ezdupe NVMe CyCLONE Pro User manual

1
Disclaimer
EZ Dupe's duplicator machine is specially designed for data backup of storage devices.
Please observe the relevant provisions of copyright when using it. Any backup without the
consent or authorization of the copyright holder is illegal. Please confirm before backup. EZ
Dupe is not responsible for any illegal acts, and the user is responsible for all legal liabilities.
The source port of duplicator is write-protected, and the settings and data content of any
storage device in the source port will not be changed at all. Do not place the source storage
device on the target port to avoid accidentally changing (deleting) of data. It has nothing to
do with EZ Dupe if there is any mistake in correcting (deleting) the data by user. In addition,
EZ Dupe is not responsible for the risks and data losses incurred as a result of duplication.
By purchasing this product, the user accepts this statement and agrees to be bound by it.
The content of this manual is for reference only. The copyright of the content belongs to EZ
Dupe. Please do not copy or repost it without authorization. EZ Dupe reserves the right to
change the function of the product without prior notice.

2
Before Use
1. Please read this manual carefully before the operation to avoid any misconduct.
2. Make sure that the storage device you want to use is of good quality and can be used
normally.
3. The capacity of target storage device must be greater than or equal to the capacity of
source storage device to avoid incomplete data backup.
4. It is recommended to use the Copy + Compare function when backing up, to ensure that
the backup data is 100% the same as the source data, because the target storage device
may have write errors or damaged sectors.
5. When updating the firmware, please do not turn off the power. If the power is interrupted
accidentally, the machine cannot be turned on, and it must be returned to the factory for
processing.
6. Keep the duplicator used in a dry environment. Rain, moisture, liquid, etc. may corrode
the circuit board and cause the machine to malfunction.
7. Avoid using the duplicator in dusty or dusty environments. Dust may cause bad contact
with the port.
8. This product warranty does not apply to accident, man-made destruction, abuse, or
improper use (such as using not in accordance with the product description, or intended
to exceed the scope of use for which this product was designed, or improper use of
fixtures, etc.)
9. If the duplicator performs normally, itis strongly recommended not to update the firmware,
unless there is a problem in use or a new function is required.
10. For convenience, the source storage device will be referred to as the source device, and
the target storage device will be referred to as the target device in this manual.

3
I. INTRODUCTION............................................................................................................ 6
1. Features..............................................................................................................................................................6
2. Duplicator Introduction ..................................................................................................................................7
3. Control Panel Overview..................................................................................................................................8
4. Specifications...................................................................................................................................................8
II. NOTICE ......................................................................................................................... 9
III. OPERATION OVERVIEW ............................................................................................. 9
IV. DAISY CHAIN OPERATION........................................................................................ 10
V. MENU OVERVIEW ...................................................................................................... 11
1. Duplicate...........................................................................................................................................................11
1.1 Copy..........................................................................................................................................................11
1.2 Secure Erase+Copy...............................................................................................................................11
1.3 Compare...................................................................................................................................................11
1.4 Copy + Compare.....................................................................................................................................12
1.5 Secure Erase+Copy+Compare ............................................................................................................12
2. Data Erase........................................................................................................................................................12
2.1 Quick Erase..............................................................................................................................................12
2.2 Full Erase..................................................................................................................................................13
2.3 3-Pass DoD Erase...................................................................................................................................13
2.4 7-Pass DoD Erase...................................................................................................................................13
2.5 Secure Erase............................................................................................................................................14
2.6 Enhance Secure Erase...........................................................................................................................14
2.7 Remove HPA............................................................................................................................................14
2.8 Remove DCO ...........................................................................................................................................15
3. Quality Check ..................................................................................................................................................15
3.1 H3 Test......................................................................................................................................................15

4
3.2 H5 Test......................................................................................................................................................15
3.3 H6 Test......................................................................................................................................................16
3.4 H7 Test......................................................................................................................................................16
3.5 Set Test Range %...................................................................................................................................16
3.6 Set Test Range Byte..............................................................................................................................16
3.7 Set Bad Sector Ratio .............................................................................................................................17
3.8 Set Bad Sector Size ...............................................................................................................................17
3.9 Set Speed Threshold.............................................................................................................................17
3.10 Set Capacity Threshold.........................................................................................................................17
3.11 Set Error Active.......................................................................................................................................18
3.12 Set Format Type .....................................................................................................................................18
3.13 Secure Erase after Test.........................................................................................................................18
3.14 Set Power Off Times..............................................................................................................................19
3.15 Set Power Off Duration .........................................................................................................................19
3.16 Set Cycle Times......................................................................................................................................19
4. Utility.................................................................................................................................................................20
4.1 Format FAT32...........................................................................................................................................20
4.2 Format exFAT..........................................................................................................................................20
4.3 Capacity Check + Format......................................................................................................................21
4.4 Measure Speed .......................................................................................................................................22
4.5 Capacity Check ......................................................................................................................................22
4.6 Aging Test................................................................................................................................................22
4.7 Media Information...................................................................................................................................22
4.8 Device Information .................................................................................................................................22
4.9 Print Last Task Label ...............................................................................................................................23
4.10 System Info..............................................................................................................................................23
4.11 System Update........................................................................................................................................23
4.12 Log Menu..................................................................................................................................................24
5. Setup.................................................................................................................................................................26
5.1 Copy Area.................................................................................................................................................26
5.2 Source Select..........................................................................................................................................27
5.3 Smaller Target.........................................................................................................................................27

5
5.4 Unknown Format.....................................................................................................................................27
5.5 Label Print................................................................................................................................................28
5.6 Set Slow Out Threshold.........................................................................................................................28
5.7 Set Format Type......................................................................................................................................28
5.8 Set Capacity Threshold.........................................................................................................................29
5.9 Clear Setup ..............................................................................................................................................29
5.10 Performance............................................................................................................................................30
5.11 Advance Setup .......................................................................................................................................30
5.11.1 Check Before Copy............................................................................................................................30
5.11.2 HPA Set................................................................................................................................................30
5.11.3 DCO Set................................................................................................................................................31
5.11.4 Erase Source Port...............................................................................................................................31
5.11.5 Display Mode.......................................................................................................................................31
5.11.6 Start-up Menu......................................................................................................................................32
5.11.7 Button Beep.........................................................................................................................................32
5.11.8 Boot Password....................................................................................................................................33
5.11.9 Setup Password..................................................................................................................................33
5.11.10 Language.........................................................................................................................................33
5.11.11 Set Date Time .................................................................................................................................33
VI. TROUBLESHOOTING................................................................................................. 34

6
I. Introduction
This duplicator systemis designed and developed based on the FPGA fromthe world famous
semiconductor company XILINX. Every processing channel is parallel to each other with its
own control unit, therefore the duplicator will not sacrifice speed for the increasing number of
targets loaded - always remain the same and fast copy speed. The duplicator supports
intelligent copy with multiple file formats created by three major operating systems
(Windows/Linux/MAC), and makes mirror copies of data efficiently. Furthermore, this
duplicator has been fully tested with quality assurance before leaving our manufacturing
facility.
1. Features
a. Each processing channel has its own control unit and operates independently with
dedicated bandwidth of up to 300 or600 MBper second depends on the model.
b. Standalone operation. No PC or software is required, minimizing possible computer
virus infection.
c. Instant power on and off, no warm-up or cool-down required.
d. Easy-to-use One-Touch copy operation.
e. Compare function available for verification of copy accuracy.
f. Menu options are user-friendly and easily accessed through the 4-button control panel.
Use ▲or ▼ button to scroll through the options and view the operation status of each
channel on the 2-line backlit LCD display.
g. Powerful 32-bit CRC checksum to assure data integrity.
h. Heavy-duty hardware construction for commercial production or personal use.
i. 115V and 230V switching power supply maximizes portability for operation anywhere.
j. Designed to save users time and effort in creating multiple copies quickly and reliably.
k. Unique source data analysis to copy data area only to achieve highest efficiency
l. Supports multiple file formats: Windows: FAT 16/32、exFAT、NTFS, Linux: ext 2/3/4、
LVM、XFS, Mac: HFS/HFS+/HFSX
m. Not only to do copy, but also test device capacity and reading/writing speed.

7
2. Duplicator Introduction
The following picture shows the 1-9 NVMe CyCLONE Pro duplicator as an example. The
source port can be selected from M.2 or SATA. The appearance of the duplicator may be
changed without notice.
Source Port
Control Panel
HDD Bracket

8
3. Control Panel Overview
▲Button: Up, Backward: To navigate backward in the menu.
▼Button: Down, Forward: To navigate forward in the menu.
OK Button: Enter, OK: Execute the function.
Back Button: Escape, Cancel: Go back to the previous level in the menu.
4. Specifications
Operation
Standalone (No PC or Software is required)
Target
4, 9
Transfer Speed
300MB/s (NVMe CyCLONE Pro 300)
600MB/S (NVMe CyCLONE Pro 600)
Copy Mode
Synchronous
Copy Area
File and System, Percentage, All Partition,
Nonzero and Whole Media,
Supported
Media
SATA SSD/HDD and M.2 NVMe/SATA SSD
Supported File
System Format
(for Intelligent Copy)
Windows：FAT16/32, exFAT, NTFS
Linux：ext2/3/4, LVM, XFS
MAC：HFS/HFS+/HFSX
Display
2-line Backlit Monochrome LCD
Control Button
4 push-button control panel (OK, Back, UP, DOWN )
Memory
256MB DDR3

9
II. Notice
1. The duplicator tasks mentioned in this user’s manual are as following: Copy, Compare,
Copy + Compare, Capacity Check, Format, Erase and Quality Check.
2. The Green/Blue LED flashes during the execution process of atask. After the taskis done,
the Green/Blue LED will stay solid if the process is successful, otherwise the Red LED
will be on if the process is failed.
3. Press and hold Back button during the execution process of a task will stop and exit the
execution of the task.
4. DO NOT unplug HDD/SSD drive from the duplicator during the execution process of a
task. It may cause damage to the duplicator system and media.
5. It is strongly recommended that the capacity of target storage device must be greater than
or equal to the capacity of source storage device to avoid incomplete data backup.
6. The setting 5.11.4 Erase Source Port is to set if the data of source port can be erased.
It is used for all erase、format and quality check functions.
When setting is Enable, the data in source port will be erased.
If Erase Source Port is Disable, a prompt “Target data will be erased!” will be showed
to double check entering the erase function.
If Erase Source Port is Enable, a prompt “Source and Target data will be erased!” will
be showed to double check entering the erase function.
III. Operation Overview
The duplicator will start to execute a task after the source and target devices have been
inserted and the OK button is pressed. The task will begin and end at the same time for all
target devices. Any other target device plugged in during the process of a task will not be
executed with the task.

10
a. Insert source media into the source port and blank media into the target port properly.
b. Select the task from menu, and press OK button to execute it.
c. If the Target SSDs are not fully connected, pressing the OK button again will
execute the function immediately. Otherwise, if the OK button is not pressed
again, the function will be executed about 40 seconds later.
d. During the execution process, the status of each target device can be checked by
using the ▲and ▼buttons.
e. After the taskis done, LCDdisplay will showthe number of successful and failed target(s),
and execution time.
IV. Daisy Chain Operation
NVMe CyCLONE PRO has daisy chain function. It can link multiple duplicators as one unit.
The unit only needs one source at the 1st duplicator and the source ports after 1st duplicator
will become target ports. The connection method is shown as below.

11
V. Menu Overview
1. Duplicate
1.1 Copy
To copy from source device to target device(s), please go to 5.1 Copy Area to select the
setting first before this step. Press OK the copy task will be executed immediately. Other
tasks have the same execution for other tasks.
Display copy progress
Final result
The process of all tasks are
displayed in the same format
1.2 Secure Erase+Copy
Before Copy, Secure Erase will be executed first to reset device(s) as factory setting. It can
enhance copy speed for used SSD. After Secure Erase, Copy will be executed immediately.
1.3 Compare
This command allows to compare the copied target devices against the source for
accuracy.
Result: 2:30
Pass：4Fail：0
S_Erase：4
00:10 (03)
1. Duplicate [Duplicate]
2.Secure Erase+Copy
OK
Copy：4 54.8G
00:15 (03) 10%
Result: 2:30
Pass：4Fail：0
[Duplicate]
3.Compare
COMP：
4 54.8G
00:15 (03) 10%
OK
Result: 2:30
Pass：4Fail：0
Copy：
4 54.8G
00:15 (03) 10%
1. Duplicate [Duplicate]
1.Copy
Copy: 4 number of targets
54.8G: data to be copied
00:15: elapsed time
(03): slowest port
10%: rate of progress
OK

12
1.4 Copy + Compare
This command allows duplicator to start Copy process first, then follow with Compare
process immediately.
1.5 Secure Erase+Copy+Compare
Before Copy, Secure Erase will be executed first to reset device(s) as factory setting. It can
enhance copy speed for used SSD. After Secure Erase, Copy will be executed immediately
and then Compare.
2. Data Erase
Users can enable the setting of 5.11.4 Erase Source Port to improve the efficiency.
The default is Disable.
2.1 Quick Erase
This option erases the table of content of file system of the target device, so it is fast to do
Quick Erase. There is chance that some files can be retrieved by software.
Target data will be erased!
No
2.Erase [Erase]
1. Quick Erase
OK
OK
Q_Erase：7
00:00 (00) Wait
Result: 00:00
Pass：7Fail：0
Target data will be erased!
Yes
▲
OK
Result: 05:30
Pass：4Fail：0
[Duplicate]
4.Copy+commpare
Copy&：454.8G
0:15 (03) 5%
10％
&COMP：
4 54.8G
02:45 (03) 55%
10％
OK
Result: 05:30
Pass：4Fail：0
[Duplicate]
5.Secure Erase+Copy+..
Copy&：4 54.8G
0:15 (03) 5%
10％
&COMP：4 54.8G
02:45 (03) 55%
10％
OK
S_Erase：4
00:10 (03)

13
2.2 Full Erase
This option completely erases the content of target device. It takes longer time to erase and
the content will not be retrieved by software.
2.3 3-Pass DoD Erase
Thisis to comply with the U.S.A. Department of Defense (DoD5220) standard to fully erase
the mediabyrewritingbit by bit three times to guaranteethe data to be permanently deleted.
It takes long time to erase, and the content will not be retrieved by software.
2.4 7-Pass DoD Erase
Thisis to comply with the U.S.A. Department of Defense (DoD5220) standard to fully erase
the media by rewriting bit by bit seven times to guarantee the data to be permanently
deleted. It takes long time to erase, and the content will not be retrieved by software.
Target data will be erased!
No
2.Erase [Erase]
4. 7-Pass DoD Erase
OK
OK
DoD_Erase：7
00:10 (03) 2%
Result: 1:10:30
Pass：7Fail：0
Target data will be erased!
Yes
▲
OK
Target data will be erased!
No
2.Erase [Erase]
3. 3-Pass DoD Erase
OK
OK
DoD_Erase：7
00:10 (03) 2%
Result: 30:30
Pass：7Fail：0
Target data will be erased!
Yes
▲
OK
Target data will be erased!
No
2.Erase [Erase]
2. Full Erase
OK
OK
F_Erase：7
00:20 (03) 10%
Result: 03:40
Pass：7Fail：0
Target data will be erased!
Yes
▲
OK

14
2.5 Secure Erase
The Secure Erase is dedicated to erasing SSD. It resets all its storage cells as empty -
restoring the SSD to factory default settings and write performance. Secure Erase is
recognized by the US National Institute for Standards and Technology (NIST), as an
effective and secure way to meet legal requirements data sanitization attacks against up
to laboratory level. It only spends few seconds (the real time depends on drive) when used
for SSD.
2.6 Enhance Secure Erase
The Enhance Secure Erase is similar to Secure Erase. Beside the function of Secure
Erase, it shall write predetermined data patterns to all user data areas. All previously
written user data shall be overwritten, including sectors that are no longer in use due to
reallocation.
2.7 Remove HPA
This option removes the HPA setting of the disks inserted into the target ports.
Target HPA will be removed?
No
2.Erase [Erase]
7. Remove HPA
OK
OK
Remove HPA：7
00:01 (03)
Result: 00:01
Pass：7Fail：0
Target HPA will be removed?
Yes
▲
OK
Target data will be erased!
No
2.Erase [Erase]
6. Enhanced Secure Erase
OK
OK
ES_Erase：7
00:10 (03)
Result: 00:11
Pass：7Fail：0
Target data will be erased!
Yes
▲
OK
Target data will be erased!
No
2.Erase [Erase]
5.Secure Erase
OK
OK
S_Erase：7
00:10 (03)
Result: 00:11
Pass：7Fail：0
Target data will be erased!
Yes
▲
OK

15
2.8 Remove DCO
This option removes the DCO setting of the disks inserted into the target ports.
3. Quality Check
Users can enable the setting of 5.11.4 Erase Source Port to improve the efficiency. The
source port can be set to execute the Quality Check function. The default is Disable.
3.1 H3 Test
Testing Read function under designated area in the device to verify if it is good. It will not
change the original data stored in the device. Attention: this function only tests Read
function, but not Write function.
Use ▲or▼ to select the information of each port
3.2 H5 Test
Testing Read and Write function under designated area in the flash media. It will clear the
original data stored in the device, and format or secure erase the device after the testing is
done.
Target DCO will be removed?
No
2.Erase [Erase]
8. Remove DCO
OK
OK
Remove DCO：7
00:01 (03)
Result: 00:01
Pass：7Fail：0
Target DCO will be removed?
Yes
▲
OK
OK
[#1]0 K 738M
R 10.9M W 0.0M
Result: 00:46
Pass：7Fail：0
[Quality Check]
1. H3 Test
H3_TEST：7
00:20 (03) 10%
[#1]0 K: [#Port] failed capacity
738M: Capacity tested
R xxM/W xxM:
Read & Write speed
OK
Result: 00:46
Pass：7Fail：0
Target data will be erased!
Continue
[Quality Check]
2.H5 Test
Target data will be erased!
Cancel
H5_TEST：7
00:20 (03) 10%
▲
OK

16
3.3 H6 Test
Testing Read and Write function under unused area (data area are excluded) in the
storage device. It will not change the original data stored in the device.
3.4 H7 Test
Advanced method to test the Read and Write function twice under designated area in the
device, which can effectively detect the overrated capacity of device. It will clear the original
data stored in the device, and format or secure erase the device after the testing is done.
3.5 Set Test Range %
Set up the testing range. It can be set from 1% to 100%.
Use ▲or▼ to select
3.6 Set Test Range Byte
Set up testing range. It can be set from 1GB to 9000GB. Both 3.5 & 3.6 are for setting test
range, the last setting works. For example, when you set Test range=10% then set 100GB,
the test range is 100GB. When you set 10% again, the test range is 10%.
Use ▲or▼ to select
[Quality Check]
5. Set Test Range
[Set Test Range]
100%
OK
[Quality Check]
6. Set Test Range
[Set Test Range]
9000 GM
OK
OK
Result: 00:46
Pass：7Fail：0
[Quality Check]
3.H6 Test
H6_TEST：7
00:20 (03) 10%
▲
OK
Result: 00:46
Pass：7Fail：0
Target data will be erased!
Continue
[Quality Check]
4. H7 Test
Target data will be erased!
Cancel
H7_TEST：7
00:20 (03) 10%
▲
OK

17
3.7 Set Bad Sector Ratio
Set up tolerance ratio of bad sector for device testing, from 0.01% to 50% or OFF.
Use ▲or▼ to select
3.8 Set Bad Sector Size
Set up tolerance size of bad sector for flash media testing, from 0MB to 9999GB or OFF.
Both 3.7 & 3.8 are for tolerance of bad sector, the last setting works.
Use ▲or▼ to select
3.9 Set Speed Threshold
Set up minimum Read and Write speed for flash media testing, ranging from 5MB/S to 700
MB/S or OFF.
Use ▲or▼ to select
3.10 Set Capacity Threshold
The difference between actual capacity and labeled capacity of storage device is allowed
and the threshold can be set up in 3 steps.
Capacity: Set up labeled capacity from 32MB to 16TB, Depend on Source, and OFF.
Use ▲or▼ to select
Unit: You can choose the unit of 1M=1000K or 1M=1024K.
[Quality Check]
7. Set Bad Sector Ratio
[Set Bad Sector Ratio]
10%
[Quality Check]
9. Set Speed Threshold
[Set Speed Threshold]
Read: 700MB/s
OK
[Quality Check]
10.Set Capacity Threshold
[Quality Check]
Capacity: 16 T
OK
OK
[Quality Check]
1M = 1024K
[Quality Check]
8. Set Bad Sector Size
[Quality Check]
[Set Bad Sector Ratio]
Below:9999GB
[Set Bad Sector Ratio]
OKO

18
Tolerance: Set up the tolerance ratio for the difference between actual and labeled
capacity, ranging from 0 to 50%.
3.11 Set Error Active
This is the setting to stop or continue the test when any of the testing conditions (such as
Capacity Threshold or Bad Sector Ratio) is failed to meet.
Use ▲or▼ to select
3.12 Set Format Type
H5 and H7 Test will format the storge devices after testing. This setting is to set up the
file system format for the Format function implemented by H5 and H7 Test. The options
are Depends on Size, FAT32, exFAT and off. The default is Depends on Size.
Depends on Size: System will automatically select FAT16 when the size is smaller than
2G, select FAT32 as file system format when the flash media capacity is less than or
equal to 32 GB, and select exFAT when the flash media capacity is greater than 32 GB.
FAT16: Select FAT16 as file system format.
FAT32: Select FAT32 as file system format.
exFAT: Select exFAT as file system format.
Use ▲or▼ to select
3.13Secure Erase after Test
This is the setting to Enable or Disable execute secure erase after H5 or H7 test finished.
The priority of this setting is high than format setting. For example, if Format Type set
exFAT and Secure Erase after Test is Enable, only Secure Erase is executed.
[Quality Check]
11. Set Error Active
[Set Error Active]
Stop
OK
[Quality Check]
12. Set Format Type
[Set Format Type]
Depends on Size
OK
OK
[Quality Check]
Upper Range: 10%
OK
[Quality Check]
Lower Range: 5%

19
Use ▲or▼ to select
3.14Set Power Off Times
This is the setting to set power off times when execute quality check function. The power off
times is for each read/write process. For example：H5 Test：if setting is 3, 3 times power
off will be happened in write & read process separately. The setting is from 5 to 1000 times
and off. The default is off.
Use ▲or▼ to select
3.15Set Power Off Duration
This is the setting to set the power off duration when the option is not off. It set the power
off duration for each power off time. The setting value is from 5 to 100 sec and off. The
default is off.
Use ▲or▼ to select
3.16Set Cycle Times
This is the setting to set the execution times of quality check function. The setting value is
from 5 to 100 times and off. The default is off.
Use ▲or▼ to select
[Quality Check]
13. Secure Erase after Test
[Secure Erase after Test]
Disable
OK
[Quality Check]
14. Set Power Off Times
[Set Power Off Times]
Off
OK
[Quality Check]
13. Set Power Off Duration
[Set Power Off Duration]
Off
OK
[Quality Check]
13. Set Cycle Times
[Set Cycle Times]
Off
OK
