ExtremeWireless™WiNG™
AP-7612 Installation Guide
9035058
Published October 2017

Copyright © 2017 Extreme Networks, Inc. All rights reserved.
Legal Notice
Extreme Networks, Inc. reserves the right to make changes in specifications and other information
contained in this document and its website without prior notice. The reader should in all cases
consult representatives of Extreme Networks to determine whether any such changes have been
made.
The hardware, firmware, software or any specifications described or referred to in this document
are subject to change without notice.
Trademarks
Extreme Networks and the Extreme Networks logo are trademarks or registered trademarks of
Extreme Networks, Inc. in the United States and/or other countries.
All other names (including any product names) mentioned in this document are the property of
their respective owners and may be trademarks or registered trademarks of their respective
companies/owners.
For additional information on Extreme Networks trademarks, please see:
www.extremenetworks.com/company/legal/trademarks
Software Licensing
Some software files have been licensed under certain open source or third-party licenses. End-
user license agreements and open source declarations can be found at:
www.extremenetworks.com/support/policies/software-licensing
Support
For product support, phone the Global Technical Assistance Center (GTAC) at 1-800-998-2408
(toll-free in U.S. and Canada) or [phone]. For the support phone number in other
countries, visit: http://www.extremenetworks.com/support/contact/
For product documentation online, visit: https://www.extremenetworks.com/documentation/

Table of Contents
Preface.........................................................................................................................................4
Text Conventions...................................................................................................................................................................4
Providing Feedback to Us................................................................................................................................................ 4
Getting Help.............................................................................................................................................................................5
Extreme Networks Documentation..............................................................................................................................5
Chapter 1: Overview...................................................................................................................6
Uplink and Power Connections...................................................................................................................................... 6
Chapter 2: Installation Process................................................................................................ 8
Verifying the Box Contents.............................................................................................................................................. 8
Safety Guidelines.................................................................................................................................................................10
Mounting the Bracket to a Wall....................................................................................................................................10
Connecting the AP to the Network............................................................................................................................ 12
Mounting the AP to the Bracket...................................................................................................................................12
Chapter 3: Specifications........................................................................................................ 14
Chapter 4: Regulatory Information........................................................................................15
United States..........................................................................................................................................................................15
Canada......................................................................................................................................................................................16
European Waste Electrical and Electronic Equipment (WEEE) Notice....................................................17
CE Statement for Mobile Device Usage................................................................................................................... 18
Hazardous Substances......................................................................................................................................................19
Declaration of Conformity in Languages of the European Community...................................................19
ExtremeWireless™WiNG™ AP-7612 Installation Guide 3

Preface
Text Conventions
The following tables list text conventions that are used throughout this guide.
Table 1: Notice Icons
Icon Notice Type Alerts you to...
General Notice Helpful tips and notices for using the product.
Note Important features or instructions.
Caution Risk of personal injury, system damage, or loss of data.
Warning Risk of severe personal injury.
New This command or section is new for this release.
Table 2: Text Conventions
Convention Description
Screen displays This typeface indicates command syntax, or represents information as it appears on the
screen.
The words enter and
type
When you see the word “enter” in this guide, you must type something, and then press
the Return or Enter key. Do not press the Return or Enter key when an instruction
simply says “type.”
[Key] names Key names are written with brackets, such as [Return] or [Esc]. If you must press two
or more keys simultaneously, the key names are linked with a plus sign (+). Example:
Press [Ctrl]+[Alt]+[Del]
Words in italicized type Italics emphasize a point or denote new terms at the place where they are defined in
the text. Italics are also used when referring to publication titles.
Providing Feedback to Us
We are always striving to improve our documentation and help you work better, so we want to hear
from you! We welcome all feedback but especially want to know about:
•Content errors or confusing or conflicting information.
•Ideas for improvements to our documentation so you can find the information you need faster.
•Broken links or usability issues.
ExtremeWireless™WiNG™ AP-7612 Installation Guide 4

If you would like to provide feedback to the Extreme Networks Information Development team about
this document, please contact us using our short online feedback form. You can also email us directly at
[e-mail].
Getting Help
If you require assistance, contact Extreme Networks using one of the following methods:
•GTAC (Global Technical Assistance Center) for Immediate Support
•Phone: [phone] (toll-free in U.S. and Canada) or [phone]. For the support
phone number in your country, visit: www.extremenetworks.com/support/contact
•Email: [e-mail]. To expedite your message, enter the product name or
model number in the subject line.
•GTAC Knowledge — Get on-demand and tested resolutions from the GTAC Knowledgebase, or
create a help case if you need more guidance.
•The Hub — A forum for Extreme customers to connect with one another, get questions answered,
share ideas and feedback, and get problems solved. This community is monitored by Extreme
Networks employees, but is not intended to replace specific guidance from GTAC.
•Support Portal — Manage cases, downloads, service contracts, product licensing, and training and
certifications.
Before contacting Extreme Networks for technical support, have the following information ready:
•Your Extreme Networks service contract number and/or serial numbers for all involved Extreme
Networks products
•A description of the failure
•A description of any action(s) already taken to resolve the problem
•A description of your network environment (such as layout, cable type, other relevant environmental
information)
•Network load at the time of trouble (if known)
•The device history (for example, if you have returned the device before, or if this is a recurring
problem)
•Any related RMA (Return Material Authorization) numbers
Extreme Networks Documentation
To find Extreme Networks product guides, visit our documentation pages at:
Current Product Documentation www.extremenetworks.com/documentation/
Archived Documentation (for earlier
versions and legacy products)
www.extremenetworks.com/support/documentation-archives/
Release Notes www.extremenetworks.com/support/release-notes
Open Source Declarations
Some software files have been licensed under certain open source licenses. More information is
available at: www.extremenetworks.com/support/policies/software-licensing.
Preface
ExtremeWireless™WiNG™ AP-7612 Installation Guide 5

1Overview
Uplink and Power Connections
The AP7612 (AP-7612-680B30-xx) is a wall-plate 11ac Wave 2 access point (AP) that lets you extend
your wireless LAN and deploy local WiFi while still providing extension for wired clients from the same
Ethernet jack. This fully-featured AP plugs into existing Ethernet cabled wall plates. he AP provides
application visibility and control and policy support over dual integrated radios and a Bluetooth Low
Energy (BLE) radio.
AP-7612 comes with a second Gigabit Ethernet port with PoE sourcing capability. The PSE port can
provide (802.3af), which allows you to directly power devices such as IP Phones.
The AP-7612 is designed with five single-band internal antennas for indoor use only.
Additional features:
•Primarily designed to support wall, single and dual-gang box installation.
•Power: 802.3at (PoE+) compliant for full functionality. 802.3af is supported with reduced
functionality.
•Supports the 802.11ac and 802.11n wireless standards, with full backward compatibility with legacy
802.11abg.
•Has two concurrent Wi-Fi radios, one 5GHz 2x2 11ac radio and one 2.4GHz 2x2 11n. One radio can
operate as a Bluetooth Radio.
•Interoperates fully with Wireless LAN, including support for VoWLAN, branch oce mode, guest
services, RTLS, availability, and mobility.
Uplink and Power Connections
The AP-7612 uses as follows:
Table 3: Power Sources
Power Source PoE Power Sourcing on GE2
GE1 PoE 802.3at 15.4 Watts.
GE1 PoE 802.3af Not available.
12V DC Not available.
The AP has two client ports (GE1/POE and GE2), where:
•GE1/POE port is the system connection.
ExtremeWireless™WiNG™ AP-7612 Installation Guide 6

•GE2 port is used for connecting to an IP Phone.
Note
Both GE1 and GE2 ports are not accessible when the AP is mounted on to a bracket.
GE1 acts as the building and system connection. The GE2 port provides optional power and connectivity
to wired devices such as IP Phones.
Caution
Do not take the AP o the bracket if you are not the owner or not trained to perform the task.
Figure 1: Power Connections on AP-7612
Overview
ExtremeWireless™WiNG™ AP-7612 Installation Guide 7

2Installation Process
Verifying the Box Contents
Safety Guidelines
Mounting the Bracket to a Wall
Connecting the AP to the Network
Mounting the AP to the Bracket
Follow these procedures to install the AP-7612:
1Verify the box contents.
2 Review the Safety Guidelines.
3Mount the bracket to a wall, or junction/gang box.
4Connect the AP to the Network.
5Mount the AP to the Bracket.
Verifying the Box Contents
Before you install the AP-7612, make sure that you have all of the necessary parts.
1 Verify that the box contains the following items:
Table 4: AP-7612 Box Contents
Quantity Item
1 AP-7612 Quick Reference
1 AP-7612-680B30-xx
1 Wall/Junction box/Gang box mounting bracket (includes Security Torx
screw)
Table 5: AP-7612 Box Hardware Contents
Quantity Item
1 100mm twister pair RJ45 Flat Cable
1 Security Torx screw (size 0.45X6)
ExtremeWireless™WiNG™ AP-7612 Installation Guide 8

Note
Only the RJ45 flat cable ships with the product. Users need to provide their own additional
cable for GE2.
2 Perform a visual inspection of the AP for any signs of physical damage. Contact Extreme Networks if
there are any signs of damage.
Note
Before mounting the AP-7612, read Safety Guidelines.
Installation Process
ExtremeWireless™WiNG™ AP-7612 Installation Guide 9

Safety Guidelines
This section contains notices that you must adhere to ensure your personal safety and to prevent any
damage to the equipment.
Caution
The unit and all interconnected equipment must be installed indoors within the same building,
including all -powered network connections as described by Environment A of the IEEE
802.3at standard.
Qualified Personnel
Danger
Only qualified personnel should perform installation procedures.
Mounting the Bracket to a Wall
This procedure assumes that you are running a LAN cable through a wall.
Note
You can also mount this AP to a wall and run a LAN cable between the AP and bracket
without creating a hole in the wall.
Installation Process
ExtremeWireless™WiNG™ AP-7612 Installation Guide 10

Figure 2: AP-7612 Mounting Bracket
Number Description
1 AP mounting tabs
To mount the bracket to a wall:
Installation Process
ExtremeWireless™WiNG™ AP-7612 Installation Guide 11

1 Using the mounting bracket as a guide, choose a location where it is feasible to place the AP’s
center. The location must allow the LAN cables to come out of the wall within the large rectangular
hole. Place the bracket against the wall. (The captive screw will be used to lock the AP in place.)
Decide which two holes to use to mount the bracket. We recommend using the two holes at the top
and the bottom center of the opening. At a minimum, use two holes on opposite sides of the large
center opening.
2 Mark the two hole centers.
3 For drywall/plasterboard walls, drill two holes using a 1/4” or 6mm diameter drill bit.
4 For drywall/plasterboard walls, screw the plastic anchors into the wall first and then insert the
screws into the anchors.
5 Insert the bracket over the screw heads and slide the bracket. Ensure that both screws get attached
to the bracket.
6 Tighten the screws to secure the bracket in its place. Torque the screw to 9.0 in-lbs.
7Connect the LAN/power to the AP.
8Attach the AP to the mounting bracket.
Connecting the AP to the Network
Connect the building wire LAN 1 wire (either + at or PoE af) to the black RJ-45 connector using short
patch cables. Alternatively, you can connect the pass-through cable to the blue connector (top) on the
back of the AP.
Mounting the AP to the Bracket
After you attach the bracket to a wall or junction/gang box and connect the LAN/power, attach the AP
to the bracket.
1Stu any extra GE1 cable into the wall/box.
2 Keep the bracket at an angle and insert the two tabs at the top of the bracket into the AP.
3 Rotate the AP on the tabs and wait for it to clip to the other side of the bracket. The other side of the
bracket is on the bottom of the AP where the cable enters.
Installation Process
ExtremeWireless™WiNG™ AP-7612 Installation Guide 12

4 Attach and tighten the Security Torx screw to the bottom of the AP so that the AP is attached to the
bracket. Torque the screw to 7 in-lbs.
Note
If you are using the optional 12V DC-IN adapter instead pf PoE on GE1 port, then cfully
insert the friction fit connector into the AP. Plug the AP into an AC receptable.
Installation Process
ExtremeWireless™WiNG™ AP-7612 Installation Guide 13

3Specifications
This appendix lists the specifications for the ExtremeWireless™ Indoor Access Point AP-7612.
Table 6: Specifications for the AP-7612
Item Specification
AP Part Number: 37101 AP-7612-680B30-US
AP Part Number: 37102 AP-7612-680B30-WR
Enclosure material AP enclosure is not plenum rated.
Power source Power is provided by Power-over-Ethernet (802.3at or 802.3af). No AC
power supply is needed.
If wall plate has more than two Ethernet ports, the extra ports are not
accessible after installing the Wall Plate AP.
Power consumption 802.3at or PoE 802.3af
Sensor radio power budget is 802.1af (12.5W)
Antenna Five internal antennas
Uplink interface One 10/100/1000BT Ethernet port
RoHS compliant Yes
Radio configuration Dual Band Dual Concurrent 802.11ac and 802.11n
Radio 1: 5 GHz; 2x2:2; IEEE 802.11 ac (up to 886 Mbps per radio)
Radio 2: 2.4 GHz; 2x2:2; IEEE 802.11n (up to 300 Mbps per radio)
Legacy 802.11abg mode support
Integrated sensor radio that operates as Bluetooth 4.0 radio or operates as
802.15.4 (one at a time)
Water/dust proof ratings Not applicable
Operating temperature 0°C to 40°C
Non-operating transportation/
storage
-40°C to 70°C (-40°F to 158°F)
Altitude (feet) >6,500 feet; safety approved to 2,000 meters
Relative humidity (% RH) 0% to 95% (non-condensing)
Wind Not applicable. The AP-7612 is an indoor-only model.
ExtremeWireless™WiNG™ AP-7612 Installation Guide 14

4Regulatory Information
United States
Canada
European Waste Electrical and Electronic Equipment (WEEE) Notice
CE Statement for Mobile Device Usage
Hazardous Substances
Declaration of Conformity in Languages of the European Community
United States
FCC Declaration of Conformity Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment o and on, the user is encouraged to try
to correct the interference by one of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit dierent from that to which the receiver is
connected.
•Consult the dealer or an experienced radio/TV technician for help.
FCC Caution:
Any changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
•This device may not cause harmful interference
•This device must accept any interference received, including interference that may cause undesired
operation.
This transmitter must not be co-located or operating in conjunction with any other antenna or
transmitter.
ExtremeWireless™WiNG™ AP-7612 Installation Guide 15

FCC Radiation Exposure Statement
For product available in the USA/Canada market, only channel 1~11 can be operated. Selection of other
channels is not possible. This device is going to be operated in 5.15~5.25GHz frequency range, it is
restricted in indoor environment only. This device is restricted for indoor use.
This equipment complies with FCC RF radiated exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with a minimum distance of 22 cm
between the radiator and your body.
Canada
Industry Canada Notice
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the
following two conditions:
1 this device may not cause interference, and
2 this device must accept any interference, including interference that may cause undesired operation
of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts
de licence. L'exploitation est autorisée aux deux conditions suivantes:
1 l'appareil ne doit pas produire de brouillage, et
2 l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est
susceptible d'en compromettre le fonctionnement.
Caution
1 For product available in the USA/Canada market, only channel 1~11 can be operated. Selection of
other channels is not possible.
2 Dynamic Frequency Selection (DFS) for devices operating in the bands 5250- 5350 MHz,
5470-5600 MHz and 5650-5725 MHz.
3 The device for operation in the band 5150-5250 MHz is only for indoor use to reduce the potential
for harmful interference to co-channel mobile satellite systems.
4 The maximum antenna gain permitted for devices in the bands 5250-5350 MHz and 5470-5725 MHz
shall be such that the equipment still complies with the e.i.r.p. limit.
5 The maximum antenna gain permitted for devices in the band 5725-5850 MHz shall be such that the
equipment still complies with the e.i.r.p. limits specified for point-to-point and non-point-to-point
operation as appropriate.
6 For indoor use only.
Avertissement:
1 Pour les produits disponibles aux États-Unis / Canada du marché, seul le canal 1 à 11 peuvent être
exploités. Sélection d'autres canaux n'est pas possible.
2 Sélection dynamique de fréquences (DFS) pour les dispositifs fonctionnant dans les bandes
5250-5350 MHz, 5470-5600 MHz et 5650- 5725 MHz.
Regulatory Information
ExtremeWireless™WiNG™ AP-7612 Installation Guide 16

3 Les dispositifs fonctionnant dans la bande 5150-5250 MHz sont réservés uniquement pour une
utilisation à l’intérieur afin de réduire les risques de brouillage préjudiciable aux systèmes de
satellites mobiles utilisant les mêmes canaux;
4 le gain maximal d’antenne permis pour les dispositifs utilisant les bandes 5250-5350 MHz et
5470-5725 MHz doit se conformer à la limite de p.i.r.e.
5 le gain maximal d’antenne permis (pour les dispositifs utilisant la bande 5725-5850 MHz) doit se
conformer à la limite de p.i.r.e. spécifiée pour l’exploitation point à point et non point à point, selon le
cas.
6 Pour une utilisation en intérieur uniquement.
For Mobile Device Usage
Warning
IC Radiation Exposure Statement: This equipment complies with IC RSS-102 radiation
exposure limits set forth for an uncontrolled environment. This equipment should be installed
and operated with minimum distance 24cm between the radiator & your body.
Warning
Déclaration d'exposition aux radiations: Cet équipement est conforme aux limites d'exposition
aux rayonnements IC établies pour un environnement non contrôlé. Cet équipement doit être
installé et utilisé avec un minimum de 24 cm de distance entre la source de rayonnement et
votre corps.
Safety Guidelines
This section contains notices that you must adhere to ensure your personal safety and to prevent any
damage to the equipment.
Caution
The unit and all interconnected equipment must be installed indoors within the same building,
including all PoEpowered network connections as described by Environment A of the IEEE
802.3af standard.
European Waste Electrical and Electronic Equipment (WEEE)
Notice
In accordance with Directive 2012/19/EU of the European Parliament on waste electrical and electronic
equipment (WEEE):
Regulatory Information
ExtremeWireless™WiNG™ AP-7612 Installation Guide 17

1 The symbol above indicates that separate collection of electrical and electronic equipment is
required.
2 When this product has reached the end of its serviceable life, it cannot be disposed of as unsorted
municipal waste. It must be collected and treated separately.
3 It has been determined by the European Parliament that there are potential negative eects on the
environment and human health as a result of the presence of hazardous substances in electrical and
electronic equipment.
4 It is the users’ responsibility to utilize the available collection system to ensure WEEE is properly
treated.
For information about the available collection system, please contact Extreme Customer Support at 353
61 705500 (Ireland).
CE Statement for Mobile Device Usage
Warning
MPE Radiation Exposure Statement: This equipment complies with EU radiation exposure
limits set forth for an uncontrolled environment. This equipment should be installed and
operated with minimum distance 20cm between the radiator and your body.
All operational modes:
2.4GHz: 802.11b, 802.11g, 802.11n (HT20), 802.11n (HT40), 802.11ac (VHT20), 802.11ac (VHT40),
Bluetooth(BR/EDR, LE)
5GHz: 802.11a, 802.11n (HT20), 802.11n (HT40), 802.11ac (VHT20), 802.11ac (VHT40), 802.11ac (VHT80)
The frequency and the maximum transmitted power in EU are listed below:
•2412-2472MHz: 19.84 dBm
•2402-2480MHz (BR/EDR): 9.99 dBm
•2402-2480MHz (LE): 9.63 dBm
•5180-5320MHz: 22.93 dBm
•5500-5700MHz: 29.97 dBm
The device is restricted to indoor use only when operating in the 5150 to 5350 MHz frequency range.
Selling Countries:
Restriction
in
AT BE BG HR CY CZ DK
EE FI FR DE EL HU IE
IT LV LT LU MT NL PL
PT RO SK SI ES SE UK
Regulatory Information
ExtremeWireless™WiNG™ AP-7612 Installation Guide 18

Hazardous Substances
This product complies with the requirements of Directive 2011/65/EU of the European Parliament and of
the Council of 8 June 2011 on the restriction of the use of certain hazardous substances in electrical and
electronic equipment.
Declaration of Conformity in Languages of the European
Community
Hereby, Extreme Networks, Inc. declares that the radio equipment type AP- 7612 is in compliance with
Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following
Internet address: www.extremenetworks.com
Note
Changes or modifications made to this device which are not expressly approved by the party
responsible for compliance could void the user’s authority to operate the equipment.
Regulatory Information
ExtremeWireless™WiNG™ AP-7612 Installation Guide 19

Regulatory Information
ExtremeWireless™WiNG™ AP-7612 Installation Guide 20
