPLIER votre ambulateur Evolution, tirez sur la poignée centrale sur siège et l'ambula-
teur restera debout.
Pour DÉPLIER l’ambulateur Trillium, poussez simplement la poignée vers le bas au milieu du
siège en vous assurant que l’ambulateur est verrouillé complètement en position ouverte.
Précaution: Assurez-vous que la poignée centrale du siège est au même niveau que le
siège avant de vous assoir.
Pour transporter l’ambulateur lorsque celui-ci est replié, prenez simplement la poignée
centrale et soulevez l’ambulateur en le transportant de côté comme une valise.
Freins:
Enclenchez les freins en tirant les deux poignées de frein vers le haut. Ne marchez pas lorsque
les freins sont enclenchés.
Freins de stationnement:
Pressez les deux freins vers le bas jusqu’à ce que vous entendiez un clic.
Assurez-vous toujours que les deux freins sont bien enclenchés. Tirez vers le haut pour relâcher
les freins de stationnement. Lorsque vous utilisez le siège, les deux freins DOIVENT être verrouillés
pour votre sécurité.
Réglage de la hauteur de poignée:
Pour régler les poignées à la hauteur désirée, placez-vous derrière l’ambulateur à hauteur des
épaules. Les poignées devraient se trouver à la même hauteur ou légèrement plus haut que le
poignet de l’utilisateur. Un thérapeute pourrait
conseiller une hauteur de poignée différente
selon les besoins particuliers de l’utilisateur.
Pour régler les poignées, enlevez la poignée et
tirez le boulon hexagonal, ajustez la poignée à
la hauteur désirée ou prescrite et insérez le
boulon hexagonal en vous assurant que la
partie hexagonale du boulon soit ajustée
adéquatement au trou hexagonal sur le cadre
de l'Trillium et serrez la poignée
convenablement. Précaution: Ne serrez
pas trop fort.
Installation du panier:
Assistance:
Votre concessionnaire Evolution le plus proche sera heureux de vous aider pour l'assemblage et
l'entretien de votre ambulateur.
2. À l’aide d’un tournevis Philips tourner la vis de réglage vers la droite (A) pour abaisser le
patin de frein (B) pour un freinage plus fort. Testez les freins, en veillant à ce que, lorsque vous
mettez le frein de stationnement, les roues arrières restent en position verrouillée.
3. Réinstallez le frein de ralentissement si installé.
1. Afin d’assurer un freinage correct, régler
de temps en temps les plaquettes de frein
situées sur le dessus des roues arrières. Pour
ajuster le frein, enlevez le frein de ralentisse
ment si installé, en enlevant les deux vis
Phillips sur le devant de la fourche arrière.
Ajustement des Freins:
A B
Porte-Gobelet >
Support de Canne >
Support de Téléphone >
Vase à Fleur >

BY / PAR EVOLUTION
3. Backrest Assembly
a. Using a Phillips screwdriver, remove screws, washers and nylock nut from back
support anchor points.
b. Insert back support on one side and align holes of back support and anchor
point (figure 1).
c. Insert screw, washer and nut and tighten securely (figure 2).
d. Repeat for second side.
4. Adjust handle height. Put Knob Bolts through from inside. Tighten until it is snug.
Caution: Do Not Overtighten.
To install the soft folding basket, fold the
Trillium, loosen the two basket clamp knobs.
Clamp the bracket on the frame and tighten
the knob.
2. Using a Philips screwdriver, rotate the adjustment screw clockwise (A) to lower the brake pad (B) for
tighter braking. Test the brakes, making sure that when applying the parking brake, the rear wheels
stay in the locked position.
3. Reinstall the Slow Down Brake if installed.
1. Upon receiving your walker, please check the contents carefully. Report any missing
items to your dealer or Evolution immediately:
2. Contents of all Evolution Trillium walkers are as follows:
a. Folded walker complete with main frame, seat, handles, and wheels already installed.
b. A soft folding basket
c. Back support
d. Warranty Registration Card
e. Owner’s Manual
f. Soft seat cushion
1. The Evolution braking system provides safety and ease of operation. Hold (squeeze) to
brake and press down on the brake handle for parking.
2. Check braking system. The wheels should stay locked while parking brake is activated.
3. Do not activate parking brake while walker is moving. This may cause permanent damage to
the wheels.
4. Always activate parking brake before using the seat.
1. Check tightness of nut and bolts regularly.
2. Check frame and tire integrity at least once a month.
To FOLD your Trillium walker, pull on the seat center handle and the walker will remain standing up.
To UNFOLD the Trillium, simply push down on the handle in the middle of the seat making sure the
walker locks in the fully open position. Caution: Ensure the center seat handle is level with the
seat before sitting.
To carry the walker while folded, simply pick it up by the center handle and lift the walker carrying it
at your side like a suitcase.
Apply the brakes by pulling both brake handles upwards. Do not walk with brakes on.
Press down on both brake handles until you hear a distinct click sound. Always make sure that both
brakes are engaged. Pull upwards to release the parking brakes. When using the seat, both brakes
MUST be in the locked position for your safety.
1. To ensure proper braking, from time to time
adjust the brake pads located on the top of the
rear wheels. To adjust the brake, remove the
Slow Down Brake if installed, by removing the
two Phillips screws on the front of the rear fork.
To adjust the handles to a suitable height, stand behind the walker with your shoulders level. The
handles should be at the same height or slightly higher than the user’s wrist. A therapist might
suggest a different handle height to accommodate a specific need for the user.
To adjust the handles, remove the knob and pull
the hex bolt out, adjust the handle to the
prescribed or desired handle height and insert
the hex bolt ensuring that the hexagonal part of
the bolt fits properly on the hexagonal cut out on
the frame of the Trillium and tighten the knob
snugly. Caution: Do Not Over Tighten.
Your nearest Evolution dealer will be pleased to assist you with the assembly and/or maintenance of
your walker.
Evolution’s motto is ‘Committed to Providing Unsurpassed Quality & Service’. Our goal is to provide
you the best service in the industry. If you encounter problems with your Evolution Walker or need
help, please:
1. Review your documentation: You will find printed documentation shipped with your Evolution
Trillium Walker. They contain maintenance guides and installation information.
2. Call or visit your Evolution dealer: They will be able to give you the assistance you need and
determine if your walker is eligible for warranty.
3. Contact Evolution Customer Service at: 1-800-556-2558 (U.S. and Canada)
If you have to return your walker to Evolution for warranty service, please call or visit your Evolution
dealer and they will be happy to assist you. If you need to locate an Evolution dealer close to you,
please contact us at 1-800-556-2558. Be prepared to provide 1) the unit model number, 2) the
serial number, and 3) a description of the problem.
If your walker is out of warranty or is not eligible for warranty, your Evolution dealer will be
happy to provide estimates to have your walker repaired.
If the problems with your walker are deemed to be the result of improper use, such as hitting curbs,
hit-opening doors, etc., it will not be covered under warranty. We reserve the right to determine if your
walker has been misused. Your Evolution dealer will be happy to assist you in arranging the return of
your walker. We will service the walker within 2 working days after receiving it and it will be on its way
back. If we cannot service your walker within 2 working days after receipt, we will send you a new
one!
Makes getting over
curbs and other
obstacles much
less of a challenge
Added security and
protection for travel
on slopes, declines,
and hills.
STEP ONE >>
Putting your walker together:
STEP TWO >>
Checking the brakes and wheels:
STEP THREE >>
Maintenance and care of your Trillium Walker:
Folding, Unfolding, and Carrying your walker:
Brake Adjusting:
Brakes:
Parking Brakes:
Assistance:
Handle Height Adjustment:
Installing Basket:
Factory Repair Information >>
For Warranty Service, Repair, or Replacement:
A few things to remember:
For Out-of-Warranty Service or Repair:
Optional Accessories for Extra Convenience >>
Curb
Climber >
Slow Down
Brake >
A B
Cup Holder >
Cane Holder >
Phone Holder >
Flower Vase >

BY / PAR EVOLUTION
3. Backrest Assembly
a. Using a Phillips screwdriver, remove screws, washers and nylock nut from back
support anchor points.
b. Insert back support on one side and align holes of back support and anchor
point (figure 1).
c. Insert screw, washer and nut and tighten securely (figure 2).
d. Repeat for second side.
4. Adjust handle height. Put Knob Bolts through from inside. Tighten until it is snug.
Caution: Do Not Overtighten.
To install the soft folding basket, fold the
Trillium, loosen the two basket clamp knobs.
Clamp the bracket on the frame and tighten
the knob.
2. Using a Philips screwdriver, rotate the adjustment screw clockwise (A) to lower the brake pad (B) for
tighter braking. Test the brakes, making sure that when applying the parking brake, the rear wheels
stay in the locked position.
3. Reinstall the Slow Down Brake if installed.
1. Upon receiving your walker, please check the contents carefully. Report any missing
items to your dealer or Evolution immediately:
2. Contents of all Evolution Trillium walkers are as follows:
a. Folded walker complete with main frame, seat, handles, and wheels already installed.
b. A soft folding basket
c. Back support
d. Warranty Registration Card
e. Owner’s Manual
f. Soft seat cushion
1. The Evolution braking system provides safety and ease of operation. Hold (squeeze) to
brake and press down on the brake handle for parking.
2. Check braking system. The wheels should stay locked while parking brake is activated.
3. Do not activate parking brake while walker is moving. This may cause permanent damage to
the wheels.
4. Always activate parking brake before using the seat.
1. Check tightness of nut and bolts regularly.
2. Check frame and tire integrity at least once a month.
To FOLD your Trillium walker, pull on the seat center handle and the walker will remain standing up.
To UNFOLD the Trillium, simply push down on the handle in the middle of the seat making sure the
walker locks in the fully open position. Caution: Ensure the center seat handle is level with the
seat before sitting.
To carry the walker while folded, simply pick it up by the center handle and lift the walker carrying it
at your side like a suitcase.
Apply the brakes by pulling both brake handles upwards. Do not walk with brakes on.
Press down on both brake handles until you hear a distinct click sound. Always make sure that both
brakes are engaged. Pull upwards to release the parking brakes. When using the seat, both brakes
MUST be in the locked position for your safety.
1. To ensure proper braking, from time to time
adjust the brake pads located on the top of the
rear wheels. To adjust the brake, remove the
Slow Down Brake if installed, by removing the
two Phillips screws on the front of the rear fork.
To adjust the handles to a suitable height, stand behind the walker with your shoulders level. The
handles should be at the same height or slightly higher than the user’s wrist. A therapist might
suggest a different handle height to accommodate a specific need for the user.
To adjust the handles, remove the knob and pull
the hex bolt out, adjust the handle to the
prescribed or desired handle height and insert
the hex bolt ensuring that the hexagonal part of
the bolt fits properly on the hexagonal cut out on
the frame of the Trillium and tighten the knob
snugly. Caution: Do Not Over Tighten.
Your nearest Evolution dealer will be pleased to assist you with the assembly and/or maintenance of
your walker.
Evolution’s motto is ‘Committed to Providing Unsurpassed Quality & Service’. Our goal is to provide
you the best service in the industry. If you encounter problems with your Evolution Walker or need
help, please:
1. Review your documentation: You will find printed documentation shipped with your Evolution
Trillium Walker. They contain maintenance guides and installation information.
2. Call or visit your Evolution dealer: They will be able to give you the assistance you need and
determine if your walker is eligible for warranty.
3. Contact Evolution Customer Service at: 1-800-556-2558 (U.S. and Canada)
If you have to return your walker to Evolution for warranty service, please call or visit your Evolution
dealer and they will be happy to assist you. If you need to locate an Evolution dealer close to you,
please contact us at 1-800-556-2558. Be prepared to provide 1) the unit model number, 2) the
serial number, and 3) a description of the problem.
If your walker is out of warranty or is not eligible for warranty, your Evolution dealer will be
happy to provide estimates to have your walker repaired.
If the problems with your walker are deemed to be the result of improper use, such as hitting curbs,
hit-opening doors, etc., it will not be covered under warranty. We reserve the right to determine if your
walker has been misused. Your Evolution dealer will be happy to assist you in arranging the return of
your walker. We will service the walker within 2 working days after receiving it and it will be on its way
back. If we cannot service your walker within 2 working days after receipt, we will send you a new
one!
Makes getting over
curbs and other
obstacles much
less of a challenge
Added security and
protection for travel
on slopes, declines,
and hills.
STEP ONE >>
Putting your walker together:
STEP TWO >>
Checking the brakes and wheels:
STEP THREE >>
Maintenance and care of your Trillium Walker:
Folding, Unfolding, and Carrying your walker:
Brake Adjusting:
Brakes:
Parking Brakes:
Assistance:
Handle Height Adjustment:
Installing Basket:
Factory Repair Information >>
For Warranty Service, Repair, or Replacement:
A few things to remember:
For Out-of-Warranty Service or Repair:
Optional Accessories for Extra Convenience >>
Curb
Climber >
Slow Down
Brake >
A B
Cup Holder >
Cane Holder >
Phone Holder >
Flower Vase >

BY / PAR EVOLUTION
3. Backrest Assembly
a. Using a Phillips screwdriver, remove screws, washers and nylock nut from back
support anchor points.
b. Insert back support on one side and align holes of back support and anchor
point (figure 1).
c. Insert screw, washer and nut and tighten securely (figure 2).
d. Repeat for second side.
4. Adjust handle height. Put Knob Bolts through from inside. Tighten until it is snug.
Caution: Do Not Overtighten.
To install the soft folding basket, fold the
Trillium, loosen the two basket clamp knobs.
Clamp the bracket on the frame and tighten
the knob.
2. Using a Philips screwdriver, rotate the adjustment screw clockwise (A) to lower the brake pad (B) for
tighter braking. Test the brakes, making sure that when applying the parking brake, the rear wheels
stay in the locked position.
3. Reinstall the Slow Down Brake if installed.
1. Upon receiving your walker, please check the contents carefully. Report any missing
items to your dealer or Evolution immediately:
2. Contents of all Evolution Trillium walkers are as follows:
a. Folded walker complete with main frame, seat, handles, and wheels already installed.
b. A soft folding basket
c. Back support
d. Warranty Registration Card
e. Owner’s Manual
f. Soft seat cushion
1. The Evolution braking system provides safety and ease of operation. Hold (squeeze) to
brake and press down on the brake handle for parking.
2. Check braking system. The wheels should stay locked while parking brake is activated.
3. Do not activate parking brake while walker is moving. This may cause permanent damage to
the wheels.
4. Always activate parking brake before using the seat.
1. Check tightness of nut and bolts regularly.
2. Check frame and tire integrity at least once a month.
To FOLD your Trillium walker, pull on the seat center handle and the walker will remain standing up.
To UNFOLD the Trillium, simply push down on the handle in the middle of the seat making sure the
walker locks in the fully open position. Caution: Ensure the center seat handle is level with the
seat before sitting.
To carry the walker while folded, simply pick it up by the center handle and lift the walker carrying it
at your side like a suitcase.
Apply the brakes by pulling both brake handles upwards. Do not walk with brakes on.
Press down on both brake handles until you hear a distinct click sound. Always make sure that both
brakes are engaged. Pull upwards to release the parking brakes. When using the seat, both brakes
MUST be in the locked position for your safety.
1. To ensure proper braking, from time to time
adjust the brake pads located on the top of the
rear wheels. To adjust the brake, remove the
Slow Down Brake if installed, by removing the
two Phillips screws on the front of the rear fork.
To adjust the handles to a suitable height, stand behind the walker with your shoulders level. The
handles should be at the same height or slightly higher than the user’s wrist. A therapist might
suggest a different handle height to accommodate a specific need for the user.
To adjust the handles, remove the knob and pull
the hex bolt out, adjust the handle to the
prescribed or desired handle height and insert
the hex bolt ensuring that the hexagonal part of
the bolt fits properly on the hexagonal cut out on
the frame of the Trillium and tighten the knob
snugly. Caution: Do Not Over Tighten.
Your nearest Evolution dealer will be pleased to assist you with the assembly and/or maintenance of
your walker.
Evolution’s motto is ‘Committed to Providing Unsurpassed Quality & Service’. Our goal is to provide
you the best service in the industry. If you encounter problems with your Evolution Walker or need
help, please:
1. Review your documentation: You will find printed documentation shipped with your Evolution
Trillium Walker. They contain maintenance guides and installation information.
2. Call or visit your Evolution dealer: They will be able to give you the assistance you need and
determine if your walker is eligible for warranty.
3. Contact Evolution Customer Service at: 1-800-556-2558 (U.S. and Canada)
If you have to return your walker to Evolution for warranty service, please call or visit your Evolution
dealer and they will be happy to assist you. If you need to locate an Evolution dealer close to you,
please contact us at 1-800-556-2558. Be prepared to provide 1) the unit model number, 2) the
serial number, and 3) a description of the problem.
If your walker is out of warranty or is not eligible for warranty, your Evolution dealer will be
happy to provide estimates to have your walker repaired.
If the problems with your walker are deemed to be the result of improper use, such as hitting curbs,
hit-opening doors, etc., it will not be covered under warranty. We reserve the right to determine if your
walker has been misused. Your Evolution dealer will be happy to assist you in arranging the return of
your walker. We will service the walker within 2 working days after receiving it and it will be on its way
back. If we cannot service your walker within 2 working days after receipt, we will send you a new
one!
Makes getting over
curbs and other
obstacles much
less of a challenge
Added security and
protection for travel
on slopes, declines,
and hills.
STEP ONE >>
Putting your walker together:
STEP TWO >>
Checking the brakes and wheels:
STEP THREE >>
Maintenance and care of your Trillium Walker:
Folding, Unfolding, and Carrying your walker:
Brake Adjusting:
Brakes:
Parking Brakes:
Assistance:
Handle Height Adjustment:
Installing Basket:
Factory Repair Information >>
For Warranty Service, Repair, or Replacement:
A few things to remember:
For Out-of-Warranty Service or Repair:
Optional Accessories for Extra Convenience >>
Curb
Climber >
Slow Down
Brake >
A B
Cup Holder >
Cane Holder >
Phone Holder >
Flower Vase >

BY / PAR EVOLUTION
3. Backrest Assembly
a. Using a Phillips screwdriver, remove screws, washers and nylock nut from back
support anchor points.
b. Insert back support on one side and align holes of back support and anchor
point (figure 1).
c. Insert screw, washer and nut and tighten securely (figure 2).
d. Repeat for second side.
4. Adjust handle height. Put Knob Bolts through from inside. Tighten until it is snug.
Caution: Do Not Overtighten.
To install the soft folding basket, fold the
Trillium, loosen the two basket clamp knobs.
Clamp the bracket on the frame and tighten
the knob.
2. Using a Philips screwdriver, rotate the adjustment screw clockwise (A) to lower the brake pad (B) for
tighter braking. Test the brakes, making sure that when applying the parking brake, the rear wheels
stay in the locked position.
3. Reinstall the Slow Down Brake if installed.
1. Upon receiving your walker, please check the contents carefully. Report any missing
items to your dealer or Evolution immediately:
2. Contents of all Evolution Trillium walkers are as follows:
a. Folded walker complete with main frame, seat, handles, and wheels already installed.
b. A soft folding basket
c. Back support
d. Warranty Registration Card
e. Owner’s Manual
f. Soft seat cushion
1. The Evolution braking system provides safety and ease of operation. Hold (squeeze) to
brake and press down on the brake handle for parking.
2. Check braking system. The wheels should stay locked while parking brake is activated.
3. Do not activate parking brake while walker is moving. This may cause permanent damage to
the wheels.
4. Always activate parking brake before using the seat.
1. Check tightness of nut and bolts regularly.
2. Check frame and tire integrity at least once a month.
To FOLD your Trillium walker, pull on the seat center handle and the walker will remain standing up.
To UNFOLD the Trillium, simply push down on the handle in the middle of the seat making sure the
walker locks in the fully open position. Caution: Ensure the center seat handle is level with the
seat before sitting.
To carry the walker while folded, simply pick it up by the center handle and lift the walker carrying it
at your side like a suitcase.
Apply the brakes by pulling both brake handles upwards. Do not walk with brakes on.
Press down on both brake handles until you hear a distinct click sound. Always make sure that both
brakes are engaged. Pull upwards to release the parking brakes. When using the seat, both brakes
MUST be in the locked position for your safety.
1. To ensure proper braking, from time to time
adjust the brake pads located on the top of the
rear wheels. To adjust the brake, remove the
Slow Down Brake if installed, by removing the
two Phillips screws on the front of the rear fork.
To adjust the handles to a suitable height, stand behind the walker with your shoulders level. The
handles should be at the same height or slightly higher than the user’s wrist. A therapist might
suggest a different handle height to accommodate a specific need for the user.
To adjust the handles, remove the knob and pull
the hex bolt out, adjust the handle to the
prescribed or desired handle height and insert
the hex bolt ensuring that the hexagonal part of
the bolt fits properly on the hexagonal cut out on
the frame of the Trillium and tighten the knob
snugly. Caution: Do Not Over Tighten.
Your nearest Evolution dealer will be pleased to assist you with the assembly and/or maintenance of
your walker.
Evolution’s motto is ‘Committed to Providing Unsurpassed Quality & Service’. Our goal is to provide
you the best service in the industry. If you encounter problems with your Evolution Walker or need
help, please:
1. Review your documentation: You will find printed documentation shipped with your Evolution
Trillium Walker. They contain maintenance guides and installation information.
2. Call or visit your Evolution dealer: They will be able to give you the assistance you need and
determine if your walker is eligible for warranty.
3. Contact Evolution Customer Service at: 1-800-556-2558 (U.S. and Canada)
If you have to return your walker to Evolution for warranty service, please call or visit your Evolution
dealer and they will be happy to assist you. If you need to locate an Evolution dealer close to you,
please contact us at 1-800-556-2558. Be prepared to provide 1) the unit model number, 2) the
serial number, and 3) a description of the problem.
If your walker is out of warranty or is not eligible for warranty, your Evolution dealer will be
happy to provide estimates to have your walker repaired.
If the problems with your walker are deemed to be the result of improper use, such as hitting curbs,
hit-opening doors, etc., it will not be covered under warranty. We reserve the right to determine if your
walker has been misused. Your Evolution dealer will be happy to assist you in arranging the return of
your walker. We will service the walker within 2 working days after receiving it and it will be on its way
back. If we cannot service your walker within 2 working days after receipt, we will send you a new
one!
Makes getting over
curbs and other
obstacles much
less of a challenge
Added security and
protection for travel
on slopes, declines,
and hills.
STEP ONE >>
Putting your walker together:
STEP TWO >>
Checking the brakes and wheels:
STEP THREE >>
Maintenance and care of your Trillium Walker:
Folding, Unfolding, and Carrying your walker:
Brake Adjusting:
Brakes:
Parking Brakes:
Assistance:
Handle Height Adjustment:
Installing Basket:
Factory Repair Information >>
For Warranty Service, Repair, or Replacement:
A few things to remember:
For Out-of-Warranty Service or Repair:
Optional Accessories for Extra Convenience >>
Curb
Climber >
Slow Down
Brake >
A B
Cup Holder >
Cane Holder >
Phone Holder >
Flower Vase >

BY / PAR EVOLUTION
3. Backrest Assembly
a. Using a Phillips screwdriver, remove screws, washers and nylock nut from back
support anchor points.
b. Insert back support on one side and align holes of back support and anchor
point (figure 1).
c. Insert screw, washer and nut and tighten securely (figure 2).
d. Repeat for second side.
4. Adjust handle height. Put Knob Bolts through from inside. Tighten until it is snug.
Caution: Do Not Overtighten.
To install the soft folding basket, fold the
Trillium, loosen the two basket clamp knobs.
Clamp the bracket on the frame and tighten
the knob.
2. Using a Philips screwdriver, rotate the adjustment screw clockwise (A) to lower the brake pad (B) for
tighter braking. Test the brakes, making sure that when applying the parking brake, the rear wheels
stay in the locked position.
3. Reinstall the Slow Down Brake if installed.
1. Upon receiving your walker, please check the contents carefully. Report any missing
items to your dealer or Evolution immediately:
2. Contents of all Evolution Trillium walkers are as follows:
a. Folded walker complete with main frame, seat, handles, and wheels already installed.
b. A soft folding basket
c. Back support
d. Warranty Registration Card
e. Owner’s Manual
f. Soft seat cushion
1. The Evolution braking system provides safety and ease of operation. Hold (squeeze) to
brake and press down on the brake handle for parking.
2. Check braking system. The wheels should stay locked while parking brake is activated.
3. Do not activate parking brake while walker is moving. This may cause permanent damage to
the wheels.
4. Always activate parking brake before using the seat.
1. Check tightness of nut and bolts regularly.
2. Check frame and tire integrity at least once a month.
To FOLD your Trillium walker, pull on the seat center handle and the walker will remain standing up.
To UNFOLD the Trillium, simply push down on the handle in the middle of the seat making sure the
walker locks in the fully open position. Caution: Ensure the center seat handle is level with the
seat before sitting.
To carry the walker while folded, simply pick it up by the center handle and lift the walker carrying it
at your side like a suitcase.
Apply the brakes by pulling both brake handles upwards. Do not walk with brakes on.
Press down on both brake handles until you hear a distinct click sound. Always make sure that both
brakes are engaged. Pull upwards to release the parking brakes. When using the seat, both brakes
MUST be in the locked position for your safety.
1. To ensure proper braking, from time to time
adjust the brake pads located on the top of the
rear wheels. To adjust the brake, remove the
Slow Down Brake if installed, by removing the
two Phillips screws on the front of the rear fork.
To adjust the handles to a suitable height, stand behind the walker with your shoulders level. The
handles should be at the same height or slightly higher than the user’s wrist. A therapist might
suggest a different handle height to accommodate a specific need for the user.
To adjust the handles, remove the knob and pull
the hex bolt out, adjust the handle to the
prescribed or desired handle height and insert
the hex bolt ensuring that the hexagonal part of
the bolt fits properly on the hexagonal cut out on
the frame of the Trillium and tighten the knob
snugly. Caution: Do Not Over Tighten.
Your nearest Evolution dealer will be pleased to assist you with the assembly and/or maintenance of
your walker.
Evolution’s motto is ‘Committed to Providing Unsurpassed Quality & Service’. Our goal is to provide
you the best service in the industry. If you encounter problems with your Evolution Walker or need
help, please:
1. Review your documentation: You will find printed documentation shipped with your Evolution
Trillium Walker. They contain maintenance guides and installation information.
2. Call or visit your Evolution dealer: They will be able to give you the assistance you need and
determine if your walker is eligible for warranty.
3. Contact Evolution Customer Service at: 1-800-556-2558 (U.S. and Canada)
If you have to return your walker to Evolution for warranty service, please call or visit your Evolution
dealer and they will be happy to assist you. If you need to locate an Evolution dealer close to you,
please contact us at 1-800-556-2558. Be prepared to provide 1) the unit model number, 2) the
serial number, and 3) a description of the problem.
If your walker is out of warranty or is not eligible for warranty, your Evolution dealer will be
happy to provide estimates to have your walker repaired.
If the problems with your walker are deemed to be the result of improper use, such as hitting curbs,
hit-opening doors, etc., it will not be covered under warranty. We reserve the right to determine if your
walker has been misused. Your Evolution dealer will be happy to assist you in arranging the return of
your walker. We will service the walker within 2 working days after receiving it and it will be on its way
back. If we cannot service your walker within 2 working days after receipt, we will send you a new
one!
Makes getting over
curbs and other
obstacles much
less of a challenge
Added security and
protection for travel
on slopes, declines,
and hills.
STEP ONE >>
Putting your walker together:
STEP TWO >>
Checking the brakes and wheels:
STEP THREE >>
Maintenance and care of your Trillium Walker:
Folding, Unfolding, and Carrying your walker:
Brake Adjusting:
Brakes:
Parking Brakes:
Assistance:
Handle Height Adjustment:
Installing Basket:
Factory Repair Information >>
For Warranty Service, Repair, or Replacement:
A few things to remember:
For Out-of-Warranty Service or Repair:
Optional Accessories for Extra Convenience >>
Curb
Climber >
Slow Down
Brake >
A B
Cup Holder >
Cane Holder >
Phone Holder >
Flower Vase >
