Exerpeutic 4200 User manual

Item #4200
TRAINING CYCLE
IMPORTANT: Read all instructions carefully before using this product.
Retain this owner’s manual for future reference.
The specifications of this product may vary from this photo, subject to
change without notice.
V1.0-061114
OWNER’S MANUAL

SERVICE ------------------------------------------------------------------------ 2
LABEL PLACEMENT --------------------------------------------------------- 3
PRODUCT SAFETY ---------------------------------------------------------- 4
OVERVIEW DRAWING ------------------------------------------------------ 5
PARTS LIST ---------------------------------------------------------------------6
HARDWARE PACKING LIST & TOOLS --------------------------------- 7
ASSEMBLY --------------------------------------------------------------------- 8
ADJUSTMENTS ----------------------------------------------------------------13
COMPUTER ---------------------------------------------------------------- 16
TROUBLE SHOOTING & MAINTENANCE ----------------------------- 20
WARM UP ----------------------------------------------------------------------- 21
WARRANTY -------------------------------------------------------------------- 22
FAX FORM ---------------------------------------------------------------------- 23
TABLE OF CONTENTS
1

IMPORTANT: FOR NORTH AMERICA ONLY
To request product service and order
replacement parts, please call our
customer service department at:
1-844-641-7921
Monday through Friday, 8:00 AM-5:00 PM Pacific Standard Time,
or email us at: [e-mail]
Please visit our website at www.paradigmhw.com.
Please have the following information ready when requesting for service:
Your name
Phone number
Model number
Serial number
Part number
Proof of Purchase
*Before returning this product to the store please contact
customer service at the contact number.
Paradigm Health & Wellness, Inc.
1189 Jellick Ave.
City of Industry, CA 91748, USA
SERVICE
2

LABEL PLACEMENT
3

Basic precautions should always be followed, including the following
safety instructions when using this equipment. Read all instructions
before using this equipment.
1. Read all the instructions in this manual and do warm up exercises before using
this equipment.
2. Before exercise, in order to avoid injuring your muscles, warm-up exercise
for every muscle group is highly recommended. Please refer to the Warm
Up pages for pre and post workout.
3. Please make sure all components are not damaged and in working order before
use. This equipment should be placed on a flat surface while in use. Using a
mat or other material on the ground is recommended.
4. Please wear proper clothes and shoes when using this equipment; do not wear
clothes that get caught in any part of the equipment.
5. Do not attempt any maintenance or adjustments other than those described in
this manual. Should any problems arise, discontinue use and consult an
Authorized Service Representative.
6. Keep Dry - do not operate in wet or moist condition.
7. Always hold on to the handlebar while using the training bike.
8. To dismount, reduce pedaling speed gradually before you stop.
9. Do not use the equipment outdoors.
10.This equipment is for household use only.
11.Only one person should be on the equipment while in use.
12. Keep children and pets away from the product while in use. This machine
is designed for adults only. This product requires a minimum of 6 feet of
space for safe operation.
13. If you feel any chest pains, nausea, dizziness, or short of breath, you should
stop exercising immediately and consult your physician before continuing.
14. The maximum weight capacity for this product is 275 lbs/125 kgs.
WARNING:Before beginning any exercise program consult your
physician. This is especially important for the people who are over 35 years
old or who have pre-existing health problems. Read all instructions before
using any fitness equipment.
CAUTION:Read all instructions carefully before operating this
product. Retain this Owner’s Manual for future reference.
PRODUCT SAFETY
4

5
OVERVIEW DRAWING

No.
Description
Qty
No.
Description
Qty
001
Seat
1
021
Water Bottle Holder
1
002
Seat Bracket
1
022
Handlebar Post
1
003
Seat Post
1
023
Handlebar
1
004
Round Knob M10*22*Φ19*35
1
024
Hexagon Socket Pan Head Cap
Screw M10*25*S6
2
005
Oval Bushing
PT80*40*PT70*30*L175
2
025
Flat Washer d10*φ20*1.5
2
006L/R
Left/Right Foot Pedal 9/16”
2
026
Hexagon Cylinder Cap Bolt
M5*10*S4
1
007L/R
Left/Right Crank 9/16”
2
027
Flat Oval Tube Plugs PT70*30*7.5
1
008
Round Knob M16*1.5*27*Φ56
2
028
Hexagon Socket Pan Head Cap
Screw M6*12*S5
2
009
Hexagon Socket Pan Head Cap
Bolt M8*65*20*S6
4
029
Multi Hex Tool with Phillips
Screwdriver S13-14-15
1
010
Flat Washer d8*Ø16*1.5
4
030
Allen Wrench S6
1
011
Square Stabilizer End Cap
J100*50*25
4
031
Cross Recessed Countersunk
Head Tapping Screws ST4*19*Φ7
2
012
Rear Stabilizer
1
032
Washer d6*Φ12*1
2
013
Bolt t4*49.5*20
4
033
Handshake Tablets
2
014
Bottom Pad Φ65*Φ7.5*12
4
034
Handshake Line Length950
Round Plug
1
015
Front Stabilizer
1
035
Sensor Wire Line Length400
Square Plug
1
016
Hexagon Pan Head Screws
Φ7.8*30*M6*15*S5
2
036
Sensor Trunk
1
017
Bearing 608ZZ
4
037
Computer
1
018
Transport Wheel Φ71*Φ19*24
2
038
Pan Head Screw With Cross
Recess M5*10
4
019
Pan Head Screw With Cross
Recess M5*16*Φ10
2
039
Main Frame
1
020
Flat Washer d5*Φ10*1
2
6
PARTS LIST

HARDWARE PACKING LIST & TOOLS
Allen Wrench S6
1 PC
Multi Hex Tool with Phillips
Screwdriver
1 PC
(9) Hexagon Socket Pan Head Cap Bolt
4PCS
7
(19) Cross Recessed Pan Head Screw
2PCS
(25) Flat Washer
2PCS
(10) Flat Washer
4PCS
(20)Flat Washer
2PCS
(24)
Hexagon Socket Pan Head Cap Screw
2 PCS

1. Front and Rear Stabilizers Installation
Position the Front Stabilizer (15) in front of the Main Frame (39) and align bolt holes.
Attach the Front Stabilizer (15) onto the front curve of the Main Frame (39) with two
Hexagon Socket Pan Head Cap Bolt (9), two Flat Washer (10). Tighten Hexagon Socket
Pan Head Cap Bolt(9)with the Allen Wrench(30) S6 Provided.
Position the Rear Stabilizer (12) behind the Main Frame (39) and align bolt holes.
Attach the Rear Stabilizer (12) onto the rear curve of the Main Frame (39) with two
Hexagon Socket Pan Head Cap Bolt (9) and two Washers (10). Tighten Hexagon
Socket Pan Head Cap Bolt(9)with the Allen Wrench(30) S6 Provided.
Hardware:
ASSEMBLY
8
(10) Washer
4PCS
(9)Hexagon Socket Pan Head Cap Bolt
4PCS
(30) Allen Wrench
S6

9
1.Water Bottle Holder Installation
Attach the Water Bottle Holder(21) onto Main Frame(39) with two Washers(20) and two
Cross Recessed Pan Head Screw(19).Tighten bolts with the Multi Hex Tool with Phillips
Screwdriver provided.
2.Foot Pedals Installation
The Cranks and Foot Pedals are marked “R” for Right and “L” for Left.
Insert the pedal shaft of Left Foot Pedal(6L) into threaded hole in the Left Crank (7L).
Turn the pedal shaft by hand in the counter-clockwise direction until snug.
Note: DO NOT turn the pedal shaft in the clockwise direction, doing so will strip
the threads.
Tighten the pedal shaft of Left Foot Pedal (6L) with the Multi Hex Tool with Phillips
Screwdriver provided.
Insert pedal shaft of Right Foot Pedal (6R) into threaded hole in Right Crank (7R).
Turn the pedal shaft by hand in the clockwise direction until snug. Tighten pedal shaft
of Right Foot Pedal (6R) with the Multi Hex Tool with Phillips Screwdriver provided.
Hardware:
Important:
Please make sure the right foot pedal
matches up with the right crank and the
left foot pedal matches up with the left
crank. If reversed the cranks may become
damaged or stripped.
Important:
Screw Right Foot Pedal (6R) into
right crank clockwise!
Screw Left Foot Pedal (6L) into Left
crank counter-clockwise!
ASSEMBLY
Multi Hex Tool with Phillips Screwdriver
Tool:
(20)Washer
2 PCS
(19)Cross recessed Pan Head Screw
2 PCS

1. Seat Post, Seat, Seat Sliding Tube, and Handlebar Post Installation
Seat Post Installation
Turn the Round Knob (8) on the Main Frame (39) in a counterclockwise direction until it
can be pulled out. Pull out the Round Knob (8) and then insert the Seat Post (3) into
the tube of the Main Frame (39). Slide the Seat Post (3) up or down direction to the
suitable position. Lock the Seat Post (3) in place by releasing the Round Knob (8)
and sliding the Seat Post (3) up or down slightly until the Round Knob (8)”pops” down
into the locked position. For added safety, tighten the Round Knob (8) in a clockwise
direction.
NOTE: When adjusting the height of seat post, the MAX line cannot be higher than
the edge of plastic bushing.
2. Seat Installation
Turn the Round Knob (4) on the Seat Post (3) in a counterclockwise direction until it can
be pulled out. Pull out the Round Knob(4) and then put the Seat Bracket (2) onto the
Seat Post (3). Slide the Seat Bracket (2) in place by releasing the Round Knob(4) and
sliding the Seat Bracket (2) back and for the slightly until the Round Knob (4) “pop” down
in the locked position. For added safety, tighten the Round Knob (4) in a clockwise
direction. Put the Seat(1) onto the Seat Bracket (2). Then tighten the Seat (1) with Multi
Hex Tool with Phillips Screwdriver onto the Seat Bracket (2).
ASSEMBLY
10
Tool:
Multi Hex Tool with Phillips Screwdriver

1.Handlebar Post Installation
Turn the Round Knob (8) on the Main Frame (39) in a counterclockwise direction until it
can be pulled out. Pull out the Round Knob (8) and then insert the Handlebar Post
(22) into the tube of the Main Frame (39). Slide the Handlebar Post (22) up or down
direction to the suitable position. Lock the Handlebar Post (22) in place by releasing
the Round Knob (29) and sliding the Handlebar Post (22) up or down slightly until the
Round Knob (8) "pops" down into the locked position. For added safety, tighten the
Round Knob (8) in a clockwise direction.
NOTE: When adjusting the height of seat post, the MAX line cannot be higher than
the edge of plastic bushing.
2. Handlebar Installation
Attach the Handlebar (23) onto the Handlebar Post (22) . Through Two Hexagon
Socket Pan Head Cap Bolts (24), Two and Washers (25) . Tighten bolts (24) with the
S6 Allen Wrench and Multi Hex Tool with Phillips Screwdriver. .
3.Computer Installation.
Use 6mm Allen Wrench to install the Computer (37) into the computer plate on the
handle bar and tighten with Phillips pan head cap screw (38).
4. Insert the Sensor Trunk (36) through into the bottom end of Handlebar Post (22) and
pull it out from the top end of Handlebar Post (22) connect the Sensor Wire (35).
Connect computer wire (37a) with the sensor wire (35) and handlebar wire (34) into the
Computer(37)
11
ASSEMBLY
Allen Wrench S6
Tool:
Multi Hex Tool with Phillips Screwdriver
S13, S14, S15

Hardware:
12
ASSEMBLY
(24) Hexagon Socket Pan Head Cap
Screw
2PCS
(25)Washer
2PCS
(38) Phillips Pan Head Cap Screw
4PCS

ADJUSTMENTS
Adjusting the Brake Knob
To increase the tension, turn the Brake Knob in a clockwise direction.
To decrease the tension, turn the Brake Knob in a counterclockwise direction.
Rear Stabilizer End Cap
Adjusting the Adjustable Leveler
Turn the Adjustable Leveler on the front and rear stabilizers as needed to level the bike.
→
Brake Knob
13

ADJUSTMENTS
Adjusting the Handlebar Height
Loosen the Round Knob by turning counterclockwise direction until it can be
pulled out. Pull out the Round Knob and then slide the Handlebar Post up or
down direction to the suitable position. Lock the Handlebar Post in place by
releasing the Round Knob and sliding the Handlebar Post up or down slightly
until the Round Knob "pops" down into the locked position. For added safety,
tighten the Round Knob in a clockwise direction.
NOTE: When adjusting the height of handlebar post, the MAX line cannot
higher than the edge of plastic bushing.
Adjusting the Seat Height
Loosen the Round Knob by turning counterclockwise direction until it can be pulled out.
Pull out the Round Knob and then slide the Seat Post up or down direction to the suitable
position. Lock the Seat Post in place by releasing the Round Knob and sliding the Seat
Post up or down slightly until the Round Knob "pops" down into the locked position. For
added safety, tighten the Round Knob in a clockwise direction.
NOTE: When adjusting the height of seat post, the MAX line cannot higher than
the edge of plastic bushing.
14
Round Knob
Round Knob

15
ADJUSTMENTS
Adjusting the Seat Forward or Back
Loosen the Round Knob by turning it in a counterclockwise direction. Slide the Seat
Sliding Tube in a forward direction to the suitable position. Lock the Seat Sliding Tube
in place by turning it in a clockwise direction.
Round Knob

FUNCTIONS：
SCAN: Displays all function TIME→DISTANCE→CALORIES→PULSE→
RPM/SPEED in sequence.
RPM: Displays the pedaling Rotation Per Minute. The RPM and SPEED will
switch to another display in every 6 seconds after exercise starts.
SPEED: Displays the user’s exercise speed.
TIME: 1.You can press “SET” button to set target time between 0:00 to 99:00 for
count down function.
2. It can be set up by the user or accumulated automatically for count up
function.
DISTANCE: 1.Your can press “SET” button to set target distance between 0:00 to
99:50 for count down function.
2. It can be set up by the user or accumulated automatically for count up
function.
CALORIES: 1.You can press “SET” button to set target calories between 0 to 9990 for
count down function.
2. It can be set up by the user or accumulated automatically for count up
function
PULSE: Displays the user’s pulse. User may set the target pulse. When pulse
value reaches to the target, the computer will alarm with “Beep” sound.
MODE
To confirm all settings.
SET
To set up the value of TIME, DISTANCE, CALORIES and PULSE.
You can hold the button to increase the value fast. (The computer
has to be in stop condition.)
RESET
To clear the set-up value. Press RESET key and hold for 2 seconds
to reset all
function figures.
RECOVERY
To test heart rate recovery status
COMPUTER
16

OPERATION PROCEDURE:
1. Installs 2 pcs of 1.5V “AAA”batteries, then the screen will display as following
“Drawing A” and have “Beep” sound at the same time.
After that, it goes to the next step to the main menu as “Drawing B”.
2. Get access to the set-up mode of TIME/DISTANCE/CALORIES/PULSE. When
you are in each set- up mode, for example in the time set-up mode, time value is
blinking, you can press “SET” button to adjust the value and press “MODE” for
confirmation. The set-up of DISTANCE, CALORIES & PULSE is the same as
TIME.
3. With any signal been transmitted into the monitor, the value of TIME, DISTANCE,
CALORIES start to count up as Drawing C. When there is any function has been
preset the target (TIME or DISTANCE or CALORIES), the function will be counting
down from the preset to zero while the training starts. Once the target is achieved to
zero, the monitor start to beep for 8 seconds, and the function will be counting up
from zero directly if the training is going. Press “MODE” button for confirmation and
skip to next set-up.
4. In SCAN mode shown as “Drawing C”. RPM/SPEED/TM/DIST/CAL/PULSE will
skip to display in every 6 seconds. The order is as follows.
COMPUTER
17

5. You can also press “MODE” button to select single function display except RPM &
SPEED function. The RPM & SPEED function will switch display.
6. RECOVERY：
(1)When the user presses “RECOVERY” button, the RECOVERY function is active.
At this time only PULSE and TIME is working, other functions will not be displayed,
and the Sensor Input is not available. TIME starts to count down from ”0：60”, Pulse
signal will be blinking according user’s heart rate BPM. When Time counts down to
“0”, it will show F1~F6.
(F1 is the best, F6 is the worst)
F1
OUTSTANDING
F2
EXCELLENT
F3
GOOD
F4
FAIR
F5
BELOW AVERAGE
F6
POOR
(2)LCD display as follows: (RECOVERY start condition & end condition)。
COMPUTER
18

(3)If the count down action to 0:00 is not completed and there is no pulse signal, the
count down action has to be done and shown F6.
(4)If you press the RECOVERY button prior to count down to 0:00, it will be end and
return to the main menu.
Note:
1. Stop training for 4 minutes, the computer will enter to Sleep mode.
You may press any button to have the computer restart working, the original value will
retain.
(If re-install batteries, the original value will remove.)
2. If the computer displays abnormally, please re-install batteries and try again.
3. Battery Spec: 1.5V “AAA”(2PCS).
COMPUTER
19
