EyeQue Personal Vision Tracker EQ101 User manual

Product Manual
Model: EQ101
Personal VisionTracker
ophthalmic refractometer
®

1
Product Specication

2
Technical Specication
Dimension:
Weight:
Power supply:
Finish:
Operating temperature:
Storage temperature:
Relative humidity:
Operating altitude:
Phone requirement:
Visual acuity range:
7.0 X 5.7 X 3.0 inches/ 177 X 144 X 77 mm
7.5 oz/ 213 g
None
Glossy White, Matte Black
32° to 95° F (0° to 35° C)
-4° to 113° F ( 20° to 45° C)
5% to 95% non-condensing
up to 10,000 feet (3000 m)
iOS 9.3 and up, Android 6.0 and up, screen resolution
PPI: >300, and active EyeQue free basic membership
20/20 to 20/400
Intended use
The EyeQue Personal Vision Tracker®(PVT) is a self-administered, mobile application-
driven refraction device that provides spherical, cylindrical and axis correction metrics
of the eye. The PVT allows the tracking of changes over time and generates estimated
refractive corrections.
Description
The EyeQue Personal Vision Tracker (PVT) is a self-administered refraction
measurement device that uses the light from your smartphone screen to determine
EyeQue EyeGlass Numbers®(EGNs): lens power needed to correct nearsightedness or
farsightedness as well as lens power and axis needed to correct for astigmatism. Your
EyeQue results are safely stored in the EyeQue Cloud®.
EyeGlass Numbers are not prescriptions and personal vision testing does not replace
the need for an annual eye health exam.
For ages 18 years or older.

3
Instructions
Download the app and complete your account activation process.
1. Download the EyeQue PVT app from Google Play or Apple app store
2. Launch the app and register for an account. If you already have an
EyeQue account, sign in to your existing account
3. You’ll be asked for the serial number. You will  nd a serial activation
number inside the box for registration
4. Complete your account activation process
How to get started and attach your EyeQue miniscope
1. Increase your smartphone’s screen brightness and volume settings. There will be
voice prompts throughout the test.
2. Click on the “test” tab in the app. If this is your  rst time using the app, please
review the tutorial and complete the practice test before
attempting a full test.
3. For either the practice test or full test, you will be prompted
to remove the miniscope from its case. Rotate the eyepiece
clockwise several times to get a feel for the movement.
4. You will see a rectangular area with a dotted outline. This
is where you attach the miniscope. Remove the cover on
the base of the miniscope and attach it directly onto your
smartphone screen, with the EyeQue logo facing the plus (+)
and minus (-) buttons displayed on the screen. The miniscope
should not slide easily once attached to your phone.
5. Secure the miniscope by attaching the silicone elastic band,
creating a snug  t.
6. Make sure the rotating eyepiece is set to position 1. Click
“next”, and select whether you will be taking the test with or
without glasses or contact lenses.

4
How to take your  rst vision test
NOTE: Your  rst time taking the test will be the hardest. Once you  nd the lines and
successfully complete your  rst test, all subsequent tests will become much easier to
perform.
1. Place your elbows on a fl at surface to hold your
smartphone as steady as possible.
2. Hold the smartphone at reading distance and slowly move
it closer until the eye cup touches your right eye.
3. You should see two lines, one red, and one green. Take a
few seconds to  nd these lines. If you do not see them, try
gently moving the miniscope left and right, up and down.
It takes some practice and is an important part of getting
accurate test results.
4. Once you see the red and green lines, open and relax your
left eye (non-testing eye) during the test. Most people  nd
it helpful to focus on a large object at least 6 feet away. If you continue to have
di culty go to eyeque.com/support for additional tips.
5. Tap on the plus (+) or the minus (-) button and overlap
the red and green lines completely until they form a solid
yellow line. You may hold down the plus (+) or minus (-)
buttons for faster movement.
6. Once you are satis ed that the lines are overlapped, click
“Next”.
7. You will be prompted to rotate your miniscope to position 2. Turn the rotating eye
piece in the direction of the arrow until the number “2” is just above the white dot.
8. Look into the miniscope. The red and green lines are now at a different angle.
Overlap them as you’ve done for the previous test; click “Next” when you see only
one solid yellow line.
9. Rotate your eye piece to position 3 and repeat. Complete all 9 measurements for
your right eye. Follow voice prompts.
10. Rotate your eye piece to position 1 and test your left eye. Complete all 9
measurements for your left eye. Follow voice prompts.
11. Congratulations! The test completion screen appears. You may choose to save or
discard this test result.

5
What to do with your vision test results
After taking three sets of saved vision tests with
the EyeQue Personal Vision Tracker, the PVT app
will generate an accurate set of EyeGlass Numbers
(EGNs) that you can use to check whether your
vision has changed since your last prescription, or
order new eyeglasses online.
NOTE: More vision tests will result in better, more accurate EyeGlass Numbers.
Multiple users
One device can be shared with other users.
EGN calculations are based upon the results of several saved tests for a given
individual and are available on their personal dashboard. Each user must have a
separate EyeQue membership.
NOTE: Clean the miniscope eye cup with rubbing alcohol between users. Remove and/
or allow the rubbing alcohol residue to evaporate before bringing the miniscope eye
cup to the eye.
Contraindications
The miniscope should not be shared with users that are known to have, or exhibit signs
or symptoms of, an eye infection.
If used on other devices
Users will need the device serial activation number to unlock the app on other devices.
What can you do with EyeGlass Numbers®?
We recommend using it for general tracking and assessment of your eyesight over time
and providing it to your eye care provider before your annual eye exam for evaluation.
EGN’s can be used to order eyeglasses from online retailers that do not require an eye
care provider’s prescription certication.

6
How other users can obtain their own membership
Via computer
1. Create an account.
a. Go to https://store.eyeque.com/customer/account/create/
b. Conrm your email address and login to your account
2. Purchase a membership.
a. Click on “Membership” on the left-hand side.
b. Select the “Buy” button.
c. Complete purchase.
3. Download the PVT app.
4. Login using the app.
5. You may be prompted for the serial activation number from the EyeQue device.
Via the app
1. Download and launch the PVT app on your smartphone.
2. From the login screen click on “Register” button.
3. Complete the information.
4. Conrm your email address.
5. Login and enter the device serial number.
6. A pop-up will appear indicating a membership is required.
7. Select the “Buy” button.
8. Complete the purchase process.
With a single active membership, a user can use the EyeQue PVT and/or EyeQue
VisionCheck device. You do not need to purchase a different membership to use the
other device. You may be prompted for the serial number from the EyeQue device when
launching the product-specic device for the rst time. This serial number validates
that you are using a genuine EyeQue product.
Warranty information
Your EyeQue Personal Vision Tracker purchase comes with a 30-day money back
guarantee and a limited 1-year parts and labor warranty. Proof of purchase from an
authorized seller (e.g.: EyeQue.com, Amazon Inc. on Amazon, EyeQue on Amazon,
Kickstarter, Indiegogo, HSN, and BestBuy.com) and serial number are required for
processing.

7
The accuracy and precision of the results can vary among individuals. Not all users
will get accurate or consistent results because of, but not limited to, effects such as
accommodation, other eye conditions, insucient manual dexterity, or improper use.
As the EyeQue vision test is self-administered, EyeQue does not make any guarantees
regarding results.
Please visit our website at www.eyeque.com for Frequently Asked Questions and
additional product information, or email us at
suppor[email protected] with any questions.
Address:
39608 Eureka Drive
Newark, CA 94560 USA
[phone]
Safety warning
While using EyeQue products to personally measure and track vision has the benet of
detecting changes between regular eye exams, it does not replace a comprehensive
eye exam that evaluates ocular health or binocularity. EyeQue urges people to visit a
doctor annually for a full eye health exam.
Pupillary distance (PD) ruler
Some EyeQue PVT’s are shipped with a PD ruler. If your purchase came with one, follow
the directions below to get proper measurements. It is provided as a useful tool if you
choose to order glasses from online retailers. It is not a part of the PVT vision test and
is not required to achieve accurate EGNs.
What is pupillary distance?
Pupillary distance is the distance between the centers of the pupils of the eyes,
measured in millimeters. PD is one of the measurements necessary to order glasses.
Depending on the PD ruler you have, there may be two methods to measure your PD.

8
For Binocular PD
Method 1
Applicable for most PD ruler styles.
1. Stand approximately 8 inches in front of a mirror or ask someone else to measure
for you.
2. Without touching the eye, align the “0” with the center of the pupil of one eye and
while looking straight ahead, measure the distance from the center of one pupil to
the center of your other pupil.
3. Note your results. (Adult PD range: 54-74 mm, Child PD range: 43-54 mm).
4. Repeat several times for accuracy and use an average for your nal measurement.
Method 2
Applicable if your ruler has eye-slits and you wish to use them.
1. Stand approximately 8 inches in front of a mirror or ask someone else to measure
for you.
2. Without touching the eye and while looking straight ahead, look through the eye
slits and note the numbers that are aligned with the center of each pupil (numbers
will range between 20 and 40 mm).
4. Add the two results.
5. Note your results. (Adult PD range: 54-74 mm, Child PD range: 43-54 mm).
6. Repeat several times for accuracy and use an average for your nal measurement.
Go to EyeQue.com to order a PD ruler or the EyeQue PDCheck.

Made in Taiwan
Manufactured for EyeQue Corp.
39608 Eureka Drive, Newark CA 94560
P/N: PVT1PM062018A Rev. 4.0
Personal VisionTracker
ophthalmic refractometer
®
