Extraflame GABRIELLA PLUS User manual

MADE IN ITALY
design & production
GABRIELLA PLUS
004280494 - Rev 000
UK PELLEt StovES USER MANUAL

2ENGLISH
APPLY TECHNICAL
DATA LABEL

3ENGLISH
ENGLISH............................................................................................................................................................................................................ 5
WarNINGS........................................................................................................................................................................................................ 5
SafEty.............................................................................................................................................................................................................. 5
routINE MaINtENaNcE................................................................................................................................................................................ 7
rEGuLatIoN (Eu) 2015/1185 ......................................................................................................................................................................... 8
INStaLLatIoN.................................................................................................................................................................................................. 9
uPPEr fuMES outLEt aSSEMBLy .............................................................................................................................................................. 11
HErMEtIcaLLy SEaLEd INStaLLatIoN ..................................................................................................................................................... 12
combustion air ....................................................................................................................................................................................................................................12
FumEs EXHaust sYstEm.....................................................................................................................................................................................................................12
GaBrIELLa PLuS dEtaILS ............................................................................................................................................................................ 13
spacErs ......................................................................................................................................................................................................................................................14
Hot aIr ductING.......................................................................................................................................................................................... 14
aDDitionaL tHErmostat to controL tHE Duct motor...............................................................................................................................................14
StoVE PoSItIoNING ..................................................................................................................................................................................... 15
NotES for corrEct oPEratIoN .............................................................................................................................................................. 15
FusE...............................................................................................................................................................................................................................................................15
PELLEtS aNd fEEdING ................................................................................................................................................................................. 16
PELLEt HoPPEr ............................................................................................................................................................................................. 16
rEMotE coNtroL......................................................................................................................................................................................... 17
rEmotE controL icons....................................................................................................................................................................................................................18
insErting tHE battEriEs...................................................................................................................................................................................................................18
aDVicE anD prEcautions For tHE usE oF tHE rEmotE controL ............................................................................................................................18
coNtroL Board........................................................................................................................................................................................... 19
icon kEY......................................................................................................................................................................................................................................................19
gEnEraL mEnu........................................................................................................................................................................................................................................20
gEnEraL Warnings..............................................................................................................................................................................................................................20
fIrSt IGNItIoN SEttINGS............................................................................................................................................................................ 21
DatE-timE...................................................................................................................................................................................................................................................21
LanguagE..................................................................................................................................................................................................................................................21
DEgrEEs ......................................................................................................................................................................................................................................................21
oPEratIoN aNd LoGIc................................................................................................................................................................................ 22
froNt aIr ...................................................................................................................................................................................................... 23
aIr ductING.................................................................................................................................................................................................. 23
EaSy SEtuP ................................................................................................................................................................................................... 23
cHroNo.......................................................................................................................................................................................................... 24
EnabLing/DisabLing tHE cHrono ..............................................................................................................................................................................................24
SEttINGS ........................................................................................................................................................................................................ 26
DispLaY........................................................................................................................................................................................................................................................26
stanD bY.....................................................................................................................................................................................................................................................26
opEration WitH aDDitionaL tHErmostat (optionaL) .................................................................................................................................................26
aDDitionaL tHErmostat..................................................................................................................................................................................................................27
aDDitionaL tHErmostat instaLLation...................................................................................................................................................................................27
DELta-t ........................................................................................................................................................................................................................................................27
First LoaD.................................................................................................................................................................................................................................................27
rEsEt.............................................................................................................................................................................................................................................................27
EasY controL.........................................................................................................................................................................................................................................28
addItIoNaL fuNctIoNS............................................................................................................................................................................. 28
DELaY sWitcH-oFF.................................................................................................................................................................................................................................28
kEYs LockED ............................................................................................................................................................................................................................................28
cLEaNING aNd MaINtENaNcE................................................................................................................................................................... 29
MaINtENaNcE............................................................................................................................................................................................... 29
pErioDic cLEaning unDEr usEr’s rEsponsibiLitY.............................................................................................................................................................29
rEmoVabLE HanDLE.............................................................................................................................................................................................................................29
routINE MaINtENaNcE PErforMEd By QuaLIfIEd tEcHNIcIaNS .................................................................................................... 32
sHut-DoWn (EnD oF sEason)........................................................................................................................................................................................................32
dISPLayS ........................................................................................................................................................................................................ 36
aLarMS .......................................................................................................................................................................................................... 36
dISPoSaL........................................................................................................................................................................................................ 37
attENtIoN
SurfacES caN BEcoME VEry Hot!
aLWayS uSE ProtEctIVE GLoVES!
During combustion, thermal energy is released that signicantly increases the heat of surfaces, doors, handles, controls, glass, exhaust
pipes, and even the front of the appliance. Avoid contact with those elements if not wearing protective clothing (protective gloves
included). Make sure children are aware of the danger and keep them away from the stove during operation.

Nelle prime ore di fuNzioNameNto possoNo essere geNerati dei fumi ed odori dovuti al Normale processo di
“rodaggio termico”.
duraNte questo processo, di durata variabile a secoNda del prodotto, si raccomaNda di rimuovere eveNtuali
parti iN maiolica ,pietra Naturale o metallo dalla parte superiore del prodotto.
duriNg the first hours of operatioN, there may be some smoke or odours, but they are due to the Normal
“thermal break-iN”process.
duratioN of which chaNges depeNdiNg oN the product, it is recommeNded to: remove aNy majolica or Natural
stoNe parts from the top part of the product.
au cours des premières heures de foNctioNNemeNt, des fumées et des odeurs peuveNt être émises; elles soNt
dues au processus Normal de «rodage thermique».
duraNt ce processus, d’uNe durée variable eN foNctioN du produit, il est recommaNdé de retirer les pièces eN
faïeNce, pierre Naturelle ou métal de la partie supérieur du produit.
iN deN ersteN betriebsstuNdeN köNNeN durch deN NormaleN prozess des „temperatureiNlaufs“ dämpfe uNd
gerüche eNtsteheN.
währeNd dieses prozesses, der je Nach produkt voN uNterschiedlicher dauer ist, wird empfohleN, eveNtuelle
teile aus majolika, NatursteiN oder metall voN der oberseite des produkts zu eNtferNeN.
eN las primeras horas de fuNcioNamieNto se puedeN geNerar humos y olores debidos al proceso Normal de
“rodaje térmico”.
duraNte este proceso, de duracióN variable segúN el producto, se recomieNda remover posibles partes eN
mayólica ,piedra Natural o metal de la parte superior del producto.
Nas primeiras horas de fuNcioNameNto, podem ser gerados fumos e odores decorreNtes do processo de
“rodagem térmica”Normal.
duraNte este processo, de duração variável coNsoaNte o produto, é recomeNdável remover eveNtuais partes
em faiaNça, pedra Natural ou metal da parte superior do produto.
gabriella plus pietra
gabriella plus
4ENGLISH

5ENGLISH
Warnings
This instructions manual is an integral part of the product: make sure that
it always accompanies the appliance, even if transferred to another owner
or user, or if transferred to another place. If it is damaged or lost, request
another copy from the area technician. This product is intended for the use
for which it has been expressly designed. The manufacturer is exempt from
any liability, contractual and extracontractual, for injury/damage caused to
persons/animals and objects, due to installation, adjustment and mainte-
nance errors and improper use.
Installation must be performed by qualied sta, which assumes com-
plete responsibility for the denitive installation and consequent good
functioning of the product installed. One must also bear in mind all laws
and national, regional, provincial and town council Standards present
in the country in which the appliance has been installed, as well as the
instructions contained in this manual.
The use of the appliance must comply with all local, regional, national
and European regulations.
The Manufacturer cannot be held responsible for the failure to comply
with such precautions.
After removing the packaging, ensure that the content is intact and com-
plete. Otherwise, contact the dealer where the appliance was purchased.
All electric components that make up the product must be replaced with
original spare parts exclusively by an authorised after-sales centre, thus
guaranteeing correct functioning.
safety
THE APPLIANCE MAY BE USED BY CHILDREN 8 YEARS OF AGE OR
OLDER AND INDIVIDUALS WITH REDUCED PHYSICAL, SENSORY, OR
MENTAL CAPACITIES OR WITHOUT EXPERIENCE OR THE NECESSARY
KNOWLEDGE, PROVIDED THAT THEY ARE SUPERVISED OR HAVE
We thank you for having chosen our company; our product is a great heating solution developed from the
most advanced technology with top quality machining and modern design, aimed at making you enjoy the
fantastic sensation that the heat of a ame gives, in complete safety.

6ENGLISH
RECEIVED INSTRUCTIONS ON SAFE USE OF THE APPLIANCE AND THAT
THEY UNDERSTAND THE INHERENT DANGERS.
THE GENERATOR MUST NOT BE USED BY PERSONS INCLUDING
CHILDREN WITH REDUCED PHYSICAL, SENSORY AND MENTAL
CAPACITIES OR WHO ARE UNSKILLED PERSONS, UNLESS THEY ARE
SUPERVISED AND TRAINED REGARDING USE OF THE APPLIANCE BY A
PERSON RESPONSIBLE FOR THEIR SAFETY.
THE CLEANING AND MAINTENANCE REQUIRED BY THE USER MUST
NOT BE PERFORMED BY CHILDREN WITHOUT SUPERVISION.
CHILDREN MUST BE CHECKED TO ENSURE THAT THEY DO NOT PLAY
WITH THE APPLIANCE.
DO NOT TOUCH THE GENERATOR WHEN YOU ARE BAREFOOT OR
WHEN PARTS OF THE BODY ARE WET OR DAMP.
IT IS FORBIDDEN TO MODIFY THE APPLIANCE IN ANY WAY.
DO NOT PULL, REMOVE, TWIST THE ELECTRICAL CABLES COMING
OUT OFTHE PRODUCT EVEN IF IT IS DISCONNECTED FROMTHE MAINS.
IT IS ADVISED TO POSITION THE POWER SUPPLY CABLE SO THAT IT
DOES NOT COME INTO CONTACTWITH HOT PARTS OFTHE APPLIANCE.
THE POWER SUPPLY PLUG MUST BE ACCESSIBLE AFTER
INSTALLATION.
DO NOT CLOSE OR REDUCETHE DIMENSIONS OFTHE AIRINGVENTS
IN THE PLACE OF INSTALLATION. THE AIRING VENTS ARE ESSENTIAL
FOR CORRECT COMBUSTION.
DO NOT LEAVE THE PACKAGING ELEMENTS WITHIN REACH OF
CHILDREN OR UNASSISTED DISABLED PERSONS.
THE HEARTH DOOR MUST ALWAYS BE CLOSED DURING NORMAL
FUNCTIONING OF THE PRODUCT.
WHEN THE APPLIANCE IS FUNCTIONING AND HOT TO THE TOUCH,
ESPECIALLY ALL EXTERNAL SURFACES, ATTENTION MUST BE PAID
CHECK FOR THE PRESENCE OF ANY OBSTRUCTIONS BEFORE
SWITCHING THE APPLIANCE ON FOLLOWING A PROLONGED PERIOD
OF INACTIVITY.
THE GENERATOR HAS BEEN DESIGNED TO ADJUST ITSELF
AUTOMATICALLY IN PARTICULAR OPERATING CONDITIONS
THE GENERATOR HAS BEEN DESIGNED TO FUNCTION IN ANY
CLIMATIC CONDITION. IN PARTICULARLY ADVERSE CONDITIONS

7ENGLISH
STRONG WIND, FREEZING SAFETY SYSTEMS MAY INTERVENE
THAT SWITCH THE GENERATOR OFF. IF THIS OCCURS, CONTACT THE
TECHNICAL AFTERSALES SERVICE AND ALWAYS DISABLE THE SAFETY
SYSTEMS.
IN THE EVENT THE FLUE CATCHES FIRE, USE SUITABLE SYSTEMS
FOR SUFFOCATING THE FLAMES OR REQUEST HELP FROM THE FIRE
BRIGADE.
THIS APPLIANCE MUST NOT BE USED TO BURN WASTE
DO NOT USE ANY FLAMMABLE LIQUIDS FOR IGNITION
DURING THE FILLING PHASE DO NOT PUT THE BAG OF PELLETS TO
INTO CONTACT WITH THE PRODUCT
THE MAJOLICAS ARE TOP QUALITY ARTISAN PRODUCTS AND
AS SUCH CAN HAVE MICRODOTS, CRACKLES AND CHROMATIC
IMPERFECTIONS. THESE FEATURES HIGHLIGHT THEIR VALUABLE
NATURE. DUE TO THEIR DIFFERENT DILATION COEFFICIENT, THEY
PRODUCE CRACKLING, WHICH DEMONSTRATE THEIR EFFECTIVE
AUTHENTICITY. TO CLEAN THE MAJOLICAS, IT IS RECOMMENDED TO
USE A SOFT, DRY CLOTH. IF A DETERGENT OR LIQUID IS USED, THE
LATTER COULD PENETRATE INSIDE THE CRACKLES, HIGHLIGHTING
THEM.
SINCE THE PRODUCT CAN TURN ON AUTOMATICALLY THANKS TO
THE TIMER, OR REMOTELY USING THE DEDICATED APPLICATIONS, IT IS
STRICTLY FORBIDDEN TO LEAVE ANY COMBUSTIBLE OBJECT WITHIN
THE SAFETY DISTANCES INDICATED ON THE TECHNICAL DATA PLATE.
INTERNAL COMBUSTION CHAMBER PARTS CAN BE SUBJECT TO
EXTETICAL WARN, IT DOESN'T AFFECT THE FUNCTIONALITY
routine Maintenance
Based on Decree 22 January 2008 n°37 art.2, routine maintenance means
interventions aimed at reducing degradation due to normal use, as well
as dealing with accidental events entailing the need of rst interventions,
which however do not modify the structure of the system upon which one
is intervening or its intended use according to the requirements laid down
by the technical standards in force and by the manufacturer's use and main-
tenance manual.

- - - GABRIELLA PLUS
- - -
kW 8,0
kW -
- - -
ηs% 82,1
PM
mg/Nm3
14
OGC 1
CO 129
NOx 132
PM
mg/Nm3
20
OGC 2
CO 630
NOx 123
Pnom kW 8,0
Pmin kW 3,5
ηth,nom % 94,0
ηth,min % 94,1
elmax kW 0,090
elmin kW 0,052
elSB kW 0,0014
- - -
- - -
8ENGLISH
INFORMATION REQUIREMENTS FOR SOLID FUEL LOCAL SPACE HEATERS
(COMMISSION REGULATION (EU) 2015/1185)
Model identier(s)
Indirect heating functionality NO
Direct heat output
Indirect heat output
Fuel Compressed wood with moisture content <12 %
Seasonal space heating energy eciency
Space heating emissions at nominal heat output (*)
Space heating emissions at minimum heat output (*)
Nominal heat output
Minimum heat output (indicative)
Useful eciency at nominal heat output
Useful eciency at minimum heat output (indicative)
Auxiliary electricity consumption - At nominal heat
output
Auxiliary electricity consumption - At minimum heat
output
Auxiliary electricity consumption - In standby mode
Type of heat output/room temperature control with electronic room temperature control plus
week timer
Other control options ---
(*)PM = particulate matter, OGCs = organic gaseous compounds, CO = carbon monoxide, NOx = nitrogen oxides

9ENGLISH
INSTALLING INSERTS
When installing inserts, access must be prevented to the internal parts of the appliance and it must not be possible to access live parts during
extraction operations.
Any wiring, for example the power cable or room probe, must be positioned so as not to be damaged during movement of the insert and must
not come into contact with hot parts. If a cavity made of combustible material is installed, we recommend taking all the safety precautions
indicated by the installation standards.
VENTILATION AND AERATION OF INSTALLATION ROOMS
In case of non-airtight heater and/or installation, the ventilation must respect the minimum area indicated below (considering the highest value
among those provided):
Appliance categories Reference standard Percentage of the net opening section with respect to the
appliance fumes outlet section
Minimum net opening value of the
ventilation duct
Pellet stoves UNI EN 14785 - 80 cm²
Boilers UNI EN 303-5 50% 100 cm²
INSTALLATION
GENERAL
The ue gas exhaust and hydraulic connections must be carried out by qualied personnel who must issue installation conformity
documentation compliant with national standards.
The installer must provide the owner or person acting for him, according to the legislation in force, with the declaration of conformity,
supplied with:
1) the use and maintenance manual of the appliance and of the system components (such as for example, the smoke ducts, chimney, etc.);
2) photocopy or photograph of the chimney plaque;
3) system booklet (where applicable).
The installer must ask to be issued with a receipt stating that the documentation has been provided, and must keep it with a copy of the technical
documentation relating to the installation.
For installation in a condominium, prior approval from the condominium's administrator must be requested.
Where required, check the exhaust gas emissions after installation. Should a sampling point be installed, it must be airtight.
COMPATIBILITY
Do not install in rooms with a re hazard. It is also forbidden to install it in living areas with the following characteristics:
1. where there are liquid fuel appliances with continuous or discontinuous operation that draw the combustion air into the room in which they
are installed.
2. wheretherearetypeBgas appliancesintendedforheating,with or without domestichotwaterproductionandinadjacentandcommunicating
rooms.
3. where the depression measured in situ between the external and internal environment is greater than 4 Pa.
N.B.: Watertight appliances can also be installed in the cases indicated in points 1, 2 and 3 of this paragraph.
INSTALLATIONS IN BATHROOMS, BEDROOMS AND STUDIO FLATS
Installation in bathrooms, bedrooms and studio ats is only allowed for sealed or closed hearth appliances with ducted combustion air taken
from the outside.
oor protection
POSITIONING AND SAFETY DISTANCES
The support surfaces and/or points must have a suitable capacity to bear the overall weight
of the appliance, accessories and coverings. If the oor is made of a combustible material,
we recommend using a non-combustible material to protect the front part from any burnt
material which might fall during routine cleaning operations. The generator must be level
to function properly. The side walls, the rear walls and the oor support surface should be
made of non-combustible material.
One must also bear in mind all laws and national,
regional, provincial and town council regulations in force
in the country in which the appliance has been installed,
as well as the instructions contained in this manual.
Air inlet
Under any condition, including in the presence of extractor hoods and/or of controlled forced ventilation systems, the pressure dierence
between the generator installation rooms and the outside must always be equal to or less than 4 Pa.
MINIMUM DISTANCES PELLET STOVES
Installation next to ammable or heat-sensitive materials is permitted only if the special
safety distances specied on the label at the beginning of the manual (pag.2) are
observed. If the materials are not ammable, you must keep a side and rear distance of at
least 100 mm (without the inserts). For products equipped with rear spacers, wall-mounting
installation is permitted exclusively for the rear side.
PREPARATIONS FOR MAINTENANCE
To carry out extraordinary maintenance operations on the product, it may be necessary to move it away from the adjacent walls. This must be
done by a technician authorised to disconnect the combustion product evacuation ducts and then reconnect them. For heaters connected to the
hydraulic system, the connection between the system itself and the product must be made in such a way that, when an authorised technician is
about to carry out extraordinary maintenance operations, it is possible to move the heater at least 1 metre away from the adjacent walls.

3 - 5%
Max 3 mt
10 ENGLISH
EXAMPLES OF CORRECT CONNECTION TO THE CHIMNEY
In the presence of type B gas appliances with intermittent operation not intended for heating, they must have their own aeration and/or
ventilation opening.
The air inlets must meet the following requirements:
they must be protected with grids, metal mesh, etc., but without reducing the net useful section;
they must be made so as to make the maintenance operations possible;
positioned so that they cannot be obstructed;
The clean and non-contaminated air ow can also be obtained from a room adjacent to that of installation (indirect aeration and
ventilation), as long as the ow takes place freely through permanent openings communicating with the outside.
The adjacent room cannot be used as a garage, or to store combustible material or for any other activity with a re hazard, bathroom,
bedroom or common room of the building.
FLUE GAS EXHAUST
The heat generator works in depression and is equipped with an outlet fan for ue gas extraction. There must be a single exhaust system for
the generator. Using a ue that is shared with other devices is not allowed.
The components of the ue gas exhaust system must be chosen in relation to the type of appliance to be installed in compliance with:
UNI/ TS 11278 in the event of metal chimneys, with particular attention to that stated in the specication;
UNI EN 13063-1 and UNI EN 13063-2, UNI EN 1457, UNI EN 1806 in the event of non-metallic chimneys.
The length of the horizontal section must be minimal and, in any case, no longer than 3 metres, with a minimum upward slope of 3%
There must not be more than 4 direction changes including the one due to the use of the "T" element.
A“T” tting with a condensation collection cap must be provided at the base of the vertical section.
If the exhaust is not inserted in an existing ue, a vertical section with a windproof end piece is required (UNI 10683).
The vertical duct can be inside or outside the building. If the smoke duct is inserted in an existing ue, it must be certied for solid fuel.
If the smoke duct is outside the building, it must always be insulated.
The smoke ducts must have at least one airtight inlet for ue gas sampling.
All the sections of the ue gas duct must be accessible to inspection.
Inspection openings must be provided for cleaning.
If the generator has a fume temperature lower than 160°C+ ambient temperature caused by the high yield (contact technicians) it
MUST be resistant to humidity.
A ue system that does not respect the previous points or, in general, that does not comply with the regulations, may cause condensation
phenomena inside it.
CHIMNEY CAP
The chimney caps must meet the following requirements:
they must have a useful outlet section no less than double that of the chimney/ducted system on which it is installed;
they must be adapted in order to prevent the penetration of rain and snow in the chimney/ducted system;
they must be built so that, in the event of winds coming from all directions and from any angle, the expulsion of combustion products
is in any case ensured;
Protection from rain
and wind
Condensation-proof
"T" tting with
inspection plug
Insulated ue
Insulated "T"
tting with
inspection plug
Protection from rain and wind
"T" tting with
inspection
plug
CONNECTION TO THE MAINS ELECTRIC SUPPLY
The generator is supplied with an electric power cable to be plugged into a 230V 50 Hz socket, possibly with a circuit breaker switch. The
socket must be easily accessible.
The electrical system must be compliant with standards. The eciency of the earthing circuit must be checked. Unsuitable earthing of the
system can cause malfunctioning for which the manufacturer will not be held liable.
Power supply variations beyond 10% can cause faulty operation of the product.
FOR GERMANY ONLY
The product can be connected to a shared ue (multi-connection) provided that the requirements of the regional and national regulations,
amongst which DIN EN 13384-2, DIN V 18160-1, DIN 18896 and of the MFeuV-2007 (Muster-Feuerungsverordnung) are strictly complied with,
and that the local chimney sweep has checked and approved the installation conditions.
Please also remember the following indications, which the end user must comply with:
• The device can be operated only with the doors closed.
• The doors and all setting devices must remain closed when the device is not on (except for cleaning and maintenance operations).

11ENGLISH
1. Remove upper swarf. 2 . Remove rear cover.
3. Remove upper closure and rear extension. 4. Install upper extension and rear closure.
5. Install rear cover. 6. Insert upper discharge.
UPPER FUMES OUTLET ASSEMBLY
FOLLOW THE ASSEMBLY INSTRUCTIONS CAREFULLY!
ALWAYS FOLLOW THE ASSEMBLY INSTRUCTIONS IN COMPLETE SAFETY!
THE STOVE MUST BE COMPLETELY COLD, SWITCHED OFF AND DISCONNECTED FROM THE ELECTRICAL POWER SUPPLY.
*NOT AVAILABLE

Max 3,5mt
Max 4 mt
Max 3,5mt
Max 4 mt
Max 3,5mt
Max 4 mt
Max 3,5mt
Max 4 mt
12 ENGLISH
installation example
One must also bear in mind all laws and national, regional, provincial and town council regulations in force in the country in which the appliance has been
installed, as well as the instructions contained in this manual.
Hermetically sealed installation
The generator is a fully sealed product with respect to the environment in which it is installed. This means that it is ideal for passive houses
because it does not take air in from within the house.
combustion air
To ensure the stove remains hermetically sealed, the connection pipe for the combustion air must be directly connected to the exterior, using
special pipes and sealed connectors.
Fumes exHaust system
• If the generator has a fumes temperature of less than 160°C+ room temperature due to the high performance (refer to technical data),
the fumes exhaust system must be completely waterproof.
• If there is a possibility that fumes may condense, an external inspection hatch must be tted.
Max. 1.5 m -
max. 2 elbows
Max. 1.5 m -
max. 2 elbows

C
h
A
f
B
D
B
l
m
i
g
k
j
e
e
A
BAe
A A
13ENGLISH
ASpacer
J
On/O
BRear fumes exhaust Fuse
CAccess to combustion chamber 230 V power supply
DLateral ducting
K
Serial input
ERoom probe Additional thermostat input
FRoom air outlet Ducting thermostat input
GDisplay LRear ducting
HUpper fumes exhaust MCombustion air inlet
IPellet hopper
gABRiellA PlUS DeTAilS

14 ENGLISH
hOT AiR DUCTiNg
The pipe used for ducting the hot air must have an internal diameter of 80 mm and it must also be insulated or at least be protected against
heat dispersion.
Features:
rear or lateral outlet
diameter of air ducting outlet: 80 mm
maximum recommended air ducting length 8 m
possibility to thermostat the ducting
3 possible settings: OFF, COMFORT, AUTO.
ADDiTiONAl TheRmOSTAT TO CONTROl The DUCT mOTOR
For models with duct motor, it is also possible to thermostat the motor itself. The connection to an external thermostat will allow for the
duct motor to be controlled regardless of stove operation.
At this point, simply set the desired temperature on the thermostat; the thermostat will command
the operation of the second motor:
when the temperature has not been reached (contact closed) the second motor will follow the
operation of the stove.
when the temperature has been reached (contact open), the motor will switch o.
The duct thermostat terminal features a standard bridge.
See drawing to the side.
SPACeRS
There are 2 spacers located at the back of the machine which determine the minimum distance from any support behind the stove.
The spacers must not be removed.
Please note: direct the room probe downwards or towards the outside of the stove.

15ENGLISH
NOTeS fOR CORReCT OPeRATiON
The following indications must be respected for correct pellet
stove operation:
Both during stove operation and when it is not used, all hatches
(pellet hopper, door, ash drawer) must remain closed at all times.
They can be opened only for the time required to load the fuel
and for maintenance.
Failure to comply with the above during operation will cause the
display to show the following:
"CLOSE HOPPER - STOVE DOOR"
This indication means that you have 60 seconds to close the
hatch/door and the pellet lid.
After the 60 seconds, during ignition the stove will go into "DEPR
ALARM" mode, while during normal operation the stove will go
into "COOLING STAND BY" mode before automatically resuming
operation once the conditions are satised (cold stove, etc.).
STOVe POSiTiONiNg
To ensure the stove works correctly, it should always be positioned so that it is perfectly level, using a spirit level.
Pellet hopper lid
Fire door
fUSe
If the stove is not powered, it is recommended to
have the fuse checked by a qualied technician.

16 ENGLISH
PELLETS AND FEEDING
Pellets are made by subjecting wood shavings, i.e. the rejects of pure wood (without paint) produced by sawmills, joineries and other activities
connected to working and transforming wood, to very high pressures.
This type of fuel is fully ecological as no glues are used to hold it together. Indeed, the compactness of the pellets over time is guaranteed by
a natural substance found in wood: lignite.
As well as being an ecological fuel, as wood residues are made the most of, the pellet also has technical advantages.
While wood has a caloric value of 4.4 kWh/kg. (with 15% humidity, thus after 18 months of seasoning), the caloric value of pellets is 5 kWh/kg.
The density of pellets is about 650 kg/m3and water content is equal to 8% of its weight. For this reason, pellets do not need to be seasoned in
order to obtain a suciently adequate heat output.
THE USE OF POOR QUALITY PELLETS OR ANY OTHER MATERIAL DAMAGES THE FUNCTIONS OF THE GENERATOR
AND MAY INVALIDATE THE WARRANTY AND RELIEVE THE MANUFACTURER OF ALL RESPONSIBILITY.
PELLET HOPPER
During stove operation, the pellet hopper lid must always be closed.
Keep clean
DO NOT PLACE THE BAG DIRECTLY ON THE STOVE WHEN LOADING THE HOPPER!
ALWAYS USE A SCOOP TO LOAD THE HOPPER. DO NOT RUB AGAINST OR PLACE WEIGHTS ON THE HOPPER SEAL.
KEEP
THE HOPPER LID SEAL SUPPORTING SURFACE CLEAN AT ALL TIMES. CHECK THE CONDITIONS OF THE SEAL FREQUENTLY.
IN CASE OF DETERIORATION, CONTACT YOUR LOCAL AUTHORISED TECHNICIAN.
The pellets used must be class A1 certied according to standard
ISO 17225-2 (ENplus-A1, DIN Plus or NF 444 of the following
category: “High quality NF biocombustible wood pellets”).
UNI EN 303-5 with the following characteristics: water content
≤ 12%, ash content ≤ 0.5% and lower caloric value >17 MJ/kg (in
the case of boilers).
The Manufacturer recommends using pellets with a diameter of
6mm with its products.
PELLET STORAGE
To guarantee combustion without problems, the pellets must be
kept in a dry place.
Open the tank lid and load the pellets using a scoop.

2
3
4
5
1
6
7
8
9
10
12
11
17ENGLISH
Remote contRol
The remote control can be used to adjust the main stove functions.
1Transmitter 7Select air mode
2Display 8Lock keyboard
3On/o stove (hold for 3 seconds) 9Degrees Celsius / Fahrenheit
4Set power 10 Press the button once to enable or disable the chrono
5
Set switch-o delay: The button allows to set the switch-
o delay.
For example, if you set it to one hour, the stove will
automatically switch o after the set time
11 Reset
6Set room temperature 12 Battery compartment

18 ENGLISH
InseRtIng the batteRIes
Remove the battery compartment cover by sliding it down. Insert 2 AAA
batteries.
Insert the batteries respecting the correct polarity (+) and (-).
Close the cover of the battery compartment.
Respect the environment!
Used batteries contain metals that are harmful to the environment, and therefore must be disposed of separately in
special containers.
If the Remote contRol Is swItched off due to no batteRy
Installed, the stove can be contRolled fRom the
command panel located on the uppeR paRt of the stove.
when changIng the batteRIes, make suRe you follow the
symbols pRInted InsIde the Remote contRol.
Remote contRol Icons
advIce and pRecautIons foR the use of the
Remote contRol
Remove the batteries if it is not used for a long time.
When being used, direct it towards the stove's signal receiver.
Handle the remote control with care. When it is not being used, place it
on the special base supplied.
The remote control must not be left in a place where it is exposed to
direct sunlight or near a source of heat.
The quality of the signal may be aected by other IR sources.
Air mode selected:
Flashing COMFORT
On AUTO
Enable chrono
Light on = activated
Light o = deactivated
Set switch-o delay
Indicates the transmission of the radio
signal
On = during all radio communication
O = radio communication absent
Battery low Keys locked
Set power level.
The power level is displayed, instead of the set room temperature, for 3 seconds when one of the set
power buttons is pressed (4).
J
THE REMOTE CONTROL IS FITTED WITH AN LCD BACKLIT DISPLAY. THE BACKLIGHTING LASTS 20 SECONDS FROM THE
LAST PRESS OF A BUTTON. AFTER A CERTAIN TIME,TO SAVE BATTERY POWER,THE DISPLAYTURNS OFF ENERGY SAVING
MODE.
THE CONTROL FUNCTIONS ARE REACTIVATED WHEN THE REMOTE IS REMOVED FROM ITS UNIT OR BY A LONG PRESS OF
THE BUTTON.

19ENGLISH
CONTROL BOARD
ON/OFF
BUTTON
TEXT MESSAGE
DISPLAY
TO ACCESS
THE MENU
TEMPERATURE
SETTINGS
OPERATING
POWER SETTINGS
ICON KEY
!
WI-FI BT STBY
OK
ON
Indicates the presence of an alarm.
O: indicates that there are no alarms
On: indicates the presence of an alarm
!
WI-FI BT STBY
OK
ON
Indicates the status of the weekly programming
O: deactivated.
On: activated.
!
WI-FI BT STBY
OK
ON
Not in use
!
WI-FI BT STBY
OK
ON
Not in use
!
WI-FI BT STBY
OK
ON
Indicates the contact of the external additional thermostat
Closed contact: the contact of the external additional
thermostat is closed.
Open contact: the contact of the external additional
thermostat is open.
(Icon visible only if SET THERMOSTAT is set to "LOWTA")
!
WI-FI BT STBY
OK
ON
STAND BY function icon
O: deactivated.
On: activated.
!
WI-FI BT STBY
OK
ON
Indicates the stove power.
Flame on: stable power.
Flame ashing: the power is increasing or decreasing.
The dashes indicate the actual power of the machine.
!
WI-FI BT STBY
OK
ON
Not in use.
!
WI-FI BT STBY
OK
ON
Indicates the operation of the tangential fan.
O = ventilation not active.
On = ventilation active.
Flashing = ventilation active in COMFORT mode
!
WI-FI BT STBY
OK
ON
Indicates the DELAY SWITCHOFF function
On = delay switch-o active
O = delay switch-o not active

1
23
45
6
1 4
3
2
5
6
20 ENGLISH
GENERAL MENU Go back - exit
Scroll parameters: next (3); previous (2)
Change settings data: increase (4); decrease (5)
Conrm - access menu
J
MAKE SURE THAT THERE ARE NO RESIDUES OR DIRT AT THE BOTTOM OF
THE BURN POT.THE HOLES ATTHE BOTTOM MUST BE COMPLETELY FREE
TO GUARANTEE PROPER COMBUSTION. THE "EASY SETUP" FUNCTION
CAN BE USED TO ADAPT COMBUSTION BASED ON THE DESCRIBED
NEEDS.
BURN POT BOTTOM
FRONT AIR SET
AIR DUCTING SET
EASY SETUP SET
CHRONO ENABLING
PRG1
PRG2
SETTINGS DATETIME PRG3
LANGUAGE PRG4
DISPLAY
STAND BY
DELTAT
FIRST LOAD
DEGREES
RESET
*TECHNICIANS ONLY
EASY CONTROL
*STOVE STATUS
*TECH
MENU
GENERAL WARNINGS
Advice to follow for the rst start-ups of the product:
During the rst hours of operation, there may be some smoke or
odours, but they are due to the normal“thermal break-in” process.
During this process, the duration of which changes depending on
the product, it is recommended to:
Ventilate the room well
If present, remove any majolica or natural stone parts from the
top part of the product
Activate the product at the maximum power and temperature
Avoid remaining in the room for a long time
Do not touch the surfaces of the product
Notes:
The process is completed after a few heating/cooling cycles.
For combustion, do not use elements or substances other than those
indicated in the manual.
Before turning on the product, it is necessary to perform the
following checks:
If it is intended to be connected to a hydraulic system, it must
be complete and fully functional and in compliance with the
instructions given in the product manual and with the relevant
regulations in force.
The pellet hopper must be fully loaded
The combustion chamber and the burn pot must be clean
Make sure that the re holder, the ash drawer and the pellet
hopper close hermetically (if present in the hermetic version); they
must be closed and there must be no foreign bodies in the sealing
elements and gaskets.
Check that the power cord is properly connected
The bipolar switch (if present) must be set to position “1”.
