INSTRUCTION MANUAL (en)

Welcome
This manual is designed to be a reference tool for the installation and operation of your system;
you can find information about the DVR features and functions, as well as, a detailed explanation
of the menu trees.
Before installation and operation please read the following safeguards and warnings carefully!
Important Safeguards and Warnings
Do not place heavy objects on the DVR.
Do not let any liquids spill onto or into the DVR.
Please ensure fans and vent openings are not blocked and that the unit is placed in an area with
adequate air circulation.
Do not try to disassemble or replace components other than the installation of the hard disk
drive.
Environment
Please place and use the DVR in an area that can maintain a temperature range of 0°C to 40°C
(32°F to 104°F).
Avoid placing the DVR in direct sunlight and keep away from any heat source.
Do not install the DVR in a damp environment.
Do not use the DVR in a smoky or dusty environment.
Please ensure that the DVR is placed on a level and stable workplace.
Please install it in a well ventilated area and please keep all vents clean and clear.
Use only the AC adapter included with your DVR and within the voltage ratings noted on the
adapter.

Directory
1 Production Introduction............................................................................................................................ 1
1.1 Product overview........................................................................................................................... 1
1.2 Main functions ............................................................................................................................... 1
2 Open-package check and cable connections.......................................................................................... 2
2.1 DVR package contents.................................................................................................................. 2
2.2 Hard disk installation ..................................................................................................................... 2
2.3 Front panel..................................................................................................................................... 3
2.4 Rear panel ..................................................................................................................................... 4
2.5 Port Connection Overview............................................................................................................. 4
2.6 Audio and video input and output connections ............................................................................. 5
2.6.1 Video input connections...................................................................................................... 5
2.6.2 Video output connections and options................................................................................ 5
2.6.3 Audio signal input................................................................................................................ 5
2.6.4 Audio signal output.............................................................................................................. 5
2.8 Speed dome connections.............................................................................................................. 6
3 Basic operation........................................................................................................................................ 7
3.1 Preview.......................................................................................................................................... 7
3.2 System Login................................................................................................................................. 8
3.3 Desktop shortcut menu ................................................................................................................. 8
3.3.1 Main menu........................................................................................................................... 9
3.3.2 Record Mode.....................................................................................................................10
3.3.3 Search/Playback ............................................................................................................... 10
3.3.4 PTZ control........................................................................................................................14
3.3.5 Tour setup..........................................................................................................................20
3.5.6 Audio Adjust.......................................................................................................................21
3.3.7 Logout................................................................................................................................21
3.3.8 Window switch...................................................................................................................22
4 Main menu .............................................................................................................................................23
4.1 Main menu navigation.................................................................................................................23
4.2 Search/Playback..........................................................................................................................24
4.3 Record .........................................................................................................................................24
4.3.1 Record...............................................................................................................................24
4.3.2 Record Conf......................................................................................................................25
4.3.3 Region Cover ....................................................................................................................26
4.4 HDD Manage...............................................................................................................................27
4.5 System setup...............................................................................................................................28
4.5.1 Language ..........................................................................................................................28
4.5.2 Date/Time..........................................................................................................................29
4.5.3 Account..............................................................................................................................30
4.5.4 GUI Display.......................................................................................................................34
4.5.5 Video .................................................................................................................................35
4.6 Advanced.....................................................................................................................................36
4.6.1 Alarm Set........................................................................................................................... 36
4.6.1.1 Mail..........................................................................................................................37

4.6.1.2 Video Blind.............................................................................................................. 38
4.6.1.3 Alarm Management.................................................................................................39
4.6.2 Version...............................................................................................................................39
4.6.3 Motion Detect ....................................................................................................................40
4.6.5 Auto Maintain.....................................................................................................................42
4.6.6 PTZ Configure................................................................................................................... 45
4.6.7 Network.............................................................................................................................46
5 FAQ and maintenance........................................................................................................................... 51
5.1 FAQ..............................................................................................................................................51
5.2 Maintenance................................................................................................................................ 55
Appendix 1. Remote control operation..................................................................................................... 57
Appendix 2. Mouse operation................................................................................................................... 58
Appendix 3.Hard disk capability calculation ............................................................................................. 59
Appendix 4. Technical Specifications........................................................................................................60

- 1 -
1 Production Introduction
1.1 Product overview
This series DVR is designed especially for security purposes which makes it an outstanding digital
surveillance product. It introduces an embedded LINUX operating system which is more stable. It
introduces the standard H.264mp video compressed format and G.711A audio compressed format
which ensures the highest quality image, low error coding ratio, and single frame playing. It utilizes
TCP/IP network technology which achieves the strongest network communication and
telecommunication ability.
This DVR can be used individually or online as part of your safety surveillance network and with the
included professional network video surveillance software, it can help you to maintain a strong
communication and telecommunication network.
1.2 Main functions
Real-time surveillance
Analog interface and VGA interface (VGA interface is equipped selectively)
Surveillance function through monitor or display
Data Storage
User selected motion activated hard drive “sleep” and “wake” functions to extend storage capacity and
extend life-span.
Special storage format which insures data safety.
Compression
Real-time compression by individual hard drive which insures the audio and video signal synchronization
and stability.
Backup
Through SATA and USB interface and also through Internet download.
Playback
Individual real-time video recording, as well as, search, playback, network surveillance, recording check,
and downloading.

- 2 -
Multi-playback mode.
Internet operating
Internet surveillance in the real time
PTZ control
Recording check and real-time playback
Communication interface
RS485 interface for PTZ control
Standard Ethernet network interface with RJ45 jack
intelligent operations
USB Mouse and backup/copy/paste functions
2 Open-package check and cable connections
2.1 DVR package contents
Please verify that there is not visible damage to the DVR and then verify the following:
•4 channel H.264 DVR
•AC Power Supply
•Remote Control (requires 2 AAA batteries – not included)
•USB Optical Mouse
•(4) Screws to Mount HDD
•Installation CD
•User Manual
•Quick Guide
2.2 Hard disk installation
Install SATA hard disk drives before completing the initial software setup. （The below images are just
used to show how to install hard disk. The DVR in the photos is not the DVR in the package.）

- 3 -
1. Remove case screws 2. Remove cover. 3. Install SATA hard drive
4.Connect SATA data cables 5. Install SATA power cables 6. Replace cover
7. Replace screws
2.3 Front panel
(1) IR remote receiver (2) Power indicator light (3) Previous file/1 (4) HDD indicator light
(5) Next file /2 (6) PTZ /8 (7) Slow play /3 (8) HDD Info/9
(9) Fast play/4 (10) Backward pause/5 (11) Record /0 (12) Play Pause /6
(13) Function switch (14) Search video/7 (15) USB (16) ESC
(17)Left (18) Up (19)Down (20) Menu/Enter (21) Right

- 4 -
2.4 Rear panel
(1) Video input (2) BNC output (3) audio output (4) audio input (5) Power supply
(6) USB/Mouse* (7) Network (8) VGAoutput (9) RS485
*NOTE* if the rear USB mouse port is used then the front USB port becomes non-functional.
2.5 Port Connection Overview
Picture 2.1 Connection Diagram

- 5 -
2.6 Audio and video input and output connections
2.6.1 Video input connections
The video input ports utilize a BNC connector plug with an input signal of NTSC BNC (1.0VP-P, 75Ω).
The video lines should be firmly connected to avoid signal interference and possible oxidation at the
connection.
2.6.2 Video output connections and options
The video output is divided into NTSC BNC (1.0VP-P, 75Ω) and VGA (selective configuration).
Please note the following regarding the display used for monitoring:
1. Do not leave the display on for long periods of time.
2. Stay away from any electromagnetic interference.
2.6.3 Audio signal input
Audio port is a BNC connector.
The audio signal line should be firmly connected to avoid signal interference and possible oxidation
at the connection.
2.6.4 Audio signal output
Normally the output parameter of DVR audio signal is greater than 200mv 1KΩ (BNC) which can be
connected to low impedance earphones, speakers, or other audio output equipments through a
power amplifier. If the speakers and microphone cannot be isolated, feedback often occurs. The
following are some suggestions to help correct this issue:
1. Use a higher quality microphone.
2. Adjust the speaker volume to be under the threshold that produces the feedback.
3. Use materials that will absorb the sound and reduce reflection of the sound.
4. Adjust the layout of the speaker and microphone.
2.7.PTZ connections
1. PTZ decoder connections
1. The grounding of a PTZ decoder and DVR must be shared otherwise the common-mode voltage

- 6 -
could result in PTZ control failure - shielded twisted pair cable is recommended.
2. Avoid high voltage connections and use surge protectors.
3. When connecting use 120Ω resistance, paralleled, to ensure the signal quality.
4. The 485 AB lines of DVR cannot be connected with other 485 output equipment that is paralleled.
5. The voltage between the AB lines of the decoder must be less than 5V.
2. Front equipment grounding note
Incorrect grounding can result in damage to the unit.
3. PTZ input type unlimited
Parameter meaning
485T+/A,485T-/B 485communication interface which is connected with the
recording control equipments such as the decoder
2.8 Speed dome connections
1. Connect the 485 lines of the speed dome with the DVR 485 interface.
2. Connect the video line to the DVR video input.
3. Power on the speed dome.
