Extang Classic Platinum Assembly instructions

PARTS INCLUDED IN YOUR KIT. You may want to lay them out in this manner for accessibility.
MISSING PARTS???
call Extang at 1-800-877-2588
Any and all needed parts will be shipped to you
directly. (DO NOT return whole kit to store)
Register your warranty at:
www.extang.com
Item No. 0143-0708 RH Printed in U.S.A.
INSTALLATION SHEET
3
Remove paper tape from all rails. Discard properly.
Foam has NO adhesive to
touch truck finish.
Wash truck bed.
PLEASE
DO NOT
LITTER
Depress the ClickLockTM
release and remove one corner
from cab rail.
Feed tarp dowel into cab rail.
(NOTE: For easiest feeding action, place tarp on a flat
smooth surface, and keep dowel straight while feeding
into cab rail. Caution, pavement may scuff tarp.)
Reinsert corner piece into cab
rail until it “clicks” and locks
into place.
ClickLockTM
12
NOTE:
B
LACK M AX has snaps on all rails.
4
Allen Wrench
Clamp Bolts
Tarp
Corner Pieces
For Classic Platinum Only (This step does not apply to BlackMax)
Cab Rail
(BlackMax includes snaps on this rail)
Side Rails
Spring Bows
Extang Corporation
1901 E. Ellsworth Rd.
Ann Arbor, MI 48108
734 677-0444, Fax: [phone]
“DOUBLE HOOK”
Side Rail Clamps
(2 sizes)
Off the truck bed, connect
the end rails to the two
side rails utilizing the
ClickLock™ clips.
Ford Flareside ‘04 –
Extra Cab Seal
Flareside Clamps
Tailgate Rail

Extang Corporation, 1901 E. Ellsworth Rd., Ann Arbor, MI 48108, 734 677-0444, Fax: [phone], Visit us at: www.extang.com
8
6
5
Insert bow onto top or bottom peg.
(Top peg for performance, Bottom for good looks.)
Ends are spring loaded
for easy installation.
Push and hold on
spring end and let the
other end slide on with
the spring action.
SPECIAL
FEATURE:
Two pegs
offer two
height
adjustments.
Note:
Bow End does not
fit between pegs.
Attach tarp by starting
at the corners, and
snap in place.
EASY USE OF TRUCK BED
Tarp may be rolled up and secured with
Velcro® for bulk hauling For each clamp mark on your bedliner a 1-1/2” x 3”
hole as shown above. Remove clamp. Cut holes in
bedliner. Reinsert side rail clamp. Return to step 6.
Side rail clamped to bed with bow
attached.
Studs Down Slides Off Rotate 180∞Studs Up
SUMMER SETTING
Takes up slack in tarp
caused by warm weather.
WINTER SETTING
Allows more slack in tarp
for cold temperatures.
7Upper
Peg
Lower
Peg
Do Not
Place
Between
the Pegs
For an OVER-THE-RAIL Bedliner
A
DIAGRAM B DIAGRAM
Start at
Corners
9SPECIAL FEATURE
Weather-adjustable Snaps
Clamp Spacing (Same for each side) See the stickers located on each side
rail for clamp position, or refer to the dimensions given below. Note: Use clamp
intended for each position.—Remove stickers after installation.
Place the rail assembly over the side of the truck
box. Center rails evenly between cab and tailgate.
(NOTE: Some applications have hard rubber risers (square rubber
pad.) A riser must go toward tailgate. Some applications will have
a riser at both ends, (most have no riser).
Insert flareside clamp over flange on truck
sidewall. Make sure clamp rests on side
wall ridge. Insert hook clamp over end
and secure with clamp bolt.
12
inches
Center middle clamp
12
inches
Sm.
Clamp Med. Clamp Med. Clamp
Note: For over-the-rail bed liners first
refer to Diagrams A and B below.
If a gap is present between the cab rail and truck bed, apply extra
cab rail foam seal to the bottom of the existing cab rail seal.
Insert side rail clamp
all the way into rail.
Place Clamp
Here
STICKER
