TP - TwisTed Pair series
TP R BNC A
TP - Twisted Pair Receiver for RGBHV and Audio
FeATures
• Input: One female RJ-45 connector
• Outputs: Female BNC connectors; audio on female RCA connectors and captive
screw connector
• Receives signals from a TP T Series transmitter
• Supports RGBHV, RGBS, RGsB, component video, S-video, and composite video
• Receives signals 1,000 feet (300 meters) or more over Category 5, 5e, or
6 UTP cable
• Two stereo audio outputs, balanced/unbalanced
• Automatic and manual level and peaking adjustments
• Rack, through-desk, under-desk, and projector-mountable
• External universal power supply included, part # 70-057-01 — Provides worldwide
power compatibility.
descriPTion
The Extron TP R BNC A computer video receiver accepts long distance transmissions of analog
computer-video with PC audio on any CAT 5, 5e, or 6 twisted pair cable or Extron Enhanced
Skew-Free™A/V UTP cable.
The TP R BNC A is compatible with nearly every computer and video signal type, including
VGA-UXGA, composite video, component video, and S-video. Special image enhancement
features, such as automatic and manual level and peaking adjustments, give the TP R BNC A
the ability to improve the brightness and sharpness of the computer-video image.
Connectors ....................... 5 BNC female
Nominal level .................... 1 Vp-p for Y of component video and S-video, and for composite video
0.7 Vp-p for RGB and for R-Y and B-Y of component video
0.3 Vp-p for C of S-video
Minimum / Maximum levels. . . 0.3 V to 1.45 Vp-p
Impedance........................ 75 ohms
Audio
Number / Signal type........... 1 set of analog proprietary signals
Connectors ....................... 1 shielded RJ-45 female
Frequency response ............ 20 Hz to 20 kHz, >±0.05 dB
THD + Noise...................... 0.03% @ 1 kHz, 0.3% @ 20 kHz at maximum output (unweighted)
S/N ................................. >63 dB at nominal level
Crosstalk.......................... <-80 dB @ 1 kHz, fully loaded
Stereo channel separation . . . . >80 dB @ 1 kHz
CMRR .............................. >33 dB @ 20 Hz to 20 kHz
Audio inPuT REFER TO THE TP TRANSMITTERS FAMILY MANUAL, PART #68-546-02
Audio ouTPuT
Number / Signal type........... 1 stereo audio balanced/unbalanced, and 1 stereo audio unbalanced
Connectors ....................... 2 female RCA (left/right) per input
(1) 3.5 mm, 5-pole captive screw connector per input
Impedance........................ 50 ohms unbalanced, 100 ohms balanced
Maximum level (600 ohm) ..... >+11.5 dBm, balanced at 1%THD+N
GenerAl
External power supply ......... 100 VAC to 240 VAC, 50/60 Hz, external, to 15 VDC, 0.8 A, regulated
Power input requirements..... 15 VDC, 0.3 A (minimum)
Rack mount ...................... Yes, with optional 1U rack shelf, part #60-190-01.
Enclosure type ................... Metal
Enclosure dimensions.......... 1.3" H x 8.75" W x 7.0" D (<1U high, half rack wide)
3.3 cm H x 22.2 cm W x 17.8 cm D (Depth excludes connectors.)
Product / Shipping weight..... 1.6 lbs (0.7 kg) / 4 lbs (2 kg)
sPeciFicATions
Video
Number / Signal type........... 1 set of proprietary analog signals
Connectors ....................... 1 shielded RJ-45 female
Video inPuT REFER TO THE TP TRANSMITTERS FAMILY MANUAL, PART #68-546-02
Video ouTPuT
Number / Signal type........... 1 analog RGBHV, RGBS, RGsB, component video, or S-video; or
1 S-video and 1 NTSC/PAL/SECAM composite video from a single source; or
3 NTSC/PAL composite video from a single source
Model Version descriPTion PArT #
TP R BNC A RGBHV & Audio Receiver - BNCs ...................................................................... 60-351-02
coMPATible TrAnsMiTTers Model descriPTion PAGe PArT #
TP T 15HD A TP - Twisted Pair Transmitter for RGBHV and Audio ............................... page 97 60-345-02
TP T 15HD AV TP - Twisted Pair Transmitter for RGBHV, Composite Video, and Audio..........page 100 60-346-03
TP T 15HD 45 TP - Twisted Pair Transmitter for RGBHV - 45 mm Mount Version ................. page 98 60-654-01
TP T A 45 TP - Twisted Pair Transmitter for Stereo Audio - 45 mm Mount Version .........page 98 70-368-01
included Accessories Model descriPTion PAGe PArT #
EPS 1508 B Extron Desktop Power Supply - 15VDC, 800mA, wire.............................page 694 70-057-01
