ExtremeWireless™ AP410C Access Point
Installation Guide
9036902-02 Rev AA
December 2021

Copyright © 2021 Extreme Networks, Inc. All rights reserved.
Legal Notice
Extreme Networks, Inc. reserves the right to make changes in specifications and other information
contained in this document and its website without prior notice. The reader should in all cases
consult representatives of Extreme Networks to determine whether any such changes have been
made.
The hardware, firmware, software or any specifications described or referred to in this document
are subject to change without notice.
Trademarks
Extreme Networks and the Extreme Networks logo are trademarks or registered trademarks of
Extreme Networks, Inc. in the United States and/or other countries.
All other names (including any product names) mentioned in this document are the property of
their respective owners and may be trademarks or registered trademarks of their respective
companies/owners.
For additional information on Extreme Networks trademarks, see: www.extremenetworks.com/
company/legal/trademarks
Open Source Declarations
Some software files have been licensed under certain open source or third-party licenses. End-
user license agreements and open source declarations can be found at: https://
www.extremenetworks.com/support/policies/open-source-declaration/

Table of Contents
Preface...................................................................................................................................4
Text Conventions.......................................................................................................................................................... 4
Documentation and Training.................................................................................................................................. 5
Help and Support.........................................................................................................................................................6
Subscribe to Product Announcements.....................................................................................................6
Send Feedback..............................................................................................................................................................6
AP410C Access Point Overview.........................................................................................8
Update the Country Code........................................................................................................................................8
AP410C Features.......................................................................................................................................................... 8
AP410C hardware components.................................................................................................................. 10
Micro USB console port information........................................................................................................10
Reset button details...........................................................................................................................................11
Device physical specifications, radio specifications, and power tables....................................11
Power Profile................................................................................................................................................................. 12
Status LED Activity Description.......................................................................................................................... 12
Install the Access Point......................................................................................................13
Box Contents.................................................................................................................................................................13
Position the Access Point before Installation................................................................................................13
Install the Access Point on a Standard Ceiling Rail....................................................................................14
Non-Standard Ceiling Grid or Wall Installation............................................................................................ 18
Lock the Access Point after Installation......................................................................................................... 22
Regulatory and Compliance Information.......................................................................23
Safety Guidelines....................................................................................................................................................... 23
Japan Indoor Use Statement............................................................................................................................... 23
Japan Voluntary Control Council for Interference (VCCI) - Class B................................................. 24
European Union (EU) Radiation Warning Statement.............................................................................. 24
FCC Notice (Part 15 - Class B).............................................................................................................................26
FCC Radiation Exposure Statement.................................................................................................................26
Brazil Agência Nacional De Telecomunicações (Anatel) Statement................................................26
Mexico Compliance Statement............................................................................................................................27
Industry Canada Statement..................................................................................................................................27
Industry Canada Notice..................................................................................................................................27
Taiwan Regulatory Statement............................................................................................................................. 28
Taiwan Maximum Permissible Exposure (MPE) Warning.............................................................. 28
European Waste Electrical and Electronic Equipment (WEEE) Notice..........................................28
Hazardous Substances............................................................................................................................................29
Supplement to Product Instructions................................................................................................................29
Index....................................................................................................................................30
ExtremeWireless™ AP410C Access Point iii

Preface
Read the following topics to learn about:
•The meanings of text formats used in this document.
•Where you can find additional information and help.
•How to reach us with questions and comments.
Text Conventions
Unless otherwise noted, information in this document applies to all supported environments for the
products in question. Exceptions, like command keywords associated with a specific software version,
are identified in the text.
When a feature, function, or operation pertains to a specific hardware product, the product name is
used. When features, functions, and operations are the same across an entire product family, such as
ExtremeSwitching switches or SLX routers, the product is referred to as the switch or the router.
Table 1: Notes and warnings
Icon Notice type Alerts you to...
Tip Helpful tips and notices for using the product
Note Useful information or instructions
Important Important features or instructions
Caution Risk of personal injury, system damage, or loss of data
Warning Risk of severe personal injury
4ExtremeWireless™ AP410C Access Point

Table 2: Text
Convention Description
screen displays This typeface indicates command syntax, or represents information as
it is displayed on the screen.
The words enter and type When you see the word enter in this guide, you must type something,
and then press the Return or Enter key. Do not press the Return or
Enter key when an instruction simply says type.
Key names Key names are written in boldface, for example Ctrl or Esc. If you must
press two or more keys simultaneously, the key names are linked with a
plus sign (+). Example: Press Ctrl+Alt+Del
Words in italicized type Italics emphasize a point or denote new terms at the place where they
are defined in the text. Italics are also used when referring to
publication titles.
New information. In a PDF, this is searchable text.
Table 3: Command syntax
Convention Description
bold text Bold text indicates command names, keywords, and command options.
italic text Italic text indicates variable content.
[ ] Syntax components displayed within square brackets are optional.
Default responses to system prompts are enclosed in square brackets.
{ x | y | z } A choice of required parameters is enclosed in curly brackets separated
by vertical bars. You must select one of the options.
x | yA vertical bar separates mutually exclusive elements.
< > Nonprinting characters, such as passwords, are enclosed in angle
brackets.
... Repeat the previous element, for example, member[member...].
\ In command examples, the backslash indicates a “soft” line break.
When a backslash separates two lines of a command input, enter the
entire command at the prompt without the backslash.
Documentation and Training
Find Extreme Networks product information at the following locations:
Current Product Documentation
Release Notes
Hardware and software compatibility for Extreme Networks products
Extreme Optics Compatibility
Other resources such as white papers, data sheets, and case studies
Extreme Networks oers product training courses, both online and in person, as well as specialized
certifications. For details, visit www.extremenetworks.com/education/.
Preface Documentation and Training
ExtremeWireless™ AP410C Access Point 5

Help and Support
If you require assistance, contact Extreme Networks using one of the following methods:
Extreme Portal
Search the GTAC (Global Technical Assistance Center) knowledge base; manage support cases and
service contracts; download software; and obtain product licensing, training, and certifications.
The Hub
A forum for Extreme Networks customers to connect with one another, answer questions, and share
ideas and feedback. This community is monitored by Extreme Networks employees, but is not
intended to replace specific guidance from GTAC.
Call GTAC
For immediate support: [phone] (toll-free in U.S. and Canada) or 1 [phone]. For the
support phone number in your country, visit: www.extremenetworks.com/support/contact
Before contacting Extreme Networks for technical support, have the following information ready:
•Your Extreme Networks service contract number, or serial numbers for all involved Extreme
Networks products
•A description of the failure
•A description of any actions already taken to resolve the problem
•A description of your network environment (such as layout, cable type, other relevant environmental
information)
•Network load at the time of trouble (if known)
•The device history (for example, if you have returned the device before, or if this is a recurring
problem)
•Any related RMA (Return Material Authorization) numbers
Subscribe to Product Announcements
You can subscribe to email notifications for product and software release announcements, Field
Notices, and Vulnerability Notices.
1. Go to The Hub.
2. In the list of categories, expand the Product Announcements list.
3. Select a product for which you would like to receive notifications.
4. Select Subscribe.
5. To select additional products, return to the Product Announcements list and repeat steps 3 and 4.
You can modify your product selections or unsubscribe at any time.
Send Feedback
The Information Development team at Extreme Networks has made every eort to ensure that this
document is accurate, complete, and easy to use. We strive to improve our documentation to help you
in your work, so we want to hear from you. We welcome all feedback, but we especially want to know
about:
•Content errors, or confusing or conflicting information.
Help and Support Preface
6ExtremeWireless™ AP410C Access Point

•Improvements that would help you find relevant information.
•Broken links or usability issues.
To send feedback, do either of the following:
•Access the feedback form at https://www.extremenetworks.com/documentation-feedback/.
•Email us at [e-mail].
Provide the publication title, part number, and as much detail as possible, including the topic heading
and page number if applicable, as well as your suggestions for improvement.
Preface Send Feedback
ExtremeWireless™ AP410C Access Point 7

AP410C Access Point Overview
Update the Country Code on page 8
AP410C Features on page 8
Power Profile on page 12
Status LED Activity Description on page 12
Details about AP410C access point.
The AP410C is a high-performance 802.11ax 5G dual band access point designed for indoor high-density
environments. This device supports IEEE 802.11ax Orthogonal Frequency-Division Multiple Access
(OFDMA) multi-user access.
Update the Country Code
Learn how to update the country code on the access point.
If your access point is configured for the World Regulatory (WR) domain, set the country code to the
country in which the access point will be deployed to meet regulatory requirements and for optimal
wireless operation.
Note
The country code selection is for WR models only and is not available to FCC, CAN, and other
country-specific models. Per Federal Communications Commission (FCC) regulations, all Wi-
Fi products marketed in the United States must be set to U.S. channels only.
1. Power on the access point and wait for it to find and connect to ExtremeCloud IQ.
After the access point is connected, it is displayed in the table of devices on the Manage > Devices
page.
2. Select the check box next to the access point, and then choose Assign Country Code from the
Actions drop-down list.
In the dialog box, select the appropriate country from the drop-down list, and then select Save.
3. Upload your changes to the access point.
AP410C Features
The access point has the following features:
•Two LED status lights
8ExtremeWireless™ AP410C Access Point

For LED activity description, see Status LED Activity Description on page 12.
•One light sensor located at the top of the device
•Two Ethernet ports - Eth0 and Eth1
Ethernet ports (Eth0 and Eth1) automatically negotiate half- and full-duplex connections with the
connecting device.
◦Eth0 is 100/1000/2500 BASE-T
◦Eth1 is 10/100/1000 BASE-T
These ports are autosensing and adjust to straight-through and crossover standard Cat5 or better
Ethernet cables automatically. The access point receives power through an Ethernet connection to
the ETH0 port from power sourcing equipment (PSE) that is compatible with the 802.3at and
802.3at standards.
•One USB port
Use the USB port to connect USB-based beacons such as iBeacon and Internet of Things (IoT)
devices.
Remove the screw that secures the protective cover to access the USB port.
•One micro USB console port
For console port information, see Micro USB console port information.
You can order a micro USB console adapter for the AP410C access point using the part number
ACC-WIFI-MICRO-USB.
•One reset button
•One security slot
Tip
The best practice is to use Kensington® locks for locking the device.
•Operating temperature: 0 °C to +40 °C (+32 °F to +104 °F)
•Storage temperature: −40 °C to +70 °C (−40 °F to +158 °F)
•Relative humidity: 10% to 95% non-condensing
AP410C Access Point Overview AP410C Features
ExtremeWireless™ AP410C Access Point 9

AP410C hardware components
Figure 1: AP410C access point hardware components
Table 4: Hardware component description
Callout Description
1 Eth0 PoE+
2 Eth1
3 USB port
4 Console port
5 Reset button
6 Security slot
7 Kensington lock
Micro USB console port information
Use the console port to make a serial connection between your management system and the access
point.
Note
When you connect to the device using the micro USB Console port, the management station
from which you connect to the device must have a VT100 emulation program, such as Tera
Term Pro© (a free terminal emulator) or Hilgraeve HyperTerminal® (provided with Windows®
operating systems from XP forward).
AP410C hardware components AP410C Access Point Overview
10 ExtremeWireless™ AP410C Access Point

Figure 2: Micro-B model console port pin information
Table 5: Micro-B USB pin information
Pin number Pin name and description
1 NC
2 R×D (input to access point)
3 T×D (output to terminal)
4 Signal (GND)
5 Signal (GND)
Reset button details
Use the Reset button to restore the factory default settings.
1. Insert a paper clip or similar tool into the Reset pinhole and press the button.
2. To reboot the device, press the button for 5 seconds.
3. To return the configuration to the factory default settings, press it for at least 10 seconds.
After releasing the button, the indicator light goes dark, and then glows steady amber while the
firmware loads and the system performs a self-test. After the software finishes loading and the
access point has connected to ExtremeCloud IQ, the status indicator glows steady white.
4. To prevent the reset button from resetting the configuration, type this command: no reset-
button reset-config-enable
When this command is enabled, pressing the button for 5 seconds will still reboot the access point,
but pressing it for more than 10 seconds will not reset its configuration.
Device physical specifications, radio specifications, and power tables
For detailed device specifications and radio specifications, refer to the AP410C access point data sheet.
AP410C Access Point Overview Reset button details
ExtremeWireless™ AP410C Access Point 11

Power Profile
Details about 802.af and 802.3at power profile.
Table 6: AP410C power profile details
AP410C 802.3af 802.3at
2.4G radio 2×2 (14 dBm) 2×2 (18 dBm)
5G radio 3×3 (17 dBm) 4×4 (18 dBm)
Sensor radio 2.4G and 5G (15 dBm) 2.4G and 5G (18 dBm)
BLE Enabled Enabled
USB No Yes
2.5G Ethernet Yes Yes
1G Ethernet No Yes
Status LED Activity Description
Details about LED activity for system power, firmware updates, Ethernet and wireless interface activity,
and major alarms.
The AP410C access point has two status lights on the top of the chassis.
Table 7: LED status and activity
Status light color Activity Description
White Steady The device has successfully
established a Control And
Provisioning of Wireless Access
Points (CAPWAP) connection to
ExtremeCloud IQ and is
operating normally
Slow-blinking The device has a CAPWAP
connection to ExtremeCloud IQ,
but is operating on 802.3af
power instead of 802.3at power
Amber Steady The device is initializing,
rebooting, or is running without
a CAPWAP connection
Slow-blinking The device has no CAPWAP
connection to ExtremeCloud IQ,
and is operating on 802.3af
power instead of 802.3at power
Fast-blinking The device is upgrading its
ExtremeCloud IQ firmware
Dark None Power is o
Power Profile AP410C Access Point Overview
12 ExtremeWireless™ AP410C Access Point

Install the Access Point
Box Contents on page 13
Position the Access Point before Installation on page 13
Install the Access Point on a Standard Ceiling Rail on page 14
Non-Standard Ceiling Grid or Wall Installation on page 18
Lock the Access Point after Installation on page 22
AP410C access point pre-installation checklist.
About This Task
Install the access point on a flat surface such as a wall or to a standard dropped ceiling grid rail. For
bracket and accessories information, see Extreme Networks 11.ax Access Points Accessories Guide.
Procedure
1. Verify the box contents.
2. Visually inspect the access point, the bracket, and any other optional accessories you have ordered
for physical damage.
If there is any damage, contact Extreme Networks Support.
3. Read and review the safety guidelines.
Box Contents
Details about AP410C access point box contents.
When you purchase the access point, ensure that the following items are available in the box:
•An AP410C access point
•Mounting bracket for Prelude (15/16 in. ceiling grid) T-bar ceiling installation (part number AH-ACC-
BKT-AX-TB)
•Read Me card
Position the Access Point before Installation
Details about access point pre-installation position.
There is a red dot on the back of the access point and the bracket that will work as a guide to position
the access point for installation. Line up the red dot on the access point and the bracket for ease of
installation.
ExtremeWireless™ AP410C Access Point 13

Install the Access Point on a Standard Ceiling Rail
Install the access point on a standard 15/16 in. dropped ceiling rail.
Before You Begin
Hardware requirements for standard ceiling rail install:
•An AP410C access point
•An AH-ACC-BKT-AX-TB bracket
•AH-ACC-BKT-AC-KIT adapter, when the ceiling rail protrusion is 1/8 in. or ¼ in.
About This Task
The AP410C access point ships with a mounting bracket for standard dropped ceiling rail installation.
You must use the AH-ACC-BKT-AC-KIT adapter with the -TB bracket when there is a 1/8 in. or ¼ in.
ceiling rail protrusion.
Procedure
1. Remove the ceiling tiles.
2. Put together the AH-ACC-BKT-AC-KIT protruded ceiling tile bracket set parts.
Note
If you are not using the -KIT bracket set, go to Step 4 of this procedure.
a. Insert the bracket tabs into the slots.
Ensure that the locking tabs slide smoothly one behind the other.
Figure 3: Locking tabs and bracket slots
Callout Description
1 Bracket tabs
2 Bracket slots
3 Locking tabs
b. Slide the two bracket halves in the direction shown in the following figure.
Install the Access Point on a Standard Ceiling Rail Install the Access Point
14 ExtremeWireless™ AP410C Access Point

Figure 4: Bracket halves attachment procedure
c. When the locking tabs click into place, the bracket ends will line up.
Figure 5: AH-ACC-BKT-AC-KIT protruded ceiling tile bracket parts attached
together
Note
When the bracket parts are put together properly, the parts are interlocked in three
places and is locked together as a single piece.
3. Using the bracket guide on the top half of the AH-ACC-BKT-AC-KIT, align and attach the -KIT on the
ceiling rail.
a. Align the -TB accessory back metal hinges on the bottom half of the AH-ACC-BKT-AC-KIT.
b. Rotate the -TB accessory clockwise until the metal hinges hook over the -KIT bracket part and
clicks in place.
4. If you are not using the AH-ACC-BKT-AC-KIT, attach the -TB accessory directly onto the ceiling rail.
a. Align the accessory on the ceiling rail in such a way that the accessory metal hinges are almost
parallel to the sides of the ceiling rail.
b. Rotate the accessory clockwise until the metal hinges hook over the edge of the rail and the
white tabs click in place.
Note
There are two white tabs in the back of the accessory that holds on to the ceiling rail in
place. Use your finger to push and unhook one side of the white tab if you want to
remove the accessory from the ceiling rail.
Install the Access Point Install the Access Point on a Standard Ceiling Rail
ExtremeWireless™ AP410C Access Point 15

Figure 6: AH-ACC-BKT-TB accessory
Callout Description
1 Metal hinges on the AH-ACC-BKT-AX-TB
accessory
2 Mounting holes for wall mounting
3 White tab on the AH-ACC-BKT-AX-TB accessory
5. Attach the Ethernet port cap to the access point Ethernet port.
For more information about Ethernet cap, refer to Ethernet Cap Accessory Information on the WiFi
6 802.11ax Access Points Accessories Guide.
Install the Access Point on a Standard Ceiling Rail Install the Access Point
16 ExtremeWireless™ AP410C Access Point

6. Align the red dot on the back of the access point against the bracket red dot.
Note
The accessory has a circular tip that fits into the circular depression on the back of the
access point.
Figure 7: Access point alignment against the red dot on the -TB bracket
7. Press and rotate the access point 1/8th turn clockwise until it clicks into place on the accessory.
Figure 8: AP410C access point ceiling install
8. Attach the Cat6 RJ45 cable to the ETH0 or ETH1 port.
Install the Access Point Install the Access Point on a Standard Ceiling Rail
ExtremeWireless™ AP410C Access Point 17

9. Place the cable cover over the Ethernet cable.
10. Replace the ceiling tiles.
Non-Standard Ceiling Grid or Wall Installation
Details about non-standard ceiling grid or wall installation using optional bracket and accessory.
Note
For all non-standard ceiling grid installation or wall installation instructions, refer to the Wi-Fi
6 802.11ax Access Points Accessories Guide.
Non-Standard Ceiling Grid or Wall Installation Install the Access Point
18 ExtremeWireless™ AP410C Access Point

The access point can be installed on a non-standard ceiling grid using the following accessories:
Order part number Description
AH-ACC-BKT-AX-TB Mounting bracket for Prelude ceilings (15/16 in.
ceiling grid), Suprafine ceilings (9/16 in. ceiling
grid), and walls
AH-ACC-BKT-AX-IL Mounting bracket for Interlude (9/16 wide T-bar
with protrusion) ceilings
Install the Access Point Non-Standard Ceiling Grid or Wall Installation
ExtremeWireless™ AP410C Access Point 19

Order part number Description
AH-ACC-BKT-AX-SL Mounting bracket for Silhouette ceilings (ceiling
grid with 1/8 in. or 1/4 in. bottom opening)
ACC-BKT-AX-JB Junction box or wall mounting for indoor access
points
Non-Standard Ceiling Grid or Wall Installation Install the Access Point
20 ExtremeWireless™ AP410C Access Point
