Excel Connect D40 User manual
D40
Quick Installation
User Guide
Screen icon
Packaging list
Keys features
Handset
Handset Cord
Stand Power Adapter
(Optional)
Ethernet Cord Quick Installation Guide
Installation the device
Bracket desktop installation
Configuration
Configuration via Phone
1. Press Menu > Advanced (Default password 123)
2. Select Network: To configure the Network Settings (IPv4/
IPv6/IPv4&IPv6, DHCP/Static/PPPoE)
3. Select Accounts: To configure enable the account, fill the
SIP server address, port, user name, password etc.
Configuration via Web
1. Get the IP address from the phone: Press key or
key, or Menu > Status > IP.
2. 2. Login: Input the IP address in the web browser. The PC
and phone should be in the same IP address segment(The
default username and password are both ‘admin’.)
3. Configure: Select network/Account etc, and fill the
relevant content.
- 2 - - 3 -
Language setting
1. Press Menu key > Basic > Language.
2. Select the desired language and press OK soft key.
Soft keys
Message waiting indicator
Left and right navigation keys
Up navigation key, Shortcut to
call log
Down navigation key, Shortcut
to Status
OK key, Shortcut to Menu
Hold key, Hold/Resume the call
Call transfer key
Conference key
Connecting to the Device
Please connect power adapter, network, PC, handset, and headset
to the corresponding ports as described in below picture.
Accepting a call
Putting a call on hold
3-party conference
Call transfer
Attended transfer:
Blind transfer:
1. Press key or Xfer soft key during the active
conversation, the call is put on hold.
2. Dial the second telephone number.
3. When the call is answered, then press key or Xfer soft
key to complete the operation.
1. Press key or Xfer soft key during the active
conversation, the call will be on hold.
2. Then enter the 2nd telephone number and press
key or Xfer soft key.
1. Once in line with 1st caller, press key or Conference
soft key, 1st caller is put on hold.
2. Then call the 2nd number.
3. After, 2nd call is established, press key or Conference
soft key to set up the conference.
1. With the handset: pick up the handset.
2. With a headset: press .
3. With the handsfree: press .
1. Press key or Hold soft key, caller is put on hold.
2. To retrieve the call press key or Resume soft key.
Note: with more than one active call, select desired call with
the navigator keys and use the corresponding soft key to
hold or resume.
Making a call
1. Pre-dialing: enter the phone number and pick up the
handset.
2. Direct dialing: lift the handset and enter the phone
number.
3. Handsfree: enter phone number and press or vice
versa.
4. Headset: enter phone number and press or vice
versa.
5. Designated line: press line key, enter phone number
and press dial key.
Call forward
1. Press Menu > Features > Call Forward.
2. Select the line, the type of forward, enter the destination
number and status and press OK.
In headset mode
In hands-free mode
In handset mode
Missed call(s)
Mute activated
Auto-answering activated
Call is on hold
Call Forward activated
Internet is connected
Do not disturb activated
Do not disturb disabled
Dialed call
Received call
Ringer off Internet is disconnected
Keypad locked
New VM Messages
New SMS
Phonebook key
Call Logs key
In idle mode: ringer off
In communication mode:
mute/un-mute a call
In idle mode or during ringing:
increase or decrease ringer volume
In communication: increase or
decrease earpiece, headset or
hands-free volume
1~9, DSS keys, It can be set as
line key/function key/speed dial
key, etc.10, Page-Jump key, It can
switch DSS pages.
Headset key, Activate/deactivate
Headset
Hands-free key, Activate/deactivate hands free
Long press to lock keypad.
Enter PIN to unlock keypad (default 123)
Redial key, Access to redial the last record
Voice message key, Access to voicemail
IP Phone
Status key
DC 12 V Internet PC
USB
Redial
Do not disturb
- 4 -
1.1. Pre key > Move tss key > Move to t1. Press
Menu > Features > DND.
2. Select the Mode, and press OK soft key.
1.1. Pre1. Press , redial a call
Phonebook
Access phonebook:
Add new entry:
1. Press Contact soft key, Press All Contacts or other
group > Press Add.
2. Enter name and number and press OK soft key.
1. Press or Contact soft key or Menu > PhoneBook > Local
Contacts.
2. Select All Contacts or other group.
3. To dial an entry, press Dial soft key or pickup handset or
press or .
Call list
1.1. Pre1. Press1. Press key or key or Menu > Cal
2.2. Scroll through the list usi
3. To dial an entry, press Dial soft key or pickup handset or
press or .
Call Mute
1. Press to Mute the microphone during the call.
2. Press again to un-mute the conversation.
Programmable keys
DSS keys :
Other keys :
1. You can also configure shortcuts for the navigation keys,
and which will be available in idle mode.
2. Press Menu > Basic > Keyboard, select among the
configurable items, and select your desired type and value,
press OK key.
1. You can use the phone web interface to configure the
keys at both sides of the display.
2. You can press any keys which is still blank or long press
the key that have configured, select a type and value,
press OK key.
3. Press Menu > Basic > Keyboard > DSS Key settings.
Select the key, type and value, press OK key.
Voice mail
1. To access your voice mailbox, press or Menu >
Message > Voice Message, number of messages will be
indicated if provided by your server or pbx.
2. Select the line and press Play to call.
- 5 -
