EXALite EXL-XL Profile Zoom CW 300W User manual

EXL-XL Profile Zoom CW 300W
USER MANUAL
CE RoHS
EXALITE

OVERVIEW
Thank you for using our product, this unit is designed for indoor using, it’s widely used for stage, building, disco, etc. as high
power led effects lighting, this unit can be operated as a single unit or multiple units for large applications. Direct input of
DMX512 signal to unit to allow it controlled by any DMX controller, powerful internal programs and friendly and convenient
operation interface allows customers to program freely to any different lighting project requirements for installation or
showing.
This high power par can has gotten the nice sculpt, efficient, save electricity and durable。
This product complies with the following standards:
EN61000-3-2:2006+A2:2009
EN60598-1:2008+A11:2009
Technical Parameter:
•LED POWER: 300W
•LED Color: CW (300w) COB LED
•IC Chip: Epistar
•LED Life Time: over 10,000 hours
•Color Rendering Index(CRI): Ra≥90
•Voltage :AC90-260V 50-60Hz
•Max.power consumption: 360W
•Beam angle: Zoom from 15°to 38°
•Dimmer :0~100% linearly adjustable
•Strobe: 1-25times/sec
•Refresh Rate: >400 Video Flicker Free
•Focus: Can be adjusted by hand
•Technology: High-quality optical system , Glass reflector
•Control protocol: DMX 512
•Control System: DMX, Auto run and Master/Slave
•DMX Channels: 1/3CH(single color)
•Working Temperature: -30~40℃
•Cooling System:Low noise fan(one fan)
•Thermal Sensor Monitoring: Over-temperature Protection
•IP Grade: IP20
•Net Weight: 10kgs Gross Weight: 13kgs
•Packing Size: 80x30.5x31cm

1. Product Introduction
1.1. Product Feature
2 kinds of running model
External control mode (Slave model)
DMX 512 controller control(2 kinds channel modes)
Master/salve model control (auto match the signal from controller and the Master light, no need to
set by menu)
static mode (Master model)
It can fix any color without the controller ,also work this color with strobe
Non-linear dimmer and linear dimmer
The speed of dimmer can be set under the controller control
Screen Protect
It will enter blank screen without any operate on the keyboard in 30 seconds . Press any keys then it can
quit screen protection.
Temperature Protection
It can be set to temperature protection mode
Speed of the Fan
The fan will start to work when the working temperature reach 40 degree, and the speed will be changed
according to the change of temperature.
Can be Reverse display
1.2. Multi-light working in the same time
When using controller to control multi lights to work in strobe, the controller just send the channel data . The
strobe effect will be depend on each light itself . And please take attention for the follow situation:
1. There will be many situations make the lights are not synchronization in the beginning. (For example: the
different time of opening the light , or different time of them connect to the controller) .In this case, you can
change value of the controller( for example push 20 to 0, and back to 20), then it can be synchronization.
2. Due to crystal frequency of different lights are not the same exactly, so it may not be synchronization
after long time.
3. If need to keep synchronization for long time, there are two ways to do so:
A. Using the controller to edit program make the strobe, auto run effect,then they must be synchronization.
B. Using the Maser/Slave model

2. Operation
2.1. Key operation
Menu：
The first list is the main menu (press MENU to
exchange), the second list is submenu (press ENTER to
get in or exchange)
If the menu include the decimal point, that’s the data,
and it can be set by the Key of Up/Down.
Key operation：
Key of “MENU” (Press it and can save the data)
If it’s the main menu, it will exchange to next main
menu.
If it’s the submenu , it will back to main menu.
Key of “ENTER” (Press it and can save the data)
If it’s the main menu and it have submenu, it will
enter the submenu.
If it’s the submenu, it will exchange to the next
submenu
Key of “UP/DOWN”
It’s no function if the menu not include the decimal
point.
If the menu include the decimal point, it can set the
data after the decimal point. And it need to press
“ENTER” to save the data.

2.2. Menu Data
Menu
State
Operation
Remark
Main Menu
Vice Menu
No vice menu
A: advance
UP/DOWN
adjust ID adress
disconnect the
controller and
connect the master
light, then it will
follow the master
light.
It will flicker if no
signal.
External control mode
(standard channel
model)
ENTER
save the ID
address
No vice menu
d: dmx
UP/DOWN
adjust ID
address
External control mode
(Basic channel model)
ENTER
Save the ID
address
two vice menu
StAt: static
ENTER
enter vice menu
Static model
C: Color
UP/DOWN
change value of
color
Set the color
ENTER
save the data
change to the
vice menu
St: strobe
UP/DOWN
change value of
strobe
strobe and its speed
ENTER
save and
exchange
two vice menu
tEMp: temperature
ENTER
enter the vice
menu
temperature control
current temperature
ENTER
change to vice
menu
t: top
UP/DOWN
change the data
of temperature
protect
set the protect
temperature
ENTER
save and change
No vice menu
diSP: display
ENTER
reverse the
display
set to show reverse
display
No vice menu
rESt: reset
ENTER
enter the
interface of key
the password is “UP
DONW UP DOWN”
return Initial State

2.3. Channel data
2.3.1. Standard channel model
channel
data
function
Mark
1
0~255
dimmer
2
0~10
default delay of dimmer
11~15
no dimmer
16~255
Choose delay of dimmer
16 is the shortest delay time, increase
gradually.... 255 is the longest delay time
3
0~10
no strobe
11~255
speed of strobe (255 is fastest)
2.3.2. Basic channel model
channel
data
function
1
0~255
dimmer

3.Photographic Chart
3.1 Spectrogram
3.2 CRI

3.3 Lumen

SAFETY WARNING
1. Warning
﹡Every person involved with the installation , operation and maintenance of this device has to be qualified .
﹡User must follow the instructions of this manual
﹡Unqualified person can not open the housing cover and operate the device , or the dealer will not accept liability for any
resulting defects or problems.
﹡The device against rain and moisture
2. Waring notes :
﹡Power supply : AC 100V-240V , 50/60Hz
﹡Make sure the power switch is off , the power plug , outlet and the earth connection is in well condition before
connecting the device with the mains.
﹡Please use qualified power plug and the outlet. Never connect the power cord of this device with other electrical
equipment.
﹡During move and installation , make sure the device not crashed with metal parts and other tough materials.
﹡Always disconnect from the mains, when the device is on the installation and dismantled
﹡The minimum distance between light-output and the illuminated surface must be more than 50cm
﹡The device must only be installed on a non-flammable surface . In order to safeguard sufficient ventilation , leave 50cm
of free space around the device . Please note that heat-sensitive objects may be deformed or damaged by the emitted
heat .
﹡During the operation the housing becomes very hot ! Do not operate the device for 15 minutes after switching off .
﹡The maximum ambient temperature Ta = 45℃must never be exceeded , The maximum housing temperature Tb =
80℃must never be exceeded .
﹡For indoor use
﹡Replace any visible cracked protective shield , filters and lens .
﹡The protective shiel, filters and lens will require weekly cleaning as smoke “Cfluid tends to building up residues ,
reducing the light “Coutput very quickly.

APPENDIX
Problem and solution
Caution :
﹡Unqualified person involved with installation , operation and maintenance of this device is prohibited .
﹡If any above mentioned problem happened , or unknown problem happened , please contact manufactory or distributor
or distributor for assistance

DISCLAIMER
1. The device is with one year warranty . The warranty period appear non-artificial quality problem, this company is
responsible for free maintenance
2. User violate operation caused the machine failure, this is user responsibility.
3. If due to the wrong operation or intense impact caused product destroy even safety accidents, the manufacturer does
not undertake any responsibility
4. Prohibit replaced product components by any person, therefore caused any consequences will be whose responsible
Please contact us freely when you need our related products or informations...
