Extron electronics DMP Plus Series User manual

DMP Plus Series / C V Models
DMP Plus Series / C V AT Models
Patton POTS Configuration Guide
REVISION: 1.0.0
DATE: OCTOBER 16, 2020

Revision Date:
10/16/2020
Page 2 of 28
DMP Plus Series C V / C V AT – Patton POTS
Revision Log
Date
Version
Notes
Oct 16, 2020 1.0.0 Initial Release

Revision Date:
10/16/2020
Page 3 of 28
DMP Plus Series C V / C V AT – Patton POTS
Table of Contents
1.0 Introduction ......................................................................................................................... 5
1.1 Overview of setup ............................................................................................................ 5
1.1.1 Features supported................................................................................................... 5
1.1.2 Features not supported ............................................................................................ 5
1.1.3 DMP Plus Setup......................................................................................................... 5
1.1.4 Patton POTS interface............................................................................................... 6
1.1.5 Wiring........................................................................................................................ 6
2.0 Configuring Patton POTS interface for DMP Plus Series C V (AT) VoIP ............................... 7
2.1 Ordering Information ....................................................................................................... 7
2.1.1 Patton SN4112/JO/EUI - VoIP Gateway 2 FXO Ports ................................................ 7
2.1.2 Firmware used during testing: R6.11 2019-07-02 ................................................... 7
2.2 Setting IP address on Patton............................................................................................ 7
2.2.1 Setting the IP address via DataViewer...................................................................... 7
2.3 Upload configuration into Patton POTS interface ........................................................... 9
2.3.1 Login to Webpage ..................................................................................................... 9
2.3.2 Patton Firmware/Software ....................................................................................... 9
2.4 Upload configuration File............................................................................................... 11
2.4.1 To restart / reload, select Reload in the lower left ................................................ 12
2.4.2 If any changes are made, they will need to be saved to the startup-config .......... 12
2.5 Adjust auto hang-up / Call disconnection...................................................................... 13
2.5.1 Adjust auto hang-up and Call disconnection if necessary ...................................... 13
3.0 Configuring DMP Plus Series C V (AT) VoIP Lines .............................................................. 14
3.1 Network Interface Configuration ................................................................................... 14
3.2 Transport Configuration................................................................................................. 16
3.3 Line Registration............................................................................................................. 17
3.4 Codecs ............................................................................................................................ 18
3.5 Dialing............................................................................................................................. 19
3.6 System Overview............................................................................................................ 20
3.7 Troubleshooting ............................................................................................................. 20

Revision Date:
10/16/2020
Page 4 of 28
DMP Plus Series C V / C V AT – Patton POTS
Appendix A: Configuration Files – Attached to PDF ..................................................................... 21
Appendix B: How to manually set the IP address of the Patton SN4112................................... 22
Appendix C: How to import configuration into DMP Plus............................................................ 23
Appendix D: Patton RS-232 Cable wiring detail............................................................................ 24
Appendix E: Copy of DMP Plus VoIP Configuration ...................................................................... 25
Appendix F: Copy of Patton configuration.................................................................................... 26

Revision Date:
10/16/2020
Page 5 of 28
DMP Plus Series C V / C V AT – Patton POTS
1.0 Introduction
This document provides essential instructions for configuring the VoIP lines of DMP Plus Series,
C V and C V AT models, with the Patton SN 4110 Series FXO.
DMP Plus Relates to the following products:
•DMP 128 Plus C V / C V AT
•DMP 128 FlexPlus C V AT
•DMP 64 Plus C V / C V AT
1.1 Overview of setup
VoIP Line 1 in the DMP Plus will be directly connected to the LAN interface of the Patton POTS
interface. This does not need to be connected to a network. The DMP Plus will not register to a
call server or Patton POTS interface.
The DMP Plus and Patton POTS interface need to be located on the same subnet / VLAN
Features supported
•POTS interface will support a single POTS line on FXO Port 0/0
•Hold is supported
1.1.1 Features not supported
•3-Way calling is not supported
•Hook Flash is not supported
•VoIP Dialer in DSP Configurator Software will not work since the line does not
register to a call server.
1.1.2 DMP Plus setup
•Firmware: 1.06.0000 or Higher
•Line 1: Ext 1001
•LAN2 IP address: 192.168.1.254 / 255.255.255.0
•LAN2 port of the DMP Plus
Figure 1 DMP 64 Plus C V AT – Rear
Figure 2 DMP 128 Plus C V AT - Rear
LAN
2
LAN
2

Revision Date:
10/16/2020
Page 6 of 28
DMP Plus Series C V / C V AT – Patton POTS
1.1.3 Patton POTS interface
•LAN port
•IP Address: 192.168.1.253 / 255.255.255.0
•Firmware: R6.11 2019-07-02
1.1.4 Wiring
•Using a CAT5/6 network cable
oDirectly connect LAN 2 of DMP Plus to
oPatton 10/100 ENET port / ETH 0/0 port
Figure 3 DMP 64 C V AT Plus Figure 4 Patton SN4112/JO/EUI
•Connect the analog Telephone POTS line to the Voice Port FXO 0/0
oPort 1
Figure 5 Patton SN4112/JO/EUI – Rear Panel Figure 6 Analog Phone Line – POTS
1
2

Revision Date:
10/16/2020
Page 7 of 28
DMP Plus Series C V / C V AT – Patton POTS
2.0 Configuring Patton POTS interface for DMP Plus Series C V (AT) VoIP
This section will guide you through the setup of the Patton POTS interface.
2.1 Ordering Information
The Patton Smart Node VoIP Gateway has multiple different models.
Note: When purchasing the Patton POTS interface, make sure to purchase the model
with FXO ports. Units with FXS ports will not work.
2.1.1 Patton SN4112/JO/EUI - VoIP Gateway 2 FXO Ports
oProduct page:
https://www.patton.com/voip-gateway/sn4110/
2.1.2 Firmware used during testing: R6.11 2019-07-02
•SN4110_H323_SIP_R6.11_2019-07-02
•Firmware can be downloaded at patton.com
ohttps://www.patton.com/support/upgrades/index.asp?um=S
martNode%20411x
2.2 Setting IP address on Patton
The Patton SmartNode default configuration has Interface Ethernet 0 (ETH0) set to
DHCP from the factory. The attached configuration (Patton_Config.cfg) needs to be
uploaded via the internal webpage on the Patton SN4112/JO/EUI VoIP Gateway.
2.2.1 Setting the IP address via DataViewer
Utilizing the included console cable that comes with the Patton POTS interface:
•Connect the RJ-45 to Port labeled “Console” on the front of the Patton
•Connect the RS-232 DB-9 to your computer

Revision Date:
10/16/2020
Page 8 of 28
DMP Plus Series C V / C V AT – Patton POTS
•Using Extron DataViewer connect to the Patton POTS interface via RS-232
oDownload the attached file “DataViewer Set Patton IP address.txt” from the PDF
Refer to Appendix A to download the files from the PDF
oOpen Extron DataViewer
oClick Connect from the toolbar
File -> Connect (ALT+E)
oSelect the RS-232 Tab
Setup the port:
•Com Port (select COM port on your computer)
•Baud Rate: 9600
•Parity Bit: None
•Data Bit: 8
•Stop Bit: 1
•Handshake: None
oPress OK/Enter until you see “login:”
•Once connected to the Patton and you see login:
•In DataViewer select “Run Script from the menu bar
oTools -> Send Script File ( ALT + F )
oSelect DataViewer Set Patton IP address.txt and Click Open
Refer to Appendix A to download the files from the PDF
•The Script will set the IP address to
o192.168.1.253 / 255.255.255.0

Revision Date:
10/16/2020
Page 9 of 28
DMP Plus Series C V / C V AT – Patton POTS
2.3 Upload configuration into Patton POTS interface
After the IP address has been setup on the Patton POTS interface, the attached
configuration file must be uploaded via the webpage interface.
2.3.1 Login to Webpage
•Connect to the internal Webpage via the IP address of the unit set in
the previous step
ohttp://192.168.1.253
othe factory defaults for logging in:
login: administrator
Password: (leave the password empty )
2.3.2 Patton Firmware/Software
•This configuration guide was developed using firmware R6.11
oif firmware is up to date skip to 2.3.3 Upload configuration File
•The Software/Firmware information is displayed on the main page
when you log in:
•If the software/Firmware needs to be updated:
•First download the Software from patton.com:
ohttps://www.patton.com/support/upgrades/index.asp?um=SmartNode%20411x
•Connect to the webpage on the Patton POTS interface
ohttp://192.168.1.253
othe factory defaults for logging in:
login: administrator
Password: (leave the password empty )
•From the Patton webpage Select Import/Export, Upper Left corner
o

Revision Date:
10/16/2020
Page 10 of 28
DMP Plus Series C V / C V AT – Patton POTS
•Select Import Firmware
•Follow the instructions below
oShutdown VoIP Gateways
oFirmware upload
oOnce the VoIP Gateways are shut down the Download firmware dialog will appear
oSelect “Choose file” and select the downloaded ZIP file.
oSelect Import
oFirmware will download and be programmed into the Patton POTS interface.
oOnce the firmware update is complete, the box will need to be Reload/Restarted before the
update will take effect.

Revision Date:
10/16/2020
Page 11 of 28
DMP Plus Series C V / C V AT – Patton POTS
2.4 Upload configuration File
•If the firmware has been updated, verify the unit has been restarted
•From the Patton webpage Select Import/Export, Upper Left corner
o
•Select Import Configuration, then click Choose file
oSelect the “Patton_Config.cfg” attached to this PDF document
Refer to Appendix A to download the files from the PDF
oSelect Import
•Once the File has been imported the Patton will need to be rebooted / reloaded

Revision Date:
10/16/2020
Page 12 of 28
DMP Plus Series C V / C V AT – Patton POTS
2.4.1 To restart / reload, select Reload in the lower left
2.4.2 If any changes are made, they will need to be saved to the startup-config
The save button is located in the lower Left, right above Reload
Any changes not saved will be lost when the unit is Reload

Revision Date:
10/16/2020
Page 13 of 28
DMP Plus Series C V / C V AT – Patton POTS
2.5 Adjust auto hang-up / Call disconnection
If the calls do not disconnect from the POTS line, the Disconnect signals may need to be
adjusted. The screen below is configured for Loop Break
2.5.1 Adjust auto hang-up and Call disconnection if necessary
•Select FXO under ports
•Then select IF_FXO_00
o
•Adjust Disconnect Signal section for POTS line
oBattery Reversal – momentarily swaps DC polarity on the line
oLoop Break – momentarily disconnects the line voltage
Most commonly used method
The Loop-break duration is set for 220 ms to 600 ms
and can be adjusted if needed
oDisconnect Tones – Specify the tones to end a call
Not commonly used
If any changes are made, you will need to select Apply and then Save
•Save is located in the lower Left
192.168.1.253

Revision Date:
10/16/2020
Page 14 of 28
DMP Plus Series C V / C V AT – Patton POTS
3.0 Configuring DMP Plus Series C V (AT) VoIP Lines
VoIP configuration of the DMP Plus Series is handled exclusively through a web interface,
served from the device itself. The VoIP landing page is accessed through an address of the
format -
http://192.168.254.254/www/voip.html
- where 192.168.254.254 in this example is the default IP address on LAN 1 of the DMP Plus
Series device.
Line 1 will be configured as a SIP to POTS connection
3.1 Network Interface Configuration
Need to make sure that the LAN 1 and LAN 2 IP subnets (IP address / Subnet) do not overlap.
The default subnet mask on LAN 1 of 255.255.0.0 needs to be changed to 255.255.255.0
The LAN 1 IP interface will be used for Setup and control. These settings can be changed per
your application.
1. Click on the Network tab followed by Interface tab
2. Under the LAN 1 Network interface:
a. IP address Mode: Static
b. IP address: 192.168.254.254
c. Subnet Mask: 255.255.255.0
d. Gateway: 0.0.0.0
3. Click Apply after making any changes
a. The Network interface will restart the VoIP services on the device.
4. After the network interface has restarted

Revision Date:
10/16/2020
Page 15 of 28
DMP Plus Series C V / C V AT – Patton POTS
5. Under VoIP Interface select LAN 2
a. The Default VoIP interface is LAN 1 and will need to be set to LAN 2
6. Under the LAN 2 Network interface:
a. IP address Mode: Static
b. IP address: 192.168.1.254
c. Subnet Mask: 255.255.255.0
d. Gateway: 0.0.0.0
7. Click Apply after making any changes
a. The Network interface will restart the VoIP services on the device.
Note: Make sure that the LAN 1 and LAN 2 IP subnets (IP address / Subnet) do not overlap

Revision Date:
10/16/2020
Page 16 of 28
DMP Plus Series C V / C V AT – Patton POTS
3.2 Transport Configuration
Click on the Transport tab to access signaling transport configuration. Check that the transport
is set to UDP.
In the event that changes need to be made, click Apply to commit any adjustments to the
device.

Revision Date:
10/16/2020
Page 17 of 28
DMP Plus Series C V / C V AT – Patton POTS
3.3 Line Registration
Click on the Line 1 tab to be configured as part of the system.
1) User Name: 1001
2) Authentication Name: 1001
3) Authentication Password: 1001
4) Display Name: Optional. Specify an identifier for the line if required.
5) Primary Proxy Name/IP: 192.168.1.253
a. IP address of the Patton POTS interface
6) Primary Proxy Port: 5060
7) Once the above settings have been entered, click the Apply button to save to the
device.
8) Click the Register button
a. Note: the VoIP Line will not register to the Patton POTS interface
The DMP Plus will always show the Patton as “Not Registered”

Revision Date:
10/16/2020
Page 18 of 28
DMP Plus Series C V / C V AT – Patton POTS
3.4 Codecs
The availability and priority of codecs may be changed from within the Audio tab. Codecs will
only be available for use within phone calls if they are moved from the Available to the
Assigned column.
By default, G.711u and G.711a are assigned to the system. Codec assignment and priority can
be set per line.
The Patton POTS interface will only work with G.711u and G.711a
Click the Apply button to commit any changes to the device.

Revision Date:
10/16/2020
Page 19 of 28
DMP Plus Series C V / C V AT – Patton POTS
3.5 Dialing
Use the Dialing tab to select Out of Band – RFC 2833 for the Patton POTS interface.
Click Apply after selecting Out of Band – RFC 2833 DTMF signaling method for the line.
This can be set per line.

Revision Date:
10/16/2020
Page 20 of 28
DMP Plus Series C V / C V AT – Patton POTS
3.6 System Overview
The Home tab is used to view a summary of Line configuration and call status.
In the example below, Line 1 has a configuration but shows as not registered. The Patton POTS
interface will not show as registered.
Appearance-specific (caller-specific) details for active calls can be accessed by clicking on the
corresponding Line entry.
VoIP Dialer in DSP Configurator Software will not work since the line does not register to a call
server.
3.7 Troubleshooting
In the event of a problem, review the following:
•Verify the correct port is used on the DMP Plus
oLAN 2 is used in the example above
Figure 7 DMP 64 PLUS C V AT - Rear
•Verify the IP addresses have been configured properly
oDMP Plus LAN2: 192.168.1.254
oPatton POTS Interface: 192.168.1.253
