Extremis Bistroo User manual

MANUAL
LAB142
Assembly instructions, how to use, useful tips for keeping
your tool for togetherness in shape.
EN – NL – DE – FR – IT – ES
Bistroo

Tools for togetherness
© All our designs are original creations and protected by intellectual property rights.

IMPORTANT! RETAIN FOR FUTURE
REFERENCE: READ CAREFULLY.
BELANGRIJK! LEES DIT DOCUMENT
AANDACHTIG EN BEWAAR HET VOOR
TOEKOMSTIGE RAADPLEGING!
WICHTIG! AUFHEBEN, UM SPÄTER
ETWAS NACHSEHEN ZU KÖNNEN:
SORGFÄLTIG DURCHLESEN!
IMPORTANT! LISEZ ATTENTIVEMENT
CE MANUEL ET CONSERVEZ-LE POUR
RÉFÉRENCE ULTÉRIEURE!
IMPORTANTE! CONSERVARE COME
RIFERIMENTO PER IL FUTURO:
LEGGERE ATTENTAMENTE!
¡IMPORTANTE! CONSÉRVELO PARA
FUTURA REFERENCIA: LÉALO
ATENTAMENTE!

Do not use
power tools!

Table of contents
Mounting kit
6
Exploded view
8
Assembly Bistroo with purse hanger & stacking spacer
10
Assembly table tray
15
Assembly cushion
15
Assembly floor fastening
16
Warnings – Assembly text instructions – Maintenance
20
Parts list
32

6
Mounting kit
x 4
x 4
x 4x 4
scale 1:1
scale 1:1
scale 1:1
M6x10 din 7984
M8x20 din 7984
M8x30 din 7984
BIS345
BIS344
BIS346
2x
VRS703
BIS347
Mounting kit to fix tabletop
to centre leg
Mounting kit to
fix centre leg
support to
centre leg
Mounting kit to fix legs & back
support to centre leg support
x 4
M6 din 137b
x 4
x 3
x 4
x 3
scale 1:1 scale 1:1
M6 din 137b
M6 din 137b
M6x12 din 7984
M6x12 din 7984
Mounting kit to fix seat
to leg
Mounting kit to fix backrest
to back support
M8 din 985

7
Floor fastening (optional)
x 3
x 3 x 3
x 3
scale 1:1
M8x50 iso 4017
Mounting kit to fix floor fastening to legs
BIS024

8
1
8
3
6
5
2
4
7
Exploded view

9

2.
10
N° 13
N° 4 - 5
35’
scale 1:2scale 1:2
BIS345
BIS344
p 14
1. Use a blanket as protection
Assembly Bistroo
x 4 x 4
x 4
M6 M6x10
M8x20
1
3
2

3b.
11
3a.
On the
outside
Insert
bolts
scale 1:2
BIS347
x 4x 4
M8x30M8
4

12
4b.
4a.
6
5
1. Insert
all nuts
2. Tighten
both sides
scale 1:2
BIS347
x 4x 4
M8x30M8

13
x 4
5.
x 8 x 8
scale 1:2
M6 M6x12
VRS703
1
2
3
8 Nm
4kg/8,8lb
MAX!
4
8 Nm
7

14
6.
x 6 x 6
scale 1:2
M6 M6x12
BIS346
8

15
Assembly table tray
1.
Assembly cushion
1.

16
2a.
N° 34
10’
Assembly floor fastening
1.
p 15
2b.

17
4.
3.
x 3

18
6.
5.

19

20
English
WARNINGS
General
• Do not use any sharp tools to open the packaging.
• We strongly advise against using power tools.
• Tripping hazard, mind your step.
• Do not put out cigarettes on the table.
• Not grafitti proof.
• Do not leave children unattended whilst playing on
the chair.
• Colours can dier over years and from batch to
batch.
Product
• Anchoring the product has to be done by qualified
people.
• For anchoring: use suitable bolts or screws from a
specialized store depending on the material your
terrace is made of.
• Stackable up to 4 pieces.
• Always stack the tables with 2 people.
• Only use Extremis accessories.
• Do not sit on the tabletop.
• Do not stand or jump on the seat or the tabletop.
• Max. 1 person or 120 kg per seat.
Powder-coating
• White powder-coating requires more
maintenance.
• Do not use abrasive scouring powders or scourers
as they will scratch the surface.
• Colour can fade to some extent when exposed to
UV.
• Flame retarding - NEN-EN13501-1 A2-sl -
Satisfying the same criteria as Class B for the
SBI-test according to EN13823. In addition, under
conditions of a fully developed fire these products
will nog significantly contribute to the fire load
and fire growth.
• Dark colors can get very hot in sunny weather.
Felt
• Stains should be removed immediately with a
clean, soft cloth, particularly in case of dark-
coloured liquids such as wine, ink, coee coke,
oild and bird droppings. If left to dry, these liquids
may cause permanent damage!
• Do not bleach to clean.
ASSEMBLY INSTRUCTIONS
Bistroo - p10
1. Lay the tabletop upside down on the ground with
the holes facing upwards and use a blanket for
protection. Position the centre leg on the tabletop
so that the holes align and attach it with 4 M6
wave washers and 4 M6x10 bolts. Caution: make
sure that the cut-out of the centre leg is on the
same side as the cut-out of the tabletop.
2. Position the logo frame in the central leg as shown
in the drawing, with the rubber stacking caps
facing upwards and fasten with 4 M8x20 bolts.
3. a. Next, position the backrest on the logo frame.
b. NoInsert the M8x30 bolts through the holes of
the logo frame and the backrest so that it stays in
position. Do not use any nuts yet.
4. a. Now slide the left and right leg over the bolts, as
shown in the drawing.
b. Fasten them with 2 M8 nuts each.
5. Attach the seats to the legs, each with 4 M6x12
bolts and 4 M6 wave washers as shown in the
drawing. Caution: Tighten the bolts diagonally as
shown in the drawing, but not too hard! Max. 8Nm
or 4 kg / 8,8 lb.
6. Turn the table over so that it is standing on 3 legs.
Attach the 2 backrests to the back support using 3
M6 wave washers and 3 M6 bolts.
Table tray - p15
1. Position the table tray in the cut-out of the
tabletop.
Cushion - p15
1. Position the cushion on the seat so that the
silicone plug of the cushion fits into the hole of
the seat.
Floor fastening - p16
1. Turn the table upside down.
2. a. Drill a hole in the plastic cap.
b. Now pull the plastic cap out using a screwdriver
as shown on the drawing.
3. Assemble the ground anchoring set as shown in
the drawing. Do not completely tighten the bolt
yet.
4. Mark the places on the ground where the
anchoring is to be located and drill at the
indicated points.
5. Use the most appropriate fasteners for the surface
on which the Bistroo is to stand.
6. Tighten all the bolts by tightening the plastic cap
Warnings – Assembly text instructions – Maintenance
