Extron electronics OCS 100C User manual

1
IMPORTANT:
Go to www.extron.com for the
complete user guide, installation
instructions, and specifications.
Occupancy Sensor OCS 100C • Setup Guide
The OCS 100C is a ceiling mounted occupancy sensor that incorporates ultrasonic (US) and passive infrared (PIR) into a dual
technology sensor. The US sensor emits ultrasonic sound waves into an area and measures the speed of their return to detect
the presence of people. Frequency changes are caused by the movement of people, which is detected by the US waves. The PIR
sensor detects the presence of people based on the difference between the heat generated by moving people versus the ambient
room temperature.
The OCS 100C has a 24 VDC power input, ground/common connection, normally open/closed relay, photocell, and occupancy
output connections.
Front Panel Features
Blue Photocell Dial
Red Infrared
Sensitivity Dial
Black
Timer Dial
Green Ultrasonic
Range Dial
DIP Switches (B)
DIP Switches (A)
Ultrasonic
Sensors
Green LED
(status indicator)
Green LED
(status indicator)
Retainer Ring
al
D
I
P
A)
1
A
2
3
4
ON ON
1
B
2
3
4
1234
1234
Infrared/Photocell
Lens
Figure 1. OCS 100C Front Panel Features
Control
Blue Photocell Dial
Red Infrar
ed
Sensitivity Dial
Black
Timer Dial
Green Ultrasonic
Range Dial
DIP Switches (B)
DIP Switches (A)
Ultrasonic
Sensors
Green LED
(status indicator)
Green LED
(status indicator)
Retainer Ring
al
D
I
P
A)
1
A
2
3
4
ON ON
1
B
2
3
4
1234
1234
Infrared/Photocell
Lens
Figure 2. OCS 100C Controls
The settings for DIP Switches B3 (timer adjust) and B4
(sensitivity adjust) can be set to:
• Automatic mode — The sensors automatically adjust for
changes in usage and seasons, eliminating the need for
manual adjustments and improving system performance.
• Manual mode — The user sets the parameters of the
sensors using the following dials.
NOTE:
• The black timer dial is inactive when the B3 timer adjust DIP Switch is in Automatic mode.
• The red infrared sensitivity dial and green ultrasonic range dial are inactive when the B4 sensitivity adjust DIP Switch is
set to Automatic mode.
• Ultrasonic sensors (4) — Detect movement in the room, based
on ultrasonic sound waves.
• Green LED status indicators (2) — Flash when the ultrasonic
sensors detect occupancy.
• Infrared/Photocell lens — Diffracts the incoming light and
directs the light to the infrared/photocell sensor. The infrared/
photocell sensor, controls and DIP switches are located behind
the lens.
• Red LED status indicator — Located behind the
infrared lens, this LED ashes when the infrared sensor
detects occupancy.
• Retainer Ring — Holds the optional IR mask in place. Remove
to access all controls and DIP switches.
1
2
• DIP Switches A —
A OPERATION OFF ON
1Not used Not used* Not used
2Threshold Auto threshold
adjustment*
High
sensitivity
(low turn on
threshold)
3LED indicators LEDs enabled* LEDs
disabled
4Automatic adjust reset Toggle to reset (Default: OFF)
*Default
• DIP Switches B —
B OPERATION OFF ON
1Strong airow
compensator
Disabled* Enabled
2Over doorway mount Disabled* Enabled
3Timer adjust Automatic Manual*
4Sensitivity adjust Automatic Manual*
*Default

2
Occupancy Sensor OCS 100C • Setup Guide (Continued)
• Black Timer Dial (see figure2 on the previous page) — The occupancy sensor has a built in timer feature. When the sensor
detects motion, it instantly triggers ON (high).
Once occupancy is no longer detected, the timer begins. If no motion is detected and the timer expires, then the sensor
triggers OFF (low).
Use the black timer dial to set the amount of time before the sensor triggers OFF.
NOTE: B3 DIP Switch must be set to ON for Manual mode, in order to adjust the timer manually.
• Ranges from 8 minutes to 42 minutes.
• Full counter clock wise (CCW) = 8 minutes
• Full clock wise (CW) = 42 minutes
• To enter the test mode (8 second timer) follow the steps below:
1. Open the retainer ring.
2. Rotate the black timer dial to about midway (12 o’clock).
3. Return to minimum setting (full CCW).
4. The timer will remain in the 8 second test mode for 1 hour, then automatically reset to 8 minutes.
5. To manually force the timer out of the 8 second test mode, turn the timer adjustment approximately 1/16 inch
clockwise. The setting is slightly above minimum (just above the 8 minute setting.
• Red Infrared Sensitivity Dial — Adjust this dial to increase or decrease infrared sensitivity.
• Turn clockwise (CW) to increase sensitivity.
• Turn counter clockwise (CCW) to decrease sensitivity.
• The factory default setting is at 75%.
• Green Ultrasonic Range Dial — Adjust this dial to increase or decrease ultrasonic sensitivity.
• Turn clockwise (CW) to increase sensitivity.
• Turn counter clockwise (CCW) to decrease sensitivity.
• The factory default setting is at 50%.
NOTE: B4 DIP Switch must be set to ON for Manual mode, in order to adjust the Red Infrared Sensitivity Dial or the Green
Ultrasonic Range Dial manually.
• Blue Photocell Dial — The photocell prevents the sensor from turning on when the area is adequately lit with natural light
and motion is detected. The sensor must be mounted directly over an area that is representative of the average, natural room
lighting. Before setting the photocell control, wait until the natural light is brightest (optional). Adjust this dial to increase or
decrease photocell sensitivity.
• Turn counter clockwise to decrease photocell sensitivity, causing it to activate with less light.
• Turn clockwise to increase photocell sensitivity, requiring brighter light to activate the sensor.
• Factory default is 100% (full clockwise).
• Full clockwise — Photocell sensor is disabled.
• Range — 10 to 1000 LUX

3
Mask Patterns and Sensor Coverage
An infrared mask may be needed to achieve the desired sensory coverage. Any area masked will block the PIR sensor from
detecting motion in that area.
Center Ceiling Mount
(mask blocks sensor seeing
out doorway into hallway)
Corner Ceiling Mount
(no mask needed)
Typical Mask Patterns
Using the Infrared Mask
Conference
Room Mask
Rectangular
Areas
Over the Door Specific Areas to Mask
180º Mask Full Mask
32'
(10 m)
23'
(7 m)
64'
(20 m)
45'
(14 m)
12'
(4 m)
22'
(7 m)
Sensory Coverage
US Minor Motion
US Major Motion
IR Minor Motion
IR Major Motion
Hallway Hallway
Specific Area
Masked
No Mask Needed
U.S.Patents: 6151529, 5946209, 5699243, 5640143, 6415205,
6078253,D404326, 6222191, 5986357, 6759954
67E4
ApplianceControl
3
(maxDisabled)
Threshold
NotUsed
OCS 100C
68-3155-52 Rev.A
ExtronHeadquarters +1.800.633.9876(Inside USA/Canada Only) ExtronUSA - West
+1.714.491.1500 +1.714.491.1517FAX
www.extron.com
Centerof
SensorCoverage
Figure 3. Mask Patterns and Sensor Coverage Diagrams
3
NOTE: These coverage dimensions are achieved when the
OCS100C is installed 10 feet (3 m) above the coverage area.

4
Occupancy Sensor OCS 100C • Setup Guide (Continued)
Installation
Insert wiring through
cover plate.
Insert wiring through
mounting post.
Ceiling
Ceiling
Ceiling
Cutting End
Mounting
Post
Threaded
Mounting Post
Nut
Washer
Cover Plate
Cover Plate
Cover Plate
Sensor Body
Sensor Body
Conference Room
Mask *
*
*
Full Mask
180º Mask
Infrared Lens w/
Retainer Ring
Sensor Body
Mounting Bolts (2)
Nut and Washer (2 ea)
Ceiling
B
od
y
Screw and mount the
twist-lock cover plate.
Secure cover
plate to the ceiling.
1
Twist and lock threaded
mounting post into the
cover plate. Drill into
ceiling tile.
2
4
Secure mounting
post to the ceiling tile with
nut and washer.
Connect building wiring to
wiring harness with wire nuts.
2
4
3
Attach sensor body to cover plate
by aligning arrows and twist lock
into place.
5
Connect building wiring to
wiring harness with wir
e nuts.
3
Installation Method 1
Installation Method 2
OCS 100C Parts
S
C
30˚ Adjustment
1
U.S. Patents:6151529, 5946209, 5699243, 5640143, 641 5205,
6078253, D404326, 6222191, 5986357, 6759954
67E4
Appliance Control
OCS 100C
68-3155-52 Rev. A
Extron Headquarters
+1.800.633.9876 (Inside USA/Canada Only)
Extron USA - West Made in China
+1.714.491.1500 +1.714.491.1517 FAX
www.extron.com
Center of
Sensor Coverage
A1 Not Used
A2 Threshold: OFF = low sensitivity, ON = high sensitivity
A3 LED Control: OFF = LEDs active, ON = LEDs disabled
A4 Automatic Adjust Reset: Toggle to reset
B1 Strong Airow Compensator: OFF = disable, ON = enable
B2 Over Doorway Mounting: OFF = disable, ON = enable
B3 Timer Adjust: OFF = automatic, ON = manual
B4 Sensitivity Adjust: OFF = automatic, ON = manual
Switch Settings: All switches OFF for full automatice operation
Relay Contacts:
Blue/White = common
Black/White = N.C.
Yellow/White = N.O.
Black : Ground
Red: +24VDC
Blue: Occupancy control output
Grey: Occupancy &
Photocell control
output
Connections
Red: Infrared Range - 75% Default
Black: Timer - 8 min to 42 max - min Default
Green: Ultrasonic Range -50% Default
Blue: Photocell - max Default
Adjustment Knobs
Match either arrow shown here
with the arrow on the twist-lock cover
plate. Then inserts the tabs into
the slots. Twist until
ratchet action indicates
engagement.
R
a
n
g
e
o
f
a
d
j
u
s
t
m
e
n
t
(
c
l
i
c
k
t
u
r
n
)
Figure 4. Installation Diagram
4
NOTE: *Only use a mask if the PIR sensor needs to be blocked.
Only one mask should be installed at any given time.
ATTENTION:
• All structural steps and electrical installation must be
performed by qualied personnel in accordance with local
and national building codes and electrical codes.
• Toute étape structurelle et installation électrique, doit être
effectuée par un personnel qualié, conformément aux
codes du bâtiment, aux codes incendie et sécurité, et aux
codes électriques, locaux et nationaux.

5
Connections
Black Ground
Red +24 VDC
Blue Occupancy control output
Gray Occupancy and photocell
control output
NOTE:
• The gray wire is used when
the control system needs
to know when the area is
adequately lit with natural
light and when motion is
detected (for example,
automatic lighting control
through an Extron control
system).
• When wiring the blue or gray
wires of the OCS to Extron
products with Digital or FLEX
Input ports, congure the
ports as Input without pull
up. The sensor provides
approximately 21 VDC in the
ON (High) state and 0 VDC in
the OFF (Low) state.
NOTE: Relay contacts could be used to trigger third party
devices, such as HVAC, based on occupancy.
OCS 100C Wiring Diagram
Extron
IPCP PRO 550
Control Processor
Dual Zone
Single Zone
RO
5
50
LAN
IPCP PRO 550
MAC: 00-05-A6-XX-XX-XX S/N: ####### E######
00-05-A6-XX-XX-XX
5A MAX
100-240V ~ 50-60Hz
1 1 2 3 72 1 2 3 4 1 2 3 4PWR OUT = 9W
eBUS
+V +S -S GTx Rx GTxRxG Tx Rx GTxRxG SGSG SGSG RTSCTS
SWITCHED 12 VDC
40W MAX TOTAL
3 4 8
4 5 6 5 6 7 8 5 6 7 83214G
FLEX I/ORELAYSIR/SERIALCOM12 VDC
SGSG SGSGTx Rx GTxRxG Tx Rx GTxRxG
RTSCTS
ECM DIO8
BUS ID
eBUS + V OUT
24 GG-S+S+V
DIGITAL I/O
1234GG6578
L
S
B
M
S
B
Ext
ron
ECM DI
O8
eBUS
Control Module
Extron
PC 1224
Power Module Extron
OCS 100C
Occupancy
Sensor 2
Extr
on
Extron
OCS 100C
Occupancy
Sensor
Extron
Extron
OCS 100C
Occupancy
Sensor 1
Extr
on
Control Signal #2 (Blue)
Control Signal #1 (Blue)
Sensor with 12 VDC
Power Supply
Sensor with 24 VDC
Power Supply
Control Signal #1 (Blue)
Ground
(Black)
Ground
(Black)
Ground (Black)
Ground (Black)
+24 V (Red)
+24 V (Red)
+12 V (Red)
Et
1.25 A MAX 75 mA MAX
1.5 A MAX
PC 1224
33-2665-01 B
www.extron.com
24V
OUT
12V
OUT
12V
IN
Figure 5. OCS 100C Wiring Diagram
Relay Contacts
Blue/White Common
Black/White Normally closed when unoccupied
Yellow/White Normally open when unoccupied
PC 1224 Wiring
ATTENTION:
• Do not connect power until you have read the ATTENTIONS: notices on the next page.
• Ne branchez pas l’alimentation avant d’avoir lu les mises en garde «ATTENTIONS » de la page suivante.
• Remove power from the system before making any connections.
• Mettez le système hors tension avant d’effectuer tout raccordement.
The OCS 100C requires 24 VDC. If the sensors are connected to a device that does not provide 24 VDC, use the included
PC1224 power module:
1. Connect a 12 VDC power source to the 12 VDC input on the supplied PC 1224 power converter,
using a 2-pole captive screw connector.
2. Wire the PC 1224 24 VDC 2-pole captive screw connector to the black and red wires on the
OCS100C.
A 12 VDC pass-through is available to power additional 12 VDC devices.
5
Extron
PC 1224
Power Module
12 V Power
Source
Additional
Devices
Occupancy
Sensor
1.25 A MAX 75 mA MAX
1.5 A MAX
PC 1224
33-2665-01 B
www.extron.com
24V
OUT
12V
OUT
12V
IN

68-3155-51 Rev. E
02 18
© 2017-2018 Extron Electronics — All rights reserved. www.extron.com
All trademarks mentioned are the property of their respective owners.
Troubleshooting
Problem Possible Cause Test Solution
Sensor remains on. Constant noise. Reduce both green and red
knobs by 1/4 turn and remove
noise source.
Move sensor to a less noisy
area within the room.
Sensor remains on too long. Timer setting is too high. Check DIP switch settings. Reduce timer setting.
Hallway trafc turns sensor
on.
Infrared sensor can see into
the hallway.
Put sensor in timer test mode
and walk the hallway.
Move sensor, so it cannot see
into the hallway.
Safety Instructions
For information on safety guidelines, regulatory compliances, EMI/EMF compatibility, accessibility, and related topics, see the
Extron Safety and Regulatory Compliance Guide on the Extron website.
FCC Class A Notice
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the
FCC rules. The Class A limits provide reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used
in accordance with the instruction manual, may cause harmful interference to radio communications. Operation of this equipment
in a residential area is likely to cause interference. This interference must be corrected at the expense of the user.
NOTE: For more information on safety guidelines, regulatory compliances, EMI/EMF compatibility, accessibility, and related
topics, see the Extron Safety and Regulatory Compliance Guide on the Extron website.
Power Attentions
ATTENTIONS:
• These products are intended for use with a UL Listed LPS type power source.
• Ces produits doivent être utilisés avec une source d’alimentation de type LPS certiée UL.
• Use of a non-LPS or unlisted power supply will void all regulatory compliance certication.
• L’utilisation d’une source d’alimentation non-listée ou non-listéeLPS annulera toute certication de conformité
réglementaire.
• Unless otherwise stated, the AC/DC adapters are not suitable for use in air handling spaces or in wall cavities. The power
supply is to be located within the same vicinity as the Extron AV processing equipment in an ordinary location, Pollution
Degree 2, secured to the equipment rack within the dedicated closet, podium, or desk.
• Sauf mention contraire, les adaptateurs CA/CC ne conviennent pas à une utilisation dans les espaces d’aération ou dans
les cavités murales. La source d’alimentation doit être placée à proximité de l’équipement Extron dans un emplacement
ordinaire soumis à un degré de pollution de catégorie II, solidement xé au rack d’équipement d’une baie technique, d’un
pupitre, ou d’un bureau.
• The installation must always be in accordance with the applicable provisions of National Electrical Code ANSI/NFPA 70,
article 725 and the Canadian Electrical Code part 1, section 16.
• Cette installation doit toujours être conforme aux dispositions applicables du Code américain de l’électricité (National
Electrical Code) ANSI/NFPA 70, article 725, et du Code canadien de l’électricité, partie1, section16.
• The power supply shall not be permanently xed to building structure or similar structure.
• La source d’alimentation ne devra pas être xée de façon permanente à la structure de bâtiment ou à d’autres structures
similaires.
