EZ-ACCESS SUITCASE Singlefold Ramp User manual

10277 REV 05-12-15
Patent No. 8,191,193
LIFETIME WARRANTY. Please register at www.ezaccess.com/warranty-satisfaction.
CE Technical Files kept at: Enable Access, Marshmoor Works Great North Road, North Horth Mymms Hatfield, AL9 5SD, UK
© EZ-ACCESS®, a division of Homecare Products, Inc. All rights reserved.
All text and images contained in this document are proprietary and may not be shared, modified,
distributed, reproduced, or reused without the express written permission of EZ-ACCESS.
Instructions
SUITCASE®Singlefold Ramp
Optional Top Lip Extension is available. Contact your local EZ-ACCESS retailer for details.
IMPORTANT INFORMATION
Rated load is 800 pounds. Never exceed rated load.
Read and follow all labels, instructions, safety and
maintenance information before use.
For additional care, use or safety information, or to
obtain replacement copies, please call 1-800-451-1903
or visit www.ezaccess.com.
Do not use if ramp is damaged or unstable.
For wheelchairs and scooters only (not intended for
commercial use).
Ramp may be slippery when wet or icy.
Use only if sufficient maneuvering room is available at
both ends of the ramp to assure safe travel when
entering and exiting the ramp.
Use ramp only with a qualified helper and always use
your lap belt.
The ramp shown in the figures below is the 5-ft length. To
select the ramp length, an incline chart is provided on the
reverse side of this document. However, it is intended only
as a guideline. Refer to your equipment's (wheelchair or
scooter) Owner Guide for the proper degree of
incline/decline and chair direction before attempting ramp
use. Never exceed its recommendations.
INSTALLATION
1. Ramp is shipped fully assembled.
2. Place ramp on landing in the folded position, making
sure that the top lip transition plate (labeled TOP) is
resting securely on the landing, see FIGURE 1.
3. Unfold ramp and center on landing as shown in
FIGURES 1 & 2.
Ensure top lip transition plate is secure before using ramp.
We recommend attaching ramp temporarily to the landing
using provided clevis pins (drill ¼” hole in landing) or semi-
permanently using screws through pre-drilled holes at the top
of each section. To prevent ramp from becoming dislodged
during use, make sure that the top lip transition plate overlaps
the resting surface as far as possible (FIGURE 2).
The surface holding the top lip transition plate needs to be
substantial and of sound construction.
SAFETY & MAINTENANCE
Regularly check ramp for damage, and check and tighten any loose
fasteners. Keep ramp surface clear of ice, snow, dirt, leaves, and
other debris. For snow/ice, remove accumulation and sweep the
surface clean. To remove dirt, leaves, and other debris, sweeping
the surface or using a garden hose will usually suffice, but, if
needed, use a damp cloth or soft brush with non-alkaloid detergent
and water. Rinse well and use extra caution if ramp surface is wet.
OPTIONAL ACCESSORY
Increase the usefulness of the SUITCASE®Singlefold ramp with the
Top Lip Extension (TLE). This optional extension increases the
standard 3” top lip
transition plate to
become 9”,
allowing the ramp
to clear the rear
bumper of SUVs
and vans by
simply attaching to
the top lip of the
ramp. TLE is for
use with
unoccupied
mobility
equipment only and, when used, reduces the overall ramp weight
capacity to 500 pounds. Contact your local retailer or visit
www.ezaccess.com.
FIGURE 1
FIGURE 2

10277 REV 05-12-15
Patent No. 8,191,193
LIFETIME WARRANTY. Please register at www.ezaccess.com/warranty-satisfaction.
CE Technical Files kept at: Enable Access, Marshmoor Works Great North Road, North Horth Mymms Hatfield, AL9 5SD, UK
© EZ-ACCESS®, a division of Homecare Products, Inc. All rights reserved.
All text and images contained in this document are proprietary and may not be shared, modified,
distributed, reproduced, or reused without the express written permission of EZ-ACCESS.
INCLINE CHART
IMPORTANT: Refer to your
equipment's (wheelchair or
scooter) Owner Guide for the
proper degree of incline/decline
and chair direction before
attempting ramp use. Never
exceed its recommendations.
TO ESTABLISH THE PROPER RAMP LENGTH:
Determine the incline that your chair is designed to climb.
Measure the rise (distance from the top step, porch, van, etc.
to the ground).
Refer to Incline Chart to find proper ramp length.
At any incline, use ramp only with a qualified helper.
