Extreme Networks WiNG AP-7602 User manual

Overview of the AP-7602
An AP-7602 is designed for the cost effective deployment of 802.11AC
networks. An AP-7602 supports scalable management options, including
standalone and Virtual Controller (where one AP can manage multiple APs),
WiNG NOC, Site Controllers, and Cloud Management.
AP-7602 Specifications
Telco Box Mounting the AP-7602 Wireless
Wallplate
For telco Box installations, the Wireless Wallplate is installed directly over the
standard wall plate supplying Ethernet. All cabled electrical connections are
made within a recessed well in the housing of the Access Point. To install the
Wireless Wallplate over a telco box:
1 Remove the existing screws and the existing wallplate cover.
2 Gently disengage and remove the RJ-45 outlets from the wallplate cover.
3 Reuse the existing screws to screw the mounting plate to the telco box.
4 Without going over any plastic, connect one end of the 10cm RJ-45 cable into GE1 and
route the GE1 cable back through the routing channel on the underside of the Wireless
Wallplate. Plug the other end of the 10cm RJ-45 cable into the RJ-45 outlet.
5 Snap the Wireless Wallplate to the mounting plate and verify the unit has power by
observing the LEDs.
6 The AP-7602 is ready to configure.
Wall Mounting the AP-7602 Wireless Wallplate
An AP-7602 can be mounted to a flush surface without a telco box.
1 Install the included mounting bracket to the wall using wood screws and wall anchors
if appropriate.
2 Connect an Ethernet cable to the GE1 port before connecting the Access Point.
3 Hook the top of the Access Point to the bracket, rotate and snap the bottom of the
Access Point.
4 Optionally install the included security screw once the installation is verified.
5 The Access Point is ready to configure.
Basic AP-7602 Configuration
Once the Access Point is installed and powered on, complete the following
WiNG Assist configuration steps to get up and running with minimal
administrative intervention.
Startup Assist updates existing settings. To delete or revise existing settings,
either rerun Startup Assist or navigate to where those parameters appear in
the user interface and update them accordingly. Refer to the Access Point’s
Wireless
Interface Dual Radio, 802.11a/b/g/n/AC; 2.4GHz/5GHz
Ethernet
Interface Two 10/100/1000Mb auto-sensing
Power 802.3af PD on GE1; or 12VDC barrel connector
Operating
Frequency
2.4GHz band: 2400 – 2483 MHz
5GHz band: 5150 - 5350 MHz
RF TX Power 1dBm to 19dBm in 1dBm increments
Actual power dependent on national standards
Antennas 2 internal dual band antennas supporting 1x1:1 or 2x2:2 2.4GHz: 3.76dBi peak gain
5GHz: 5.95dBi peak gain
Management Telnet, SSH, HTTP, HTTPS, SNMPv2/v3
Wing Controller, Azara Cloud
more advanced configuration documentation, available on the support site,
for updating the management interface beyond the scope of the WiNG Assist
configuration described in this guide. For more information, see:
www.extremenetworks.com/support.
To define a basic Startup Assist configuration:
1 Power the Access Point using an appropriate power adapter, PoE injector, or PoE
switch.
2 Connect to the Access Point using its default IP address located on the backside of the
Access Point.
3 Enter the default username admin in the Username field.
4 Enter the default password admin123 in the Password field.
5 Select the Login button to load the management interface. If logging in using a factory
default configuration, Startup Assist automatically displays.
Select the Basic screen, click Startup Assist.
Set the following Startup Assist parameters:
• Virtual Controller - Sets this Access Point as a Virtual Controller capable of managing
and provisioning up to 24 other Access Points of the same model. Access Points
managed by this Virtual Controller list this Access Point's AP Name as its own. Only
one Virtual Controller can be designated.
• Date & Time -Set the date, hour and minute for the current system time in AM or PM
format.
• WLAN 1 Name - Provide a unique network identifier name for this WLAN. This is a
required setting. The name is used for the SSID.
• Authentication - Select PSK to apply a 64 character maximum passphrase in either
ASCII or Hex format.The authenticating device must use the same PSK algorithm
during authentication. Selecting Show displays the key in exposed plain text (not
recommended).
Selecting Open is not a recommended authentication scheme, as it would provide the
Access Point's WLAN no security via credential exchange and would only make sense
in a network where no sensitive data is either transmitted or received.
6 Select Apply to save and commit the Startup Assist changes to the Access Point's
configuration. Select Discard to revert to the last saved configuration.
Regulatory Information
This guide applies to the following Model Number AP-7602.
Extreme Networks devices are designed to be compliant with rules and
regulations in locations they are sold and will be labeled as required.
Local language translations are available at the following Website:
www.extremenetworks.com/support
Any changes or modifications to Extreme Networks equipment, not expressly
approved by Extreme Networks could void the user's authority to operate the
equipment.
Extreme Networks devices are professionally installed, the Radio Frequency
Output Power will not exceed the maximum allowable limit for the country of
operation.
Antennas: Use only the supplied or an approved replacement antenna.
Unauthorized antennas, modifications, or attachments could cause damage
and may violate regulations.
Bluetooth® Wireless Technology
This is an approved Bluetooth® product. For more information or to view the
End Product Listing, please visit https://www.bluetooth.org/tpg/listings.cfm.
Ad-Hoc Operation (2.4 GHz band)
Ad-Hoc operation is limited to Channels 1-11 (2412-2462 MHz).
Warning: Operation of the device without regulatory approval is
illegal.
Health and Safety Recommendations
Caution: In order to avoid or minimize the potential risk of ergonomic injury
follow the recommendations below. Consult with your local Health & Safety
Manager to ensure that you are adhering to your company's safety programs
to prevent employee injury.
• Reduce or eliminate repetitive motion
• Maintain a natural position
• Reduce or eliminate excessive force
• Keep objects that are used frequently within easy reach
• Perform tasks at correct heights
• Reduce or eliminate vibration
• Reduce or eliminate direct pressure
• Provide adjustable workstations
• Provide adequate clearance
• Provide a suitable working environment
• Improve work procedures
Wireless devices transmit radio frequency energy and may affect medical
electrical equipment. When installed adjacent to other equipment, verify that
the adjacent equipment is not adversely affected.
Pacemakers
Pacemaker manufacturers recommended that a minimum of 15cm (6 inches)
be maintained between a handheld wireless device and a pacemaker to avoid
potential interference with thepacemaker. These recommendations are
consistent with independent research and recommendations by Wireless
Technology Resea rch .
Persons with Pacemakers:
• Should ALWAYS keep the device more than 15cm (6 inches) from their pacemaker
when turned ON.
• Should not carry the device in a breast pocket.
• Should use the ear furthest from the pacemaker to minimise the potential for
interference.
• If you have any reason to suspect that interference is taking place, turn OFF your
device.
Other Medical Devices
Please consult your physician or the manufacturer of the medical device to
determine if the operation of your wireless product may interfere with the
medical device.
RF Exposure Guidelines
Safety Information
Reducing RF Exposure - Use Properly
Only operate the device in accordance with the instructions supplied.
International
The device complies with internationally recognized standards covering
human exposure to electromagnetic fields from radio devices.
Power Supply
Use ONLY an approved UL LISTED ITE (IEC/EN 60950-1, LPS/SELV) power
supply with electrical ratings: Output 12Vdc, min 1A, with a maximum ambient
temperature of at least 50 degrees C. Use of alternative power supply will
invalidate any approvals given to this unit and may be dangerous.
Alternately this device may be powered from a 802.3af compliant power
source which has been certified by the appropriate agencies, or by an
approved UL LISTED ITE (IEC/EN 60950-1, LPS/SELV) power supply with
electrical ratings: Output 48Vdc, min 0.25A, with a recommended ambient
temperature greater than 50 degrees C. Use of alternative power supply will
invalidate any approvals given to this unit and may be dangerous.
The product is to be connected to PoE networks without routing to the
outside plant.
CE Marking and European Economic Area (EEA)
The use of 2.4GHz RLAN’s, for use through the EEA, have the following
restrictions:
Maximum radiated transmit power of 100 mW EIRP in the frequency range
2.400 -2.4835 GHz.
Bluetooth® Wireless Technology for use throughout the EEA has the following
restrictions:
Maximum radiated transmit power of 100 mW EIRP in the frequency range
2.400 -2.4835 GHz.
Statement of Compliance
Extreme Networks hereby declares that this radio equipment is in compliance
with Directive 2011/65/EU and 1999/5/EC or 2014/53/EU (2014/53/EU
supersedes 1999/5/EC from 13th June 2017).
Ergonomic Recommendations
European Waste Electrical and Electronic Equipment
(WEEE) Notice
In accordance with Directive 2012/19/EU of the European Parliament on waste
electrical and electronic equipment (WEEE):
1 The symbol above indicates that separate collection of electrical and electronic
equipment is required.
2 When this product has reached the end of its serviceable life, it cannot be disposed of
as unsorted municipal waste. It must be collected and treated separately.
3 It has been determined by the European Parliament that there are potential negative
effects on the environment and human health as a result of the presence of hazardous
substances in electrical and electronic equipment.
4 It is the users’ responsibility to utilize the available collection system to ensure WEEE
is properly treated.
For information about the available collection system, please contact Extreme
Environmental Compliance at [e-mail].
AP-7602 RoHS Compliance

Extreme WirelessTM
WiNGTM AP-7602
Wireless Wallplate
Quick Reference
AP-7602-68B30-IL
Notice
Copyright © 2018 Extreme Networks, Inc. All Rights Reserved.
Legal Notices
Extreme Networks, Inc. reserves the right to make changes in specifications
and other information contained in this document and its website without
prior notice. The reader should in all cases consult representatives of Extreme
Networks to determine whether any such changes have been made. The
hardware, firmware, software or any specifications described or referred to in
this document are subject to change without notice.
Trademarks
Extreme Networks and the Extreme Networks logo are trademarks or
registered trademarks of Extreme Networks, Inc. in the United States and/or
other countries. All other names (including any product names) mentioned in
this document are the property of their respective owners and may be
trademarks or registered trademarks of their respective companies/owners.
For additional information on Extreme Networks trademarks, please see:
www.extremenetworks.com/company/legal/trademarks/
Documentation & Support
For product support, including documentation, visit:
www.extremenetworks.com/support/
P/N 9035373
