Extremis Hopper picnic 2 User manual

Hopper
picnic

IMPORTANT! RETAIN FOR FUTURE
REFERENCE: READ CAREFULLY.

Table of contents 1/2
Mounting kit 
Exploded view 
Assembly Hopper picnic 
Assembly backrest 
This is an interactive PDF
You can easily navigate through this manual, allowing you to
smoothly jump from one page to the other.

Table of contents 2/2
Assembly floor fastening set 
Assembly floor fastening 
Warnings - Text instructions -
Maintenance 
This is an interactive PDF
You can easily navigate through this manual, allowing you to
smoothly jump from one page to the other.

6
11 x M10
11 x M10x30
11 x M10
11 x M1011 x M10
Mounting kit HOP571 to fix
aluminium legs to tabletop & bench
Mounting kit HOP157 to fix
galvanized legs to tabletop & bench
Mounting kit

7
2 x M10 6 x 5x25
2 x M10x402 x M10
Mounting kit HOW417
to fix aluminium
supports to bench
Mounting kit HOP152 to
fix backrest slat to the
supports
Mounting kit HOP478 to fix
galvanized supports to bench

8
Exploded view

9
2.
1.
Hopper picnic
N° 17
45’

2.
The packaging material must stay intact for
the rest of the assembly!

10
3.
4.

11
5.
6.

12
7a.
12 x M10x3012 x M1012 x M10
HOP157
With galvanized legs

13
7b.
HOP571
12 x M1012 x M10
15 Nm
MAX!
With powder coated aluminium legs
Tighten carefully!
Excessive force may
damage the coating!

14
8.
Remove packaging before mounting the benches
9a. Go to page 18 if you want to assemble a backrest 

15
9b.

16
10a.
8 x M10x308 x M108 x M10
HOP157
With galvanized legs

17
10b.
HOP571
8 x M108 x M10
15 Nm
MAX!
With powder coated aluminium legs
Tighten carefully!
Excessive force may
damage the coating!

18
1a.
15’
With galvanized legs
Remove these bolts, nuts and spring washers
at the outside of the bench
Backrest

19
1b.
Remove these bolts, nuts and spring washers
at the outside of the bench
With powder coated aluminium legs

20
2a.
HOP478
2 x M10x402 x M10
With galvanized legs
